Frigidaire FRT21NRH User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21NRHB5 FRT21NRH R134a System black 115
FRT21NRHD5 FRT21NRH R134a System almond 115
FRT21NRHW5 FRT21NRH R134a System white 115
MARKET
North America
Publication No.
5995343489
000914
-EN/SERVICE /DJH
357
REFRIGERATOR
Model No.
FRT21NRH
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 193832
OWNER’S GUIDE - # 218972200
SERVICE DATA SHEET - #218755000
101 Masters Blvd.
Anderson, SC 29624

09/00 2
Publication No. FRT21NRH
5995343489
DOOR

# = Fast-moving Parts 3 09/00
* = Non-Illustrated Parts
FRT21NRH Publication No.
5995343489
DOOR
A = FRT21NRH (FRT21NRHW5)
B = FRT21NRH (FRT21NRHD5)
C = FRT21NRH (FRT21NRHB5)
POS. NO PART NO DESCRIPTION
1 215608913 A B - Gasket-frzr door,white ,magnetic
1 # 215608923 - - C Gasket-frzr door,black ,magnetic
2 # 218730609 A B - Gasket-refr door,white ,magnetic
2 # 218730622 - - C Gasket-refr door,black ,magnetic
3 215393201 A B C Panel-inner door,refr
4 218763644 A B C Rack-door,23.09" x 2.04"
4A 218763643 A B C Rack-door,22.51" x 2.04"
4B 218763642 A B C Rack-door,9.24" x 2.04"
5 218758601 A B C Support-door rack,RH/LH
5A 218809701 A B C Support-door rack,LH
5B 218809801 A B C Support-door rack,RH
7 5303304569 A B C Door-dairy,12.96" wide ,clear ,no graphics
8 218763645 A B C Rack-door,23.47" x 2.04" ,(2)
9 215530301 A B C Panel-inner door,frzr
10 5308000134 A - - Plug-button,white ,hinge brg hole
10 5303001308 - B - Plug-button,almond ,hinge brg hole
10 5303272397 - - C Plug-button,black ,hinge brg hole
11 5303917826 A - - Panel-frzr door,white ,w/insulation
11 5303917827 - B - Panel-frzr door,almond ,w/insulation
11 5303918031 - - C Panel-frzr door,black ,w/insulation
12 218917601 A - - Label-nameplate,white
12 218917602 - B - Label-nameplate,almond
12 218917603 - - C Label-nameplate,black
13 218800300 A B C Door Stop,plated
13A 218249001 A - - Door Stop,white ,frzr section
13A 218249002 - B - Door Stop,almond ,frzr section
13A 218249003 - - C Door Stop,black ,frzr section
14 218915701 A - - Plug-button,white
14 218915702 - B - Plug-button,almond
14 218915703 - - C Plug-button,black
14B 218074001 A - - Plug-button,white ,refr door front ,1 ,lower
14B 218074002 - B - Plug-button,almond ,refr door front ,lower
14B 218074003 - - C Plug-button,black ,refr door front ,lower
15 5303917828 A - - Panel-refr door,white ,w/insul & brace
15 5303917829 - B - Panel-refr door,almond ,w/insul & brace
15 5303918030 - - C Panel-refr door,black ,w/insulation
18 218668001 A - - Handle-door,white
18 218668002 - B - Handle-door,almond
18 218668003 - - C Handle-door,black
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C Bearing-hinge
37 218811621 A - - Trim-handle,white ,upper ,w/chrome band
37 218811622 - B - Trim-handle,almond ,upper ,w/chrome band
37 218811623 - - C Trim-handle,black ,upper
37A 218811613 A - - Trim-handle,white ,lower ,w/chrome band
37A 218811614 - B - Trim-handle,almond ,lower ,w/chrome band
37A 218811626 - - C Trim-handle,black ,lower
58 218781100 A B C Screw,pan head ,8-18 x 0.625
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)

