Frigidaire FFBN1721TV0 Operating manual

Technical Service Manual, Four-door Refrigerator
MODEL FFBN1721TV0
Publication # 5995695680 May 2018
™

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Table of Contents
Page 3
Important Safety Instructions......................................... 5
Safe Servicing Practices for All Appliances................. 5
Safety Precautions ...................................................... 6
Fire Hazard .................................................................. 6
Electrical Shock Hazard .............................................. 6
Safety Instructions for Refrigerant............................... 6
Before Servicing........................................................ 6
After Testing.............................................................. 6
After Repairing .......................................................... 6
General Warnings ........................................................ 7
Grounding Instructions ................................................ 8
Electrostatic Discharge (ESD)...................................... 8
Precautions ............................................................... 8
Product Information ....................................................... 9
Model Layout............................................................... 9
External Dimension.................................................... 10
Product Specification ................................................ 11
Technical Specification........................................... 11
Electrical Parameters .............................................. 11
Defrosting Parts ...................................................... 11
Refrigerating Temperature ...................................... 12
Circuit Diagram ....................................................... 12
Installation and Commissioning ................................ 13
Handling.................................................................. 13
Installation Location................................................ 13
Adjustment to Level Door ....................................... 13
Levelling of Refrigerator.......................................... 13
Refrigerating Piping System ...................................... 14
Theory of Operation - 3-Way Valve ........................... 15
Connections............................................................ 15
Testing 3-Way Valve ............................................... 15
Theory of Operation - Fan Motor............................... 15
Removal and Replacement of Parts ............................ 16
Inside Fresh-food Compartment ............................... 16
Door Seal ................................................................ 16
Light Assembly ....................................................... 16
Air Duct ................................................................... 16
Fan Motor................................................................ 17
Fresh-food Temperature Sensor............................. 18
Fresh-food Defrost Sensor ..................................... 18
Evaporator .............................................................. 18
Deodorizer............................................................... 19
Rollover Beam......................................................... 19
Inside Freezer Compartment..................................... 20
Freezer Partition...................................................... 20
Air Duct ................................................................... 20
Fan Motor................................................................ 20
Freezer Temperature Sensor .................................. 21
Freezer Defrost Sensor ........................................... 21
Evaporator .............................................................. 21
On Refrigerator...........................................................22
Light Switch.............................................................22
Ambient Temperature and Humidity Sensor ...........22
Display Control Panel ..............................................22
Main Control Panel ..................................................22
Sealed System..............................................................23
Warnings ....................................................................23
Introduction ................................................................24
Compressor................................................................24
Refrigeration Systems................................................24
Sealed System Repair................................................24
Definitions ..................................................................24
Recovery:.................................................................24
Recycling: ................................................................24
Reclaim:...................................................................24
Charging Sealed Systems..........................................25
Soldering ....................................................................25
Basic Components.....................................................25
Refrigerant Cycle .....................................................25
Recovering Refrigerant ..............................................26
Low/High Side Leak or Undercharge.........................26
Testing for Refrigerant Leaks .....................................27
Checking for Internal Leaks .......................................27
Compressor Replacement .........................................27
Flushing System with Nitrogen ..................................28
Installing New Compressor ........................................28
Freezer Evaporator and Suction Line Replacement ..30
Condenser Replacement ...........................................31
Filter-drier Replacement.............................................31
Installing Evacuation and Recharging Equipment .....32
Evacuating System.....................................................32
Charging System........................................................33
Final Leak Test ...........................................................33
Dedicated Equipment.................................................33
Vacuum Pump Maintenance ......................................34
Vacuum Chart..........................................................34
Function & Operation....................................................35
Operation Panel .........................................................35
Button.........................................................................35
Display........................................................................35
Locking and Unlocking ..............................................35
Temperature Setting ..................................................35
Mode Setting..............................................................35
Test Mode ..................................................................36
Operating Mode.......................................................36
Forced Compressor Operating Mode Control Rule 36
Forced Defrosting Mode Control Rule.....................36
Self-Diagnosis ............................................................36
Automatic Defrost Operation .....................................37
Air Circulation Patterns............................................37

