# = Fast-moving Parts 7 02/02
* = Non-Illustrated Parts
FRS23KR4A Publication No.
5995367033
A = FRS23KR4A (FRS23KR4AB3)
B = FRS23KR4A (FRS23KR4AB4)
C = FRS23KR4A (FRS23KR4AQ3)
D = FRS23KR4A (FRS23KR4AQ4)
E = FRS23KR4A (FRS23KR4AW3)
F = FRS23KR4A (FRS23KR4AW4)
POS. NO PART NO DESCRIPTION
10 240435901 A B C D E F Cover-air duct
10A 240475901 A B C D E F Cover-evap coil,lower
11 5303208309 A B C D E F Plug-hole,factory test
14 # 240413601 A B C D E F Switch,light/lamp ,rocker
14A# 215486600 A B C D E F Switch-light/lamp
21C 218252200 A B C D E F Screw,#8 truss hd ,10-32CA x 0.500
22 240457701 A B C D E F Plate-door closer
23 240402701 A B C D E F Screw-#10-32 x 1/4 flat hd
28 240335501 A B C D E F Bolt-roller adj,hex wshr hd,1/4-20 x 4.020,(2),special
30 240419103 A B C D E F Bracket-lower hinge, ref
30A 240419104 A B C D E F Bracket-lower hinge
37 240337603 A B - - - - Trim-cabinet corner,black
37 240337604 - - C D - - Trim-cabinet corner,bisque ,(2)
37 240337601 - - - - E F Trim-cabinet corner,white ,(2)
38 240327202 A B C D E F Bracket-upper hinge
40 240327003 A B - - - - Cover-upper hinge,black
40 240327002 - - C D - - Cover-upper hinge,bisque
40 240327001 - - - - E F Cover-hinge
41 240358701 A B C D E F Grommet-shelf mtg,1.40" long
41* 240358801 A B C D E F Grommet-shelf mtg,.875" long
42 240315301 A B C D E F Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B C D E F Roller Assy,front ,(2)
45 241500301 A B C D E F Screw,hex washer head ,8-18AB x 0.500
47 218659500 A B C D E F Channel-shelf mtg,side ,(2)
58 218749600 A B C D E F Screw,#10 pan hd ,8-18 x .5
66B 240374301 A B C D E F Diffuser-air
66B* 240518802 A B C D E F Pin-push,push-in ,plastic
72 240324405 A B - - - - Grille/Kickplate,black
72 240324403 - - C D - - Grille/Kickplate,bisque
72 240324401 - - - - E F Grille/Kickplate,white
81 5308016566 A B C D E F Screw, hex wshr hd, 8-15A x 0.625, low profile
82 5304418225 A B C D E F Roller,compressor base ,rear ,(2)
83 5303316859 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326103 A B C D E F Cover,access ,system compt ,with label
90 218249807 A B C D E F Seal-coil cover
91 240380101 A B C D E F Duct-ice maker
92 5303001479 A B C D E F Screw-hinge mtg,hex hd ,1/4-20 x 0.875
100 240423701 A B C D E F Support,crisper cover ,front ,(4)
100* 240350802 A B C D E F Support,crisper cover ,rear ,(4)
150 240368701 A B C D E F Guide-control bulb
* 240481601 A B C D E F Shim-lower hinge
* 5303305345 A B - - - - Paint,touch-up ,black
* 5304414035 - - C D - - Paint,touch-up ,bisque
* 5303305324 - - - - E F Paint,touch-up ,white
CABINET
