Frigidaire FRS23H5AS User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRS23H5ASB0 FRS23H5AS R134a stainless/black 115
FRS23H5ASB1 FRS23H5AS R134a stainless/black 115
MARKET
North America
Publication No.
5995364261
020122
-EN/SERVICE/KHB
357
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS23H5AS
©2002 Electrolux Home Products, Inc.
All rights reserved
WIRING DIAGRAM - 240389604
OWNER’S GUIDE - 0 = 240389302 & 1 = 240389303
SERVICE DATA SHEET - 240389604
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
FACTORY
PARTS CATALOG

01/02 2
Publication No. FRS23H5AS
5995364261
FREEZER DOOR

# = Fast-moving Parts 3 01/02
* = Non-Illustrated Parts
FRS23H5AS Publication No.
5995364261
FREEZER DOOR
A = FRS23H5AS (FRS23H5ASB0)
B = FRS23H5AS (FRS23H5ASB1)
POS. NO PART NO DESCRIPTION
1 # 240390608 A B Gasket-frzr door,black ,magnetic
4A 240367301 A B Bin-door,frzr-upper
4B 240359001 A B Bin-door
11 240451830 A B Door-frzr,stainless steel, complete assy
13A 240456906 A B Door Stop,black ,frzr
18 240359108 A B Handle-door,black
21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
21C 218781100 A B Screw,pan head ,8-18 x 0.625
22A 240328202 A B Bearing-hinge,closer
22C 240328404 A B Bearing-hinge,black ,upper
37 240359203 A B Trim-handle,30.13" ,black ,lower
68 240465801 A B Chute-ice
72 240421701 A B Button-handle mtg,dovetail
73 218396700 A B Block-handle mtg,dovetail
73A 240339101 A B Clip-trim
74 215503200 A B Screw,cr pan hd ,10-16 x 0.500
96 240345506 A B Plug,door foam hole ,black
* 218490900 A B Cleaner,stainless steel
* 240323201 A B Wiring Harness
* 240352101 A B Connector-water,straight
* 5303918256 A B Dispenser heater kit

01/02 4
Publication No. FRS23H5AS
5995364261
REFRIGERATOR DOOR

# = Fast-moving Parts 5 01/02
* = Non-Illustrated Parts
FRS23H5AS Publication No.
5995364261
A = FRS23H5AS (FRS23H5ASB0)
B = FRS23H5AS (FRS23H5ASB1)
POS. NO PART NO DESCRIPTION
2 # 240390607 A B Gasket-refr door,black ,magnetic
4 240363701 A B Bin-door,2-liter
7 240338303 A B Door,dairy ,clear
13 240456905 A B Door Stop,black ,ref
15 240451921 A B Door-refr,stainless steel, complete assy
18 240359103 ABHandle-door,black
21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
21C 218781100 A B Screw,pan head ,8-18 x 0.625
22 240328201 A B Bearing-hinge,closer
22B 240328403 A B Bearing-hinge,upper
37 240359203 A B Trim-handle,30.13" ,black ,lower
49 240324501 A B Bin-door,gallon
72 240421701 A B Button-handle mtg,dovetail
73 218396700 A B Block-handle mtg,dovetail
73A 240339101 A B Clip-trim
74 215503200 A B Screw,cr pan hd ,10-16 x 0.500
96 240345506 A B Plug,door foam hole ,black
* 218490900 A B Cleaner,stainless steel
REFRIGERATOR DOOR