Table of Contents
Service Manual -Four-door Refrigerator (FFBN1721TV0)
Page 4
Troubleshooting ........................................................... 38
Refrigeration Fault Codes and Solutions................... 38
No Cooling................................................................. 39
No Cooling of Freezer Compartment and Fresh-food
Compartment.......................................................... 39
Freezer Compartment Cooling, Fresh-food Compart-
ment not Cooling .................................................... 40
Compressor Failure ................................................... 41
Defrosting not Working.............................................. 42
Fan Failure ................................................................. 43
Lights Inside Fresh-food Compartment not Switching
Off ..............................................................................44
Electrical Diagrams .......................................................45
Main Board.................................................................45
Power Supply.............................................................46
Test Circuit for Door Switch.......................................47
Fan Motor Circuit of Freezer Compartment ...............48
Test Circuit for Sensor ...............................................49
Resistance Values of Sensor (R/T) .............................50

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Important Safety Instructions
Page 5
Important Safety Instructions
Safe Servicing Practices for All Appliances
Avoid personal injury and/or property damage by observing important Safe Servicing Practices.
Following are some limited examples of safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to complete the repair in a safe and satisfactory manner.
2. DO NOT exceed maximum recommended wattage on light bulb replacements. Doing so could blow fuses and/or damage trans-
formers.
3. Before servicing or moving an appliance:
•Remove power cord from the electrical outlet, trip circuit breaker to the OFF position, or remove fuse.
•Turn off water supply if applicable.
•Turn off gas supply if applicable.
4. Never interfere with the proper operation of any safety device.
5. Use ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE. Substitutions may defeat compliance with safety
standards set for home appliances.
6. GROUNDING: The standard color coding for safety ground wires is GREEN, or GREEN with YELLOW STRIPES. Ground leads are
not to be used as current carrying conductors. It is EXTREMELY important that the service technician reestablish all safety grounds
prior to completion of service. Failure to do so will create a hazard.
7. Prior to returning the product to service, ensure that:
•All electrical connections are correct and secure.
•All electrical leads are properly dressed and secured away from sharp edges, high-temperature components, or moving parts.
•All non-insulated electrical terminals, connectors, heaters, etc. are adequately spaced away from all metal parts and panels.
•All safety grounds (both internal and external) are correctly and securely connected. All panels are properly and securely reas-
sembled.
•All mounting hardware, mounting brackets, and anti-tip devices are properly installed and engaged.
Service Tips - Develop Good Work Habits
Consistently following a standard routine when servicing appliances will insure that you do not waste time searching for a complex
solution to a simple problem. One of the most common mistakes made by service technicians is failing to verify the incoming power
supply to the appliance.
Many times electronic controls and other components are replaced unnecessarily because the incoming power supply was not verified.
When testing the electrical supply, the test should be performed at the terminal block where the power cord or house wiring attaches to
the appliance. Verify that there are 240 volts between L1 & L2 and that there is 120 volts from L1 to Neutral and also from L2 to Neutral.
You should also check the power supply while the appliance is operating or “under load”. The power supply may show good with the
product sitting idle but fail when certain components are turned on. This can be caused by a weak connection in the customer’s house
wiring, or a faulty circuit breaker or fuse.
Another common mistake is failure to verify all component part wire harness connections. It is essential that all component connections
are checked visually and with the appropriate circuit tester. Many times components are assumed to be faulty because they do not
operate or there is an error code displayed by the electronic control system. Often the failure is caused by a loose or miswired connec-
tion which can cause the same error code as a defective component part. Newly installed appliances may have loose connections
resulting from shipping and handling conditions or improper installation. Check the wiring connections before you order replacement
parts.
When the repair has been completed, the product should be thoroughly tested to verify that the service corrected the problem and that
all of the other features and functions of the product are in proper working order. The extra time taken to do this will create consumer
confidence in your efficiency and professionalism as well as possibly saving an expensive callback.
© 2018 Electrolux Home Products, Inc.
ATTENTION
This service manual is intended for use by persons having electrical and mechanical training and a level of
knowledge of these subjects generally considered acceptable in the appliance repair trade. Electrolux Home
Products, Inc. cannot be responsible, nor assume any liability, for injury or damage of any kind arising from the use
of this manual.

