Frigidaire FRS23LH5D User manual

Product No. FRS23LH5DSR FRS23LH5DSS
Series R134a R134a
Color stain/blk stain/blk
Volts 115 115
Wiring Diagram 241526901 241526901
Owner's Guide 241661500 241661500
Market North America North America
Energy Guide 241538736 241538736
Service Data Sheet 240389616 240389616
N58L00001.eps N58FACBBB4.eps N58RACBBB7.eps N58BAAAAB0.eps
N58SJCAAB12.eps N58TAAAAA6.eps N58CAAAAA5.eps N58XDAAAA1.eps
N58YBAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps
u x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995450664
05/10/06
(EN/SERVICE/WC)
357
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS23LH5D
Copyright ©2005 Home Pr oducts, Inc.
All rights reserved.

Publication No: 5995450664 FRS23LH5D
10/05 2
FREEZER DOOR

FRS23LH5D Publication No: 5995450664
# Functional Parts 3 10/05
* Non-Illustrated Parts
FREEZER DOOR
Model Index: AFRS23LH5D (FRS23LH5DSR)
BFRS23LH5D (FRS23LH5DSS)
POS. NO PART NO. DESCRIPTION
1 # 241569808 A B Gasket-frzr door, black, magnetic
4A 240367301 A B Bin-door, frzr-upper
4B 240359001 A B Bin-door
11 241668184 A B Door-frzr, stainless, complete assy
13A 240581906 A B Door Stop, black, frzr
18 218762703 A B Handle-door, black
21A 240598401 A B Screw, 10-32 x 1/2
21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
21C 218781100 A B Screw, pan head, 8-18 x 0.625
22A 240328202 A B Bearing-hinge(frz), closer
22A 240328204 A B Bearing-hinge(frz), black, closer
22C 240328404 A B Bearing-hinge, black, upper
37 218811620 A B Trim-handle, black, upper
37* 218676004 A B Band-decorative, satin aluminum, handle trim
37A 218811617 A B Trim-handle, black, lower
37A* 215782300 A B Lock-handle trim, snap-in
68 241525101 A B Chute-ice
* 218490901 A B Cleaner, stainless steel
* 240352102 A B Connector-water, straight
* 240552101 A B Harness-wiring, door
* 5303918256 A B Dispenser heater kit

Publication No: 5995450664 FRS23LH5D
10/05 4
REFRIGERATOR DOOR
21A
22
13
15
22B
2
7
49
49
4
4
21C
21C 37A
37
18
N58RACBBB7
12

FRS23LH5D Publication No: 5995450664
# Functional Parts 5 10/05
* Non-Illustrated Parts
REFRIGERATOR DOOR
Model Index: AFRS23LH5D (FRS23LH5DSR)
BFRS23LH5D (FRS23LH5DSS)
POS. NO PART NO. DESCRIPTION
2 # 241569807 A B Gasket, refr door seal, black, magnetic
4 240363701 A B Bin-door, 2-liter
7 240338303 A B Door, dairy, clear
12 240572601 A B Label-nameplate
13 240581905 A B Door Stop, black, ref
15 241534528 A B Door-refr, stainless, complete assy
18 218762703 A B Handle-door, black
21A 240598401 A B Screw, 10-32 x 1/2
21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
21C 218781100 A B Screw, pan head, 8-18 x 0.625
22 240328201 A B Bearing-hinge(ref), closer
22 240328203 A B Bearing-hinge, black, closer
22B 240328403 A B Bearing-hinge, black, upper
22B 240328404 A B Bearing-hinge, black, upper
37 218811620 A B Trim-handle, black, upper
37* 218676004 A B Band-decorative, satin aluminum, handle trim
37A 218811617 A B Trim-handle, black, lower
37A* 215782300 A B Lock-handle trim, snap-in
49 240324502 A B Bin-door, gallon
* 218490901 A B Cleaner, stainless steel