01/02 6
Publication No. FRS23H5AS
5995364261
CABINET

# = Fast-moving Parts 7 01/02
* = Non-Illustrated Parts
FRS23H5AS Publication No.
5995364261
A = FRS23H5AS (FRS23H5ASB0)
B = FRS23H5AS (FRS23H5ASB1)
POS. NO PART NO DESCRIPTION
10 240435901 A B Cover-air duct
10A 240475901 A B Cover-evap coil,lower
11 5303208309 A B Plug-hole,factory test
14 # 240413601 A B Switch,light/lamp ,rocker
14A# 215486600 A B Switch-light/lamp
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240457701 A B Plate-door closer
23 240402701 A B Screw-#10-32 x 1/4 flat hd
28 240335501 A B Bolt-roller adj,hex wshr hd,1/4-20 x 4.020,(2),special
30 240419103 A B Bracket-lower hinge, ref
30A 240419104 A B Bracket-lower hinge
37 240337603 A B Trim-cabinet corner,black
38 240327202 A B Bracket-upper hinge
40 240327003 A B Cover-upper hinge,black
41 240358701 A B Grommet-shelf mtg,1.40" long
41* 240358801 A B Grommet-shelf mtg,.875" long
42 240315301 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
45 241500301 A B Screw,hex washer head ,8-18AB x 0.500
47 240349401 A B Channel-shelf mtg,side ,(2)
58 218749600 A B Screw,#10 pan hd ,8-18 x .5
66 240504901 A B Cover-damper
66* 240518802 A B Pin-push,push-in ,plastic
66A 240505001 A B Damper-meat keeper
66B 240355901 A B Insulation-damper
72 240324405 A B Grille/Kickplate,black
81 5308016566 A B Screw,hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326103 A B Cover,access ,system compt ,with label
90 218249807 A B Seal-coil cover
91 240380101 A B Duct-ice maker
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
100 240423701 A B Support,crisper cover ,front ,(4)
100* 240350802 A B Support,crisper cover ,rear ,(4)
150 240368701 A B Guide-control bulb
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* 240479601 A B Plug,button ,cab liner holes
* 5303305345 A B Paint,touch-up ,black
CABINET

01/02 8
Publication No. FRS23H5AS
5995364261
SHELVES

# = Fast-moving Parts 9 01/02
* = Non-Illustrated Parts
FRS23H5AS Publication No.
5995364261
A = FRS23H5AS (FRS23H5ASB0)
B = FRS23H5AS (FRS23H5ASB1)
POS. NO PART NO DESCRIPTION
2 240434601 A B Trim-basket
11 240338801 A B Shelf-freezer,flip-up
11A 240338703 A B Shelf-freezer,fixed wire
24 240355211 A B Shelf-"Spill-Safe",fixed
24A 240355209 A B Shelf-"Spill-Safe",fixed
24B 240350107 A B Shelf-"Spill-Safe",cantilever ,sliding
25 240354501 A B Cover-crisper pan,upper
25* 240362101 A B Clip-slide,cover-crisper
25A 240354601 A B Cover-crisper pan,lower
26 240354705 A B Pan-crisper,upper
26* 240349801 A B Clip-slide,pan-crisper
26A 240351101 A B Control-humidity
27 240354805 A B Pan-crisper,lower
39 240430705 A B Trim-shelf,front
39A 240430701 A B Trim-shelf,front
42 240356501 A B Hanger-meat pan,RH
42A 240349701 A B Hanger-meat pan,LH
42A* 240349901 A B Block-meat pan rail,LH
42A* 240350001 A B Spring-meat pan rail
47 240350635 A B Insert-pan cover,glass
47A 240350614 A B Insert-pan cover,glass
49 240338401 A B Basket-sliding
49B 240338501 A B Basket-sliding,upper ,half
51 240343002 A B Hanger-basket,RH
52 240343102 A B Hanger-basket,LH
54 240351901 A B Plug-hanger,right hand
55 240352001 A B Plug-hanger,left hand
62 240355505 A B Pan-meat
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
97 240453003 A B Water Tank Assy, coiled tubing, front filter
100 240326301 A B Cover-water tank
101 218493100 A B Screw,hex washer head ,8-18AB x 1-3/4
123 215005100 A B Screw-roller/hanger,8-10 x 0.438
126 218867401 A B Channel,auger mtg ,LH
126 218867402 A B Channel,auger mtg ,RH
140 240430501 A B Channel,water tube cvr
SHELVES

01/02 10
Publication No. FRS23H5AS
5995364261
CONTROLS