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Important Safety Instructions
Page 6
Safety Precautions
Do not attempt to install, operate or service the unit until you
have read the safety precautions in this manual. Safety items
throughout this manual are labeled with a Warning, or Caution
based on the risk type.
Definitions
Fire Hazard
Electrical Shock Hazard
Safety Instructions for Refrigerant
Before Servicing
1. Disconnect the power supply cord, and then open the unit.
2. Whenever troubleshooting is performed, the power supply
must be disconnected. It may be necessary to connect the
power supply after the unit is opened, in this event:
•Disconnect the power supply cord and then open the
unit for servicing.
•Ensure that the leads remain isolated from other compo-
nents and the unit chassis by using insulation tape.
•After that, reconnect the power supply cord.
After Testing
1. Disconnect the power supply cord, and then open the unit.
2. Reconnect the leads.
3. Reassemble the unit.
4. Reconnect the power supply cord.
5. Run the unit and check all functions.
After Repairing
1. Reconnect all the leads removed from components during
testing. Reassemble the unit.
2. Reconnect the power supply cord. Run the unit and check all
functions.
3. Before performing servicing procedure, test all the connec-
tions to the component.
WARNING
POTENTIALLY HAZARDOUS SITUATION
WHICH, IF NOT AVOIDED COULD
RESULT IN DEATH OR SERIOUS INJURY.
CAUTION
POTENTIALLY HAZARDOUS SITUATION
WHICH, IF NOT AVOIDED, MAY RESULT
IN MINOR OR MODERATE INJURY.
IMPORTANT
INSTALLATION, OPERATION OR
MAINTENANCE INFORMATION WHICH IS
IMPORTANT BUT NOT HAZARD
RELATED.
FIRE HAZARD
WARNING
DO NOT OBSTRUCT THE FLOW OF AIR
VENTILATION.
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE LIQUIDS NEAR THE
APPLIANCE. READ PRODUCT LABELS
FOR WARNINGS REGARDING
FLAMMABILITY AND OTHER HAZARDS.
DO NOT SERVICE THE APPLIANCE IN
THE PRESENCE OF EXPLOSIVE FUMES.
ELECTRIC
SHOCK
WARNING
ENSURE THAT THE ELECTRICAL
INSTALLATION IS ADEQUATE AND IN
CONFORMANCE WITH THE NATIONAL
ELECTRICAL CODE, ANSI/NFPA 70—
LATEST EDITION, AND WITH ALL LOCAL
CODES AND ORDINANCES.
FAILURE TO DO SO COULD RESULT IN
FIRE, ELECTRICAL SHOCK, OR OTHER
PERSONAL INJURY.
RISK OF FIRE
OR
EXPLOSION
FLAMMABLE REFRIGERANT USED.
TO BE REPAIRED ONLY BY TRAINED
SERVICE PERSONNEL. DO NOT USE
MECHANICAL DEVICE.
DO NOT PUNCTURE REFRIGERANT
TUBING.
DISPOSE PROPERLY IN ACCORDANCE
WITH LOCAL REGULATIONS.
WARNING
1. Do not touch the interior of freezer with
wet hands. This may result in frost bite.
2. Do not damage the refrigerant circuit.
3. Do not damage the refrigerant tubing
when servicing.
4. Do not use mechanical devices or other
means to accelerate the defrosting
process, other than those recom-
mended.
NOTE
Ensure that all mounting hardware, mounting
brackets, and anti-tip devices are properly
installed and engaged.