Publication No: 5995450664 FRS23LH5D
10/05 6
CABINET

FRS23LH5D Publication No: 5995450664
# Functional Parts 7 10/05
* Non-Illustrated Parts
CABINET
Model Index: AFRS23LH5D (FRS23LH5DSR)
BFRS23LH5D (FRS23LH5DSS)
POS. NO PART NO. DESCRIPTION
10 240435905 A B Cover-air duct
10A 240475906 A B Cover-evap coil, lower
11 5303208309 A B Plug-hole, factory test
14 # 240505801 A B Switch, light/lamp
14A 241547901 A B Switch-light/lamp, frzr door
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 240457701 A B Plate-door closer
22 240457702 A B Plate-door closer
23 240402701 A B Screw-#10-32 x 1/4 flat hd
28 240335501 A B Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 241603701 A B Bracket-lower hinge, ref
30A 241603702 A B Bracket-lower hinge
37 240337603 A B Trim-cabinet corner, black, (2)
38 240327201 A B Bracket-upper hinge
40 240327007 A B Cover-upper hinge, black
41 241550801 A B Grommet-shelf mtg, 1.40" long
41* 241550701 A B Grommet-shelf mtg, .96" long
42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B Roller Assy, adjustable, front, (2)
45 241500301 A B Screw, hex washer head, 8-18AB x 0.500
47 218659500 A B Channel-shelf mtg, side, (2)
58 218781100 A B Screw, pan head, 8-18 x 0.625
66B 240374301 A B Diffuser-air
66B* 240518802 A B Pin-push, push-in, plastic
72 240324405 A B Grille/Kickplate, black
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574601 A B Cover access
90 218249807 A B Seal-coil cover
91 240380101 A B Duct-ice maker
92 216850900 A B Screw, hex washer hd, 1/4 x 7/8, hinge mtg
100 240423701 A B Support, crisper cover, front, (4)
100* 240350802 A B Support, crisper cover, rear, (4)
150 240368701 A B Guide-control bulb
* 240396801 A B Clamp, tube/wiring, nylon, black/natural
* 240479601 A B Plug, button, cab liner holes, (2)
* 5303305345 A B Paint, touch-up, black

Publication No: 5995450664 FRS23LH5D
10/05 8
SHELVES
N58SJCAAB12
11B
11A
126
81
81
126
39B
39B
97
81
24
24
24
42
62
123
42
51
25
26
47
25A
27
47A
52
101
101
49
11
39
26A
140

FRS23LH5D Publication No: 5995450664
# Functional Parts 9 10/05
* Non-Illustrated Parts
SHELVES
Model Index: AFRS23LH5D (FRS23LH5DSR)
BFRS23LH5D (FRS23LH5DSS)
POS. NO PART NO. DESCRIPTION
11 241657601 A B Shelf, flip up, wire
11A 241657501 A B Shelf, fixed, freezer
11B 241657503 A B Shelf, fixed upper, freezer
24 240355211 A B Shelf-"Spill-Safe", fixed
25 240354502 A B Cover-crisper pan, upper
25* 240362101 A B Clip-slide, cover-crisper
25A 240354602 A B Cover-crisper pan, lower
26 240354705 A B Pan-crisper, upper
26* 240349801 A B Clip-slide, pan-crisper
26A 240351101 A B Control-humidity
27 240354807 A B Pan-crisper, lower
39 240430705 A B Trim-shelf, front
39B 240430701 A B Trim-shelf, front
42 240356501 A B Track, meat pan hanger, RH
47 240350635 A B Insert-pan cover, glass
47A 240350614 A B Insert-pan cover, glass
49 240564301 A B Basket-sliding
51 240343002 A B Hanger-basket, RH
52 240343102 A B Hanger-basket, LH
62 240355506 A B Pan-meat
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
97 240545302 A B Water Tank Assy, coiled tubing, rear filter
101 218493100 A B Screw, hex washer head, 8-18AB x 1-3/4
123 215005100 A B Screw, hanger/rlr mtg, 8-10 x 0.438
126 241630701 A B Channel, auger mtg, LH
126 241630702 A B Channel, auger mtg, RH
140 240430501 A B Channel, wtr tube cover

Publication No: 5995450664 FRS23LH5D
10/05 10
CONTROLS
140
139
81
138
137
81
151
150
115
23
22
53
81
101
15
16
21A 21
18
17
81
81
81
N58TAAAAA6
149
14
13
9
8
5
