Frigidaire FGF376CXA User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FGF376CXASA FGF376CXA white North America
Publication No.
5995373874
020610
-EN/SERVICE /ECL
369

06/02 2
BACKGUARD

POS. NO PART NO DESCRIPTION
1 316028700 Shield,backguard ,galv ,rear wall
2 316051600 Shield,backguard ,inner
2A 316053800 Shield,backguard ,inner top
11 316083722 Trim,wrapper ,white ,textured,w/hole
15 316023108 Support,backguard ,RH
15A 316023109 Support,backguard ,LH
19 316100581 Panel,backguard ,white
20 # 316080011 Clock/Timer,slew
20A 316089306 Overlay,clock
23 316033204 Bracket,timer
24 # 316118101 Switch,oven light ,white ,rocker
36 316109513 Knob,top valve ,white
40 316009285 Panel,manifold ,white
42 316055201 Trim,vent ,chrome
56 316074907 Deflector,flue ,black
* 316001475 Wiring Harness,backguard
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021109 Screw,8-18 x 0.5 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
BACKGUARD

06/02 4
BURNER

POS. NO PART NO DESCRIPTION
1 316134501 Manifold Pipe,1
2 # 5303935184 Valve,top buner ,9K ,with mtg screws
2A # 5303935185 Valve-top burner,11K ,with mtg screws
2B # 5303935186 Valve-top burner,5K ,with mtg screws
* 316134300 Screw,10-24 ,valve mounting
3 # 316001824 Wiring Harness,w/igntr switch
4 # 316059612 Tube,burner ,red ,RF
5 # 316059613 Tube,burner ,green ,LF
6 # 316059614 Tube,burner ,natural ,RR
7 # 316059615 Tube,burner ,black ,LR
8 # 316135701 Module,spark
8* 5303289034 Wiring Harness,module/igniter
10 # 5303935025 Burner Assy,sealed ,small ,9K
10A# 5303935098 Burner Assy,sealed ,large ,11,100 BTU ,(2), includes,11,37,44A,45
10B 316010605 Burner Assy,sealed ,small ,5K
11 316011200 Ignitor,top burner ,(4) ,w/mtg bracket
13 # 316065005 Tube,3/8 ,aluminum ,rgltr to manf ,with fittings
14 # 316091706 Regulator,pressure
14* 316021104 Screw,hex ,8-18 x 3/8 ,nick ,(3) ,regulator brkt
15 316091600 Bracket,regulator
16 # 316065003 Tube,valve to regul. ,3/8
17 # 5303208499 Valve,safety ,dual
17* 08068018 Shield,wire ,safety valve
18 # 3131290 Burner,oven
19 # 5303935066 Ignitor,oven kit ,w/nut & instr
20 3131284 Baffle,oven burner
21 5303013272 Nut,hex head sems
22 # 316065002 Tube,valve to mixer
23 # 08067935 Burner,broiler
24 # 316070400 Elbow,mixer
24* 316113400 Spacer,mixer elbow
25 5303210379 Baffle,broiler
26 # 316119302 Ignitor,broiler
37 316069301 Screw,burner mtg
44 5303210090 Orifice,top burner ,9K
44A 316010804 Orifice,top burner ,large ,11K
44B 316010809 Orifice,top burner ,5K
45 316011100 Screw,self-tapping ,M3x5.8 ,ignitor mtg
46 316074700 Plate,burner tube
47 # 316039616 LP Conversion Kit,orange
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
BURNER

