Frigidaire Gas Range Owner's manual

All about the
Use&Care
of your
TABLE OF CONTENTS
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
Gas Range
316901220 (May 2011)
Important Safety Instructions ........................... 3-6
Features at a Glance ......................................... 7
Before Setting Oven Controls ........................... 8-9
Before Setting Surface Controls ....................10-11
Setting Surface Controls................................... 12
Oven Control Functions (540L preset LP) ............ 13
Setting Oven Controls ..................................14-24
Lower Oven Drawer .....................................25-26
Self-Cleaning ..............................................27-29
Care & Cleaning (EZ/MO) .............................30-34
Before You Call............................................35-38
Major Appliance Warranty .................... back cover

2©2011 Electrolux Home Products, Inc. All rights reserved. Printed in the USA
PRODUCT RECORD AND REGISTRATION
Contents
Serial plate location:
lower oven drawer.
Serial plate
location
Purchase date
Model number
Serial number
Record model & serial numbers here
Thankyoufor choosingFrigidaire.
This Use & Care Guide is part of our commitment to customer
satisfaction and product quality throughout the service life of
your new appliance.We view your purchase as the beginning
of a relationship. To ensure our ability to continue serving you,
please use this page to record important product information.
Registering your product with Frigidaire enhances our ability
to serve you. You can register online at
www.frigidaire.com or by dropping your Product
Registration Card in the mail.
Product Registration
Need help??
Visit the Frigidaire web site at www.frigidaire.com
Before you call for service, there are a few things you can
do to help us serve your better.
Read this Use & Care manual.
It contains instructions to help you use and maintain your
range properly.
If you received a damaged range ...
immediately contact the dealer (or builder) that sold you the
range.
Save time and money.
Check the section "Before You Call". This section helps step
you through some common problems that might occur. If you
do need service, help is only a phone call away. Call
Frigidaire Customer Services at 1-800-944-9044.
Product Registration...................................................... 2
Important Safety Instructions ............................ 3-6
Features at a Glance .............................................. 7
Before Setting Oven Controls ............................... 8-9
Removing, replacing & arranging the oven racks........... 8
Effortless™ Oven Rack system and assembly ................ 9
Before Setting Surface Controls............................ 10
Cookware material types .......................................... 10
Using and caring for the griddle (some models) .......... 11
Setting Surface Controls ....................................... 11
Setting a surface burner........................................... 11
Home canning ......................................................... 11
Oven Controls Functions ........................................ 13
Setting Oven Controls ...................................... 14-24
Setting the clock...................................................... 14
Changing between 6-Hour Energy Saving or
continuous bake mode settings ................................. 14
Setting 12 or 24 hour display mode ........................... 14
Changing oven temperature display mode .................. 15
Setting for audible or silent keypad operation ............. 15
Setting oven lock ..................................................... 15
Timer..................................................................... 16
Add a minute .......................................................... 16
Quick preheat ......................................................... 16
Bake ...................................................................... 17
Bake time ............................................................... 17
Delay start .............................................................. 18
Quick bake.............................................................. 19
Broil ....................................................................... 20
Setting pizza feature................................................ 21
Setting chicken nuggets feature ................................ 21
Setting keep warm .................................................. 21
Adjusting the oven temperature ................................ 22
Restoring to factory default settings........................... 22
Operating the oven light ........................................... 22
To set the Sabbath feature ...................................23-24
Lower Oven Drawer ......................................... 25-26
Self-Cleaning .................................................... 27-29
Care & Cleaning ............................................... 30-34
Cleaning recommendations table............................... 30
Removing & replacing the lower oven drawer............. 31
Cleaning the cooktop and surface burners ..............32-33
Replacing the oven light ........................................... 33
Removing & replacing oven door ............................... 34
Before You Call - Solutions to common problems... 35-38
Appliance Warranty ................................. back cover

3
Read all instructions before using this appliance.
Do not attempt to install or operate your appliance until you
have read the safety precautions in this manual. Safety
items throughout this manual are labeled with a WARNING
or CAUTION statement based on the risk type.
WARNING indicates a potentially hazardous
situation which, if not avoided, may result in death
or serious injury.
Save these instructions for future reference.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
IMPORTANT
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
CAUTION
IMPORTANT indicates installation, operation,
maintenance or valuable information that is not hazard
related.
Definitions
Important Safety Instructions
•Remove all tape and packaging before using the
range. Destroy the carton and plastic bags after
unpackingthe range. Neverallow children toplay with
packagingmaterial.
•ProperInstallation—Be sure your applianceis
properly installed and grounded by a qualified
technicianin accordance with the NationalFuel Gas
Code ANSI Z223.- latest edition, or in Canada CAN/
CGAB149.1,andCAN/CGAB149.2,and the National
ElectricalCode ANSI/NFPA No.70-latest edition, or
inCanada CSA Standard C22.1, CanadianElectrical
Code, Part 1, and local code requirements. Install
onlyperinstallationinstructionsprovidedintheliterature
package for this range. Ask your dealer to recommend a
qualifiedtechnician andanauthorizedrepairservice.
Know how to disconnect the power to the range at the
circuit breaker or fuse box in case of an emergency.
WARNING
Ifthe information in thismanualis not followed
exactly, a fire or explosion may result causing
property damage, personal injury or death.
FORYOURSAFETY:
— Do not store or use gasoline or other
flammablevapors and liquids inthe vicinity of
this or any other appliance.
— WHATTO DOIFYOUSMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediatelycall your gas supplierfrom a
neighbor'sphone. Follow the gassupplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, servicer or the gas
supplier.
WARNING
Tip Over Hazard
• A child or adult can tip the
rangeand be killed.
• Verify the anti-tip device has
been installed to floor or wall.
To check if the anti-tip bracket is installed properly, use
both arms and grasp the rear edge of range back.
Carefully attempt to tilt range forward. When properly
installed, the range should not tilt forward.
Refertotheanti-tipbracketinstallationinstructions
suppliedwithyour rangeforproper installation.
• Ensure the anti-tip device is re-engaged when
the range is moved to floor or wall.
• Do not operate the range without the anti-tip
device in place and engaged.
• Failure to follow these instructions can result in
death or serious burns to children and adults.
Range
leveling leg Anti-Tip
bracket

4
IMPORTANT SAFETY INSTRUCTIONS
• Do not use water or flour on grease fires — flour
may be explosive. Smother the fire with a pan lid,
or use baking soda, a dry chemical or foam-type
extinguisher.
• When heating fat or grease, watch it closely. Fat
or grease may catch fire if allowed to become too hot.
• Use dry potholders - moist or damp potholders
on hot surfaces may result in burns from steam.
Donotletpotholderstouchhotheatingelements.Do
not use a towel or other bulky cloth instead of a
potholder.
• Do not heat unopened food containers - buildup
of pressure may cause container to burst and
resultin injury.
WARNING
• Wear proper apparel—loose-fitting or hanging
garments should never be worn while using the
appliance. Donotlet clothing or otherflammable
materials contact hot surfaces.
CAUTION
For electric ignition models only: Do not attempt to
operate the range during a power failure. If the
power fails, always turn off the range. If the range is not
turned off and the power resumes, the range will begin
to operate again. Once the power resumes, reset the
clockandovenfunction.
IMPORTANT
CAUTION
• Do not store items of interest to children in the
cabinets above a range or on the backguard of
the range. Children climbing on the range to reach
items could be seriously injured.
• Do not touch surface burners, areas near
these burners, oven burners or interior
surfaces of the oven. Both surface and oven
burners may be hot even though flames are not
visible. Areas near surface burners may become hot
enough to cause burns. During and after use, do not
touch, or let clothing or other flammable materials
touch these areas until they have had sufficient time
to cool. Among these areas are the cooktop, surfaces
facingthe cooktop,theoven ventopeningsand
surfaces near these openings, oven door and
window.
• Stepping, leaning or sitting on the door or
drawers of a range can result in serious injuries
and also cause damage to the appliance. DO NOT
allow children to climb or play around the range. The
weight of a child on an open oven door may cause the
range to tip, resulting in serious burns or other injury.
• NEVER use this appliance as a space heater to
heat or warm the room. Doing so may result in
carbonmonoxidepoisoning.
• NEVER cover any slots, holes or passages in the
oven bottom or cover an entire rack with
materialssuchasaluminumfoil.Doingsoblocksair
flow through the oven and may cause carbon
monoxidepoisoning.Aluminumfoilliningsmaytrap
heat, causing a fire hazard.
• Storage in or on appliance — to avoid a fire
hazard,flammablematerialsshould notbestored
in an oven, near surface units or in the storage
drawer, warmer drawer or lower oven. This
includespaper,plasticandclothitems,suchas
cookbooks, plasticware and towels, as well as flammable
liquids.Donotstoreexplosives,suchasaerosolcans,on
or near the range.
• DONOTLEAVECHILDRENALONE—toavoidinjuries
or burns children should not be left alone or
unattended in the area where the range is in use.
They should never be allowed to sit or stand on any part
of the range including the storage drawer, lower broiler
drawer, lower oven or warmer drawer.
• Be sure to always have an appropriate foam-type fire
extinguisher available,visibleandeasilyaccessible
locatedneartheappliance.
• Never modify or alter the construction of a range
by removing the leveling legs, panels, wire covers,
anti-tip bracket/screws, or any other part of the
range.
• Remove the oven door from any unused range if it
is to be stored or discarded.
• User servicing — Do not repair or replace any part
oftheappliance unless specifically recommended
in the manuals. Allotherservicing should bedoneonly
by a qualified technician. This may reduce the risk of
personal injury and damage to the range.

5
IMPORTANT SAFETY INSTRUCTIONS
Important Safety Notice
The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth
defects or other reproductive harm, and requires
businesses to warn customers of potential exposure to such
substances.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
• Use care when opening oven door , warmer
drawer or lower oven door—Stand to the side of the
range when opening the door of a hot oven. Let hot air or
steam escape before you remove or replace food in the
oven.
• Keep Oven Vent Ducts Unobstructed. The oven vent
is located below the backguard. Touching the surfaces in
this area when the oven is operating may cause severe
burns. Also, do not place plastic or heat-sensitive items
on or near the oven vent. These items could melt or
ignite.
• Placement of Oven Racks. Always place oven racks in
desired location while oven is cool. If rack must be
moved while oven is hot use extreme caution. Use
potholders and grasp the rack with both hands to
reposition.Donotletpotholderscontactthehotheating
elements in the oven. Remove all utensils from the rack
beforemoving.
• Do not use the broiler pan without its insert. The
broiler pan and its insert allow dripping fat to drain and
be kept away from the high heat of the broiler.
• Do not cover the broiler insert with aluminum foil.
Exposed fat and grease could ignite.
•Protective liners—Do not use aluminum foil to line the
ovenbottom. Only usealuminum foil asrecommended in
thismanual. Improper installationofthese linersmay
result in risk of electric shock, or fire.
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
• Know which knob controls each surface burner.
Place a pan of food on the burner before turning it on,
and turn the burner off before removing the pan.
• Always turn knob to the full LITE position when
igniting top burners. Visuallycheckthatburnerhaslit.
Then adjust the flame so it does not extend beyond the
edgeof the utensil.
• Utensil handles should be turned inward and not
extend over adjacent surface burners—To reduce
the risk of burns, ignition of flammable materials, and
spillageduetounintentionalcontactwiththeutensil,the
handle of the utensil should be positioned so that it is
turnedinward,anddoes not extend over adjacent
surfaceburners.
• Never leave surface burners unattended at high
heat settings—Boiloverscause smokingand greasy
spillovers that may ignite, or a pan that has boiled dry
may melt.
•Glazed cooking utensils—Onlycertaintypesofglass,
glass/ceramic, ceramic, earthenware, or other glazed
utensils are suitable for cook top service without breaking
duetothe sudden change in temperature.Checkthe
manufacturer’srecommendationsforcooktopuse.
• When flaming foods under a ventilating hood, turn
the fan on.
• Air curtain or other overhead range hoods, which
operate by blowing a downward air flow on to a range,
shall not be used in conjunction with gas ranges other
thanwhenthehoodandrangehavebeendesigned,
testedandlistedby an independent test laboratoryfor
useincombination with each other.
WARNING
Use Proper Flame Size—Adjustflame sizeso itdoes
not extend beyond the edge of the utensil. The use of
undersized utensils will expose a portion of the burner
flame to direct contact and may result in ignition of
clothing. Proper relationship of utensil to flame will also
improveefficiency.

6
This appliance is factory preset to operate using LP/
Propane Gas fuel type ONLY.Do not attempttoconvert
tothisappliance to NaturalGas.
Gas Conversion
IMPORTANTINSTRUCTIONSFOR CLEANING
YOUR RANGE
•Clean the range regularly to keep all parts free of
grease that could catch fire. Pay particular attention
to the area around each surface burner. Do not allow
greasetoaccumulate.
• Kitchen cleaners and aerosols—Always follow the
manufacturer’srecommended directions for use.
Be aware that excess residue from cleaners and aerosols
mayignitecausingdamageandinjury.
•Clean ventilating hoods frequently—Grease should
not be allowed to accumulate on the hood or filter.
Followthemanufacturer’sinstructionsforcleaninghoods.
• Clean in the self-cleaning cycle only the parts
listed in this Use & Care Manual. Beforeself-cleaning
the oven, remove the broiler pan and any utensils or
foodsfrom theoven.
• Do not use oven cleaners—No commercial oven
cleanerorovenlinerprotectivecoatingofanykindshould
be used in or around any part of the oven.
• Do not clean door gasket—The door gasket is
essential for a good seal. Care should be taken not to
rub, damage or move the gasket.
•The health of some birds is extremely sensitive to the
fumesgivenoff during theself-cleaningcycle of any
range.Movebirds toanotherwell-ventilated room.
SELF-CLEANING OVENS
WARNING
• Do not touch the oven during the self-clean cycle.
•Keep children away from oven during self-clean cycle.
•Failure to follow these instructions can result in burns.
Personal injury or death from electrical shock may occur if
the range is not installed by a qualified installer or
electrician. Anyadditions, changesorconversions
required in order for this appliance to satisfactorily meet
theapplicationneedsmust be made by a qualified
technician.
WARNING
WARNING
SeetheINSTALLATIONINSTRUCTIONS packagedwiththis
rangeforcompleteinstallationandgroundinginstructions.
Grounding Instructions
Do not under any
circumstance, cut,
remove, or bypass
the grounding
prong.
Power supply cord
with 3-prong
grounding plug.
Grounding type
wall receptacle
Avoid fire hazard or electrical shock. Do not use
an adapter plug, an extension cord, or remove
groundingprong from electricalpower cord.
Failure to follow this warning can cause serious
injury, fire or death.
Thisapplianceisequippedwitha3-prong grounding plug
foryourprotection against shockhazardand should be
pluggeddirectlyintoaproperlygroundedreceptacle.DO
NOT cutorremovethegroundingprongfromthisplug.
For personal safety, the range must be properly grounded.
For maximum safety, the power cord must be plugged into
an electrical outlet that is correctly polarized and properly
grounded.
If a 2-prong wall receptacle is the only available outlet, it is
thepersonalresponsibilityof the consumer to have it
replaced with a properly grounded 3-prong wall receptacle
installedbyaqualifiedelectrician.
IMPORTANT SAFETY INSTRUCTIONS

7
Your gas range features include:
1. Electronic oven control with timer.
2. Bake-n-Warm™ lower oven cooking control & indicator light.
3. Left front burner valve and control knob.
4. Left rear burner valve and control knob.
5. Center burner valve and control knob (some models).
6. Right front burner valve and control knob.
7. Right rear burner valve and control knob..
8. Automatic oven light switch (some models).
9. Self-clean oven door latch mechanism.
10. Oven interior light with removable cover.
11. Self-cleaning oven interior.
12. Quick bake fan (some models)
13. Adjustable interior oven rack(s). Effortless Oven Rack™
system (some models; not shown).
FEATURES AT A GLANCE
1
2
3456
21
7
20
10
8
13
12
16
15
17
19
22
23
29
14
11
14. Griddle grate (some models).
15. Full width oven door with window.
16. Large 1-piece oven door handle.
17. Bake-n-Warm™ lower oven and drawer
handle.
18. Leveling legs and anti-tip bracket
(included).
19. Easy to clean upswept cooktop.
20. Burner grates (colors vary with model).
21. Center burner grate.
22. LP gas simmer burner (some models).
23. LP gas standard size burner (some models).
24. LP gas center or accent burner (some
models).
25. 12,000 BTU LP gas burner (some models).
26. 14,000 or 16,000 BTU LP gas burner (some
models).
27. Broil pan (some models).
28. Broil pan insert (some models).
29. Bake-n-Warm™ lower oven rack.
9
25
23
24
27
23
25
26
23
28
26
Be sure to visit us online at
www.frigidaire.com
for a complete line of accessories.
Note: The features shown for your
appliancemayvaryaccordingtomodel
type & color.
18
20

8
BEFORE SETTING OVEN CONTROLS
Types of oven racksOven vent location
The oven vent is located below the control panel (See
Fig. 1). When the oven is on, warm air passes through this
vent. The oven vent is necessary for proper air circulation
and the best baking results. Do not block the oven vent.
Fig. 1
Recommended rack positions by food type
Food type Position
Broilingmeats See broil
Cookies, cakes, pies, biscuits & muffins 3 or 4
Frozen pies, angel food cake, yeast, bread
and casseroles 1 or 2
Small cuts of meat or poultry 1 or 2
Turkey, roast or ham 1
flat
oven rack
flat handle
oven rack
bottom
oven rack
offset
oven rack
The flat oven rack or flat handle oven rack (some
models) may be used for most cooking needs. The half
rack (some models) design comes with a removable
section that allows for taller cooking utensils. The offset
oven rack (some models) is designed to place the base of
the rack about 1/2 of a rack position lower than normal.
Thisrackdesign provides several additionalpossible
positionsbetweenthestandardpositions.Tomaximize
oven cooking space place the bottom oven rack (some
models) in the lowest rack position for baking or roasting
large cuts of meat. The Effortless™ Oven Rack (some
models) is described later in this section.
Removing, replacing &
arranging racks
To remove - pull the rack
forwarduntilitstops.Liftup front
of rack and slide out.
To replace - fit the rack onto the
guides on the oven walls. Tilt the
front of the rack upward and
slide the rack back into place.
Arranging - always arrange the
oven racks when the oven is cool
(prior to operating the oven).
half oven
rack
Air circulation in the oven
For best baking results allow 2-4" (5-10 cm) around the
cookware for proper air circulation and be sure pans and
cookware do not touch each other, the oven door, sides or
back of the oven cavity. Hot air must be able to circulate
around the pans and cookware in the oven for even heat to
reacharoundthefood.
Fig. 2
oven vent location
Always use oven mitts to protect hands from possible
burnswhenusing the oven or cooktop. Theoven,oven
racks and cooktop will become very hot.
CAUTION
Do not remove or attempt to arrange oven racks with
cookware still on the racks. To avoid damaging cookware
or spilling food items, always remove any cookware first.
IMPORTANT
2
3
4
5
6
1
Baking layer cakes with 1 or 2 oven racks
For best results when baking cakes using 2 oven racks,
place cookware on rack positions 2 & 5 (See Fig. 2). For
best results when using a single oven flat rack, place
cookware on rack positions 2, 3 or 4.

9
Effortless™ Oven Rack system (some models)
Some models are equipped with a special oven rack system
thatautomaticallypartiallyextendsthe ovenrackfromthe
interior oven glides to assist in easier access to your food
items. This feature works whenever the oven door is
openedorclosed.
To assemble the Effortless™ Oven Rack system:
1. Locate all required parts. You will need the supplied
oven rack (Effortless™ Oven Rack is a flat rack with a
special dark coating on the left and right rack
sides) and the 2 supplied chrome connector arms.
2. Open the oven door. Be sure the oven is completely
coolbeforeproceeding.
3. Place the oven rack in positions 2, 3 or 4 only (see
previouspage to verifypositions).Be sure therack
connector brackets are at the rear of the range and
pointing towards oven bottom (See Fig. 2).
4. Assemble one connector arm at a time. With the oven
door open and the oven rack in place, install one end of
the connector arm to the hole in the door connector
bracket (Fig. 1) and the other end in the hole in the
rack connector bracket (Fig. 2 and as in Fig. 3). The
oven rack may need to be adjusted in or out in the rack
positiontomatch the length oftheconnector arm.
5. While holding the connector arm in place, twist the
connector arm so the ends of the connector arm point
upwards (See Figs. 4 & 5). The connector arm should
nowbe lockedintoposition.
6. Repeat steps 4 and 5 for the other connector arm.
7. Once both connector arms are properly in place, be
suretotestthe oven rack operation by gently closing
the oven door. The oven rack should move in and out of
the oven freely when the door is opened or closed.
Fig. 6 - Effortless™ Oven Rack after assembly
BEFORE SETTING OVEN CONTROLS
left and right
door connector
brackets
with connector arm ends
shown in locked position
(pointing upwards)
connector
arm
connector
arm
Fig. 5
door
connector
bracket
rack connector
bracket
connector
arm
connector
arm oven
rack
open oven
door
Fig. 2
Fig. 1
Fig. 3 - assembly
of the Effortless™
Oven Rack
Fig. 4
IMPORTANT
CAUTION
Never pick up hot oven rack parts. Make sure the
oven and oven racks are COMPLETLY cool and safe to
touchbeforeattempting to assemble ordisassemblethe
Effortless™OvenRack.
IMPORTANT
Remove ALL oven racks and accessories before
starting a self-clean cycle. If the oven racks are left in
theovenduringself-clean, the glide ability of the
Effortless™ Oven Rack system will be damaged and will
cause oven racks to loose their shiny finish. Remove ALL
ovenracksand clean accordingtoinstructions providedin
the Care & Cleaning section of this manual.
• Only the Effortless™ Oven Rack system should
be used in oven rack position 2. Placing ANY other
rack in oven rack position 2 will prevent the oven
door from fully closing andmay damagetheoven
door,oven cavity orthe door connectorbrackets.
• If the rack system is not assembled with the connector
arms the Effortless™ Oven rack may be used in oven
rack positions 2 thru 6. Do not attempt to use the
Effortless™Ovenrackinrackposition1.

10
BEFORE SETTING SURFACE CONTROLS
The size and type of utensil used, the amount and type
offoodbeingcookedwillinfluence the settings needed to
obtainthebestcookingresults.
Use quality cookware in good condition
Fig. 2
Set proper burner flame size
For most cooking; startonthehighestsettingandthenturn
to a lower setting to complete the process. Use the
recommendationsbelow asa guidefordetermining proper
flame size for various types of cooking (Fig. 2)
For deep fat frying; use a thermometer and adjust the
surfaceknobaccordingly. If the fat istoocool, the food will
absorb the fat and be greasy. If the fat is too hot, the food will
brownsoquicklythatthecenterwillbeundercooked.Donot
attempt to deep fat fry too much food at once as the food will
neitherbrownorcookproperly.
Flamesize* Typeofcooking
Highflame Startmostfoods;bringwatertoaboil;
panbroiling.
Mediumflame Maintain a slow boil; thicken sauces,
gravies;steaming.
Low flame Keepfoodscooking;poach;stewing.
Neverextendtheflamebeyondtheouteredge ofthe
cookingutensil. Ahigher flamewastes energy,and
increases your risk of being burned by the flame.
*These settings are based for medium-weight metal or
aluminumpanswithlids.Settingsmayvarywhenusing
othertypes ofpans.
Thecoloroftheflameisthekeytoproperburneradjustment.
Agood flameis clear,blue andhardlyvisibleinawell-lighted
room.Eachconeofflameshouldbesteadyandsharp.Adjust
or clean burner if flame is yellow-orange.
CAUTION
Correct flame
setting
Incorrect
flame setting
CAUTION
IMPORTANT
Do not place aluminum foil, or ANY material that
can melt on the range cooktop. If these items melt
theymaydamagethecooktop.
Fig. 1
NOTE
Cookware material types
The most popular materials available are:
Aluminum - Excellentheatconductor.Sometypesoffood
will cause it to darken (Anodized aluminum cookware
resistsstaining &pitting).
Copper - Excellentheatconductor but discolorseasily.
Stainless - Slow heat conductor with uneven cooking
results. Is durable, easy to clean and resists staining.
Cast Iron - A slow heat conductor however will retain heat
verywell.Cooks evenly oncecookingtemperature is
reached.
Porcelain-enamel on metal - Heatingcharacteristicswill
varydepending onbasematerial.
Glass - Slowheatconductor.
For the best possible
cookingresultswhenusing
the cooktop,alwaysuse
qualitycookwareingood
condition.Pansshouldhave
flatbottomsthat sit level
on the burner grate. Before
usingcookware,checkfor
flatness by rotating a ruler
acrossthebottomofthe
cookware (Fig. 1).
Donotplaceflammable itemssuchasplasticwrappings,
spoon holders or plastic salt and pepper shakers on the
cooktop when it is in use.These items could melt or ignite.
Potholders,towelsor wooden spoonscouldcatch fire if
placedtoo closetotherangecooktop.

11
To prevent flare-ups and avoid creation of harmful
by-products, do not use the cooktop without all burner
caps properly installed to insure proper ignition and gas
flame size.
WARNING
CAUTION
ToavoidpossibleburnsDO NOT touchburnercapsor
surface burner grates after using any of the surface
burners. The surface burner grates, caps, and areas
around them may still be very hot. Providesufficient
time for these areas and the parts to completely cool
beforehandling.
Fig. 1 - correct burner cap
placement
Be sure to review the Care & Cleaning section for
complete detailed information about cleaning the burner
caps and proper burner cap placement.
Using the griddle (some models)
Before first use:
•Wash griddle in hot soapy water.
•Rinse and dry completely.
After each use:
•To prevent possible rusting, store in a dry place and keep
uncovered.
•After each use, clean with a stiff brush and hot water
only, then rinse.
•Dry immediately.
•Do not clean griddle in the dishwasher.
Using the griddle:
Remove the center burner grate (some models) and
carefully replace with the griddle.
For best results, preheat the griddle for 5 minutes on
medium or a medium low setting. Slow preheating
provides more even heat distribution during the cooking
process. Do not preheat the griddle on Hi setting.
Preheating using a Hi burner setting may warp the griddle
and prevent even heat distribution.
Fig. 2 - incorrect burner cap
placement
Visually check for proper burner cap placement before
operating any of the surface burners (See Fig.1).
Check for proper burner cap placement
If any of the surface burner caps appears to be resting
unevenly, not centered or appears unlevel on the burner
head (Fig. 2), be sure to correct the burner cap position on
the burner head before starting the surface burner.
BEFORE SETTING SURFACE CONTROLS
Home canning
Be sure to review all the following recommendations when
home canning using your appliance.
• Use only quality flat bottom canners when home canning.
Use a straight-edge to check canner bottom.
• Start with hot tap water to bring water to boil more
quickly.
•Use the highest heat seating when first bringing the water
to a boil. Once boiling is achieved, reduce heat to lowest
possible setting to maintain that boil.
•When using two canners at the same time, stagger the
canners on the left and right sides of the cooktop. This
will help distribute the heat generated more evenly.
Be sure to review the latest online information for home
canning. Some suggestions might be the U.S. Department
of Agriculture Food Safety and Inspection Service or the
National Center for Home Food Preservation (NCHFP).

12
SETTING SURFACE CONTROLS
Fig. 1
IMPORTANT
Setting surface controls
The ability to heat food quicker and in larger volumes
increases as the burner size increases. Your gas appliance
may be equipped with many different sized surface burners.
It is important to select cookware that is suitable for the
amount and type of food being prepared. Select a burner
and flame size appropriate for the cookware size.
The standard size burner or burners may be used for most
surfacecookingneeds.Usethesmallersimmer burner
(some models) when simmering delicate sauces, etc.
The larger quick boil (some models) burner or burners are
best when used to bring large quantities of liquid to
temperatureorwhen heating larger quantities offood.
Setting a surface burner:
1. Place cooking utensil on center of surface burner grate.
Be sure the cooking utensil rests stable on the burner
grate.
2. Push the desired surface control knob in and turn
counterclockwise outofthe OFFposition(Fig. 1).
3. Release the surface control knob and rotate to the lite
position.Visuallycheckthat the burner has a steady
gas flame.
4. Once the surface burner has a flame, push the surface
controlknobinandturncounterclockwise tothe
desired flame size setting. Use the knob markings and
adjust the flame as needed.
Do not placeflammable items suchasplasticwrappings,
spoon holders or plastic salt and pepper shakers on the
cooktop when it is in use.These items could melt or ignite.
Potholders,towelsor wooden spoonscouldcatch fire if
placedtoo closetotherangecooktop.
CAUTION
• DO NOT cook withasurfacecontrol knob leftinthelite
position.Theelectronicignitor will continue to spark.
Turncontrolknob out oflite position andadjustthe
flame size.
• Do not place aluminum foil, or ANY material that
can melt on the range cooktop. If items melt the
they may permanently damage the appearance of the
cooktop.
NOTES
•Whensettingasurfacecontrolknobtothelite position,all
theelectronicsurfaceignitorswillsparkatthesametime.
However, only the surface burner you are setting will
ignite.
•In the event of an electrical power outage, the surface
burners may be lit manually. To light a surface burner,
hold a lit match to the burner head, then slowly turn
the surfacecontrol knob to lite.Once the burner
ignites, push inand turn knobout of lite then to the
desiredflamesetting.Usecautionwhenlighting
surfaceburnersmanually.

13
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
For satisfactory use of your oven, become familiar with the various pad functions of the oven as described below.
OVEN CONTROL FUNCTIONS
0 thr 9 number
keypads — Use
to enter
temperature and
times.
timer on /off
— Use to set
or cancel the
minute timer.
broil —
Use to set
broil
feature.
bake —Use to
set the bake
feature.
delay start — Use with
bake, quick bake and
self-clean features to
program a delayed timed
bake or delayed self-
cleaning cycle.
cancel — Use to
cancel any oven
mode previously
entered except
the oven lockout,
time of day &
minute timer.
Press cancel to
stop cooking.
start — Use
to start all
oven
features
(not used
with oven
light).
oven light
—Use to turn
the oven
light ON and
OFF.
quick preheat
— Use to
quickly preheat
the oven.
keep warm —
Use to set the
keep warm
feature.
quick bake — Use
to set the quick
bake convection
feature.
self-clean — Use to
set a 2, 3 or 4 hour
(some models) self-
clean cycle.
oven lock —
Use to activate
oven lock
setting.
set clock pad—
Use to set the
time of day.
bake time — Use
to enter the
length of baking
time needed.
chicken nuggets —
Use to set the
chicken nuggets
feature.
pizza — Use
to set the
pizza
feature.
add a min pad— Use
to quickly add a minute
to the timer.
Minimum & maximum
control settings
All of the features listed have
minimum and maximum time or
temperaturesettingsthat maybe
entered into the control. An entry
acceptance tone (1 beep) will
sound each time a keypad is
touched(thelockkeypadisdelayed
3seconds).
Feature
quickpreheattemperature
baketemperature
broiltemperature
timer
bake time
delaystart
self-clean time
quickbaketemperature
Min.temp. /time
170°F / 77°C
170°F / 77°C
400°F / 205°C
1min.
1min.
1min.
2hours
300°F / 149°C
Max.temp./time
550°F / 288°C
550°F / 288°C
550°F / 288°C
11 hrs., 59 mins.
6hours
11 hrs., 59 mins.
4hours
550°F / 288°C
An entry error tone (3 short beeps) will sound if the entry of the temperature or time is below the minimum or above the
maximumsettingsforthefeature.

14
SETTING OVEN CONTROLS
Fig. 2 Fig. 3
Setting the clock
When the appliance is powered up for the first time or when
theelectricsupplytotheappliancehasbeen interrupted,the
displaywill flash "12:00"(Fig. 1).
Changing between 6-Hour Energy Saving
or continuous bake mode settings
The oven control is factory preset with to the 6 Hour Energy
Saving mode that will automatically turn the oven off after 6
hours. The control may also be programmed to override
thisfeaturetocontinuouslybake.
To switch between 6-Hour Energy Saving or
continousbakemodes:
Step Press
1. Press and hold timer on •off
for 6 seconds.
2. Pressself-clean
to toggle between "6 Hr OFF"
(Fig. 2) or "StAY On" (Fig. 3)
andreleasekeypad.
3. Press start to accept.
NOTES
•Be sure to set the clock with the correct time of day
before using the oven.
•The clock cannot be adjusted when the oven is active
with any cooking function or during self-clean.
•The clock may be reviewed when the time is active by
pressing the set clock keypad once.
To set the clock for 1:30:
Step Press
1. Press set clock.
2. Enter 1 3 0.
3. Press start to accept.
Fig. 1
Setting 12 or 24 hour display mode
The oven control is factory preset to display the time of day
with a 12 hour clock. This setting may be changed to
provide the time of day with a 24 hour clock.
To set 12 or 24 hour display mode:
Step Press
1. Press and hold set clock
for 6 seconds.
2. Pressself-clean
to toggle between "12 Hr dAY" or
"24HrdAY"displaymodes
(See Figs. 4 & 5) and release
keypadwhenthemode you prefer
isdisplayed.
3. Press start to accept.
Changing between the 6-Hour Energy Saving or
continuous bake mode will not change how the cooktop
controls operate.
NOTE
Fig. 4 Fig. 5

15
SETTING OVEN CONTROLS
Changing oven temperature display mode
The oven control is preset to display temperatures in
Fahrenheit (°F). The display may be changed to provide
either Fahrenheit or Celsius (°C) temperatures.
To change the temperature display mode:
Step Press
1. Pressandhold broil for
6 seconds.
2. Pressself-clean to toggle
between"FAhrnht" or
"CELSIUS"temperaturedisplay
modes (Figs. 1 & 2) and release
keypadwhenthemode you prefer
isdisplayed.
3. Press start to accept.
Fig. 1 Fig. 2
To switch between audible or silent keypad
operationmodes:
Step Press
1. Press and hold
delay start for 6 seconds.
2. Pressself-clean
totoggle between "bEEPOn"(Fig. 3)
or "bEEP OFF" (Fig. 4) . Release keypad
when the mode you prefer is displayed.
3. Press start to accept.
Setting for audible or silent keypad
operation
Normally a beep will sound each time a keypad is pressed.
If desired, the control may be set for silent keypad
operation.
NOTE
The temperature display mode option cannot be changed
when the oven is active with any cooking function or
during self-clean.
Fig. 3 Fig. 4
Fig. 5
When the control is set for silent keypad operation the
timer, preheat and any end of cycle or error tone alerts
will remain audible.
Setting oven lock
The control may be programmed to lock the oven door and
locktheovencontrolkeypadoperations.
To activate the oven lock feature:
Step Press
Pressandholdlock keypad for 3 seconds.
"door Loc" will appear in the display until
theoven dooris completelylocked.
Press andhold lock keypad for
3 seconds. Once the oven door has
unlocked the "door Loc" message
will no longer display (See Fig.5).
To cancel the oven lock feature:
Step Press
NOTE
NOTES
• To avoid possible damage to the oven door latching
mechanism, do not attempt to force open the oven door
whenever the door Loc message is displayed.
• If a control keypad is pressed when oven lock is active,
the oven control may produce an error tone (triple
beep) indicating the keypad action requested is not
available when the oven lock feature is active.

