Frigidaire FEFS68CJ User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
FEFS68CJBA FEFS68CJ Frigidaire black/black Sears
FEFS68CJSA FEFS68CJ Frigidaire white/white Sears
FEFS68CJTA FEFS68CJ Frigidaire almond/almond Sears
Publication No.
5995346821
001129
-EN/SERVICE /ECL
369
ELECTRIC
RANGE
Model No.
FEFS68CJ
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - #316002709
OWNER’S GUIDE - # 316135911
SERVICE DATA SHEET - #316097864
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

01/01 2
Publication No. FEFS68CJ
5995346821
BACKGUARD

# = Fast-moving Parts 3 01/01
* = Non-Illustrated Parts
FEFS68CJ Publication No.
5995346821
BACKGUARD
A = FEFS68CJ (FEFS68CJBA)
B = FEFS68CJ (FEFS68CJSA)
C = FEFS68CJ (FEFS68CJTA)
POS. NO PART NO DESCRIPTION
1 316081600 A B C Shield-backguard,galv steel ,rear wall
2 316015905 A B C Shield-backguard,inner
11 316083719 A - - Trim-wrapper,textured ,black
11 316083721 - B - Trim-wrapper,textured ,white ,w/switch hole
11 316083720 - - C Trim-wrapper ele w/hole,almond
14 316022503 A B C Light/Lamp, indicator , surface ,250 V
14A 316022500 A B C Light/Lamp, warmer, indicator , drawer/zone, 125 V
15 316023108 A B C Support-backguard,RH
15A 316023109 A B C Support-backguard,LH
19 316100588 A - - Panel-control,black ,19
19 316100586 - B - Panel-control,white ,19
19 316100587 - - C Panel-control,almond ,19
20 316131605 A - - Clock/Timer,electronic
20 316131602 - B C Clock/Timer,electronic ,20
20A 316101545 A - - Overlay-clock,gray
20A 316101543 - B - Overlay-clock,white
20A 316101544 - - C Overlay-clock,almond
23 316100301 A B C Bracket-timer
24 # 316118100 A - - Switch-oven light,rocker ,black
24 # 316118101 - B - Switch-oven light,rocker ,white
24 # 316118102 - - C Switch-oven light,rocker ,almond
24C# 316114003 A - - Switch-Speed Bake,grey
24C# 316114000 - B - Switch-Speed Bake,white
24C# 316114001 - - C Switch-Speed Bake, almond
36 316109606 A - - Knob-control,black ,36
36 316109607 - B - Knob-control,white
36 316109608 - - C Knob-control,almond
40 316025800 A - - Panel-manifold,black
40 316025808 - B - Panel-manifold,white
40 316025809 - - C Panel-manifold,almond
46 316040201 A B C Lens-light/lamp,indicator ,red
54 # 316021500 A B C Switch,infinite , 6" element
54A# 316021501 A B C Switch,infinite , 8" element
69 5303292005 A B C Screw,8-32 x 5/32 ,switch/handle
* 316021110 A B C Screw,8-18 x 0.500 ,black
* 316021105 A B C Screw,hex head cup pt ,8-18 x .375,black,back/bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrm,hng,ind light,mnfld pnl

