Frigidaire FEF365A User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF365ASA FEF365A white North America
FEF365ASB FEF365A white North America
Publication No.
5995357802
010817
-EN/SERVICE /ECL
369
ELECTRIC
RANGE
Model No.
FEF365A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERVICE DATA SHEET - # 316259142
WIRING DIAGRAM - #316255105
OWNER’S GUIDE - # 316257105
INSTALLATION INSTRUCTIONS -# 316259200

08/01 2
Publication No. FEF365A
5995357802
BACKGUARD

# = Fast-moving Parts 3 08/01
* = Non-Illustrated Parts
FEF365A Publication No.
5995357802
A = FEF365A (FEF365ASA)
B = FEF365A (FEF365ASB)
POS. NO PART NO DESCRIPTION
1 316239900 A B Shield,backguard ,rear wall
11 316241000 A B Shield,end cap ,RH
11A 316241001 A B Shield,end cap ,LH
14 316022503 A B Light/Lamp,indicator ,surface ,250 V
15 316220202 A B Support,backguard ,white ,RH
15A 316220203 A B Support,backguard ,white ,LH
18 316240900 A B End Cap,white ,RH
18A 316240901 A B End Cap,white ,LH
19 316244495 A B Panel,backguard ,white
20 # 316222905 A B Clock/Timer,electronic
20A 316220800 A B Overlay,clock ,white
24 # 316246000 A B Switch,rocker ,white ,oven light
31 316223000 A B Knob,control ,white
46 316040201 A B Lens,indicator light ,red
54 # 316021500 A B Switch,infinite ,small element
54A# 316021501 A B Switch,infinite ,large element
56 316234001 A B Shield,backguard ,white ,inner
69 5303288565 A B Screw,truss sqdr ,8-32 x 3/16 ,switch mtg
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 316021122 A B Screw,truss hd ,8-18 x 0.375 ,white
BACKGUARD

08/01 4
Publication No. FEF365A
5995357802
BODY

# = Fast-moving Parts 5 08/01
* = Non-Illustrated Parts
FEF365A Publication No.
5995357802
A = FEF365A (FEF365ASA)
B = FEF365A (FEF365ASB)
POS. NO PART NO DESCRIPTION
1 316201300 A B Back,main
3 316230102 A B Panel,bodyside ,white ,RH
3 316230103 A B Panel,bodyside ,white ,LH
5 316129200 A B Screw,leveling ,plastic ,with stop
6 316067902 A B Rack,oven
7 316205006 A B Hinge,oven door ,RH
7A 316205007 A B Hinge,oven door ,LH
8 3203540 A B Panel,oven bottom
9 316081900 A B Pan,broiler
10 316082000 A B Insert,broiler pan
12 # 316027701 A B Switch,oven light
13 316238800 A B Rod,light switch
14 # 316116400 A B Receptacle,oven light
15 5303013071 A B Bulb/Lamp,oven light
16 08011086 A B Lens,oven light ,glass
17 316087500 A B Retainer,lens
18 # 316213900 A B Latch,oven door
21 3014099 A B Spacer,bodyside
25 3200848 A B Shield,heat ,lower
26 316206300 A B Support,chassis ,(2)
29 3051162 A B Glide,drawer ,front
30 316217700 A B Bracket,hinge ,RH ,main top
30A 316217701 A B Bracket,hinge ,LH ,main top
37 # 316233900 A B Probe,oven temp
41 316233400 A B Cover,hinge cutout ,RH
41A 316233500 A B Cover,hinge cutout ,LH
42 316206200 A B Shield,wool ,lower
44 316246500 A B Spacer,oven door
45 316234100 A B Shield,wire ,vent tube
57 316081100 A B Cover,access
58 3200847 A B Insulation,oven bottom
58A 316047708 A B Insulation,2" ,oven wrapper
58B 316240100 A B Insulation,oven back
59 316208200 A B Tube,oven vent ,lower
59A 316208300 A B Tube,oven vent ,upper
59B 316247300 A B Catalyst,oven vent ,ceramic
62 # 5303935061 A B Terminal Block Kit
62* 316085600 A B Insulator
62* 5303308427 A B Nut,hex ,10-32
63 5301145190 A B Plate,grounding strap
66 # 316203200 A B Element,broil
67 # 316075103 A B Element,bake
68 316203400 A B Support,broil element
71 316015810 A B Shield,rear wall ,galv steel
72 316234500 A B Cover,rod end ,light switch
87 316081200 A B Bracket,cable mtg
88 316203500 A B Rod,auto latch
89 # 316135202 A B Motor,latch/lock
89A 316245800 A B Bracket,latch ,rear
151 316239300 A B Shield,bodyside
170 5303935180 A B Anti-tip Kit,w/bracket,screw
170* 316107200 A B Bracket,anti-tip
170* 316112500 A B Template,anti-tip
170* 316116000 A B Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* # 316253203 A B Wiring Harness,main
* 3203550 A B Plug,button ,oven bottom
* 5303305324 A B Paint,touch-up ,white
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black
* 5308014215 A B Screw,6-20 x 0.312
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 0.5
BODY

