Frigidaire GLGF376D Manual

FGFL79D.eps T24G0009.eps T24B0002.eps T24V0026.eps T24T0021.eps T24D0005.eps
316417808d.eps 316417808s.eps
Product No. GLGF376DBA GLGF376DQA GLGF376DSA
Series 30" f/s gas 30" f/s gas 30" f/s gas
Color black bisque white
Market North America North America North America
Wiring Diagram 316417808 316417808 316417808
Owner's Guide 316417101 316417101 316417101
Installation Instructions 316259336 316259336 316259336
Service Data Sheet 316417603 316417603 316417603
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995420758
04/11/03
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
GLGF376D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995420758 GLGF376D
11/04 2
BACKGUARD

GLGF376D Publication No: 5995420758
# Functional Parts 3 11/04
* Non-Illustrated Parts
BACKGUARD
Model Index: AGLGF376D (GLGF376DSA)
BGLGF376D (GLGF376DBA)
CGLGF376D (GLGF376DQA)
POS. NO PART NO. DESCRIPTION
1 316416100 A B C Shield, backguard, rear wall
2 316051600 A B C Shield, backguard, inner
2A 316235100 A B C Shield, top, inner
14 316022500 A B C Light/Lamp, indicator, 125 V
15 316411403 A - - Support, backguard, white, RH
15 316411405 - B - Support, backguard, black, RH
15 316411407 - - C Support, backguard, bisque, RH
15A 316411402 A - - Support, backguard, white, LH
15A 316411404 - B - Support, backguard, black, LH
15A 316411406 - - C Support, backguard, bisque, LH
19 316424126 A - - Panel, control, white
19 316424128 - B - Panel, control, black
19 316424127 - - C Panel, control, bisque
20 # 316418303 A B C Clock/Timer, electronic, ES330
20A 316419301 A - - Overlay, clock, white, ES330
20A 316419300 - B - Overlay, clock, black, ES330
20A 316419302 - - C Overlay, clock, bisque, ES330
24C# 316114000 A - - Switch, speed bake, white
24C# 316114002 - B - Switch, speed bake, black
24C# 316114004 - - C Switch, convection, bisque
36 316220000 A - - Knob, top valve, white, (4)
36 316220002 - B - Knob, top valve, black, (4)
36 316220003 - - C Knob, top valve, bisque, (4)
40 316204917 A - - Panel, manifold, white
40 316204918 - B - Panel, manifold, black
40 316204919 - - C Panel, manifold, bisque
42 316416201 A - - Trim, extrusion, gray
42 316416200 - B - Trim, extrusion, black
42 316416202 - - C Trim, extrusion, tan
46 316040201 A B C Lens, indicator light, red
56 316230701 A B C Shield, backguard, inner
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B C Screw, 8-18 x 0.5, chrome
* 316021110 A B C Screw, 8-18 x 0.5, black

Publication No: 5995420758 GLGF376D
11/04 4
BURNER

GLGF376D Publication No: 5995420758
# Functional Parts 5 11/04
* Non-Illustrated Parts
BURNER
Model Index: AGLGF376D (GLGF376DSA)
BGLGF376D (GLGF376DBA)
CGLGF376D (GLGF376DQA)
POS. NO PART NO. DESCRIPTION
1 # 316219500 A B C Pipe, manifold
2A # 5303935236 A B C Valve, 14K burner, w/mtg screw
2B # 5303935235 A B C Valve, 5K burner, w/mtg screw
2C # 5303935234 A B C Valve, 9.5K burner, w/mtg screw
* 316215600 A B C Screw, valve mtg., 1/4 - 20
3 # 316219004 A B C Wiring Harness, w/igntr switch
8 # 316135701 A B C Module, spark
10A# 316223400 A B C Burner, sealed, 14K
10B# 316206400 A B C Burner, sealed, 5K
10C# 316212400 A B C Burner, sealed, 9.5K
11 # 316237701 A B C Ignitor/orifice assy., top burner, rear, 9.5K, w/holder, tube
11A# 316272000 A B C Ignitor/orifice assy., top burner, front, 14K, w/holder, tube
11B# 316237700 A B C Ignitor/orifice assy., top burner, rear, 5K, w/holder, tube
11C# 316237800 A B C Ignitor/orifice assy., top burner, front, 9.5K, w/holder, tube
13 # 316405300 A B C Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 A B C Regulator, pressure
14* 316021104 A B C Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 A B C Bracket, regulator
16 # 316405500 A B C Tube, valve to regul., 3/8
17 # 316404900 A B C Valve, safety
17* 08068018 A B C Shield, wire, safety valve
18 # 316404400 A B C Burner, oven
19 # 316428500 A B C Ignitor, oven burner
20 316401401 A B C Baffle, oven burner
21 5303013272 A B C Nut, hex head sems
22 # 316405400 A B C Tube, valve to mixer
23 # 316404300 A B C Burner, broiler
24 # 316409700 A B C Elbow, mixer
25 316401301 A B C Baffle, broil burner
26 # 316428600 A B C Ignitor, burner
26* 316401500 A B C Cover, broil Ignitor
37 316240600 A B C Screw, assy mtg, ignitor/orifice
44A 316237900 A B C Orifice, top burner, 14K
44B 316237903 A B C Orifice, top burner, 5K
44C 316237902 A B C Orifice, top burner, 9.5K
47 GRLP2 A B C LP Conversion Kit, w/instructions
47* 316248105 A B C Instructions, LP kit
* # 316253700 A B C Wiring Harness, ignitor module
* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5

Publication No: 5995420758 GLGF376D
11/04 6
BODY

GLGF376D Publication No: 5995420758
# Functional Parts 7 11/04
* Non-Illustrated Parts
BODY
Model Index: AGLGF376D (GLGF376DSA)
BGLGF376D (GLGF376DBA)
CGLGF376D (GLGF376DQA)
POS. NO PART NO. DESCRIPTION
1 316401600 A B C Back, main
2 316402201 A B C Shield, oven top
2* 316437100 A B C Brace, oven top
3 316400102 A - - Panel, bodyside, white, RH
3 316400103 A - - Panel, bodyside, white, LH
3 316400104 - B - Panel, bodyside, black, RH
3 316400105 - B - Panel, bodyside, black, LH
3 316400106 - - C Panel, bodyside, bisque, RH
3 316400107 - - C Panel, bodyside, bisque, LH
4 316201403 A B C Burner Box
5 316272900 A B C Screw, leveling, plastic, rear, (2)
5A 316407200 A B C Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 A B C Rack, oven
8 316400603 A B C Panel, oven bottom
12 # 316407100 A B C Switch, oven light/door
14 316116400 A B C Receptacle, oven light
15 5303013071 A B C Bulb/Lamp, oven light
16 08011086 A B C Lens, oven light, glass
17 316087500 A B C Retainer, lens
18 # 316405800 A B C Latch Assembly, oven door
21 316408000 A B C Clip, bodyside
25 316406200 A B C Shield, heat, lower
29 316407301 A B C Glide, drawer, front
30 316217700 A B C Bracket, hinge, RH, main top
30A 316217701 A B C Bracket, hinge, LH, main top
33 316402500 A B C Shield, rear wall
35 316116600 A B C Gasket, flue
36 316208901 A B C Flue
37 # 316217001 A B C Probe, oven temp
39 3202006 A B C Cord, electric power
42 316400703 A B C Shield, wool, lower
43 3131732 A B C Screw, 8-18 x 1.438, oven bottom
44 316246501 A B C Spacer, oven door
49 316234200 A B C Clip, maintop mtg, (2)
54 316404200 A B C Shield, heat
55 316404800 A B C Shield, flue
58A 316403700 A B C Insulation, oven wrapper
58B 316403600 A B C Insulation, oven back
58G 08067973 A B C Insulation, main front
82 316400801 A B C Shield, bake burner
82* 316432800 A B C Clip, wire
86 316407000 A B C Receptacle, hinge
86* 316418901 A B C Screw, trilobe, 10-32 x 5/16"
87 316401200 A B C Bracket, harness
88 316232700 A B C Rod, auto latch
89 # 316415400 A B C Motor, latch/lock
90 316401100 A B C Shield, main front
91 316401000 A B C Shield, front, burner

Publication No: 5995420758 GLGF376D
11/04 8
BODY

GLGF376D Publication No: 5995420758
# Functional Parts 9 11/04
* Non-Illustrated Parts
BODY
Model Index: AGLGF376D (GLGF376DSA)
BGLGF376D (GLGF376DBA)
CGLGF376D (GLGF376DQA)
POS. NO PART NO. DESCRIPTION
106 316404100 A B C Bracket, motor mtg.
107 316026701 A B C Cover, fan
108# 316415700 A B C Motor, convection
109 316136400 A B C Blade, fan
110 316136500 A B C Washer, fan motor
111 316136600 A B C Nut, fan retainer
151 316404600 A B C Shield, bodyside
170 5303935180 A B C Anti-tip Kit, w/bracket, screw
170* 316107200 A B C Bracket, anti-tip
170* 316112500 A B C Template, anti-tip
170* 316116000 A B C Screw, concrete, 1.75", anti-tip brkt
264 316404700 A B C Bracket, air dam
* 316416603 A B C Harness, wiring, main
* 316231800 A B C Cover, hole, conv. element
* 5303305324 A - - Paint, touch-up, white
* 5303305345 - B - Paint, touch-up, black
* 5304414035 - - C Paint, touch-up, bisque
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 A B C Screw, 8-18 x 0.5, black
* 316021132 A B C Screw, 8-18 X 11/16, black
* 316089500 A B C Screw, 10-16 x .486
* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B C Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995420758 GLGF376D
11/04 10
TOP/DRAWER

GLGF376D Publication No: 5995420758
# Functional Parts 11 11/04
* Non-Illustrated Parts
TOP/DRAWER
Model Index: AGLGF376D (GLGF376DSA)
BGLGF376D (GLGF376DBA)
CGLGF376D (GLGF376DQA)
POS. NO PART NO. DESCRIPTION
1 316408701 A B C Drawer, utility
2 316403200 A B C Liner, drawer
4 316403401 A - - Panel, drawer, white, front
4 316403402 - B - Panel, drawer, black, front
4 316403403 - - C Panel, drawer, bisque, front
7 316407400 A B C Glide, drawer, rear
16 316202350 A - - Main Top, white
16 316202349 - B - Main Top, black
16 316202351 - - C Main Top, bisque
20 316202401 A - - Grate, gray
20 316202400 - B - Grate, black
20 316202403 - - C Grate, brown
22A 316219901 A - - Cap, 14K burner, grey
22A 316219900 - B - Cap, 14K burner, black
22A 316219904 - - C Cap, 14K burner, brown
22B 316206601 A - - Cap, 5K burner, gray
22B 316206600 - B - Cap, 5K burner, black
22B 316206602 - - C Cap, 5K burner, brown
22C 316213501 A - - Cap, 9.5K burner, gray
22C 316213500 - B - Cap, 9.5K burner, black
22C 316213503 - - C Cap, 9.5K burner, brown
88 316099500 A B C Pin, guide, (2)
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 A B C Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 A B C Screw, 8-18 x 0.5, chrome
* 316021110 A B C Screw, 8-18 x 0.5, black
* 5303280308 A B C Screw, wafer hd sq dr, 10-24T x 2.00, handle mtg

Publication No: 5995420758 GLGF376D
11/04 12
DOOR

GLGF376D Publication No: 5995420758
# Functional Parts 13 11/04
* Non-Illustrated Parts
DOOR
Model Index: AGLGF376D (GLGF376DSA)
BGLGF376D (GLGF376DBA)
CGLGF376D (GLGF376DQA)
POS. NO PART NO. DESCRIPTION
3 316402001 A - - Trim, oven door, white
3 316402002 - B - Trim, oven door, black
3 316402003 - - C Trim, oven door, bisque
4 316402600 A - - Glass, door, white
4 316402601 - B - Glass, door, black
4 316402602 - - C Glass, door, bisque
6 316402307 A B C Shield, wool
7 316403900 A B C Insulation, oven door
8 316117500 A B C Glass, oven door, heat barrier
9 316423801 A B C Liner, oven door
10 316422204 A B C Screw, 10-24 x 2.02", (2)
10B 316008401 A B C Washer, 3/4 OD x 1/4 ID, steel
12 316403101 A B C Seal, oven door
17 316402403 A B C Spacer, door glass, (2)
23 316406909 A B C Hinge, oven door
23* 316418900 A B C Screw, sims lp, #8-32 x 5/16", black
39 316203001 A - - Handle, door, white
39 316203000 - B - Handle, door, black
39 316203003 - - C Handle, door, bisque
52 316405100 A - - Cap, door trim, white
52 316405101 - B - Cap, door trim, black
52 316405102 - - C Cap, door trim, bisque
54 316427801 A B C Deflector, door hinge, (2)
60B 316021110 A B C Screw, 8-18 x 0.5, black
* 316433603 A B C Label, anti-tip
* 316021109 A B C Screw, 8-18 x 0.5, chrome
* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303280308 A B C Screw, wafer hd sq dr, 10-24T x 2.00, handle mtg
* 5303285179 A B C Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995420758 GLGF376D
11/04 14
WIRING SCHEMATIC

GLGF376D Publication No: 5995420758
# Functional Parts 15 11/04
* Non-Illustrated Parts
WIRING DIAGRAM
