PLGFMZ96EC.eps T24G0028.eps T24B0015.eps T24V0056.eps T24T0049.eps
T24D0029.eps 316255207D.eps 316255207S.eps
This Publication Supercedes Publication # 5995454021
Product No. PLGFMZ96ECC
Series 30" f/s gas
Color stainless
Market North America
Owner's Guide 316417113
Service Data Sheet 316441707
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995459483
06/01/24
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
PLGFMZ96E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.
Publication No: 5995459483 PLGFMZ96ECC
01/06 2
BACKGUARD
PLGFMZ96ECC Publication No: 5995459483
# Functional Parts 3 01/06
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
1 316416100 Shield, backguard, rear wall
2 316051600 Shield, backguard, inner
2A 316235100 Shield, top, inner
13 316414405 Control, bake, mini oven
14A 316022500 Light/Lamp, indicator, 125 V
15 316411405 Support, backguard, black, RH
15A 316411404 Support, backguard, black, LH
19 316436231 Panel, control, stainless
20 # 316418706 Clock/Timer, electronic, ES510
20A 316419700 Overlay, clock, black, w/mini oven, ES510
31 316223019 Knob, control, black
36 316220002 Knob, top valve, black, 4
40 316249015 Panel, manifold, stainless steel
42 316416200 Trim, extrusion, black
46 316040201 Lens, indicator light, red
55 316247700 Nut, hex control mtg
55A 316247800 Washer, lock, control mtg
56 316230701 Shield, backguard, inner
* 316416921 Harness, mini oven cntl
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021109 Screw, 8-18 x 0.5, chrome
* 316021110 Screw, 8-18 x 0.5, black
Publication No: 5995459483 PLGFMZ96ECC
01/06 4
BURNER
PLGFMZ96ECC Publication No: 5995459483
# Functional Parts 5 01/06
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 # 316219501 Pipe, manifold
2 # 5303935233 Valve, 17K burner, w/mtg screw
2A # 5303935235 Valve, 5K burner, w/mtg screw
2B # 5303935232 Valve, 9.5k/12k burner, w/mtg screw
2C # 5303935234 Valve, 9.5K burner, w/mtg screw
* 316215600 Screw, valve mtg., 1/4 - 20
3 # 316219006 Wiring Harness, w/igntr switch
8 318079001 Module, spark
10 # 316223300 Burner, sealed, 17K
10A# 316206400 Burner, sealed, 5K
10B# 316212300 Burner, sealed, 12K
10C# 316212400 Burner, sealed, 9.5K
11 # 316430500 Ignitor/orifice assy., top burner, right front, 16K, w/holder, tube
11A# 316430800 Ignitor/orifice assy., top burner, right rear, 5K, w/holder, tube
11B# 316430401 Ignitor/orifice assy., top burner, left rear, 12K, w/holder, tube
11C# 316237800 Ignitor/orifice assy., top burner, front
11D# 316430700 Ignitor/orifice assy., top burner, center, 9.5K, w/holder, tube
13 # 316405300 Tube, 3/8, aluminum, rgltr to manf, with fittings
14 # 316091706 Regulator, pressure
14* 316021104 Screw, hex, 8-18 x 3/8, nick, (3), regulator brkt
15 316091600 Bracket, regulator
16 # 316405500 Tube, valve to regul., 3/8
17 # 316404901 Valve, safety
18 # 316404400 Burner, oven
19 # 316428500 Ignitor, oven burner
20 316401401 Baffle, oven burner
21 5303013272 Nut, hex head sems
22 # 316405401 Tube, valve to mixer
23 # 316404300 Burner, broiler
24 # 316409700 Elbow, mixer
25 316401301 Baffle, broil burner
26 # 316428601 Ignitor, burner
26* 316401500 Cover, broil Ignitor
37 316240600 Screw, assy mtg, ignitor/orifice
44 316237912 Orifice, top burner, 16K
44A 316237903 Orifice, top burner, 5K
44B 316237901 Orifice, top burner, 12K
44C 316237902 Orifice, top burner, 9.5K
* # 316253702 Wiring Harness, ignitor module
* # 316064103 Wire, ground assembly
* 316001003 Screw, ground wire
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
Publication No: 5995459483 PLGFMZ96ECC
01/06 6
BODY
PLGFMZ96ECC Publication No: 5995459483
# Functional Parts 7 01/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 316401602 Back, main
2 316402201 Shield, oven top
2* 316437100 Brace, oven top
3 316400118 Panel, bodyside, black, RH
3 316400119 Panel, bodyside, black, LH
4 316201403 Burner Box
5 316272900 Screw, leveling, plastic, rear, (2)
5A 316407201 Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404501 Rack, oven
6A 318219500 Rack, broiler pan
8 316400603 Panel, oven bottom
9 316081900 Pan, broiler
10 316082000 Insert, broiler pan
12 316445500 Switch, oven light, door frame
14 316116400 Receptacle, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 316087500 Retainer, lens
18 # 316405800 Latch Assembly, oven door
21 316408000 Clip, bodyside
30 316217700 Bracket, hinge, RH, main top
30A 316217701 Bracket, hinge, LH, main top
33 316402500 Shield, rear wall
35 316116600 Gasket, flue
36 316208901 Flue
37 # 316217001 Probe, oven temp
39 # 3131425 Cord, electric power
42 316400703 Shield, wool, lower
43 3131732 Screw, 8-18 x 1.438, oven bottom
44 316246501 Spacer, oven door
49 316234200 Clip, maintop mtg, (2)
54 316404200 Shield, heat
55 316404800 Shield, flue
57 316451100 Cover, access, w/ holes
57A 316451101 Cover, access, w/o holes
58A 316403700 Insulation, oven wrapper
58B 316403600 Insulation, oven back
58G 08067973 Insulation, main front
77 316451200 Plate, mounting, safety valve
82 316400801 Shield, bake burner
82* 316432800 Clip, wire
86 316441300 Receptacle, hinge
86* 316418901 Screw, trilobe, 10-32 x 5/16"
87 316451000 Bracket, harness, mini oven
88 316232700 Rod, auto latch
89 # 316415400 Motor, latch/lock
90 316401100 Shield, main front
91 316401000 Shield, front, burner
106 316404100 Bracket, motor mtg.
107 316026701 Cover, fan
108# 316415700 Motor, convection
Publication No: 5995459483 PLGFMZ96ECC
01/06 8
BODY
PLGFMZ96ECC Publication No: 5995459483
# Functional Parts 9 01/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
109 316136400 Blade, fan
110 316136500 Washer, flat
111 316136600 Nut, fan retainer
112 316435200 Standoff, strike plate
113 316431600 Plate, strike, mini oven
113* 316436700 Screw, countersunk HD, #10-16 x 1/4, (2)
151 316404600 Shield, bodyside
161# 316211604 Element, convection fan, 200 W
164 316450301 Trim, front, mini oven
170 5303935180 Anti-tip Kit, w/bracket, screw
170* 316107200 Bracket, anti-tip
170* 316112500 Template, anti-tip
170* 316116000 Screw, concrete, 1.75", anti-tip brkt
264 316404700 Bracket, air dam
* # 316416628 Harness, wiring, main
* 5303305345 Paint, touch-up, black
* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black
* 316021108 Screw, cup pt, 8-18 x 0.375, chrome
* 316021110 Screw, 8-18 x 0.5, black
* 316021132 Screw, 8-18 X 11/16, black
* 316089500 Screw, 10-16 x .486
* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 Screw, wafer head, 8-32T x 0.500, black
Publication No: 5995459483 PLGFMZ96ECC
01/06 10
TOP/DRAWER