06/02 6
BODY

POS. NO PART NO DESCRIPTION
1 316029416 Panel,main back
2 3131314 Shield,oven top
3 316081034 Panel,bodyside ,white ,RH
3 316081035 Panel,bodyside ,white ,LH
4 316011917 Burner Box,with hole
4* 08067757 Cover Plate,burner box
5 316129200 Screw,leveling ,plastic ,with stop
6 316067902 Rack,oven
7 316007005 Hinge,oven door , (2)
8 5303300701 Panel,oven bottom
8* 316064600 Support,oven bottom
9 316081900 Pan,broiler
10 316082000 Insert,broiler pan
12 # 316027701 Switch,oven light
13 316026800 Rod,light switch
14 # 316116400 Receptacle,oven light
15 5303013071 Bulb/Lamp,oven light
16 08011086 Lens,oven light ,glass
17 316087500 Retainer,lens
18 # 316036300 Latch,door
21 3014099 Spacer,bodyside
25 5303288580 Shield,heat ,lower
28 3011813 Clip,wire ,bodyside
29 3051162 Glide,drawer ,front
30 316059200 Bracket,main top ,RH
30A 316059201 Bracket,main top ,LH
33 5303288495 Shield,rear wall
35 316116600 Gasket,flue
36 316133002 Flue
37 # 316134900 Probe,oven temp
38 316051700 Shield,heat
39 # 3202006 Cord,electric power
40 3200836 Shield,heat baffle
40* 5303288570 Screw,hd shldr sqdr ,8-18 X 1/2 ,heat shield
41 3131570 Cover,hinge cut-out
42 5303288578 Shield,bake burner
43 3131732 Screw,8-18 x 1.438 ,oven bottom
44 3131903 Bumper,door/drawer , rubber
49 3051124 Clip,spring mtg
53 5303288579 Shield,main front
53A 08067992 Shield,insulation ,front frame
55 316107800 Shield,flue
58A 316047708 Insulation,2" ,oven wrapper
58B 316218303 Insulation,oven back
58G 08067973 Insulation,main front
72 5303285692 Cover,rod end ,lt switch rod
88 316026400 Rod,auto latch
89 # 316028101 Motor,latch
170 5303935180 Anti-tip Kit,w/bracket,screw
170* 316107200 Bracket,anti-tip
170* 316112500 Template,anti-tip
170* 316116000 Screw,concrete tpg ,1.75 inch ,anti-tip brkt
* 316001632 Wiring Harness,chassis
* 316246400 Plug,button ,oven probe
* 5303305324 Paint,touch-up ,white
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
BODY

06/02 8
TOP/DRAWER

POS. NO PART NO DESCRIPTION
1 316011503 Drawer
2 5303288582 Liner,drawer ,galv steel ,front panel
4 316084405 Panel,drawer ,white
7 3051163 Glide,drawer ,rear
16 316114801 Maintop,white
20 # 316085205 Grate,gray ,(4)
21 316011308 Trim ring,gray ,small
21A 316011307 Trim ring,gray ,large
22 # 316122101 Cap,burner ,small ,gray
22A# 316098509 Cap,burner ,large ,gray
22B# 316118801 Cap-burner,simmer ,gray
48 316077401 Shield,deflector ,main top panel ,(2)
* 316089600 Spacer,drawer ,(2)
* 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
TOP/DRAWER

06/02 10
DOOR

POS. NO PART NO DESCRIPTION
3 316067804 Trim,oven door ,white
4 316089013 Glass,oven door ,white ,outer
5 316117601 Glass,door ,4mm ,airwash
6 316091404 Shield,wool
8 316117500 Glass,oven door ,heat barrier
9 316066619 Liner,oven door
10 5303280308 Screw,wafer hd sq dr ,10-24T x 2.00 ,handle mtg
10* 316008401 Washer,3/4 OD x 1/4 ID ,steel
12 # 5303131601 Seal,oven door
14 316102203 Foil,aluminum
14A 316102202 Foil,4" x 5.5" ,aluminum ,clear ,(2)
15 316081405 Bracket,glass , (2)
17 316117701 Spacer,door glass ,(2)
39 316248301 Handle,oven door ,white
52 316081301 Shield,oven door ,white ,top
* 316065306 Plate,warning/caution
* 3203618 Rivet,pop
* 316132100 Spacer,sponge pad
* 316021109 Screw,8-18 x 0.5 ,chrome
* 316021110 Screw,8-18 x 0.5 ,black
* 316021112 Screw,8-18 x 0.500 ,white
* 5303271648 Screw,wafer hd sq dr ,8-18AB x 0.5
* 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312
* 5303285179 Screw,wafer head ,8-32T x 0.500 ,black
DOOR

06/02 12
WIRING DIAGRAM