16
SETTING OVEN CONTROLS
Add a minute
Use the add a minute feature to set additional minutes to
the timer. When the timer is active, each press of the
keypadwilladdone additional minute to the timer.
To add two additional minutes to the timer:
Step Press
Press add a minute keypad twice.
Step Press
1. Press timer on•off.
2. Enter5 minutes.
3. Press start to activate.
NOTES
•The timer does not start or stop the cooking
process. The timer may be started alone or with any
other active oven feature.
•The timer will display hours and minutes until 1 hour
remains. When less than 1 hour remains, the display
will count down in minutes and seconds. Once the timer
has less than 1 minute remaining only seconds will
display.
•If both the oven and timer are active, the timer
information will display by default. To momentarily
display information for any other active oven feature,
press the keypad once for the active feature.
To set the timer for 5 minutes:
NOTE
If the add a minute keypad is pressed once when the
timer is inactive, the timer will activate and start counting
downfrom oneminute.
The timer helps keep track of cooking times without
interferring with the cooking process. The timer may be set
for 1 minute up to 11 hours and 59 minutes.
Timer
Whenthetimer countdown expires, "End" willappearinthe
display and alert the user with 3 beeps 1 second apart. The
alert will continue until the timer on•off keypadis pressed.
Quick preheat
Use this feature to quickly preheat the oven. For best
results use when baking with a single rack only. A
reminder tone will sound indicating when to place the food
in the oven. Quick preheat may be set for 170°F (77°C) to
550°F(288°C). Thequick preheatdefaultoventemperature
is350°F(177°C).
1. Pressquick preheat.
2. Press start.
To set quick preheat using the default temperature
temperature of 350°F:
Step Press
Once the oven has fully preheated, the quick preheat
feature will perform like bake and continue to bake until
cancelled.
IMPORTANT
To set quick preheat with oven temperature of
325°F:
Step Press
1. Pressquick preheat.
2. Enter 3 2 5.
3. Press start.
NOTE
bake time and delay start settings may be added to
quick preheat.
Always use pot holders or oven mitts when working with
a hot oven. When cooking, the oven, oven racks and
cooktop will become hot enough to cause burns.
To stop quick preheat at any time press cancel.
To stop quick preheat at any time press cancel.
CAUTION

17
Bake
Use the bake feature to prepare most food items when the
recipe calls for normal baking. A reminder tone will sound
once the oven finishes preheating. Bake may be set for any
temperature from 170°F (77°C) to 550°F (288°C). If bake is
programmed with no temperature, the control will use the
defaultsettingof350°F(177°C).
NOTES
Dark or dull pans absorb more heat than shiny bakeware
resulting in dark or overbrowning of foods. It may be
necessary to reduce the oven temperature or cook time
to prevent overbrowning of some foods. Dark pans are
recommended for pies. Shiny pans are recommended
for cakes, cookies and muffins.
IMPORTANT
Always use pot holders or oven mitts when working with
a hot oven. When cooking, the oven interior, oven racks
and cooktop will become hot enough to cause burns.
CAUTION
•If bake is active without bake time instructions and
bake is not cancelled, the oven will continue to bake for
6 hours before automatically turning off.
•A bake time instruction may be be added even when
the bake feature is already active.
To set bake with oven temperature of 425°F:
Step Press
1. Pressbake.
2. Enter 4 2 5.
3. Press start.
To stop bake at any time press cancel.
Bake time
A bake time setting may be added to most oven baking
features. Use the bake time setting to start the oven
immediatelyandtoturn off automatically after the set bake
timerunsout.
NOTES
1. Pressbake time.
2. Enter 3 0 minutes.
3. Press start.
4. Pressbake.
5. Press start to activate.
Toset bake usingthedefaulttemperature of 350°Fand
to stop baking after 30 minutes:
Step Press
When the set bake time runs out:
1. "End" will appear in the display window and the oven
willshut-offautomatically.
2. The control will beep 3 times every 30 seconds as a
reminder untilthe cancel keypadispressed.
FOOD POISONINGHAZARD. Donotletfoodsitformore
than one hour before or after cooking. Doing so can result
infoodpoisoning or sickness.
•The maximum bake time setting is 6 hours.
•Press the keypad once to momentarily display
the remaining bake time.
•When bake is active with bake time settings you may
remove the bake time instructions at anytime by setting
a new bake time of 0:00.
•bake time settings cannot be added to the broil feature
or to a self-clean cycle.
• bake time settings may be added to quick preheat
or the quick bake feature.
To stop bake at any time presscancel.
WARNING
SETTING OVEN CONTROLS

18
SETTING OVEN CONTROLS
When the set bake time runs out:
1. "End" will appear in the display window and the oven
will shut-off automatically (See Fig. 2).
2. The control will beep 3 times every 30 seconds as a
reminderuntil thecancel keypadis pressed.
To program the oven for delay start and to shut-off
automatically(example for baking at375°Ffor 50
minutes and to start at 5:30):
Step Press
NOTES
FOODPOISONING HAZARD. Donotletfoodsitformore
than one hour before or after cooking. Doing so can result
infoodpoisoning or sickness.
WARNING
Fig. 1 Fig. 2
1. Pressbake time.
2. Enter50 mintues.
3. Press start.
4. Press delay start (See Fig. 1).
5. Enter530.
6. Press start.
7. Pressbake.
8. Enter375.
9. Press start to activate.
•A delay start setting may be set with self-clean. The
self-clean feature will not accept bake time instructions.
Refer to the self-clean section for details on how to
select different self-clean cycle times.
•The delay start setting may be added to the quick
preheat, or quick bake features. A delay start setting
cannot be added to the broil feature.
•Once the delay start feature has started the cooking
process, press the bake time keypad once to display
any bake time remaining.
Delay start
Use this keypad to add delay start time instructions for most
timed cooking features or with the self-clean feature.
To stop baking with a delay start setting at any time
presscancel.
Use caution when setting bake time or delay start
instructions. Foods that can easily spoil such as milk,
eggs, fish, meat or poultry, should be chilled in the
refrigeratorfirst.Even when chilled,theyshouldnot stand
in the oven for more than 1 hour before cooking begins,
andshouldberemovedpromptlywhenfinishedcooking.
CAUTION

19
Quick bake uses a fan to circulate theoven'sheat
uniformlyandcontinuouslyaroundtheoven.Heatedair
flows around the food from all sides, sealing in juices and
flavors. Breads and pastry brown more evenly.
Thisimprovedheat distribution allowsforfast,even cooking
and browning results. It also gives better baking results
when using two oven racks at the same time.
Most foods baked in a standard oven may be cooked faster
andmoreevenly when usingthequick bake feature.
Suggestions for quick bake:
1. For optimum cooking results it is recommended to
preheattheovenwhenbaking foods such as cookies,
biscuitsandbreads.
2. Reduce oven temperature 25°F from recipe’s
recommendedoventemperature.Followtheremainder
oftherecipe’s instructionsusingthe minimum
recommendedcooktime.
3. When using 2 oven racks at the same time, place in
positions 2 & 5 for best results (Fig. 1).
Quick bake
Benefits of the quick bake feature
— Foods may cook up to 25 to 30% faster, saving time and
energy.
—Multiplerackbaking.
— No special pans or bakeware needed.
When roasting
1. Preheatingisnot necessary whenroastingfoods using
quickbake.
2. Since quick bake cooks food faster,reduce the cook
time by 25% from the recommended cook time of your
recipe. Check the food at this time. If necessary,
increase cook time until the desired doneness is
obtained.
3. Do not cover foods when dry roasting - this will keep
the air from circulating around the food.
1. Pressquickbake.
2. Press start.
To set quick bake with a default oven set
temperatureof 350°F:
Step Press
Setting quick bake
The oven may be programmed to quick bake at any
temperature from 300°F to 550°F (147°C to 287°C). The
factorypresetquickbaketemperatureis350°F(177°C).
To set quick bake for oven temperature of 425°F:
Step Press
1. Pressquickbake.
2. Enter425.
3. Press start.
SETTING OVEN CONTROLS
Fig. 1
2
3
4
5
1
•When baking layer cakes, use the bake feature to
obtainthebest possible results.
• Whenusing thequick bake feature, any cooktime
reductionsused may needtovary dependingonthe
ovensettemperature.
•The quick bake fan will not start until 6 minutes after
setting the quick bake feature.
•If the oven door is opened when the quick bake feature
is active, the fan will stop rotating until the oven door is
closed.
NOTES
To stop quick bake at any time press cancel.
To stop quick bake at any time press cancel.
6

20
SETTING OVEN CONTROLS
Use the broil feature to cook meats that require direct
exposure to flame heat for optimum browing results.
When broiling, always remember to arrange the oven
racks while the oven is still cool.
Broil
1. Arrange the oven racks when cool
(See Figs. 2 & 4). For optimum
browningresults,preheattheoven
forabout5 minutes beforeaddingfood.
2. Be sure to place prepared food
directlyunderupperovenburner.
Close the oven door.
3. Pressbroil.
4. Press start (See Fig. 1) to activate.
5. Broil food on one side until browned.
Turn and broil food on other side.
To set broil:
Step Press
Suggested broil settings table (gas oven)
Food Rack position Setting Cook time in minutes
1st side 2nd side Doneness
Steak 1"thick 5th or 6th* 550°F 8 6 Medium
Steak 1"thick 5th or 6th* 550°F 10 8 Medium-well
Steak 1"thick 5th or 6th* 550°F 11 10 Well
Pork chops 3/4"thick 5th 550°F 12 8 Well
Chicken-bone in 4th 450°F 25 15 Well
Chicken-boneless 5th 450°F 10 8 Well
Fish 5th 550°F - as directed - Well
Shrimp 4th 550°F - as directed - Well
Hamburger 1"thick 6th* 550°F 12 10 Medium
Hamburger 1"thick 5th 550°F 14 12 Well
Insert
Broil
pan
Fig. 2
Fig. 4
Fig. 3
NOTES
* Use the off-set rack if you choose to use rack position 6.
Fig. 1
4
5
6
To stop broil at any time press cancel.
Should an oven fire occur, close the oven door and turn
the oven OFF. If the fire continues, use a fire extinguisher.
DO NOT put water or flour on the fire. Flour may be
explosive.
•For better access to food while broiling, use oven mitts
and pull the oven rack out to the rack stop position
before turning or removing the food.
•If needed, lower the oven temperature to avoid over
browning or drying of food items that should be cooked
to the well-done stage.
• bake time or start time instructions cannot be
added to the broil feature.
•When broiling the oven control does not provide a
preheat indicator or reminder tone when the oven
reaches set temperature.
•When broiling with a pan, be sure to use only
Electrolux Home Products, Inc. approved broil pan &
insert (Fig. 3).
WARNING