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Important Safety Instructions
Page 7
General Warnings
CAUTION
FIRE
ELECTRIC
SHOCK
1. Read all servicing instructions.
2. Read and follow all warnings.
3. Unplug the appliance before carrying out
checks.
4. Do not attempt to service this appliance
near water.
5. Clean only with a damp cloth.
6. Do not block any ventilation openings.
7. Install in accordance with the manufac-
turer's instructions.
8. Do not install near any heat sources,
such as radiators, heat registers, stoves.
or other apparatus that produce heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third
grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replace-
ment of the obsolete outlet.
10. Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the appliance.
11. Do not attempt to modify or extend the
power cord of this appliance.
12. Do not attempt to service the appliance
during lightning storms.
13. Make sure that the available AC power
matches the voltage requirements of this
appliance.
14. Do not handle the plug with wet hands.
This could result in an electric shock.
15. Unplug the power cord by holding the
plug, never by pulling the cord. Do not
turn the appliance ON or OFF by
plugging or unplugging the power cord.
CAUTION
FIRE
ELECTRIC
SHOCK
16. Servicing is required when the appliance
has been damaged in any way, such as
the power-supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the appliance,
the appliance has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
17. While servicing, do not expose this
appliance to rain, moisture, dripping, or
splashing, and no objects filled with
liquids should be placed on top of it.
18. Do not use extension cords or
ungrounded (two prong) adapters.
19. This appliance is not intended for use by
persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person respon-
sible for their safety.
20. Children should be supervised to ensure
that they do not play with the appliance
during servicing procedure to avoid child
entrapment.
21. If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent, or similarly qualified person, in
order to avoid a hazard.
22. Leave the shelves in place when door is
open for servicing, so that children may
not easily climb inside.
23. Follow local regulations regarding
disposal of the freezer due to flammable
refrigerant and gas. All refrigeration
products contain refrigerants, which
under the guidelines of federal law must
be removed before disposal. It is the
consumer's responsibility to comply with
federal and local regulations when
disposing of this product.

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Important Safety Instructions
Page 8
Grounding Instructions
The refrigerator must be plugged into its own dedicated 115 Volt,
60 Hz., 15 Amp, AC only electrical outlet. The power cord of the
appliance is equipped with a three-prong grounding plug for your
protection against electrical shock hazards. It must be plugged
directly into a properly grounded three prong receptacle. The
receptacle must be installed in accordance with local codes and
ordinances. Consult a qualified electrician. Avoid connecting
refrigerator to a Ground Fault Interrupter (GFI) circuit. Do not use
an extension cord or adapter plug.
If the power cord is damaged, it should be replaced by an autho-
rized service technician to prevent any risk.
•Never unplug the refrigerator by pulling on the power cord.
Always grip the plug firmly, and pull straight out from the
receptacle to prevent damaging the power cord.
•Unplug the refrigerator before cleaning and before replacing
a light bulb to avoid electrical shock.
•Performance may be affected if the voltage varies by 10% or
more. Operating the refrigerator with insufficient power can
damage the compressor. Such damage is not covered under
your warranty.
•Do not plug the unit into an electrical outlet controlled by a
wall switch or pull cord to prevent the refrigerator from being
turned off accidentally.
Electrostatic Discharge (ESD)
The circuit boards and all the wire connectors to be connected
on the boards are ESD sensitive. Take the following precautions
when servicing or handling the circuit boards and wire connec-
tors.
Precautions
•Use appropriate personal grounding equipment such as wrist
straps.
•Connect the wrist straps properly with the grounding source.
•The parts to be replaced must remain fully enclosed within
ESD packs until assembled.
•Allow only trained or escorted people in the servicing area.
•Visually check all the grounding cords.
•Use shielded packaging for shipping or storing ESD sensitive
items outside the servicing area.
•Handle unpacked ESD sensitive items only when grounded.
•Do not drag test equipment as it might develop ESD.
To move ESD sensitive parts or assemblies inside a servicing
area, use one of the following:
•Static dissipative containers
•Static shielding containers
•Conductive containers or board carriers.
IMPORTANT
TO TURN OFF POWER TO YOUR REFRIG-
ERATOR YOU MUST UNPLUG THE
POWER CORD FROM THE ELECTRICAL
OUTLET.
CAUTION
TO AVOID PERSONAL INJURY OR
PROPERTY DAMAGE, HANDLE
TEMPERED GLASS SHELVES CARE-
FULLY. SHELVES MAY BREAK
SUDDENLY IF NICKED, SCRATCHED, OR
EXPOSED TO SUDDEN TEMPERATURE
CHANGE.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
WARNING
HUMAN BODY GENERATES ELECTRO-
STATIC DISCHARGE (ESD). WHEN IT
COMES IN CONTACT WITH THE TEST
UNIT, THE CURRENT DISSIPATES
THROUGH IT. HUMAN TOUCH IS
SENSITIVE ON ESD LEVELS THAT
EXCEED 4,000V. HOWEVER, THE
VOLTAGE LIMIT IN WHICH THE PCB
GETS DAMAGED IS GENERALLY 3.3 TO
30V. IF THE ELECTROSTATIC
DISCHARGE POSSESSES SUFFICIENT
ENERGY, DAMAGE COULD OCCUR IN
THE DEVICE DUE TO LOCALIZED OVER-
HEATING THAT MAY OR MAY NOT BE
VISIBLE TO HUMAN EYE.

