Frigidaire FRT15IB3A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT15IB3AQ1 FRT15IB3A R134a bisque 115
FRT15IB3AT1 FRT15IB3A R134a bisque 115
FRT15IB3AW1 FRT15IB3A R134a white 115
FRT15IB3AZ1 FRT15IB3A R134a white 115
MARKET
North America
Publication No.
5995365037
020131
-EN/SERVICE/DCS
390
TOP MOUNT
REFRIGERATOR
Model No.
FRT15IB3A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - # 240379007
OWNER’S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007

01/02 2
Publication No. FRT15IB3A
5995365037
DOOR

# = Fast-moving Parts 3 01/02
* = Non-Illustrated Parts
FRT15IB3A Publication No.
5995365037
A = FRT15IB3A (FRT15IB3AQ1)
B = FRT15IB3A (FRT15IB3AT1)
C = FRT15IB3A (FRT15IB3AW1)
D = FRT15IB3A (FRT15IB3AZ1)
POS. NO PART NO DESCRIPTION
1 # 240514601 A B C D Gasket-frzr door,white ,magnetic
2 # 240514602 A B C D Gasket-refr door,white ,magnetic
4 240331404 A B C D Rack-door,18.65"
4A 240331407 A B C D Rack-door,9.04"
5 240311502 A B C D Support-door rack,2 liter ,RH
5A 240331502 A B C D Support-door rack,gallon ,RH
6 240311501 A B C D Support-door rack,2 liter ,LH
6A 240331501 A B C D Support-door rack,gallon ,LH
7 240337701 A B C D Door-dairy,w/o graphics ,white
8 240331405 A B C D Rack-door,16.21"
10 240381302 A B - - Plug-button,bisque ,hinge brg hole ,(2)
10 240381301 - - C D Plug-button,white ,hinge brg hole ,(2)
12 240415203 A B - - Label-nameplate,bisque
12 240415201 - - C D Label-nameplate,white
11 240415402 A B - - Door,frzr ,bisque ,complete assy
11 240415401 - - C D Door,frzr ,white ,complete assy
13 240312407 A B - - Door Stop,bisque ,ref
13 240312403 - - C D Door Stop,white ,ref
13A 240312408 A B - - Door Stop,bisque ,frzr
13A 240312404 - - C D Door Stop,white ,frzr
14 240494002 A B - - Plug-button,bisque
14 240494001 - - C D Plug-button,white
15 240415502 A B - - Door,refr ,bisque ,complete assy
15 240415501 - - C D Door,refr ,white ,complete assy
18A 218428119 A B - - Handle-door,bisque ,w/block & screw
18A 218428101 - - C D Handle-door,white ,w/block & screw
21 240383401 A B C D Screw,truss hd quad ,#10-16 x .500
21A 240521301 A B C D Screw,#10-16 x 1/2
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 240311201 A B C D Bearing-hinge,natural color ,(8)
73 218396700 A B C D Block-handle mtg,dovetail
74 215503200 A B C D Screw,cr pan hd ,10-16 x 0.500
96 240345505 A B C D Plug,door foam hole ,white
DOOR

01/02 4
Publication No. FRT15IB3A
5995365037
CABINET

# = Fast-moving Parts 5 01/02
* = Non-Illustrated Parts
FRT15IB3A Publication No.
5995365037
A = FRT15IB3A (FRT15IB3AQ1)
B = FRT15IB3A (FRT15IB3AT1)
C = FRT15IB3A (FRT15IB3AW1)
D = FRT15IB3A (FRT15IB3AZ1)
POS. NO PART NO DESCRIPTION
1 240355401 A B C D Cover-fan
2 240367001 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 240367401 A B C D Damper-fan cover
5 # 5308000010 A B C D Fan Blade,red ,evaporator fan
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303292396 A B C D Bracket-motor mtg,front
10 240462004 A B C D Cover-evap coil
10* 240371301 A B C D Seal,insulation ,46.15 in. long ,foam, coil cover
10*# 240385401 A B C D Wiring Harness,freezer section
11 5303208309 A B C D Plug-hole,factory test
13 # 240369701 A B C D Motor-evap fan
13* 218931001 A B C D Clamp-motor wiring,nylon, w/adhesive tape
14 5303292397 A B C D Bracket-motor mtg,rear
18 240411901 A B C D Support-evap cover,(2)
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 215774919 A B - - Plug-button,bisque ,upr hinge holes
22 215774901 - - C D Plug-button,white ,upr hinge holes
28 240335501 A B C D Bolt-roller adj,hex washer hd, 1/4-20 x 4.020,(2) ,special
30 240357104 A B - - Bracket-hinge,bisque ,bottom
30 240357102 - - C D Bracket-hinge,white ,bottom
34 240311301 A B C D Washer,hinge ,nylon ,(2)
35 240357004 A B - - Bracket-ctr hinge,bisque
35 240357002 - - C D Bracket-ctr hinge,white
35A 240336801 A B C D Spacer-hinge,center
36 240516401 A B C D Pin-center hinge
37 240337604 A B - - Trim-cabinet corner,bisque ,(2)
37 240337601 - - C D Trim-cabinet corner,white ,(2)
38 240356901 A B C D Bracket-upper hinge
40 240354403 A B - - Cover-upper hinge,bisque
40 240354401 - - C D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,1.25" ,LH
42 240423601 A B C D Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B C D Roller Assy,front ,(2)
56 240516501 A B C D Pin-lower hinge
58 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
59 240442704 A B - - Screw-#10-32 X 3/4,bisque
59 240442702 - - C D Screw-#10-32 X 3/4,white
72 240368302 A B - - Grille/Kickplate,bisque ,lower front
72 240368301 - - C D Grille/Kickplate,white
81 5308016566 A B C D Screw,hex wshr hd, 8-15A x 0.625, low profile
82 5304418225 A B C D Roller,compressor base ,rear ,(2)
83 5303316859 A B C D Rivet,flat head ,1/4 OD x 1-3/4, roller pin
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 5304414035 A B - - Paint,touch-up ,bisque
* 5303305324 - - C D Paint,touch-up ,white
CABINET

