Frigidaire FED300WC User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FED300WCW3 37854310A5013 WHITE U.S.A.
FED300WCW5 37854310A5015 WHITE U.S.A.
FED300WCD3 37854310A5033 ALMOND U.S.A.
FED300WCD5 37854310A5035 ALMOND U.S.A.
ELECTRIC - RANGE
Model No.
FED300WC
©1998 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
DROP-IN
WIRING DIAGRAM # - 318045000
OWNER’S GUIDE # - 318200805
TIMER INSTRUCTION GUIDE # - 318200104
INSTALLATION INSTR. # - 318064101
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5995315024
981118
-EN/SERVICE
377

Publication No. FED300WCW/D
5995315024
11/98 2
BACKGUARD
LAP23G0003B
28
12
54A
54A
23
14A
64
14
69
18A
54 14
54
21
102
18
36
36
36
42
36
19
20
36
24
46
46

FED300WCW/D Publication No.
5995315024
# = Functional Part 311/98
* = Non-Illustrated Part
BACKGUARD
POS. NO PART NO DESCRIPTION
12# 5303311369 AB C D Thermostat-oven
14 5303051533 AB C D Light/Lamp
14A 3051539 AB C D Light-lamp-oven indicatrice
18 5303300160 AB C D End Cap black RH
18A 5303300161 AB C D End Cap black LH
19 5303311121 AB C D Panel-control
20# 318012300 AC Clock/Timer
20# 318011401 B D Clock/Timer
21 318027800 AC Trim-backguard
21 318027803 B D Trim-backguard
23 318015001 AB C D Bracket-clock mtg
24 # 316005602 AB C D Switch-rocker
28 5303311122 AC Knob-clock
28 5303272306 B D Knob-clock
32 318016306 AB C D Knob-thermostat
36 5303299751 AB C D Knob surface unit. black
42 318106900 AC Trim-vent black
42 318106903 B D Trim-vent black
46 5308006417 AB C D Lens-light/lamp
54 # 318120501 AB C D Switch-surface unit
54A# 5303311186 AB C D Switch-surface unit
64 318112200 AB C D Plate
69 5303323134 AB C D Screw mtg 8-32 X 3/16
102 318055600 AB C D Bracket-mounting
* 5303323145 AB C D Nut
*08002868 AB C D Screw, 10-24 X ½
*08016432 AB C D Screw, 8-18 X 3/8
*5303211311 AB C D Screw, #8 X ½
*5303305528 AB C D Screw, switch mtg
A=FED300WCW (FED300WCW3)
B=FED300WCW (FED300WCW5)
C= FED300WCD (FED300WCD3)
D= FED300WCD (FED300WCD5)

FED300WCW/D Publication No.
5995315024
11/98 4
BODY
63
68
62
71
87
221
80
LAP23V005
6
67
25
83
58B
58A
10
9
127
12
70
3
114
114
1A
62
14
54 15 16
17
81
81
1
59
56
56
70
41
86
86
76
217
41
66
220
58D
4134
27
103

FED300WCW/D Publication No.
5995315024
# = Functional Part 511/98
* = Non-Illustrated Part
BODY
POS. NO PART NO DESCRIPTION
1 5303310527 AB C D Back-main
1A 5303311161 AB C D Panel-back
3 5303300143 AB C D Panel-bodyside
4318133400 AB C D Burner box
6 5303310522 AB C D Rack-oven
9 5303317977 AB C D Pan-broiler
10 5303317976 AB C D Insert-broiler pan
12 # 5301314211 AB C D Switch-light
14 5308011085 AB C D Socket-light/lamp
15 3201908 AB C D Lamp-oven light
16 3201911 AB C D Glass-oven light lens
17 5304400195 AB C D Retainer-lens
25 5303311141 AB C D Shield-heat
27 5303284616 AB C D Clip-thermo bulb
41 5303310526 AB C D Cover-hinge cutout
54 5303310514 AB C D Housing-oven light
56 318002702 A B Trim-oven front white
56 318002703 C D Trim-oven front almond
58A 5303310519 AB C D Insulation wrapper
58B 5303310516 AB C D Insulation oven back
58D 3008673 AB C D Insulation
59 5303311139 AB C D Tube-oven vent
62 # 5303310518 AB C D Terminal Block
63 5303310517 AB C D Plate-ground strap
66 # 5303310513 AB C D Element-broil
67 # 5303310512 AB C D Element-bake
68 5304403015 AB C D Support-element
70 5303300142 AB C D Shield-insulation
71 5303310515 AB C D Cover-wiring
76 318124101 AB C D Front-oven
80 5303324473 AB C D Bracket-oven
81 5303301261 AB C D Spring-oven
83 318089600 AB C D Liner-oven
86 5303310524 AB C D Channel-hinge
87 318111800 AB C D Plate-mounting
103 5303300213 A B Trim-base
103 5303300214 C D Trim-base
114 3051827 AB C D Plate-filler
127 5303310542 AB C D Adapter assy
134 5303319029 AB C D Shield rear wall
217 316042301 AB C D Warning plate
220 5304401475 AB C D Bracket
221 5304401476 AB C D Bracket
* 5303211311 AB C D Screw #8 X ½
A= FED300WCW (FED300WCW3)
B= FED300WCW (FED300WCW5)
C= FED300WCD (FED300WCD3)
D= FED300WCD (FED300WCD5)