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Product Information
Page 9
Product Information
Model Layout
FFBN1721TV0
1. Air duct in fresh-food compartment
2. Fan motor for fresh-food evaporator
3. Fresh-food evaporator
4. Air duct in freezer compartment
5. Freezer evaporator
6. Fan motor for freezer evaporator
7. Compressor
8. Display control panel
9. Main control panel
1
2
5
7
3
4
9
8
6

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Product Information
Page 10
External Dimension
All values in mm.
Front view Side view
Down view
Open Door
1805
933.5
769.5
830
655
1058
1394
130˚
23
830
Maximum angle for open door
903
657
412
1090

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Product Information
Page 11
Product Specification
Technical Specification
Electrical Parameters
Defrosting Parts
Product Name FFBN1721TV0
Compressor LJ63XZ - Includes Capacitor/121 Watts (1.25 Amps)
Climate T
Rated Voltage / Frequency 115V / 60Hz
Defrost power 230 Watts / 2 Amps
LED lamp power MAX 4 Watts
Rated current 1.9 Amps
Foam agent Cyclopentane
Energy level DOE
Refrigerant and weight R134a,145g (5.12oz)
High pressure 300 Psig (109.5°F)
Low pressure 110 Psig (109.5°F)
Name Item Type Specification
Compressor
Compressor LJ63XZ /
Starter PTC QPE2-A4R7MD3
Overload protector OLP 4TM412PHBYY-53
Winding resistance of compressor wiring terminal
Rmc: 3.1Ω±15%
Rsc: 5.7Ω±15%
Rms=Rmc+Rsc
Motor
Fan motor of freezer compartment BLDC DC12V
Fan motor of fresh-food compartment BLDC DC12V
Condensation fan //
Lights inside
refrigerator
Lights inside freezer compartment / /
Lights inside fresh-food compartment LED 12V
Refrigerator door switch Magnetic switch /
Defrosting period Initial power on Normal defrosting period
Power on for 4 hours Cumulative operation for 8-14 hours by compressor
Defrosting sensor NTC B3839
Thermal fuse Cannot be restored 171°F (77°C)
Defrosting heater in freezer compartment Steel pipe 115V / 230W
1
1
C
M
2
2
3
3
S