08/01 6
Publication No. FEF365A
5995357802
TOP/DRAWER

# = Fast-moving Parts 7 08/01
* = Non-Illustrated Parts
FEF365A Publication No.
5995357802
A = FEF365A (FEF365ASA)
B = FEF365A (FEF365ASB)
POS. NO PART NO DESCRIPTION
1 316011503 A B Drawer
2 316231500 A B Liner,drawer
4 316231305 A B Panel,drawer ,white
7 3051163 A B Glide,drawer ,rear
15 # 316010206 A B Element,8" ,surface ,2200 W ,radiant
15A# 316010205 A B Element,6" ,surface ,1200 W ,radiant
15B# 316224200 A B Element,9" ,surface ,2500W ,radiant
16 316251900 A - Main Top Assy,glass/steel ,white
16 316251942 - B Main Top Assy,glass/steel ,white
18 316235900 A B Hinge,main top ,RH
18A 316235901 A B Hinge,main top ,LH
26 316230200 A B Channel,element support ,(2)
26A 316099200 A B Bracket,chassis support ,rear
26B 316214200 A B Bracket,chassis support ,front
52 316099400 A B Clip,element mtg
88 316099500 A B Pin,guide ,(2)
* 316253515 A B Wiring Harness,surface element
* 316112101 A B Cleaner,cooktop
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 A B Screw,6-20 x 0.312
TOP/DRAWER

08/01 8
Publication No. FEF365A
5995357802
DOOR

# = Fast-moving Parts 9 08/01
* = Non-Illustrated Parts
FEF365A Publication No.
5995357802
A = FEF365A (FEF365ASA)
B = FEF365A (FEF365ASB)
POS. NO PART NO DESCRIPTION
3 5303935192 A B Trim kit-door,3 sided ,white ,w/tape and foil
4 5303935204 A B Glass,door kit ,white ,outer ,w/ foil tape
5 316088700 A B Glass,oven door ,airwash
6 316222706 A B Shield,wool ,oven door
7 316236800 A B Insulation,oven door
8 316088600 A B Glass,oven door ,inner
9 316230604 A B Liner,oven door
10 316001014 A B Screw,waf hd sq ,10-24 x 1.6 ,handle ,(2)
10B 316008401 A B Washer,3/4 OD x 1/4 ID ,steel
12 316230900 A B Seal,oven door
14 316102207 A B Foil,1.5" x 29" ,aluminum ,clear
14A 3131360 A B Reflector,aluminum foil ,(2)
15 316081403 A B Bracket,glass mtg
16 316085701 A B Glass,oven door ,heat barrier
20 316248401 A B Spacer,handle ,white ,(2)
39 316248301 A B Handle,oven door ,white
52 316201003 A - Cap,door trim ,white
52 316201013 - B Cap,door trim ,white
60B 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 0.5
* 316065306 A B Plate,warning/caution
* 3203618 A B Rivet,pop
* 316021109 A B Screw,8-18 x 0.5 ,chrome
* 316021110 A B Screw,8-18 x 0.5 ,black
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 A B Screw,wafer head ,8-32T x 0.500 ,black
DOOR

08/01 10
Publication No. FEF365A
5995357802
WIRING DIAGRAM
