p/n 316905204(1110)
SERVICE DATA SHEET
ElectricRangeswithES200/205/300&305ElectronicOvenControls
ElectronicOven Control(RearView)
IMPORTANT
DO NOT REMOVE THIS BAG
OR DESTROY THE CONTENTS
WIRINGDIAGRAMSANDSERVICE
INFORMATION ENCLOSED
REPLACE CONTENTS IN BAG
NOTICE - This service data sheet is intended for use by persons
having electrical and mechanical training and a level of knowledge of these subjects generally considered acceptable in the appliance repair trade. The manufacturer cannot be responsible, nor assume any liability for injury or damage of any kind arising from the use of this data sheet.
SAFESERVICINGPRACTICES To avoid the possibility of personal injury and/or property damage, it is importantthatsafeservicing practices be observed. Thefollowingare examples, but without limitation, of such practices. 1. Beforeservicingormovinganapplianceremovepowercordfrom
electrical outlet, trip circuit breaker to OFF, or remove fuse.
2. Neverinterferewiththeproperinstallationofanysafetydevice. 3. GROUNDING: Thestandardcolor coding forsafetygroundwiresis
GREEN or GREEN WITH YELLOW STRIPES. Ground leads are not to be used as current carrying conductors. It is extremely important that the service technician reestablish all safety grounds prior to completion of service. Failure to do so will create a potential safety hazard.
4. Prior to returning the product to service, ensure that:
• All electric connections are correct and secure. • All electrical leads are properly dressed and secured away from sharpedges,high-temperaturecomponents,andmovingparts. • All uninsulated electrical terminals, connectors, heaters, etc. are adequately spaced away from all metal parts and panels. • All safety grounds (both internal and external) are correctly and securelyreassembled.
RTD SCALE
Temperature (°F) Resistance (ohms)
32 ± 1.9 1000 ± 4.0 75 ± 2.5 1091 ± 5.3
250 ± 4.4 1453 ± 8.9 350 ± 5.4 1654 ± 10.8 450 ± 6.9 1852 ± 13.5 550 ± 8.2 2047 ± 15.8 650 ± 9.6 2237 ± 18.5
900 ± 13.6 2697 ± 24.4
Resistance Temperature Detector
Simmer Select PCB (some models)
OvenCalibration Setthe electronic ovencontrol for normalbaking at 350°F. Obtainan average oven temperature after a minimum of 5 cycles. Press STOP or CLEAR OFF to end bake mode. TemperatureAdjustment 1. Set EOC to bake at 550°F. 2. Within 5 seconds of setting 550°F, press and hold the bake keypad for
approximately 15 seconds until a single beep is heard (longer may cause F11 shortedkeypadalarm).
3. Calibrationoffsetshouldappear in thedisplay. 4. Use the slew keys to adjust the oven temperature up or down 35°F in 5°F
increments.
5. Once the desired (-35° to 35°) offset has been applied, press STOP or
CLEAROFF.
Note: Changingcalibration affectsnormal Bakemode. The adjustments made willnot change the self-cleaning cycle temperature.
CircuitAnalysisMatrix
E.O.C.ControlConnections P5Connections
Please note that the Warmer Drawer feature is only for some models.
ElectronicOvenControlFaultCodeDescriptions
Fault Code
Runaway temperature. Oven heats when no cook cycle is programmed. Likely failure condition/cause Suggested Corrective Action Shorted keypad or selector switch.
F11 1. Reset power supply to range - Disconnect power, wait 30 seconds and reapply power.
2. Check/reseat ribbon harness connections between touch panel and EOC. 3. Test keyboard circuits. Replace touch panel if defective. 4. If keyboard ciruits check good replace the EOC.
EOC Internal software error or failure.
F12 F13 Disconnect power, wait 30 seconds and reapply power. If fault returns upon power-up, replace EOC.
Open oven sensor probe circuit. Shorted oven sensor probe circuit.
F30 1. (F30) Check resistance at room temperature & compare to RTD Sensor resistance chart. If resistance is correct replace the EOC. If
resistance does not match the RTD chart replace RTD Sensor Probe. Check Sensor wiring harness between EOC & Sensor Probe connector. 2. (F31) Check resistance at room temperature, if less than 500 ohms, replace RTD Sensor Probe. Check for shorted Sensor Probe harness between EOC & Probe connector. If resistance is correct replace the EOC.
F31
F90 F91 F92 F93 F94 F95
If lock motor runs: 1. Test continuity of wiring between EOC and lock switch on lock motor assy. Repair if needed. 2. Advance motor until cam depresses the plunger on lock motor switch. Test continuity of switch contacts. If switch is open replace lock motor assemblyy. 3. If motor runs and switch contacts and wiring harness test good, replace the EOC. If lock motor does not run: 1. Test continuity of lock motor windings. Replace lock motor assembly if windings are open. 2. Test lock motor operation by using a test cord to apply voltage. If motor does not operate replace lock motor assy. 3. If motor runs with test cord check continuity of wire harness to lock motor terminals. If harness is good replace the EOC.
Door lock motor or latch circuit failure.
If Oven is cold: 1. If fault code is present with cold oven test oven temperature sensor probe circuit resistance. Use RTD scale found in the tech sheet. 2. Replace probe or repair wiring connections if defective. 3. If temperature sensor probe circuit is good but fault code remains when oven is cold replace the EOC. If Oven is overheating: 1. If oven is severely overheating/heating when no cook cycle is programmed test oven temperature sensor probe circuit resistance using the RED scale found in the service tech sheet. Also verify that the temperature sensor probe in properly installed in the oven cavity. 2. Disconnect power from the range, wait 30 seconds and reapply power. If oven continues to heat when the power is reapplied, replace the EOC. NOTE: Severe overheating may require the entire oven to be replaced should damage be extensive.
F10

GENERALTROUBLESHOOTING SCHEMATICGENERALTROUBLESHOOTING DIAGRAM
AVERTIS SEMENT
EXAMPLE: FIRST , STRIPE NEXT.
COPPER / CUIVRE GREEN / VERT BROW N / BRUN BLACK / NOI R ORANGE GRA Y / GRI S BL UE / BLEU
EXEMPLE:
FIL VERT AVEC BANDE JAUNE .
COL OR CODE / CODE DES COULEURS
CELLE DE TOUTE BANDE . DU FI L E N PREMIER. SUIVI E D E LEGENDE DE FILAGE: LA COULEUR
GREEN WIRE WITH YELL OW STRIPE .
L' ALIMENT ATION ELECTRIQU E A VANT
TRACER WIRE: WIRE CO LO R N OTED
DE FAIRE TOUT SERVICE D' ENTRETIEN DEBRANCHEZ L' APPAREL DE DISCONNECT POWER BEFORE SERVICING
G/Y-8
VIOLET RED / ROUG E WHITE / BLANC YELL OW / JAUNE
TAN / BRUN CLAI R PURPL E / POURPRC
PINK / ROSE
G/Y-8
WARNING