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Product Information
Page 12
Refrigerating Temperature
Note: Temperature Tolerance ≤37°F
The actual start-up/shutdown temperature is the screen temperature plus the corresponding offset of ambient temperature in the table
below.
Circuit Diagram
Cyclic temperature 
Ambient
Temperature ≤
57°F
57< Ambient
Temperature ≤
70°F
70 < Ambient
Temperature ≤
82°F
82 < Ambient
Temperature ≤
95°F
Ambient
Temperature>
95°F
Chambers 
Offset of the start-up /
shutdown temperature in
fresh-food compartment
(when setting at 36 °F)
Start-up
Temperature +2 +1 +0.5 +0.75 +1.5
Shutdown
Temperature +1.5 +0.5 +0 +0 +0.5
Offset of the start-up /
shutdown temperature in
fresh-food compartment
(when setting at 37-46 °F)
Start-up
Temperature +2 +1 +0 +0.5 +1
Shutdown
Temperature +1 +0 -1 -0.5 +0
Freezer - Offset of the start-
up /shutdown temperature
Start-up
Temperature -2.5 +0.5 +0 +2 -1
Shutdown
Temperature -9 -4.5 -3 -2 -3
R-SnrR-Led
R-S1 R-S2
M-Heater
F-Def Heater
Fuse Fuse
F-Snr R-Def Snr
F-Def Snr
Electric Switch Valve
Main PCB
T-H Snr Panel PCB
OLP
Compressor
Capicitor
PTC
POWER
L
t
N
FM
3364
4
θθθθ
RM
* No. of wires
***
**

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Product Information
Page 13
Installation and Commissioning
Handling
1. Move the refrigerator only as shown in below picture, on a
handcart with cushion.
2. Remove all packing materials and bottom cushion, and then
move into the room for placement.
3. After moving the refrigerator into appropriate location, wait
for 2 hours before power on.
Installation Location
Select a location for installation with appropriate ventilation to
facilitate heat dissipation, which helps enhance the performance
of the refrigerator and reduce energy consumption.
Adjustment to Level Door
Use adjusting washers in the hinges under the doors, to make the
heights of the left and right doors equal and consistent.
Levelling of Refrigerator
If the refrigerator cannot be placed steady, adjust the footing to
level it.
11.81”
3.94”
3.94”
NOTE Refer to adjusting washers in use and care
manual.

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Product Information
Page 14
Refrigerating Piping System
Refrigerator
Evaporator
R-F Connection
F-Capillary Tube
R-Capillary Tube
Air-return and Heat
Exchange Tube
Electric Valve
(1 IN 2 OUT)
Freezer Evaporator
Compressor Condenser Filter Drier
Anti-condensation
pipe inside
freezer frame
Left Condenser Right Condenser

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Product Information
Page 15
Theory of Operation - 3-Way Valve
The 3-way valve regulates refrigerant flow to the fresh-food evap-
orator and the freezer evaporator, to control temperature as per
requirement. It is operated by the main control board. The valve is
composed of a magnetic coil and a valve body.
The 3-way valve coil controls the valve opening and closing
according to the 12 VDC pulses from the main board. It is difficult
to measure this current using a volt meter as it comes too quickly.
The 3-way valve coil has a resistance value of approximately 46
ohms that can be measured between the coil pins.
The valve body contains a cam, rotor and magnet. The rotor and
cam are grooved to rotate with the magnet. Refrigerant flows
through the entire valve body when the compressor is operating.
The pulses of the valve coil cause the magnet to rotate inside the
valve body. As the magnet rotates, it moves the cam at the
bottom of the valve. The cam opens or covers the ports to the
capillary tubes.
Connections
Three copper tubes are connected to the 3-way valve:
1. A tube connecting from the filter drier to the inlet on the valve
2. A capillary tube connecting the fresh-food evaporator and
the valve
3. A capillary tube connecting the freezer evaporator and the
valve.
Testing 3-Way Valve
The valve returns to “home” at the end of every freezer defrost
cycle and whenever the refrigerator is reconnected to power.
To test the valve:
1. Disconnect power from the refrigerator for at least 10
seconds, and reapply power.
2. Place a finger on top of the valve to feel the valve move as it
returns to home position.
If movement is present, the main board and valve coil are
operating correctly.
Theory of Operation - Fan Motor
The speed of the motor is controlled by the program. When the
workload is high, the speed of the fan goes high. When the user
selects Quick Chill mode in the settings, the speed of motor is
higher than normal.
Coil
Valve body
Tube from lter drier
Capillary tube to fresh food Capillary tube to freezer