01/02 6
Publication No. FRT15IB3A
5995365037
SHELVES

# = Fast-moving Parts 7 01/02
* = Non-Illustrated Parts
FRT15IB3A Publication No.
5995365037
A = FRT15IB3A (FRT15IB3AQ1)
B = FRT15IB3A (FRT15IB3AT1)
C = FRT15IB3A (FRT15IB3AW1)
D = FRT15IB3A (FRT15IB3AZ1)
POS. NO PART NO DESCRIPTION
11 5303282284 A B C D Shelf-freezer,"table type"
12 240362502 A B C D Diffuser-air,top
13 240362601 A B C D Diffuser-air,bottom
14 240505801 A B C D Switch,light/lamp
15 240436701 A B C D Light Bulb/Lamp, A-15, 40 W, 120 V, miniature
16 # 241500701 A B C D Socket-light/lamp
17 240368001 A B C D Box-control
17*# 240388701 A B C D Wiring Harness,control box
18 240360801 A B C D Knob-control
21 # 5304421256 A B C D Control-temperature
22A 240468201 A B C D Tube, sensor sleeve, 31 inch, plastic, white
23 # 215846606 A B C D Timer-defrost, 60 Hz, 120 V, 10 hour/30 min
23* 5303001259 A B C D Screw-timer mtg,pan hd, 6-20 x 0.438, (2)
24 240360902 A B C D Shelf,sliding ,wire
25 240364706 A B C D Cover-crisper pan
26 240364501 A B C D Pan,crisper ,(2)
34 240385201 A B C D Container-ice
81 5308016566 A B C D Screw, hex washer head, 8-15A x 0.625, low profile
SHELVES

01/02 8
Publication No. FRT15IB3A
5995365037
SYSTEM

# = Fast-moving Parts 9 01/02
* = Non-Illustrated Parts
FRT15IB3A Publication No.
5995365037
A = FRT15IB3A (FRT15IB3AQ1)
B = FRT15IB3A (FRT15IB3AT1)
C = FRT15IB3A (FRT15IB3AW1)
D = FRT15IB3A (FRT15IB3AZ1)
POS. NO PART NO DESCRIPTION
1 # 240406402 A B C D Condenser,static
1* 5303208866 A B C D Spacer-cond tube,black
2 5308000296 A B C D Bracket,condenser mtg ,(4)
4 # 218944001 A B C D Drier-filter,R134a System
6 # 240375401 A B C D Wiring Harness,machine compt, w/service cord
6* # 240385401 A B C D Wiring Harness,freezer section
6* # 240388701 A B C D Wiring Harness,control box
14 # 5303918203 A B C D Defrost Heater Kit
15 # 5303918257 A B C D Evaporator Kit
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 240434001 A B C D Trough-drain
18 240362301 A B C D Insulation Block,RH
20 240362401 A B C D Insulation Block,LH
21 # 5303918202 A B C D Thermostat-defrost,kit
22* 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C D Grommet-compr mtg,(4)
25 240491501 A B C D Screw-compressor mtg, 1/4-28 x 1.16,shoulder,typ CF
26 240346901 A B C D Pan-defrost drain
29 # 5303918233 A B C D Compressor,R134a ,w/electricals
30 # 218721113 A B C D Starter-PTC
32 218740800 A B C D Clamp,elec cont mtg ,compressor
41 5308016566 A B C D Screw, hex washer head, 8-15A x 0.625, low profile
44 5303001199 A B C D Clamp-wiring harness, strain relief, galv steel
45 218897001 A B C D Screw,hex washer head ,8-32 x 1/4
55 # 218909901 A B C D Capacitor-run,220 VAC ,15 microfarad
55* 218897002 A B C D Screw,hex washer head ,8-32 x 0.375
57 240403601 A B C D Clip-wiring harness
82 5304418225 A B C D Roller,compressor base ,rear ,(2)
83 5303316859 A B C D Rivet,flat head, 1/4 OD x 1-3/4, roller pin
84 240367101 A B C D Tube-drain,lower
85 240346202 A B C D Tube-connector,suction
* 240396801 A B C D Clamp,tube/wiring ,nylon ,black/natural
* # 5303918234 A B C D Hot Tube Repair Kit,Service
* # 5303918263 A B C D Heat Exchanger Kit,suction line
SYSTEM