09/00 4
Publication No. FRT21NRH
5995343489
CABINET

# = Fast-moving Parts 5 09/00
* = Non-Illustrated Parts
FRT21NRH Publication No.
5995343489
A = FRT21NRH (FRT21NRHW5)
B = FRT21NRH (FRT21NRHD5)
C = FRT21NRH (FRT21NRHB5)
POS. NO PART NO DESCRIPTION
1 5304402655 A B C Cover-fan
2 5303307351 A B C Knob-damper control
3 5303001028 A B C Nut,push-on
4 218722200 A B C Damper-fan cover,black
5 # 218649000 A B C Fan Blade,black
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303205118 A B C Bracket-motor mtg,front
10 218973801 A B C Cover-evap coil
10* 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg
11 5303208309 A B C Plug-hole,factory test
12 215079000 A B C Plug-harness hole,round
12 215079100 A B C Plug-wtr inlet tube,round
13 # 218878801 A B C Motor-evap fan
14 5303205119 A B C Bracket-motor mtg,rear
14 5303322992 A B C Bracket-motor mtg,rear
17 218974001 A B C Trough-drain
18 215245000 A B C Support-evap cover,(2)
19 5303001198 A B C Tube,rubber
20 5303001286 A B C Ferrule-inner
21 5303001287 A B C Ferrule-outer
22 215774901 A - - Plug-button,white ,upr hinge holes
22 215774911 - B - Plug-button,almond ,upr hinge holes
22 215774918 - - C Plug-button,black ,upr hinge holes
23 5303210377 A B C Tube-drain,w/seal ring
24 5303207353 A B C Seal Ring,drain tube
25 215774100 A B C Spout-drain tube,w/mounting pins
26 218605101 A - - Base-cabinet,white
26 218605102 - B - Base-cabinet,almond
26 218605103 - - C Base-cabinet,black
27 5303212922 A B C Screw-leveling
28 5303271412 A B C Bolt-roller adj,hex hd sems ,1/4-28 x 2.750,(2)
29 218875801 A B C Washer,nylon ,0.245 ID w/nibs
29* 218666700 A B C Washer,.28 x .62 x .03 ,nylon
30 218220203 A B C Bracket-lower hinge,zinc chromate
30* 218605200 A B C Tapping Plate/Gusset,RH
30* 218605300 A B C Tapping Plate/Gusset,LH
35 218998901 A - - Bracket-ctr hinge,light gray
35 218998902 - B - Bracket-ctr hinge,almond
35 218998903 - - C Bracket-ctr hinge,black
36 218251300 A B C Pin-center hinge
37 5303321081 A - - Trim-cabinet corner,white
37 5303321082 - B - Trim-cabinet corner,almond
37 5303321083 - - C Trim-cabinet corner,black
38 3206100 A B C Bracket-upper hinge
40 3206101 A - - Cover-upper hinge,white
40 3206105 - B - Cover-upper hinge,almond
40 5304400454 - - C Cover-upper hinge,black
41 5303001609 A B C Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C Grommet,shelf mtg ,1.25" ,LH
43 218703001 A B C Roller Assy,front ,(2)
43* 5308009790 A B C Spring-roller adj
43* 5308011326 A B C Washer,.34 x .62 x .02 ,nylon
44 218713600 A B C Roller Assy,rear ,(2)
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
45* 218754500 A B C Screw,hex hd ser wshr ,8-18 x 0.375
46 5308009762 A B C Bolt-roller mtg,hex wshr hd ,1/4-28 x 0.500,(2)
47 218233300 A B C Channel-shelf mtg,side ,(2)
56 218220300 A B C Pin-lower hinge
58 5308002748 A B C Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B C Screw,pan hd ,10-32 x 0.625 ,hinge/mullion,thrd form
71 218515401 A B C Clip-grille
72 218916404 A - - Grille/Kickplate,white ,w/fasteners
72 218916405 - B - Grille/Kickplate,almond ,w/fasteners
72 218916406 - - C Grille/Kickplate,black ,w/fasteners
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
CABINET

09/00 6
Publication No. FRT21NRH
5995343489
CABINET

# = Fast-moving Parts 7 09/00
* = Non-Illustrated Parts
FRT21NRH Publication No.
5995343489
CABINET
A = FRT21NRH (FRT21NRHW5)
B = FRT21NRH (FRT21NRHD5)
C = FRT21NRH (FRT21NRHB5)
POS. NO PART NO DESCRIPTION
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C Bracket-connector
92 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099701 A - - Plug-button,white
98 215099711 - B - Plug-button,almond
98 215099718 - - C Plug-button,black
100 5303288973 A B C Support-pan cover
110 215363501 A B C Support-crisper rod
116 215426703 A B C Rod-crisper support
* 5308016571 A B C Plug-button,cab liner holes
* 218905701 A B C Cover-sound insul,pressboard/foam, machine compt
* 5303305324 A - - Paint,touch-up ,white
* 5303305325 - B - Paint,touch-up ,almond
* 5303321321 - - C Paint,touch-up ,black