FED300WCW/D Publication No.
5995315024
11/98 6
TOP
143
17
18
18
16
19A
93
93
93
93
27
27
15
15A
15A
15
19
19A
19
LAP23T0002A
28
28
28
28

FED300WCW/D Publication No.
5995315024
# = Functional Part 711/98
* = Non-Illustrated Part
TOP
POS. NO PART NO DESCRIPTION
15# 5303309001 A C Element-surface 2600W
15# 5308011964 B D Element-surface 2100W
15A# 5303309000 AC Element-surface 1500W
15A# 5303299749 B D Element-surface 1250W
16 5303300166 A B Main Top white
16 5303300167 C D Main Top almond
17 3051554 AB C D Rod-maintop support
18 5303305530 AB C D Bracket-hinge main top
19 318067010 AB C D Pan-surface element
19A 5303280336 AB C D Pan-surface element
27# 5303323704 AB C D Terminal block
28 5303301461 AB C D Medaillon surface element
93 318122500 AB C D Support terminal block
143 5303300148 AB C D Bracket hinge
*5303211311 AB C D Screw, #8 x ½
*5303325174 AB C D Cap screw
A= FED300WCW (FED300WCW3)
B= FED300WCW (FED300WCW5)
C= FED300WCD (FED300WCD3)
D= FED300WCD (FED300WCD5)

Publication No. FED300WCW/D
5995315024
11/98 8
DOOR
54
10
5
15
13
23
23
20
32
39
16
22
22
55
50
18
50
18
15A
9
12
20
LAP23CD004A

FED300WCW/D Publication No.
5995315024
# = Functional Part 911/98
* = Non-Illustrated Part
DOOR
POS. NO PART NO DESCRIPTION
55303310508 AB C D Glass-oven door
9 318112910 AB C D Liner-oven door
10 5303324305 AB C D Screw handle
12 318053301 AB C D Seal-oven door
13 318009026 AB Panel-oven door, white
13 318009027 C D Panel-oven door, almond
15 5303311136 AB C D Bracket-glass mtg RH
15A 5303311137 AB C D Bracket-glass mtg LH
16 5303310507 AB C D Glass-oven door
18 5303310505 AB C D Seal-rope
20 318014301 A B Spacer handle, white
20 318014302 C D Spacer handle, almond
22 5303310511 AB C D Retainer-glass
23 5303310506 AB C D Hinge
23* 3201899 AB C D Washer
32 318057202 AB C D Deflector-handle
39 316091119 A B Handle-door white
39 316091120 C D Handle-door almond
50 318144900 AB C D Strenchening glass
54 5303317175 AB Screw 8-18 X ½ white
54 5303300265 C D Screw 8-18 X ½
55 318122300 AB C D Bracket-glass
* 5303307980 AB C D Screw 8-32 X 7/16
*5303211311 AB C D Screw, #8 x ½
*08016432 AB C D Screw, 8-18 X 3/8
A= FED300WCW (FED300WCW3)
B= FED300WCW (FED300WCW5)
C= FED300WCD (FED300WCD3)
D= FED300WCD (FED300WCD5)

Publication No. FED300WCW/D
5995315024
11/98 10
WIRING DIAGRAM
318045000

Publication No. FED300WCW/D
5995315024
11/98 11
WIRING DIAGRAM
