Drop-In Cooktop
FPEC3085K S 30" Electric30" Electric
Signature Features
Large Capacity
Our large capacity oven gives you
room to cook more at once.
Ready-Select® Controls
Easily select options or control
cooking temperature with our
easy-to-use controls.
Hi /Lo Broil Option
Offers two-position broiling and
variable temperature control for
more control.
Even Baking Technology
Our latest technology ensures
even baking every time.
Product Dimensions
Height 26-1/2"
Width 30"
Depth 27-1/2"
More Easy-To-Use Features
Color-Coordinated Oven Door
with Large Window
Stylish look with a large window
makes it easy to check on what’s
cooking without opening the door.
Timed Cook Option
Electronic Kitchen Timer
Auto Preheat
Bright Lighting
Our bright lighting makes it easy
to see what’s inside.
Manual Clean Oven
Chrome Drip Bowls
A.D.A. Compliant1
Available in:
Drop-In Range
FFED3005L W
1
When properly installed, meets the appliance
standards in the Americans with Disabilities Act
and the Architectural Barriers Act Accessibility
Guidelines as published by the United States
Access Board on June 23, 2004, as amended
August 5, 2005.
White
(W)
Elements
Right Front
Right Rear
Left Front
Left Rear
Watts
2,600
1,500
1,500
2,600
Size
8"
6"
6"
8"

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
1
When properly installed, meets the appliance standards in the
Americans with Disabilities Act and the Architectural Barriers Act
Accessibility Guidelines as published by the United States
Access Board on June 23, 2004, as amended August 5, 2005.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFED3005L 11/11 © 2011 Electrolux Home Products, Inc.
Features
Oven Control / Timing System
Surface Type
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Drawer Functionality
Oven Controls
Bake
Broil
Add-a-Minute
Delay Bake
Self Clean
Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Auto Oven Shut-O
Cooktop Features
Right Front Element (Watts)
Right Rear Element (Watts)
Left Front Element (Watts)
Left Rear Element (Watts)
Center Element (Watts)
Hot Surface Indicator Light
Coil Cooktop / Drip Bowls
Oven Features
Capacity (Cu. Ft.)
Oven Light
Hidden Bake Element
Rack Configuration
Even Baking System
Broiling System
Bake Element / Broil Element (Watts)
Optional Accessories
Rear Filler Kit –
White (W) / Black (B)
Side Panel Kit –
White (W) / Black (B)
Backguard Kit –
White (W) / Black (B)
Side Trim Kit –
White (W) / Black (B)
Bottom Trim Kit –
White (W) / Black (B)
Certifications
A.D.A. Compliant1
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Ready-Select® Controls
Color-Coordinated Porcelain
Large
Color-Coordinated
Color-Coordinated
Color-Coordinated
Manual Clean
Yes
Low and High
Yes
Yes
8" – 2,600
6" – 1,500
6" – 1,500
8" – 2,600
Yes / Chrome
4.2
1
2 Standard
Yes
Vari-Broil™ Hi / Lo
2,750 / 3,400
(W) PN # 901193-9011
(W) PN # 903046-9011
(W) PN # 903076-9011
(W) PN # 903068-9011
Yes
16-1/2" x 24-1/8" x 18-1/32"
Left Bottom Rear
240V / 208V / 60 Hz
11.2 / 8.4
46.6 / 40.4
40
132 Lbs.
Drop-In Range
FFED3005L W 30" Electric
Cutout Dimensions
Height
Width (Min.)
(Max.)
Depth (Min.)
(Max.)
29" †
29-15/16"
30-1/16" *
21-3/4"
22-1/8" **
Slide-In Electric Ranges
Frigidaire Baseline
B
A
* To extreme
rear protrusion
C*
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
†27-1/2" min. if additional front cabinet filler panel is
required (refer to product installation guide on web
for filler panel details)
*Cutout and countertop cutout width should match.
** 24" with optional backguard installed.
Product Dimensions
A - Height
B - Width
C - Depth
Depth with Door Open 90˚
26-1/2"
30"
27-1/2"
45-1/2"

Specifications
subject to change.
30" Electric Drop-In Range
Frig Baseline
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFED3005L 11/11 © 2011 Electrolux Home Products, Inc.
Drop-In Range Specifications
•Product Shipping Weight (approx.) – 132 Lbs.
•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt,
60 Hertz, fused on both sides of line with ground. (If local code
permits, range may be connected by hard-wiring or by means
of power supply cord kit.)
•Connected Load (kW Rating) @ 240 / 208 Volts = 11.2 / 8.4 kW
•Amps @ 240 / 208 Volts = 46.6 / 40.4 Amps
•Recommended Circuit Breaker – 50 Amps (40 Amps minimum)
•Always consult local and national electric codes.
•Make sure wall coverings around range can withstand heat generated
by range.
•Linoleum or any other synthetic floor covering located beneath range,
must be capable of withstanding minimum heat of 90° F above room
temperature without shrinking, warping or discoloring. Insulating pad
or 1/4"-thick plywood required between range and a carpeted floor.
•When installing optional Backguard Kit, cutout depth of 21-3/4"
minimum / 22-1/8" maximum needs increased to 24".
•Overhead cabinetry should not exceed a 13" maximum depth.
•Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum
width of appliance.
•Allow 24" minimum clearance between rangetop and bottom of cabinet
when bottom of wood or metal cabinet is protected by not less than
1/4" flame-retardant millboard covered with not less than No. 28 MSG
sheet steel, 0.015" stainless steel, 0.024" aluminum or 0.020" copper.
Allow 30" minimum clearance when cabinet is unprotected.
•To reduce risk of fire when using overhead cabinetry, install
range hood that projects horizontally a recommended minimum
of 5" beyond bottom of cabinets.
Countertop Preparation
For detailed preparation instructions, refer to installation guide
on the web.
•Flat square-finish (flat) countertop requires no preparation since
rangetop flange lays directly on countertop edge.
•Formed front-edged countertops require front molded edge to
be shaved flat 3/4" from each front corner of opening.
•Tile countertops may need cut back 3/4" from each front corner
of opening and /or rounded edge flattened.
•For existing cutout width greater than 30-1/16" reduce the 3/4"
overlap dimension.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Optional Accessories
•Rear Filler Kit: White – (PN # 901193-9011),
•Backguard Kit: White – (PN # 903046-9011),
•Side Trim Kit: White – (PN # 903076-9011),
•Bottom Trim Kit: White – (PN # 903068-9011),
Drop-In Range
FFED3005L W 30" Electric

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator
