Frigidaire FES388WG User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FES388WGCF 37957396H8366 STAINLESS U.S.A.
ELECTRIC - RANGE
Model No.
FES388WG
©1999 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
SLIDE-IN RANGE
WIRING DIAGRAM # - 318045025
OWNER’S GUIDE # - 318200813
TIMER INSTRUCTION GUIDE # - 318130805
INSTALLATION INSTRUCTION # - 318104602
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5992325684
990713
-EN/SERVICE
377
WARM & SERVEZONE
HOTSURF ACE
OVENLIGHT
DUALRADIANT BAKINGAND ROASTING
CLEAN
CONV
BAKE/ROAST
VARI
BROIL BAKE TIME CLOCK CANCEL
BAKE TIMER ON/OFF
STOP
TIME
SELF-CLEANINGCONVECTION OVEN
WARM & SERVE
DRAWER
OFF HI
MED
SURFACE
LEFTREAR
LO
LEFT FRONT
Galler y
PROFESSIONAL SERIES
SURFACE
RIGHTFRONT
RIGHT REAR
OFF OFF
OFFOFF
WARM& SERVE
DRAWER
OFF HI
MED
LO

Publication No. FES388WG
5992325684
07/99 2
BACKGUARD
80
24B
24B
LA9923G35
54 54
54
54
13A
13A
23
64
14
14
69
18A
14 14
21
102
18
36
36
36
36A
19
42
36
20
36A
24
46
46
46
46

FES388WG Publication No.
5992325684
# = Functional Part 307/99
* = Non-Illustrated Part
BACKGUARD
POS. NO PART NO DESCRIPTION
13A 316095500 ASwitch-warmer infinite
14 5303051533 ALight/Lamp
18 5303300160 AEnd Cap black RH
18A 5303300161 A End Cap black LH
19 318005555 APanel-control
20# 318012903 AClock/Timer
21 318027803 A Trim-backguard
23 318015508 ABraket timer
24 # 316005602 ASwitch-rocker
24B# 316086903 ASwitch-rocker
36 318099202 AKnob control
36A 318017600 AKnob-warmer grey
42 318106903 ATrim-vent
46 5308006417 ALens-light/lamp
54# 318120503 ASwitch surface unit
69 5303323134 AScrew mtg 8-32 X 3/16
102 318055601 ABracket-mounting
*3205110 AClip, plate connector
*5303211311 AScrew, #8 X ½
*08016432 AScrew, 8-18 X 3/8
*08002868 AScrew, 10-24 X ½
*5303323145 ANut
*218490900 ACleaner stainless steel
A= FES388WG (FES388WGCF)

Publication No. FES388WG
5992325684
07/99 4
BODY
219
68
170
170A
53B
102
191
62
71
87
80
LA9923V42
6
67
25
83
58B
142
58A
2A
88
89 108
59
141
10
9
127
37
12
129
128
70
3
70
114
114
1A
62
14
54 15 16
17
81
81
125
1
56
56
41
86
86
76 41
217
6A
107
66
3A
5
102
5
177
63
222

FES388WG Publication No.
5992325684
# = Functional Part 507/99
* = Non-Illustrated Part
BODY
POS. NO PART NO DESCRIPTION
1 318066400 ABack-main
1A 318070901 APanel-back
2A 318108600 AShield-oven top
3 5303300143 APanel-bodyside
3A 318160004 APanel-bodyside RH
3B 318160005 APanel-bodyside LH
5318175503 AScrew-leveling
6 318025301 ARack-oven
6A 5303311206 ARack, broiler pan
9 5303317977 APan-broiler
10 5303317976 AInsert-broiler pan
12 # 318089910 ASwitch-light
14 5308011085 ASocket-light/lamp
15 3201908 ALamp-oven light
16 3201911 AGlass-oven light lens
17 5304400195 ARetainer-lens
25 318179101 AShield-heat
37 # 316111203 AProbe-oven temp
41 5303310526 A Cover-hinge cutout
54 5303310514 AHousing-oven light
56 318002601 ATrim-oven front black
58A 5303310539 AInsulation
58B 5303310538 AInsulation oven back
59 318072502 ATube-oven vent
62 # 5303310518 ATerminal Block
63 5303310517 A Plate-ground strap
66 # 5303310513 AElement-broil
67 # 5303310512 AElement-bake
68 5304403015 ASupport-element
70 5303300142 AShield-insulation
71 5303310515 ACover-wiring
76 318124100 AFront-oven
80 5303320846 APlate oven
81 5303301261 ASpring-oven
83 318089609 ALiner-oven
86 5303310524 AChannel-hinge
87 318111800 APlate-mounting
88 5303311160 ARod-latch
89# 5304404899 AMotor-latch
89 * 318120702 ASwitch latch
102 5303311142 ASupport-oven front
107 318119600 ACover-fan
108# 318073001 AMotor-fan
109 5303311203 AFan blade
111 5303311205 ANut-fan retainer
114 3051827 APlate-filler
125# 5303311202 AMotor-convection
127 5303310542 AAdapter assy
128 5303311163 ABushing
129 5303311164 ASpring
141 5303284446 ASwitch thermal cutout
142 318123901 AAir Deflector
170 318175700 AAnti-tip bracket right
170A 318175701 AAnti-tip bracket left
177 5303324040 AGasket-vent
191 5303304030 ABracket
217 316042300 AWarning plate
219# 318003400 AThermostat safety
222 318080000 APlate, oven temp probe
263 5303322885 ASpacer
*5303311207 ATube protector
* 5303211311 A Screw #8 X ½/
*5303311124 AScrew
A= FES388WG (FES388WGCF)

Publication No. FES388WG
5992325684
07/99 6
TOP/DRAWER
60
85
1
80
2
193
4
87
39
86
81
1A
1B
1C
124A
124
13A
13
84
72
72
95
6
6
LAP23T0005D
51
15
15
15C
15A
55
55
55
55
55
56
56
56
56
56
52
52
52
52
52 15B
53
16

FES388WG Publication No.
5992325684
# = Functional Part 707/99
* = Non-Illustrated Part
TOP/DRAWER
POS.NO PART NO DESCRIPTION
1 318142500 ADrawer-warmer
1A 318143307 ADeflector-warmer side
1B 318143306 ADeflector-warmer side
1C 318143202 ADeflector-warmer rear
2318108011 ALiner-drawer
4 318107900 APanel-drawer white
6318111101 ASupport-element
13 316094900 ARail-drawer RH outer
13A 316094901 ARail-drawer LH outer
15# 318178100 AElement surface 1200W
15A# 318178000 AElement surface 700/2100W
15B# 318178001 AElement surface 1000/2100W
15C# 318178103 AElement warmer 120W
16 318079523 AMain Top & glass assy.
39 316079500 AHandle-drawer white
51# 5303297484 ALight indicator
52 5303317177 ASpring-element
53 318125900 ABracket-indicator
55 5303317178 ASpacer element
56 5303317179 AScrew element
60 5304400794 AScrew handle (10-32 x 1 1/8)
72 318113402 ABracket-slide (2)
80 318052700 ASeal-door, warmer drawer
81# 316093100 AElement warmer drawer
84# 318005101 AThermostat
85 316093600 ARack, warmer drawer
86 316095800 AClip hold down
87 318121502 ABase-warmer
95 318143701 ACover-wire
124 316096500 AChannel-drawer RH, inner
124A 316096501 AChannel-drawer LH, inner
193 5304400796 APlug
*5303323221 AWasher
*5303211311 AScrew, #8 X ½
*08002868 AScrew, 10-24 X 1
A= FES388WG (FES388WGCF)

Publication No. FES388WG
5992325684
07/99 8
DOOR
6
29
29
29
29
54
23
17
23
9
18
12
10
16
31
16
7
5
16 22
22
39
52
LA9922D06
13
57
58

FES388WG Publication No.
5992325684
# = Functional Part 907/99
* = Non-Illustrated Part
DOOR
POS. NO PART NO DESCRIPTION
5318041104 AGlass-oven door black
6 318056802 AShield-wool
7 318106001 AInsulation-door
9 318048802 ALiner-oven door
10 5304400794 AScrew 10-32 X X1 1/8
12 318053103 ASeal-oven door
13 318009220 APanel oven door
16 318041603 AGlass-oven door
17 318042102 ASpacer-glass
18 318053001 ASeal-window
22 5303310511 ARetainer glass
23 5303310828 AHinge-oven door assy.
29 5303310535 ABumper base
31 5303310536 ALatch-door
39 316079500 AHandle-door
52 318123401 AShield oven door
54 5303300265 AScrew, 8-18 X ½
57 318172902 AStiffener glass
58 316082300 AName plate
* 3201899 AWasher
*08016432 AScrew, 8-18 X 3/8
*5303211311 AScrew, #8 X ½
*218490900 ACleaner, stainless steel
A= FES388WG (FES388WGCF)

Publication No. FES388WGCA
5992325684
07/99 10
WIRING DIAGRAM
