p/n 316441731 (0611)
SERVICE DATA SHEET
ElectricRangeswithES200/205/300&305ElectronicOvenControls
ELECTRONICOVENCONTROL(REARVIEW)
IMPORTANT
DO NOT REMOVE THIS BAG
OR DESTROY THE CONTENTS
WIRINGDIAGRAMSANDSERVICE
INFORMATION ENCLOSED
REPLACE CONTENTS IN BAG
ELECTRONICOVENCONTROLFAULTCODEDESCRIPTIONS
RunawayTemperature.
ShortedKeypad.
BadMicroIdentification.
BadEEPROMIdentification/Checksumerror.
Openprobeconnection.
ShortedProbeconnection.
Maximumovendoorunlocktimeexceeded.
Maximumovendoorunlockattemptsexceeded.
Maximumovendooropentimeexceeded.
Maximumovendoorlocktimeexceeded.
Maximumovendoorlockattemptsexceeded.
Likely Failure Condition/Cause Suggested Corrective Action
Fault Code
1.(F10only)CheckRTDSensorProbe&replace ifnecessary.Ifovenisoverheating,disconnect
power.Ifovencontinuestooverheatwhenthepowerisreapplied,replaceEOC.Severeoverheating
may require the entire oven to be replaced should damage be extensive.
2. (F11, 12 & 13) Disconnect power, wait 30 seconds and reapply power.
3. (F11, 12 & 13) If fault returns upon power-up, replace EOC.
1.(F30orF31)Checkresistanceatroomtemperature&comparetoRTDSensorresistancechart.
If resistance does not match the RTD chart replace RTD Sensor Probe. Check Sensor wiring
harness between EOC & Sensor Probe connector.
2.(F30orF31)Checkresistanceatroomtemperature,iflessthan500ohms,replaceRTDSensor
Probe. Check for shorted Sensor Probe harness between EOC & Probe connector.
1. (F90, 91, 92, 93 & 94) Check the wiring between EOC & Lock Motor Micro Switch.
2. (F90, 91, 92, 93 & 94) Replace the Motor Door Latch assembly if necessary.
3.(F90,91,92,93& 94) CheckforbindingoftheLatchCam,Lock Motor Rod&LockMotorCam.
4. (F90, 91, 92, 93 & 94) Check to see if Lock Motor Coil is open. If open, replace Lock Motor
Assembly.
5.(F90,91,92,93&94)LockMotorcontinuoslyruns-ifMicroSwitchisopen,replaceLockMotor
Assembly.
6. (F92, 93 & 94) Check oven door Light Switch - if open, replace Switch.
7. If all situations above do not solve problem, replace EOC.
F10
F11
F12
F13
F30
F31
F90
F91
F92
F93
F94
NOTICE - This service data sheet is intended for use by
persons having electrical and mechanical training and a level of
knowledge of these subjects generally considered acceptable
in the appliance repair trade. The manufacturer cannot be
responsible, nor assume any liability for injury or damage of
any kind arising from the use of this data sheet.
SAFESERVICINGPRACTICES
To avoid the possibility of personal injury and/or property damage, it
is important that safe servicing practices be observed. The following
are examples, but without limitation, of such practices.
1. Before servicing or moving an appliance remove power cord
from electrical outlet, trip circuit breaker to OFF, or remove fuse.
2. Never interfere with the proper installation of any safety device.
3. GROUNDING: The standard color coding for safety ground
wires is GREEN or GREEN WITH YELLOW STRIPES. Ground
leads are not to be used as current carrying conductors. It is
extremely important that the service technician reestablish
all safety grounds prior to completion of service. Failure
to do so will create a potential safety hazard.
4. Prior to returning the product to service, ensure that:
• All electric connections are correct and secure.
• All electrical leads are properly dressed and secured away
from sharp edges, high-temperature components, and moving
parts.
• All uninsulated electrical terminals, connectors, heaters, etc.
are adequately spaced away from all metal parts and panels.
• All safety grounds (both internal and external) are correctly
and securely reassembled.
RTD SCALE
Temperature (°F) Resistance (ohms)
32 ± 1.9 1000 ± 4.0
75 ± 2.5 1091 ± 5.3
250 ± 4.4 1453 ± 8.9
350 ± 5.4 1654 ± 10.8
450 ± 6.9 1852 ± 13.5
550 ± 8.2 2047 ± 15.8
650 ± 9.6 2237 ± 18.5
900 ± 13.6 2697 ± 24.4
RESISTANCETEMPERATUREDECTECTOR
SIMMER SELECT PCB (some models)
E.O.C.CONTROLCONNECTIONS(P5)
OVENCALIBRATION
Set the electronic oven control for normal baking at 350°F. Obtain an average
oven temperature after a minimum of 5 cycles. Press STOP/CLEAR to end bake
mode.
TEMPERATUREADJUSTMENT
1. Set EOC to bake at 550°F.
2. Within 5 seconds of setting 550°F, press and hold the bake pad for
approximately 15 seconds until a single beep is heard (longer may cause
F11 shorted keypad alarm).
3. Calibration offset should appear in the display.
4. Use the slew keys to adjust the oven temperature up or down 35°F in 5°F
increments.
5. Once the desired (-35°to 35°) offset has been applied, press STOP/CLEAR.
Note: Changing calibration affects normal Bake mode. The adjustments made will
not change the Self-Cleaning cycle temperature.
CIRCUITANALYSISMATRIX
