Frigidaire FEFL89C User manual

FEFL89CC.eps L20G0071.eps L20V0092.eps L20T0037.eps L20D0014.eps
316255344d.eps 316255344s.eps
Product No. FEFL89CCA
Series 30" f/s elec
Color stainless
Market North America
Wiring Diagram 316255344
Owner's Guide 316257125
Installation Instructions 316259200
Service Data Sheet 316259183
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995400933
04/01/07
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEFL89C
Copyright 2003 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995400933 FEFL89CCA
01/04 2
BACKGUARD

FEFL89CCA Publication No: 5995400933
# Functional Parts 3 01/04
* Non-Ilustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316239900 Shield, backguard, rear wall
13A# 316095500 Switch, infinite, warmer
14 316022500 Light/Lamp, indicator, 125 V
15 316220216 Support, backguard, black, RH
15A 316220217 Support, backguard, black, LH
19 316233876 Panel, backguard, stainless
20 # 316207620 Clock/Timer, EOC
20A 316243301 Overlay, clock, black
23 316220900 Bracket, clock mtg
31 316223002 Knob, black
46 316040201 Lens, indicator light, red
54 # 316021500 Switch, infinite, small element
54B# 316238200 Switch, infinite, dual element
56 316234003 Shield, backguard, black, inner
69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 218490900 Cleaner, stainless steel
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995400933 FEFL89CCA
01/04 4
BODY
ANTI-TIP
BRACKET
62
63
21
6
9
10
6B
107
161
110
109
111
106
108
3
66
68 68
67
8
6A
1
NOTE: Oven Liner N/A
Ass. du four N/A
58A 58B
7
7A
17
14
5
5
57
71
87
41
41A
37
18
88
59B
59
59A
45
89
3
L20V0092
170
58
42
58C
16
15
44
33A
77
77
155
25A
26
12
89A

FEFL89CCA Publication No: 5995400933
# Functional Parts 5 01/04
* Non-Ilustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316201300 Back, main
3 316216404 Panel, bodyside, black, RH
3 316216405 Panel, bodyside, black, LH
3* 316021132 Screw, bodyside, 8-18 X 11/16, black
5 316129200 Screw, leveling, plastic, with stop
6 316216000 Rack, oven
6A 316262901 Rack, oven sump
6B 318219500 Rack, broiler pan
7 316216500 Hinge, oven door, RH
7A 316216501 Hinge, oven door, LH
8 316201501 Panel, sump, oven bottom
9 316081900 Pan, broiler
10 316082000 Insert, broiler pan
12 # 316209903 Switch, oven light/door
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, oven light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316213900 Latch, oven door
21 3014099 Spacer, bodyside
25A 316092400 Shield, warmer drawer, upper
26 316211800 Shield, chassis filler, side lower, (2)
33A 316231600 Shield, rear wall, lower, warmer drawer
37 # 316233900 Probe, oven temp
41 316233400 Cover, hinge cutout, RH
41A 316233500 Cover, hinge cutout, LH
42 316206200 Shield, wool, lower
44 316246500 Spacer, oven door
45 316234100 Shield, wire, vent tube
57 316081100 Cover, access
58 316240300 Insulation, oven bottom
58A 316047708 Insulation, 2", oven wrapper
58B 316240102 Insulation, oven back
58C 316240400 Insulation, oven sump
59 316208200 Tube, oven vent, lower
59A 316208302 Tube, oven vent, upper
59B 316247300 Catalyst, oven vent, ceramic
62 5303935061 Terminal Block Kit
62* 316085600 Insulator
62* 316205500 Nut, hex flange, 3/8 10-32
63 316208500 Plate, grounding strap
66 # 316203301 Element, broil
67 # 316202200 Element, bake
68 316203400 Support, broil element
71 316015810 Shield, rear wall, galv steel
77 316105500 Glide, warmer drawer, outer/RH & LH, (2)
87 316081200 Bracket, cable mtg
88 316203500 Rod, auto latch
89 # 316135201 Motor, latch/lock
89A 316245800 Bracket, latch, rear
106 316026600 Bracket, motor mtg

Publication No: 5995400933 FEFL89CCA
01/04 6
BODY
ANTI-TIP
BRACKET
62
63
21
6
9
10
6B
107
161
110
109
111
106
108
3
66
68 68
67
8
6A
1
NOTE: Oven Liner N/A
Ass. du four N/A
58A 58B
7
7A
17
14
5
5
57
71
87
41
41A
37
18
88
59B
59
59A
45
89
3
L20V0092
170
58
42
58C
16
15
44
33A
77
77
155
25A
26
12
89A

FEFL89CCA Publication No: 5995400933
# Functional Parts 7 01/04
* Non-Ilustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
107 316026701 Cover, fan
108# 316136300 Motor, fan
109 316136400 Blade, fan
110 316136500 Washer, fan motor
111 316136600 Nut, fan retainer
155 316095201 Shield, warmer drawer, front
161# 316211603 Element, convection fan, 350 W
170 5303935180 Anti-tip Kit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
* 316269511 Harness, wiring, main
* 318235300 Connector assy., w/3 lugs, & instructions
* 5303305345 Paint, touch-up, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303280311 Screw, wafer hd sq dr, 10-32 x 0.312
* 5303285179 Screw, wafer head, 8-32T x 0.500, black
* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995400933 FEFL89CCA
01/04 8
TOP/DRAWER

FEFL89CCA Publication No: 5995400933
# Functional Parts 9 01/04
* Non-Ilustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 316115901 Drawer, warmer
2 316231503 Liner, drawer
4 316248801 Panel, drawer, stainless
13 316231700 Glide, drawer, RH inner
13A 316231701 Glide, drawer, LH inner
15A# 316010205 Element, surface, 6", 1200 W, radiant
15B# 316224300 Element, dual, 6"/9", surface, 1000W/2500W, radiant
15C# 316098202 Element, warmer zone, 100W
15E# 316235301 Element, double 6", surface, 4400 W, w/bridge
16 316251952 Main Top Assy, glass/steel, black
18 316235900 Hinge, main top, RH
18A 316235901 Hinge, main top, LH
26 316230202 Channel, element support, (2)
26A 316099202 Bracket, chassis support, rear
26B 316214200 Bracket, chassis support, front
39 316203000 Handle, door, black
52 316099400 Clip, element mtg
81 # 316239201 Element, warmer drawer
82 316093200 Bracket, element mtg
83 316093300 Shield, terminal, warmer drawer
84 316093501 Thermo disc, warmer drawer
85 316093600 Rack, warmer drawer
86 316095800 Clip, hold down, warmer element
87 316091900 Base, warmer drawer
96 316122000 Clip, lock, warmer drawer
97 316003802 Screw, Hex HD 3/16", 6 x 3/8
* 316001917 Harness, warmer drawer
* 316253603 Harness, warmer drawer, main
* 218490900 Cleaner, stainless steel
* 316264000 Cleaner, cooktop
* # 316253520 Wiring Harness, surface element
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 5303280311 Screw, wafer hd sq dr, 10-32 x 0.312
* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995400933 FEFL89CCA
01/04 10
DOOR

FEFL89CCA Publication No: 5995400933
# Functional Parts 11 01/04
* Non-Ilustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
4 316240000 Glass, oven door, black, outer
5 316237000 Glass, oven door, air wash
6 316222707 Shield, wool, oven door
7 316236700 Insulation, oven door
8 316237100 Glass, oven door, clear, heat barrier
9 316230617 Liner, oven door
10 316001015 Screw, waf hd sq, 10-24 x 1.25, (2), handle mtg
10B 316008401 Washer, 3/4 OD x 1/4 ID, steel
12 316230901 Seal, oven door
13 316209401 Panel, oven door, stainless, outer
14 316102208 Foil, 1.5" x 29", aluminum, black
14A 316102205 Foil, 4" x 5.5", aluminum, black, (2)
15 316237201 Bracket, glass support, (2)
15B 316085501 Bracket, glass support
16 316117500 Glass, oven door, heat barrier
17 316117701 Spacer, door glass, (2)
39 316203000 Handle, door, black
60B 316021110 Screw, 8-18 x 0.5, black
* 316221001 Label, anti-tip
* 218490900 Cleaner, stainless steel
* 316021109 Screw, 8-18 x 0.5, chrome
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303280311 Screw, wafer hd sq dr, 10-32 x 0.312
* 5303285179 Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995400933 FEFL89CCA
01/04 12
WIRING SCHEMATIC

FEFL89CCA Publication No: 5995400933
# Functional Parts 13 01/04
* Non-Ilustrated Parts
WIRING DIAGRAM
