Frigidaire FGF355CG User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET
FGF355CGBG FGF355CG Frigidaire black/black North America
FGF355CGSG FGF355CG Frigidaire white/white North America
FGF355CGTG FGF355CG Frigidaire almond/almond North America
Publication No.
5995346458
001115
-EN/SERVICE /ECL
369
GAS
RANGE
Model No.
FGF355CG
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - #316002168
OWNER’S GUIDE - # 316135902
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

02/01 2
Publication No. FGF355CG
5995346458
BACKGUARD

# = Fast-moving Parts 3 02/01
* = Non-Illustrated Parts
FGF355CG Publication No.
5995346458
BACKGUARD
A = FGF355CG (FGF355CGBG)
B = FGF355CG (FGF355CGSG)
C = FGF355CG (FGF355CGTG)
POS. NO PART NO DESCRIPTION
1 316028700 A B C Shield-backguard,galv ,rear wall
2 316051600 A B C Shield-backguard,inner
2A 316053802 A B C Shield-backguard,inner/top
11 316083718 A - - Trim-wrapper,black ,textured,w/hole
11 316083722 - B - Trim-wrapper,white ,textured,w/hole
11 316083723 - - C Trim-wrapper,almond ,textured,w/hole
15 316023108 A B C Support-backguard,RH
15A 316023109 A B C Support-backguard,LH
19 316100530 A - - Panel-control,black
19 316100525 - B - Panel-control,white
19 316100547 - - C Panel-control,almond
20 # 316131600 A B C Clock/Timer,electronic
20* 316101503 A - - Overlay-clock,black
20* 316101502 - B - Overlay-clock,white
20* 316101504 - - C Overlay-clock,almond
23 316100301 A B C Bracket-timer
24 # 316118100 A - - Switch-oven light,rocker ,black
24 # 316118101 - B - Switch-oven light,rocker ,white
24 # 316118102 - - C Switch-oven light,rocker ,almond
36 316109512 A - - Knob-top valve,black
36 316109513 - B - Knob-top valve,white
36 316109514 - - C Knob-top valve,almond
40 316009268 A - - Panel-manifold,black
40 316009285 - B - Panel-manifold,white
40 316009287 - - C Panel-manifold,almond
42 316055200 A - C Trim-vent,black
42 316055201 - B - Trim-vent,chrome
56 316074907 A B C Deflector-flue, black
* 316021105 A B C Screw,hex head cup pt ,8-18 x .375,blck,back/bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrm,hng,ind light,mnfld pnl
* 316021110 A B C Screw,8-18 x 0.500 ,black

02/01 4
Publication No. FGF355CG
5995346458
BURNER

# = Fast-moving Parts 5 02/01
* = Non-Illustrated Parts
FGF355CG Publication No.
5995346458
BURNER
A = FGF355CG (FGF355CGBG)
B = FGF355CG (FGF355CGSG)
C = FGF355CG (FGF355CGTG)
POS. NO PART NO DESCRIPTION
1 316134501 A B C Manifold Pipe,1
2 # 316134100 A B C Valve-top burner
2* 316134300 A B C Screw,10-24 ,valve mounting
3 # 316001824 A B C Wiring Harness,w/igntr switch
4 # 316059612 A B C Tube-burner,red ,RF
5 # 316059613 A B C Tube-burner,green ,LF
6 # 316059614 A B C Tube-burner,natural ,RR
7 # 316059615 A B C Tube-burner,black ,LR
8 # 316135701 A B C Spark Module
10 # 5303935025 A B C Burner Assy-top,sealed ,small ,9000 BTU
11 316011200 A B C Ignitor-top burner,(4) ,w/mtg bracket
13 # 316065005 A B C Tube,3/8 ,aluminum ,rgltr to manf ,with fittings
14 # 316091706 A B C Regulator-pressure
14* 316021104 A B C Screw-regulator/brkt, hex , 8-18 x 3/8 ,nick, 3
15 316091600 A B C Bracket-regulator
16 # 316065003 A B C Tube-valve to regulator,3/8
17 # 5303208499 A B C Valve-safety,dual
17* 08068018 A B C Shield-wire,safety valve
18 # 3131290 A B C Burner-oven
19 # 5303935066 A B C Ignitor-oven,kit ,w/nut & instr
20 3131284 A B C Baffle-oven burner
21 5303013272 A B C Nut,hex head sems
22 # 316065002 A B C Tube-valve to mixer
23 # 08067935 A B C Burner-broiler
24 # 316070400 A B C Mixer Elbow
24* 316113400 A B C Spacer-broil elbow
25 5303210379 A B C Baffle-broiler
26 # 316119302 A B C Ignitor-broiler
37 316069301 A B C Screw-burner mtg
44 5303210090 A B C Orifice-top burner,small
45 316011100 A B C Screw-ignitor mtg,self-tapping ,M3x5.8
46 316074700 A B C Plate-burner tube
47 5303286386 A B C LP Conversion Kit
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.500 ,burner box

