30" Induction
Signature Features
Versatile Induction Elements
Features four elements with induction
technology, including a powerful 10"
element with up to 3,400 watts of
power to bring water to a boil quickly.
Cooking Versatility
Gentle enough to melt chocolate
and powerful enough to boil water,
so it’s great for entertaining or
getting dinner on the table quickly.
True Convection
Multi-rack baking is faster and more
even with True Convection.
Fits-More™ Oven
More cooking space – plus even cooking.
Product Dimensions
Height (Max.) 47-3/4"
Width 29-7/8"
Depth (Including Handle) 28-7/8"
More Easy-To-Use Features
More Responsive
Cooking with induction is more
responsive than gas or electric so you
can easily go from simmer to boil.
Pro-Select® Controls
Precise control at your fingertips.
Cookware Compatibility
Most stainless steel and cast iron cookware
is compatible with induction elements.
An easy rule of thumb: if a magnet sticks
to the bottom of the cookware, it’s
induction-friendly.
PowerPlus® Boost
Generates rapid heat for a quicker boil.
More Energy-Ecient
Cooking with induction is 70% more
efficient than gas and 20% more efficient
than electric.
Keep Warm Drawer
A place to keep food warm until
everything — and everyone — is ready.
One-Touch Keep Warm Setting
Just one touch of a button keeps food
warm until everything — and everyone —
is ready.
One-Touch Options
Our ovens feature easy-to-use one-touch
buttons so you can cook pizza or chicken
nuggets — or even add a minute to the
timer — with the touch of a button.
Sabbath Mode (Star-K® Certified)
Available in:
Freestanding Range
FPIF3093L F
Elements
Right Front
Right Rear
Left Front
Left Rear
Watts
2,400 / 3,400
1,500 / 1,900
2,400 / 3,400
1,900 / 2,600
Size
Induction 10"
Induction 6"
Induction 8"
Induction 7"
Stainless
(F)

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
Cutout Dimensions
Height (Standard)
Width (Min.)
Depth (Min.)
36"
30"
24"
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
47-3/4"
29-7/8"
28-7/8"
48-3/4"
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
30" Electric Freestanding Ranges
Frigidaire Professional
C
A
36"
(Adjustable)
B
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPIF3093L 10/11 © 2011 Electrolux Home Products, Inc.
Freestanding Range
FPIF3093L F 30" Induction
Features
Oven Control / Timing System
Surface Type
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Drawer Functionality
Oven Controls
Bake / Broil
Eortless™ Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
PowerPlus® Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self Clean
Rapid Clean Option
Delay Clean
Kitchen Timer / Timed Cook Option
Auto Oven Shut-O
Oven Lock-Out
Lower Drawer Control
Cooktop Features
Right Front Element (Watts)
Right Rear Element (Watts)
Left Front Element (Watts)
Left Rear Element (Watts)
Bridge Element (Watts)
Center Element (Watts)
Oven Features
Capacity (Cu. Ft.)
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake Element / Broil Element (Watts)
Drawer Racks
Certifications
Sabbath Mode (Star-K® Cert.)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating)
@ 240 / 208 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Pro-Select® Controls
Black Ceramic Glass
Wide-View with
Pro-Tint Finish
Smudge-Proof
Stainless Steel
Stainless Steel
Black
True Convection
Self Clean
Warmer
Yes / Variable
(400 - 500 °F)
Yes
Yes / Yes / Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
2, 3, 4 Hours
Yes / Yes
6 Hours
Yes
Warmer,
Low-Med-High
Induction 10" –
2,400 / 3,400
Induction 6" –
1,500 / 1,900
Induction 8" –
2,400 / 3,400
Induction 7" –
1,900 / 2,600
6.0
1
Yes
1 Heavy-Duty,
1 SpaceWise® Half Rack,
1 Eortless™, 1 Deep-Sump
Even Baking Technology
PowerPlus® Broil
3,500 / 3,900
Yes
15-3/4" x 24-3/8" x 17-3/4"
Middle Bottom Rear
240V / 208V / 60 Hz
15.0 / 11.5
40
220 Lbs.

Specifications
subject to change.
30" Full Induction / Induction Hybrid Freestanding Ranges
Professional
Freestanding Range Specifications
•Product Shipping Weight (approx.) – 220 Lbs.
•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz,
fused on both sides of line with ground.
•Connected Load (kW Rating) @ 240 / 208 Volts = 15.0 / 11.5 kW
•Recommended Circuit Breaker – 40 Amps
•Always consult local and national electric codes.
•Make sure wall coverings around range can withstand heat generated
by range.
•Floor beneath range MUST be solid and level.
•Overhead cabinetry should not exceed a 13" maximum depth.
•Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum
width of appliance.
•Range can be installed flush to wall with 0" minimum rear clearance.
•Minimum 1" clearance required from edge of rangetop to nearest
combustible wall on either side of range above 36" height.
•Allow 30" minimum clearance between top of cooking surface and
bottom of unprotected wood or metal overhead cabinet; or 24"
minimum clearance when bottom of wood or metal overhead cabinet
is protected by not less than 1/4" flame retardant millboard covered
with not less than No. 28 MSG sheet steel, 0.015" stainless steel,
0.024" aluminum or 0.020" copper.
•To reduce risk of fire when using overhead cabinetry, install
range hood that projects horizontally a recommended minimum
of 5" beyond bottom of cabinets.
•Follow all dimension requirements provided to prevent property
damage, potential fire hazard, and incorrect countertop and
cabinet cuts.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPIF3093L 10/11 © 2011 Electrolux Home Products, Inc.
Freestanding Range
FPIF3093L F 30" Induction

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator
