Frigidaire Gallery FGGF305MKF Installation instructions

frigidaire.com
Signature Features
Express-Select® Controls
Easily go from warm to boil.
SpaceWise® Lower Oven
This range features a .5 cu. ft
SpaceWise® Lower Oven that gives
you more space to cook multiple
dishes at the same time.
Quick Preheat
Preheat in less than six minutes.
1
Quick Boil
Boils water faster.
30" Gas
Product Dimensions
Height (Max.) 47-1/2"
Width 29-7/8"
Depth (Including Handle) 28-1/2"
More Easy-To-Use Features
One-Touch Options
Our ovens feature easy-to-use one touch
buttons so you can cook pizza or chicken
nuggets — or even add a minute to the
timer — with the touch of a button.
SpaceWise® Half Rack
Flexible rack system that adjusts to
cook multiple dishes at once. Remove the
half rack and you’ll have extra height for
tall dishes.
One-Touch Keep Warm Setting
Just one touch of a button keeps food
warm until everything — and everyone —
is ready.
Eortless™ Oven Rack
Bottom rack extends when you open the
door for easy access.
Real Stainless Steel
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it’s easy to clean.
Quick Bake Convection
Bake faster and more evenly with
Quick Bake Convection.
Low Simmer Burner
Perfect for delicate foods and sauces.
Continuous Grates
Continuous Grates make it easy to move
heavy pots and pans between burners
without lifting.
Sabbath Mode (Star-K® Certified)
Available in:
Stainless
(F)
Burners
Right Front
Right Rear
Left Front
Left Rear
Center Extra Zone
BTU
17,000
5,000
9,500
15,000
10,000
1Based on single rack cooking performance,
not set temperature, using Quick Preheat.
Freestanding Range
FGGF305MK F

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
1For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe operation.
Features
Oven Control / Timing System
Surface Type
Sealed Gas Burners
Grates
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Cleaning System
Auxiliary Oven
Oven Controls
Bake / Broil
Eortless™ Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
Quick Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self Clean
Quick Clean Option
Delay Clean
Kitchen Timer / Timed Cook Option
Auto Oven Shuto
Auxiliary Oven Control
Cooktop Features
Right Front Burner (BTU)
Right Rear Burner (BTU)
Left Front Burner (BTU)
Left Rear Burner (BTU)
Center Extra Zone Burner (BTU)
Oven Features
Main / Auxiliary Capacity (Cu. Ft.)
Oven Light
Rack Configuration
Baking System
Broiling System
Main Bake / Broil Burners (BTU)
Auxiliary Bake / Broil Burners (BTU)
Auxiliary Oven Racks
Certifications
Sabbath Mode (Star-K® Cert.)
Specifications
Main Oven Interior ( H x W x D )
Auxiliary Oven Interior ( H x W x D )
Power / Gas Supply Conn. Location
LP Gas Conversion Kit
Voltage Rating
Conn. Load (kW Rating) @ 120 Volts1
Amps @ 120 Volts
Shipping Weight (Approx.)
Express-Select® Controls
Black Porcelain
Yes
Continuous Cast Iron
w/ Black Matte Finish
Extra-Large
Real Stainless Steel
Stainless Steel
Black
Quick Bake Conv. (Main)
Self Clean (Main)
SpaceWise® Lower Oven
Yes / Variable
(400 – 500 °F)
Yes (Main)
Yes
Yes
Yes
Yes
Yes
Yes
2, 3, 4 Hours (Main)
Yes
Yes
Yes / Yes
6 Hours
Bake and Warm,
140°– 170°– 450°
with 6 Hour Shuto
17,000
5,000
9,500
15,000
Oval 10,000
5.0 /.587
1
1 Heavy Duty, 1 SpaceWise®
Half Rack, 1 Eortless™
Even Baking Technology
Even Broil
18,000 / 13,500
700 / No
1 SpaceWise® Half Rack
Yes
17-5/8" x 24-3/8" x 19-3/4"
3-3/8" x 18-1/2" x 16-1/4"
Left / Right Bottom Rear
Not Convertible –
Natural Gas Only
120V / 60Hz / 15A
1.8
15
220 Lbs.
Cutout Dimensions
Height (Standard)
Width (Min.)
Depth (Min.)
36"
30"
24"
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
47-1/2"
29-7/8"
28-1/2"
46-5/8"
30" Gas Freestanding Ranges_Double Oven_Lower
Frigidaire Gallery
C
A
36"
(Adjustable)
B
NOTE: For planning purposes only. Always consult local and national electric and gas codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGGF305MK 01/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Freestanding Range
FGGF305MK F 30" Gas

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator
