Frigidaire PLES389D User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. SERIES COLOR
PLES389DCA PLES389D 37957396H45S1 30" slide-in stainless
MARKET
North America
Publication No.
5995394748
030827
-EN/SERVICE /ECL
377
ELECTRIC
RANGE
Model No.
PLES389D
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318045090
OWNER’S GUIDE - # 318200840
TIMER INSTRUCTION SHEET - # 318200195
INSTALLATION INSTRUCTIONS - # 318201606
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

08/03 2
Publication No. PLES389DCA
5995394748
BACKGUARD

# = Functional Parts 3 08/03
* = Non-Illustrated Parts
PLES389DCA Publication No.
5995394748
BACKGUARD
POS. NO PART NO DESCRIPTION
14 # 318044825 Light,indicator ,125v ,(2)
16 318235001 Console,assy. ,black ,w/ end caps
19 318239700 Panel,control assy. ,black/stainless ,w/ membrane
19A 318224403 Panel,control mtg.
20 # 316272204 Clock/Timer,electronic ,ES500/ES550
35 318233700 Retainer,control panel ,black
36 318229301 Knob,control ,black
42 318224301 Trim,vent ,black ,bottom
46 318228300 Lens,indicator light
54 # 318120521 Switch,surface unit
54A# 318191023 Switch,infinite ,dual
69 5303323134 Screw,switch mtg. ,8-32 x 0.188
99A 318223900 Gasket,dark grey
* 218490900 Cleaner,stainless steel
* 3201861 Screw,6 x 0.375
* 08002868 Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 08016432 Screw,truss head ,8-18 x 0.375
* 5303211311 Screw,8 x 0.500

08/03 4
Publication No. PLES389DCA
5995394748
BODY

# = Functional Parts 5 08/03
* = Non-Illustrated Parts
PLES389DCA Publication No.
5995394748
BODY
POS. NO PART NO DESCRIPTION
1 318066402 Panel,main back
1A 318225100 Panel,main back ,upper
2A 318227600 Shield,oven top
3 318225200 Panel,bodyside ,upper RH
3A 318225201 Panel,bodyside ,upper LH
3B 318160010 Panel,body side ,lower RH
3C 318160011 Panel,body side ,lower LH
5 318175503 Screw,leveling
6 318025304 Rack,oven
6A 318219500 Rack,broiler pan
9 5303317977 Pan,broiler
10 5303317976 Insert,broiler pan
12 # 318089914 Switch,light
14 318224000 Receptacle,oven light
15 5303013071 Bulb/Lamp,oven light
16 3201911 Cover,oven light ,glass
17 5304400195 Retainer,light cover
25 318179108 Shield,heat ,lower
37 # 316217002 Probe,oven temp
41 5303310526 Cover,hinge cutout
54 318222400 Housing,oven light
56 318225902 Trim,oven ,black
58A 318133783 Insulation,oven wrapper
58B 318133785 Insulation,oven back
59 318072534 Tube,vent ,oven
62 5303935061 Terminal Block Kit
62* 5303323144 Nut,10-32
63 316208500 Plate,grounding strap
66 # 5303310513 Element,broil ,2750 W
67 # 5303310512 Element,bake ,3000 W
68 5304403015 Support,element hanger
70 318194400 Shield,insulation
71 5303310515 Panel,wiring cover ,rear
76 318225302 Front,oven
80 5303320846 Plate,oven mtg
81 318192400 Spring,oven
83 318089616 Liner,oven complete
86 5303310524 Receptacle,hinge
86* 318246500 Deflector,RH
86* 318246600 Deflector,LH
87 318111803 Plate,mounting
88 318118904 Rod,latch
89 # 318095937 Motor,latch assy ,w/brkt & switch
89* 318120711 Switch
102 5303311142 Support,oven front
107 318219401 Cover,fan
108# 318073016 Motor,blower
109 316136400 Blade,fan
111 316136600 Nut,fan retainer
125# 316136300 Motor,fan
127 5303310542 Adapter,vent tube ,with converter
128 5303311163 Bushing
129 5303311164 Spring
141# 318005201 Switch,thermal cutout
141B 318003607 Thermostat,safety
142 318123901 Deflector
161# 318050710 Element,convection ,2500 W
170 5304405244 Anti-tip & accessories
191 5303304030 Bracket,angle ,corner
219# 318112701 Relay
263 316136500 Washer,fan motor
273 5303311207 Tube,protector
284 318226600 Box,vent tube
285 318236200 Shield,hidden wires
* 5304400795 Bushing,snap-in ,nylon
* 318226300 Clip,wiring
* 08016432 Screw,truss head ,8-18 x 0.375
* 5303211311 Screw,8 x 0.500
* 5303307980 Screw,8-32 x 0.437
* 5304400427 Screw,6-20 x 1/2

08/03 6
Publication No. PLES389DCA
5995394748
MAINTOP/DRAWER

# = Functional Parts 7 08/03
* = Non-Illustrated Parts
PLES389DCA Publication No.
5995394748
MAINTOP/DRAWER
POS. NO PART NO DESCRIPTION
1 318142500 Drawer,warmer
1A 318143335 Deflector,warmer drawer ,RH
1B 318143334 Deflector,warmer drawer ,LH
1C 318143203 Deflector,warmer drawer ,rear
2 318108025 Liner,drawer
4 318107903 Panel,drawer ,stainless
13 316105602 Glide,warmer ,inner RH
13A 316105601 Glide,warmer ,inner LH
15 # 318198810 Element,surface ,6" ,1200 W
15A# 318177900 Element,bridge
15B# 316224300 Element,dual ,6"/9" ,surface ,1000W/2500W,radiant
15C# 318198804 Element,surface ,warmer ,100 W
16 318223626 Main Top,glass assy. ,black
39 318219800 Handle,door/drawer ,stainless
46 318225401 Box,burner
51 # 318044822 Light,indicator ,clear
52 318122010 Spring,element mtg ,1000W/2500W
52A 318122006 Spring,element mtg ,small
52B 318122004 Spring,element mtg ,700W & 2100W
52C 318122008 Spring,element mtg
60 5303311174 Screw,10-24 x 3/8
72 318113403 Bracket,slide ,(2)
80 318054310 Gasket,warmer drawer
81 # 318112400 Element,warmer drawer
84 # 318005103 Thermostat,safety
85 316093600 Rack,warmer drawer
86 316095800 Clip,hold down ,warmer element
87 318121503 Base,warmer
95 318143702 Cover,wire
124 316105500 Glide,warmer drawer ,outer/RH & LH ,(2)
165 318227500 Plate,mounting
176 3201909 Washer
193 5303325173 Cap,plug
* 218490900 Cleaner,stainless steel
* 08002868 Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 08016432 Screw,truss head ,8-18 x 0.375
* 5303211311 Screw,8 x 0.500

08/03 8
Publication No. PLES389DCA
5995394748
DOOR

# = Functional Parts 9 08/03
* = Non-Illustrated Parts
PLES389DCA Publication No.
5995394748
DOOR
POS. NO PART NO DESCRIPTION
6 318056802 Shield,insulation
7 318133781 Insulation,oven door
9 318157011 Liner,door
10 5303311174 Screw,10-24 x 3/8
* 3201909 Washer
12 318053103 Gasket,oven door seal
13 318187917 Stainless Panel,oven door ,w/ glass/nmplt
16 318041603 Panel,glass ,inner oven door
17 318042102 Spacer,glass
18 318053001 Seal,window
22 5303310511 Bar,glass retainer
23 5303310828 Hinge,oven door ,(2)
29 318147410 Bumper,base
31 5303310536 Latch,oven door
39 318219800 Handle,door/drawer ,stainless
54 5303300265 Screw,8-18 x 0.500 ,chrome
57 318172902 Stiffener,glass
* 218490900 Cleaner,stainless steel
* 316221001 Label,anti-tip
* 08016432 Screw,truss head ,8-18 x 0.375
* 5303211311 Screw,8 x 0.500
* 5303307980 Screw,8-32 x 0.437

08/03 10
Publication No. PLES389DCA
5995394748
WIRING DIAGRAM