01/02 10
Publication No. FRT15IB3A
5995365037
ICE MAKER

# = Fast-moving Parts 11 01/02
* = Non-Illustrated Parts
FRT15IB3A Publication No.
5995365037
A = FRT15IB3A (FRT15IB3AQ1)
B = FRT15IB3A (FRT15IB3AT1)
C = FRT15IB3A (FRT15IB3AW1)
D = FRT15IB3A (FRT15IB3AZ1)
POS. NO PART NO DESCRIPTION
1 218976901 A B C D Tube-water inlet,inlet valve to ice maker
2 5304420650 A B C D Spring,shut-off arm
2* 5308000039 A B C D Screw,hex wshr hd, 8-32CA x 0.500, serrated head
3 3206299 A B C D Label,ID plate
4 3206301 A B C D Gear
5 3206303 A B C D Plate-mounting
6 3206305 A B C D Screw-ground wire,8-32 x 0.250
7 # 3206306 A B C D Motor-ice maker
8 3206312 A B C D Spacer-hold switch
9 3206313 A B C D Cam
10 3206315 A B C D Clamp
11 # 3206319 A B C D Thermal Cutoff,ice maker ,complete assy
12 # 5304420651 A B C D Wiring Harness,ice maker ,internal, with plug
13 # 3206322 A B C D Thermostat Assy,ice maker
14 5304420652 A B C D Screw,4 x 0.750 ,switch mtg.
15 # 3206324 A B C D Switch,(3)
16 5304420653 A B C D Support,phenolic
17 # 5303320545 A B C D Mold-ice maker,Radius Cube ,with heater
18 3206328 A B C D Ejector-ice
19 3206330 A B C D Bearing & Inlet
20 5304408581 A B C D Screw,8-32 x 0.375
21 3206332 A B C D Ice Stripper
22 3206333 A B C D Shut-off Arm
23 5304408582 A B C D Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B C D Lever Arm
25 3206336 A B C D Screw,8-18 x 0.562 ,lever arm/sprt
26 5304420654 A B C D Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B C D Screw,4-40 x 1.000 ,hold switch mtg, (2)
28 3206339 A B C D Screw-timing stop,4-40 x 0.375
29 3206323 A B C D Screw,4-24 x 0.750 ,(6)
30 3206341 A B C D Screw-timing adj,8-32 x 1.000
31 3206342 A B C D Insulator
32 3206343 A B C D Plate-valve switch
33 5304408583 A B C D Spring-timing adj
34 5304420655 A B C D Screw,plazscrew ,8-10 ,(3)
35 5304408585 A B C D Screw
36 3206347 A B C D Cover-ice maker
45 5308016566 A B C D Screw,hex washer head, 8-15A x 0.625, low profile
45* 218843800 A B C D Screw,hex wshr hd ,8-15A x 0.500
51 240387101 A B C D Tube-water,ice mold fill ,extension
55 # 240380301 A B C D Valve-water, single solenoid, 50/60 Hz, 105/120 V
60 218362500 A B C D Screw,hex washer head ,8-18AB x 1.250
61 218721500 A B C D Bracket-leveling,ice maker
62 218737900 A B C D Screw-IM brkt mtg, hex wshr hd, 8-32D x 0.375
64 5303001549 A B C D Clamp,0.31 ID ,steel ,copper wtr line
* 218888001 A B C D Adapter-water supply, nut & sleeve, compression ftg
* 240352403 A B C D Ice Maker, Radius Cube, 115 V, no instl parts
ICE MAKER

01/02 12
Publication No. FRT15IB3A
5995365037
WIRING SCHEMATIC

# = Fast-moving Parts 13 01/02
* = Non-Illustrated Parts
FRT15IB3A Publication No.
5995365037
WIRING DIAGRAM