02/01 6
Publication No. FGF355CG
5995346458
BODY

# = Fast-moving Parts 7 02/01
* = Non-Illustrated Parts
FGF355CG Publication No.
5995346458
BODY
A = FGF355CG (FGF355CGBG)
B = FGF355CG (FGF355CGSG)
C = FGF355CG (FGF355CGTG)
POS. NO PART NO DESCRIPTION
1 316029416 A B C Back-main,1
2 3131314 A B C Shield-oven top
3 316081038 A - - Panel-bodyside, black, RH,textured
3 316081039 A - - Panel-bodyside, black, LH, textured
3 316081034 - B - Panel-bodyside,white ,RH
3 316081035 - B - Panel-bodyside,white ,LH
3 316081036 - - C Panel-bodyside,almond ,RH
3 316081037 - - C Panel-bodyside,almond ,LH
4 316011917 A B C Burner Box,with hole
5 316129200 A B C Screw-leveling,plastic ,with stop
6 316067902 A B C Rack-oven
7 316007002 A B C Hinge-oven door,(2)
8 5303300701 A B C Panel-oven bottom
8* 316064600 A B C Support-oven bottom
9 316081900 A B C Pan-broiler
10 316082000 A B C Insert-broiler pan
12 # 316027701 A B C Switch-oven light
13 316026800 A B C Rod-light switch /door
14 # 316116400 A B C Socket-light/lamp,oven
15 5303013071 A B C Light Bulb/Lamp
16 08011086 A B C Lens-light/lamp, glass , oven
17 316087500 A B C Retainer-lens
18 # 316036300 A B C Latch-door
21 3014099 A B C Spacer-bodyside, (8)
25A 5303288580 A B C Shield-heat,lower
28 3011813 A B C Clip-wire, bodyside
29 3051162 A B C Glide-drawer,front
30 316059200 A B C Bracket-main top,RH
30A 316059201 A B C Bracket-main top,LH
33 5303288495 A B C Shield,rear wall
35 316116600 A B C Gasket-flue
36 316133002 A B C Flue
37 # 316111202 A B C Probe-oven temp
38 316051700 A B C Shield-heat
39 # 3202006 A B C Cord-electric power
40 3200836 A B C Shield-heat baffle
40* 5303288570 A B C Screw-heat shield, hd shldr sqdr ,8-18 X 1/2
41 3131570 A B C Cover-hinge cutout
42 5303288578 A B C Shield-bake burner
43 3131732 A B C Screw-oven bottom, 8-18 x 1.438
44 3131903 A B C Bumper-door/drawer, rubber
49 3051124 A B C Clip-spring mtg
53 5303288579 A B C Shield,main front
53A 08067992 A B C Shield,insulation ,front frame
55 316107800 A B C Shield-flue
58A 316047708 A B C Insulation, 2" ,oven wrapper
58B 316054200 A B C Insulation, 2" ,oven back
58G 08067973 A B C Insulation,main front
72 5303285692 A B C Cover-rod end,lt switch rod
88 316026400 A B C Rod-latch,auto
89 # 316028101 A B C Motor-latch/lock
170 5303935180 A B C Anti-tip Kit,w/bracket,screw
170* 316107200 A B C Bracket,anti-tip
170* 316112500 A B C Template, Anti-tip bracket
170* 316116000 A B C Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* 08067757 A B C Cover Plate,burner box
* 316001632 A B C Wiring Harness,chassis
* 316021105 A B C Screw,hex head cup pt ,8-18 x .375,blck,back/bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrm,hng,ind light,mnfld pnl
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.500 ,burner box
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312 ,(2)
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black