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Removal and Replacement of Parts
Page 16
Inside Fresh-food Compartment
Door Seal
Door seal is installed into the door liner groove.
1. Open the refrigerator door.
2. Hold the door seal and pull out as shown in Figure 1.
Light Assembly
Light inside the fresh-food compartment is located in the ceiling
of the chamber.
1. Disconnect power and open the refrigerator door fully.
2. Remove the refrigerator shelves.
3. Open the snaps of the lamp cover using a flat-head
screwdriver as shown in Figure 2 and remove the cover.
4. Open the snaps of the LED light using a flat-head
screwdriver as shown in Figure 3 and take the light assembly
out.
5. Disconnect the wire connector and remove the LED light.
Air Duct
1. Disconnect power and open the refrigerator door fully.
2. Remove the refrigerator shelves.
3. Remove the crisper boxes.
4. Remove crisper cover.
5. Remove the crisper support by removing 4 screws as shown
in Figure 4.
NOTE
TO REINSTALL OR REPLACE PARTS,
REVERSE THE REMOVAL PROCEDURES
IN PROPER ORDER.
CAUTION
BEFORE SERVICING THE UNIT, TURN
OFF ELECTRICAL SUPPLY TO THE UNIT.
Figure 1
Figure 2
Figure 3
Figure 4
Pull out
Open snapusing
flat-head screwdriver
LED light
Fresh-food compartment
ceiling
Open snaps using
flat-head screwdriver
Disconnect
wire connector
LED light
Remove screw
Remove screws
Crisper support
Removal and Replacement of Parts

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Removal and Replacement of Parts
Page 17
6. Remove screw cap using a flat-head screwdriver.
7. Remove the screw using a Phillips-head screwdriver.
See Figure 5.
8. Hold the air duct on both sides, as shown in Figure 6 and
pull the air duct out from the fresh-food compartment.
9. Unplug the fan and temperature sensor wires and take the
air duct out from the fresh-food compartment. See Figure 7.
Fan Motor
1. Disconnect power and open the refrigerator door fully.
2. Remove the refrigerator shelves.
3. Remove the crisper boxes.
4. Remove crisper cover.
5. Remove air duct. See section Air Duct.
6. Cut the sealing tape and remove the foil as shown in Figure 8.
7. Remove the upper cover of the air duct, using a flat-head
screwdriver as shown in Figure 8.
8. Remove the 3 screws shown in Figure 9, using a Phillips-
head screwdriver.
9. Take the fan motor out.
NOTE The fresh-food fan has a 2-speed motor. See
Theory of Operation - Fan Motor.
Figure 5
Figure 6
Figure 7
Figure 8
Remove screw
Screw location
Remove screw cap
Remove air duct
Disconnect
Wire connector
Remove upper
cover
Cut sealing tape
Remove foil