01/01 4
Publication No. FEFS68CJ
5995346821
BODY

# = Fast-moving Parts 5 01/01
* = Non-Illustrated Parts
FEFS68CJ Publication No.
5995346821
BODY
A = FEFS68CJ (FEFS68CJBA)
B = FEFS68CJ (FEFS68CJSA)
C = FEFS68CJ (FEFS68CJTA)
POS. NO PART NO DESCRIPTION
1 316080803 A B C Panel-main back,galv steel ,short
3 316081038 A - - Panel-bodyside, black, RH,textured
3 316081039 A - - Panel-bodyside, black, LH, textured
3 316081034 - B - Panel-bodyside,white ,RH
3 316081035 - B - Panel-bodyside,white ,LH
3 316081036 - - C Panel-bodyside,almond ,RH
3 316081037 - - C Panel-bodyside,almond ,LH
5 316129200 A B C Screw-leveling,plastic ,with stop
6 316067902 A B C Rack-oven
7 316007005 A B C Hinge-oven door, (2)
8 3203540 A B C Panel-oven bottom
9 316081900 A B C Pan-broiler
10 316082000 A B C Insert-broiler pan
12 # 316027701 A B C Switch-oven light
13 316026800 A B C Rod-light switch /door
14 316116400 A B C Socket-light/lamp,oven
15 5303013071 A B C Light Bulb/Lamp
16 08011086 A B C Lens-light/lamp, glass , oven
17 316087500 A B C Retainer-lens
18 # 316036300 A B C Latch-door
21 3014099 A B C Spacer-bodyside, (8)
25 3200848 A B C Shield-heat,lower
28 316045000 A B C Clip-wiring harness,retainer ,green ,main top
29 3051162 A B C Glide-drawer,front
37 # 316134900 A B C Probe-oven temp
41 3131570 A B C Cover-hinge cutout
44 3131903 A B C Bumper-door/drawer, rubber
45 316066100 A B C Shield-wire,s/t vent
57 316081100 A B C Cover-access
58 3200847 A B C Insulation,oven bottom
58A 316047708 A B C Insulation, 2" ,oven wrapper
58B 316054201 A B C Insulation,oven back
59 316073602 A B C Tube-oven vent
59A 316023600 A B C Tube-oven vent,upper
59B 316040100 A B C Bracket-mounting,vent tube
62 # 5303935061 A B C Terminal Block Kit
62* 316085600 A B C Insulator
62* 5303308427 A B C Nut,hex ,10-32
63 5301145190 A B C Plate-ground strap
66 # 5303051140 A B C Element-broil,2950 W
67 # 316075103 A B C Element-bake,67
68 316075300 A B C Support-element, broil
71 316015804 A B C Shield-rear wall,galv steel
72 5303285692 A B C Cover-rod end,lt switch rod
82 5303289913 A B C Shield-insulation
87 316081200 A B C Bracket-cable mtg
88 316026400 A B C Rod-latch,auto
89 # 316135200 A - - Motor-latch/lock
89 # 316028101 - B C Motor-latch/lock
106 316026600 A B C Bracket-motor mtg
107 316026701 A B C Cover-fan
108# 316136300 A - - Motor-fan
108# 316090500 - B C Motor-fan
109 316136400 A - - Fan Blade
109 316090600 - B C Fan Blade
110 316136500 A - - Washer,fan motor
110 316090700 - B C Washer,fan motor
111 316136600 A - - Nut-fan retainer
111 316090800 - B C Nut-fan retainer
112 316082700 - B C Relay,oven door lock
170 5303935180 A B C Anti-tip Kit,w/bracket,screw
170* 316107200 A B C Bracket,anti-tip
170* 316112500 A B C Template, Anti-tip bracket
170* 316116000 A B C Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* # 316001586 A - - Wiring Harness,main
* # 316001581 - B C Wiring Harness,main
* 3203550 A B C Plug-button,oven bottom
* 316021105 A B C Screw,hex head cup pt ,8-18 x .375,black,back/bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chom,hng,ind light,mnfld pnl