09/00 8
Publication No. FRT21NRH
5995343489
SHELVES

# = Fast-moving Parts 9 09/00
* = Non-Illustrated Parts
FRT21NRH Publication No.
5995343489
SHELVES
A = FRT21NRH (FRT21NRHW5)
B = FRT21NRH (FRT21NRHD5)
C = FRT21NRH (FRT21NRHB5)
POS. NO PART NO DESCRIPTION
1 218651900 A - - Mullion,white
1 218651901 - B - Mullion,almond
1 218651902 - - C Mullion,black
5 # 218781002 A B C Heater-mullion
6 218845602 A B C Tapping Plate,mullion mtg ,(2)
7 218866101 A B C Top Panel-refr
8 218909706 A B C Divider,styrofoam ,w/foil tape
8* # 218878600 A B C Wiring Harness,control/divider
9 218865900 A B C Bottom Panel-frzr
10 215667501 A B C Tray-ice,plastic
11 5303288243 A B C Shelf-freezer,fixed/flat ,full width ,wire
11* 5303299664 A B C Spacer-shelf
12 218730000 A B C Deflector-air
13 218631001 A B C Cover-air deflector
14 # 5309918806 A B C Switch-light/lamp
15 # 5303001179 A B C Light Bulb/Lamp,40 W
16A# 218906801 A B C Socket-light/lamp
17 5304414816 A B C Control Box
17* 5308016567 A B C Nut-anchor
18 5303311079 A B C Knob-temp control
19 # 5303286905 A B C Switch-energy saver,rocker type
21 # 5304403736 A B C Control-temperature
21* 5303001260 A B C Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C Tube,sensor sleeve ,plastic ,clear
22B 218731104 A B C Tube,PVC ,white ,@ air deflector ,insulator
23 # 215846606 A B C Timer-defrost,60 Hz ,120 V ,10 hour/30 min
23* 5303001259 A B C Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 215919117 A B C Frame-full shelf,cantilever
24A 215919174 A B C Frame-full shelf,cantilever ,w/hanger tabs
25 215363203 A B C Cover-crisper pan,less insert
25A 5304412423 A B C Trim-crisper cover
25A* 5303301393 A B C Control-humidity
26 215363301 A B C Pan-crisper,tilt-out
28 3201150 A B C End Cap-shelf,protector ,frzr shelf
29 215919405 A B C Trim-glass shelf,26.80" ,front
31 215742602 A B C Pan-meat
34 5303212918 A B C Container-ice
40 218498176 A B C Glass-shelf,26.76" x 14.57"
41 215919805 A B C Trim-glass shelf,26.80" ,rear
42 218971202 A B C Hanger-meat pan,LH
42 218971302 A B C Hanger-meat pan,RH
46 215412106 A B C Front-crisper pan,(2)
47 218498178 A B C Insert-pan cover,glass
59 218188000 A B C Screw,pan hd,10-32x 0.625,hinge/mullion,thrd form
60 5303207328 A B C Screw,hex washer head ,8-15A x 1.000 ,(2)
61 215781501 A B C Shelf-ice tray,wire
67 215357813 A B C Front-meat pan
81 218362500 A B C Screw,hex washer head ,8-18AB x 1.250
123 215005100 A B C Screw-roller/hanger,8-10 x 0.438
145 218660800 A B C Clip,plastic ,temp sensor mtg ,snap-in
* 3205266 A B C Edge Protector,wiring harness

09/00 10
Publication No. FRT21NRH
5995343489
SYSTEM

# = Fast-moving Parts 11 09/00
* = Non-Illustrated Parts
FRT21NRH Publication No.
5995343489
SYSTEM
A = FRT21NRH (FRT21NRHW5)
B = FRT21NRH (FRT21NRHD5)
C = FRT21NRH (FRT21NRHB5)
POS. NO PART NO DESCRIPTION
1 # 218657100 A B C Condenser
1* 5304406039 A B C Spacer-tube,5/8 OD x 3" lg
1* 5304406040 A B C Spacer-tube,5/8 OD x 12" lg
1* 5304406721 A B C Spacer-cond tube,round ,5/8 OD x .81"lg
1* 5304406722 A B C Spacer-tube,5/8 OD x 2" lg
2 5308000296 A B C Bracket,condenser mtg ,(4)
4 # 218944001 A B C Drier-filter,R134a System
5 # 218878600 A B C Wiring Harness,control/divider
6 # 215257001 A B C Wiring Harness,compressor
7 # 5316254901 A B C Cord-electric power
8 5303001197 A B C Cover-wiring
13 # 215076408 A B C Heat Exchanger,suction line
14 # 5317842502 A B C Heater-defrost
15 # 218955701 A B C Evaporator,bundy
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
17 218973901 A B C Insulator-evap,plastic
18 218773700 A B C Insulation Block,RH
20 218821201 A B C Insulation Block,LH
21 # 218969902 A B C Thermostat-defrost
22 5308013663 A B C Plate-compr mtg
23 218254500 A B C Grommet-compr mtg,(4)
24 5308003633 A B C Washer-compr mtg
25 5308003596 A B C Clip-compressor mtg
26 215372500 A B C Pan-defrost drain
26* 5308017610 A B C Sound Tape,defrost pan
27 5303001348 A B C Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C Pan Retainer Kit,Service
29 # 218973601 A B C Compressor,w/o electricals
30 # 218721108 A B C Starter-PTC
32 218973501 A B C Clamp,elec cont mtg ,compressor
41 5308000039 A B C Screw,hex washer hd ,8-32CA x 0.5,(7),serrated hd
43 5303001199 A B C Clamp-wiring harness,strain relief ,galv steel
43* 5308000133 A B C Clamp,nylon ,.625 ID
44 218974101 A B C Clamp,nylon ,1.00 OD tube
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
45* 218754500 A B C Screw,hex hd ser wshr ,8-18 x 0.375
45* 5300141713 A B C Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 # 218909901 A B C Capacitor-run,220 VAC ,15 microfarad
* 218905701 A B C Cover-sound insul,pressboard/foam,machine compt
* # 5300189383 A B C Hot Tube Repair Kit,Service

09/00 12
Publication No. FRT21NRH
5995343489
WIRING SCHEMATIC

# = Fast-moving Parts 13 09/00
* = Non-Illustrated Parts
FRT21NRH Publication No.
5995343489
WIRING DIAGRAM
W193832