02/01 8
Publication No. FGF355CG
5995346458
TOP/DRAWER

# = Fast-moving Parts 9 02/01
* = Non-Illustrated Parts
FGF355CG Publication No.
5995346458
TOP/DRAWER
A = FGF355CG (FGF355CGBG)
B = FGF355CG (FGF355CGSG)
C = FGF355CG (FGF355CGTG)
POS. NO PART NO DESCRIPTION
1 316011501 A B C Drawer-utility
1* 316089600 A B C Spacer-drawer,(2)
2 5303288582 A B C Shield-drawer,liner ,galv steel ,front panel
4 316084407 A - - Panel-drawer front,black
4 316084405 - B - Panel-drawer front,white
4 316084406 - - C Panel-drawer front,almond
4* 316021110 A B C Screw,8-18 x 0.500 ,black
4* 316021112 - B - Screw,8-18 x 0.500 ,white
4* 316021113 - - C Screw,8-18 x 0.500 ,almond
7 3051163 A B C Glide-drawer,rear
16 5303291521 A - - Panel-main top,black
16 5303301546 - B - Panel-main top,white
16 5303301547 - - C Panel-main top,almond
19 # 316011401 A - - Pan-burner,small ,black
19 # 316011409 - B - Pan-burner,small ,gray
19 # 316011410 - - C Pan-burner,small ,almond
20 316085305 A - - Grate,black ,(4)
20 316085304 - B C Grate,gray ,(4)
22 316122100 A - - Cap-burner,small ,black ,(4)
22 316122101 - B C Cap-burner,small ,gray ,(4)
* 3131903 A B C Bumper-door/drawer, rubber
* 316021105 A B C Screw,hex head cup pt ,8-18 x .375,blck,back/bodyside
* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrm,hng,ind light,mnfld pnl
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312 ,(2)

02/01 10
Publication No. FGF355CG
5995346458
DOOR

# = Fast-moving Parts 11 02/01
* = Non-Illustrated Parts
FGF355CG Publication No.
5995346458
DOOR
A = FGF355CG (FGF355CGBG)
B = FGF355CG (FGF355CGSG)
C = FGF355CG (FGF355CGTG)
POS. NO PART NO DESCRIPTION
3 316067802 A - - Trim-oven door,black
3 316067804 - B - Trim-oven door,white
3 316067803 - - C Trim-oven door,almond
4 316089000 A - - Glass-oven door,black ,outer
4 316089005 - B - Glass-oven door,white ,outer
4 316089004 - - C Glass-oven door,almond ,outer
5 316088700 A B C Glass-oven door,airwash
6 316088401 A B C Shield-wool
7 316076403 A B C Insulation-door
8 316088600 A B C Glass-oven door,inner
9 316066610 A B C Liner-oven door
10 5303280308 A B C Screw-handle mtg,wafer hd sq dr ,10-24T x 2.00
10* 316008401 A B C Washer,3/4 OD x 1/4 ID ,steel
12 # 5303131601 A B C Seal-oven door
14 5303208656 A - - Reflector,aluminum foil ,black door
14 3131361 - B C Reflector,aluminum foil
14A 5303208655 A - - Reflector,aluminum foil ,black door
14A 3131360 - B C Reflector,aluminum foil ,(2)
15 316081403 A B C Bracket-glass mtg
16 316085701 A B C Glass-oven door,heat barrier
39 316091114 A - - Handle-door,black ,oven
39 316091115 - B - Handle-door,white ,oven
39 316091116 - - C Handle-door,almond ,oven
52 316081303 A - - Shield-oven door,black ,top
52 316081301 - B - Shield-oven door,white ,top
52 316081302 - - C Shield-oven door,almond ,top
* 316065306 A B C Plate-warning/caution
* 3203618 A B C Rivet-pop,warning-plate
* 316132100 A B C Spacer,sponge pad
* 316021109 A B C Screw,8-18 x 0.500 ,chrome
* 316021110 A B C Screw,8-18 x 0.500 ,black
* 316021112 - B - Screw,8-18 x 0.500 ,white
* 5303212762 - - C Screw,pan hd phillips ,8-18 x 0.500
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.500 ,burner box
* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312 ,(2)
* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black

02/01 12
Publication No. FGF355CG
5995346458
WIRING DIAGRAM