01/01 6
Publication No. FEFS68CJ
5995346821
TOP/DRAWER

# = Fast-moving Parts 7 01/01
* = Non-Illustrated Parts
FEFS68CJ Publication No.
5995346821
TOP/DRAWER
A = FEFS68CJ (FEFS68CJBA)
B = FEFS68CJ (FEFS68CJSA)
C = FEFS68CJ (FEFS68CJTA)
POS. NO PART NO DESCRIPTION
1 316011501 A B C Drawer-utility
2 5303288582 A B C Shield-drawer,liner ,galv steel ,front panel
4 316084407 A - - Panel-drawer front,black
4 316084405 - B - Panel-drawer front,white
4 316084406 - - C Panel-drawer front,almond
7 3051163 A B C Glide-drawer,rear
15 # 318178100 A B C Element-surface,radiant ,small/6 inch ,1200 W
15A# 318178101 A B C Element-surface,radiant ,large/8 inch ,2100 W
16 316098137 A - - Maintop, smoothtop,black
16 316098105 - B - Panel-main top,white ,smooth top assy
16 316098104 - - C Main Top,smooth top ,almond
18 5303273062 A B C Hinge-main top,RH
18A 5303273063 A B C Hinge-main top,LH
26 316099100 A B C Channel-support,element ,galv steel ,(2)
26A 316099200 A B C Bracket-support,chassis ,galv steel
44 3131903 A B C Bumper-door/drawer, rubber
48 316100200 A B C Shield-wire,main top
51 # 316105100 A B C Light/Lamp,hot surface ind ,assy
52 316099400 A B C Clip-spring, element mtg,(8)
53 316099300 A B C Bracket-indicator light,hot surface ,4 hole
88 316099500 A B C Pin-guide, (2)
* # 316001763 A B C Wiring Harness,surface element ,w/ind light #51
* 316045000 A B C Clip-wiring harness,retainer ,green ,main top
* 316112101 A B C Cleaner-cooktop
* 316089600 A B C Spacer-drawer,(2)
* 316021105 A B C Screw,hex head cup pt ,8-18 x .375,black,back/bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrm,hng,ind light,mnfld pnl
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312 ,(2)

01/01 8
Publication No. FEFS68CJ
5995346821
DOOR

# = Fast-moving Parts 9 01/01
* = Non-Illustrated Parts
FEFS68CJ Publication No.
5995346821
DOOR
A = FEFS68CJ (FEFS68CJBA)
B = FEFS68CJ (FEFS68CJSA)
C = FEFS68CJ (FEFS68CJTA)
POS. NO PART NO DESCRIPTION
3 316067802 A - - Trim-oven door,black
3 316067804 - B - Trim-oven door,white
3 316067803 - - C Trim-oven door,almond
4 316089012 A - - Glass-oven door,black ,outer
4 316089013 - B - Glass-oven door,white ,outer
4 316089014 - - C Glass-oven door,almond ,outer
5 316117601 A B C Glass-Door Airwash 4MM,5
6 316091404 A B C Shield-wool
8 316117500 A B C Glass-oven door, inner , (2)
9 316066619 A B C Liner-oven door
10 5303280308 A B C Screw-handle mtg,wafer hd sq dr ,10-24T x 2.00
10* 316008401 A B C Washer,3/4 OD x 1/4 ID ,steel
12 # 5303131601 A B C Seal-oven door
14 316102204 A - - Foil-aluminum,black backing ,14
14 316102205 A - - Foil-aluminum,14A , (2)
14A 316102202 - B C Foil-aluminum, (4)
14A 316102203 - B C Foil-aluminum, (2)
15 316081405 A B C Bracket-glass, (2)
17 316117701 A B C Spacer-glass, (2)
39 316091117 A - - Handle-door,black ,oven
39 316091115 - B - Handle-door,white ,oven
39 316091116 - - C Handle-door,almond ,oven
52 316081303 A - - Shield-oven door,black ,top
52 316081301 - B - Shield-oven door,white ,top
52 316081302 - - C Shield-oven door,almond ,top
* 316065306 A B C Plate-warning/caution
* 3203618 A B C Rivet-pop,warning-plate
* 316132100 A B C Spacer,sponge pad
* 316021109 A B C Screw,8-18 x 0.500 ,chrome
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.500 ,burner box
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312 ,(2)
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black
* 316021110 A B C Screw,8-18 x 0.500 ,black
* 316021112 A B C Screw,8-18 x 0.500 ,white

01/01 10
Publication No. FEFS68CJ
5995346821
WIRING DIAGRAM