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Removal and Replacement of Parts
Page 18
Fresh-food Temperature Sensor
1. Disconnect power and open the fresh-food door fully.
2. Remove the refrigerator shelves.
3. Remove the crisper boxes.
4. Remove crisper cover.
5. Remove air duct. See section Air Duct.
6. Remove fan motor. See section Fan Motor.
7. Remove the cover by opening the snaps on all sides. See
Figure 10.
8. Take the temperature sensor out.
Fresh-food Defrost Sensor
The defrost sensor is located on the upper side of the evapo-
rator, on the copper tube leading to the evaporator inlet.
1. Disconnect power and open the refrigerator door fully.
2. Remove the refrigerator shelves.
3. Remove the crisper boxes.
4. Remove crisper cover.
5. Remove air duct. See section Air Duct.
6. Cut the plastic band which fixes the sensor, using a cutting
plier. See Figure 11.
7. Take the defrost sensor out.
Evaporator
1. Disconnect power and open the refrigerator door fully.
2. Remove the refrigerator shelves.
3. Remove the crisper boxes.
4. Remove crisper cover.
5. Remove air duct. See section Air Duct.
6. Separate the defrost sensor from the evaporator. See above
section.
7. Cut the welding on inlet and outlet tubes at the locations
shown in Figure 12.
8. Remove the evaporator.
NOTE
DO NOT BREAK THE WELDING OF THE
EVAPORATOR, IF REMOVING ONLY THE
DEFROST SENSOR.
Figure 9
Figure 10
Figure 11
Figure 12
Remove screw
Remove cover
Crisper box
sensor
Fresh-food sensor
Defrost sensor
Evaporator
Cut welding on inlet
and outlet tubes

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Removal and Replacement of Parts
Page 19
Deodorizer
1. Disconnect power and open the refrigerator door fully.
2. Remove the refrigerator shelves.
3. Remove the crisper boxes.
4. Remove crisper cover.
5. Remove the crisper support by removing 4 screws as shown
in Figure 4.
6. Release snap using Phillips-head screw driver and remove
deodorizer. See Figure13.
Rollover Beam
1. Disconnect power and open the refrigerator door fully.
2. Remove screws mounting rollover beam using phillips-head
screw driver. See Figure 14.
3. Hold the hinge and gently pull out. See Figure 14.
4. Hold the rollover beam and push it up. See Figure 15.
5. Release the snap using flat-head screw driver on both top
and bottom of the rollover beam. See Figure 15.
6. Mark and disconnect the wires connecting the rollover
beam. See Figure 16.
Figure 13
Figure 14
Figure 15
Figure 16
Release snap
Remove
screw Pull out
Release
snap
Push up
Disconnect wire

Service Manual -Four-door Refrigerator (FFBN1721TV0)
Removal and Replacement of Parts
Page 20
Inside Freezer Compartment
Freezer Partition
1. Disconnect power and open the freezer door fully.
2. Remove upper drawers, lower drawers, and glass cover.
3. Remove 3 screws using Phillips-head screwdriver as shown
in Figure 17.
4. Push the freezer partition with a little force from the left
freezer compartment to the right freezer compartment as
shown in Figure 17.
5. Pull the freezer partition out.
Air Duct
1. Disconnect power and open the freezer door fully.
2. Remove upper drawers, lower drawers, and glass cover.
3. Remove freezer partition. See section Freezer Partition.
4. Hold the air duct as shown in figure 18. Slightly pull the air
duct.
5. Disconnect the fan and temperature sensor wire connectors.
6. Carefully pull the air duct out from the freezer.
Fan Motor
1. Disconnect power and open the freezer door fully.
2. Remove upper drawers, lower drawers, and glass cover.
3. Remove freezer partition. See section Freezer Partition.
4. Remove air duct. See section Air Duct.
5. Remove one screw in the front of the cover of the freezer air
duct using a Phillips-head screwdriver as shown in Figure 19.
6. Open the snaps on all sides using a flat-head screwdriver
and remove the cover of the freezer air duct. See Figure 20.
NOTE The freezer fan has a 2-speed motor. See
Theory of Operation - Fan Motor.
Figure 17
Figure 18
Figure 19
Figure 20
Remove screws
Push towards
right
Pull out
Disconnect wire
connectors
Pull out
Remove screw
Open snaps
