Frigidaire FRT18HS6J Instruction Manual

Product No. FRT18HS6JB0 FRT18HS6JK0 FRT18HS6JM0 FRT18HS6JQ0 FRT18HS6JS0 FRT18HS6JW0
Series R134a R134a R134a R134a R134a R134a
Color black stainless (LH) silver mist bisque stainless (RH) white
Volts 115 115 115 115 115 115
Wiring Diagram 241582401 241582401 241582401 241582401 241582401 241582401
Owner's Guide 241857201 241857201 241857201 241857201 241857201 241857201
Market North America North America North America North America North America North America
Energy Guide 241868083 241868083 241868083 241868083 241868083 241868083
Service Data Sheet 241588203 241588203 241588203 241588203 241588203 241588203
Installation Instructions 240568303 240568303 240568303 240568303 240568303 240568303
N05L00004.eps N05DCDBCA1.eps N05BBAABA17.eps N05SAAAFI21.eps
N05CAABAD4.eps W241582401.eps S241582801.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995506713
08/02/12
(EN/SERVICE/KHB)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18HS6J
Copyright ©All rights reserved.

Publication No: 5995506713 FRT18HS6J
02/08 2
DOOR
14
14
48
48A
48B
10
22
22
11
12
22
22
22
13A
13
21C
21C
10
22
14
22
1
7
2
22
N05DCDBCA1
15
21 14B
21
14B
18
21
18A
49
49

FRT18HS6J Publication No: 5995506713
# Functional Parts 3 02/08
* Non-Illustrated Parts
DOOR
Model Index: AFRT18HS6J (FRT18HS6JB0)
BFRT18HS6J (FRT18HS6JK0)
CFRT18HS6J (FRT18HS6JM0)
DFRT18HS6J (FRT18HS6JQ0)
EFRT18HS6J (FRT18HS6JS0)
FFRT18HS6J (FRT18HS6JW0)
POS. NO PART NO. DESCRIPTION
1 241872509 A B C - E - Gasket-frzr door, black, magnetic
1 241872503 - - - D - F Gasket-frzr door, white, magnetic
2 241872512 A B C - E - Gasket-refr door, black, magnetic
2 241872506 - - - D - F Gasket-refr door, white, magnetic
7 240337712 A B C D E F Door-dairy
10 240381303 A - - - - - Plug-button, black, hinge brghole
10 240381306 - - C - - - Plug-button, silver mist, hinge brg hole
10 240381302 - - - D - - Plug-button, bisque, hinge brg hole, (2)
10 240381301 - - - - - F Plug-button, white, hinge brg hole, (2)
11 240409919 A - - - - - Door, frzr, black
11 241623306 - B - - - - Door-frzr, stainless, LH, complete assy
11 240409920 - - C - - - Door-frzr, silvermist,complete assy
11 240409902 - - - D - - Door-frzr, bisque,complete assy
11 241623305 - - - - E - Door, frzr, stainless, RH, complete assy
11 240409901 - - - - - F Door-frzr, white, complete assy
12 241808601 A B C D E F Label-nameplate
13 240312405 A B C - E - Door Stop, black, refr
13 240312407 - - - D - - Door Stop, bisque, ref
13 240312403 - - - - - F Door Stop, white, ref
13A 240312406 A B C - E - Door Stop, black, frzr
13A 240312408 - - - D - - Door Stop, bisque, frzr
13A 240312404 - - - - - F Door Stop, white, frzr
14 240494003 A - - - - - Plug-button, black
14 240494006 - - C - - - Plug-button, silver mist
14 240494002 - - - D - - Plug-button, bisque
14 240494001 - - - - - F Plug-button, white
14B 240383603 A B C - E - Plug-button, black, door handle
14B 240383602 - - - D - - Plug-button, bisque, door handle
14B 240383601 - - - - - F Plug-button, white, door handle
15 240410125 A - - - - - Door, refr, black
15 241623423 - B - - - - Door, refr, stainless steel, LH
15 240410133 - - C - - - Door-refr, silver mist, complete assy
15 240410002 - - - D - - Door-refr, bisque, complete assy
15 241623422 - - - - E - Door, refr, stainless steel, RH
15 240410001 - - - - - F Door-refr, white, complete assy
18 240339203 A B C - E - Handle-door, black, refr-LH/frzr-RH
18 240339204 - - - D - - Handle-door, bisque, refr-LH/frzr-RH
18 240339201 - - - - - F Handle-door, white, refr-LH/frzr-RH
18A 240339208 A B C - E - Handle-door, black, refr-RH/frzr-LH
18A 240339209 - - - D - - Handle-door, bisque, refr-RH/frzr-LH
18A 240339206 - - - - - F Handle-door, white, refr-RH/frzr-LH
21 240383406 A B C D E F Screw, truss hd quad, #10-16 x .500, zinc
21C 218252201 A B C D E F Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 A B C - E - Bearing-hinge, black
22 240527101 - - - D - F Bearing-hinge, natural color
48 240338101 A B C D E F Bin-door, pseudo, bottom
48A 240337901 A B C D E F Bin-door, refr
48B 240338001 A B C D E F Bin-door, pseudo, gallon, refr
49 240495804 A B C D E F Bin-door, pseudo, frzr

Publication No: 5995506713 FRT18HS6J
02/08 4
CABINET

FRT18HS6J Publication No: 5995506713
# Functional Parts 5 02/08
* Non-Illustrated Parts
CABINET
Model Index: AFRT18HS6J (FRT18HS6JB0)
BFRT18HS6J (FRT18HS6JK0)
CFRT18HS6J (FRT18HS6JM0)
DFRT18HS6J (FRT18HS6JQ0)
EFRT18HS6J (FRT18HS6JS0)
FFRT18HS6J (FRT18HS6JW0)
POS. NO PART NO. DESCRIPTION
1 241652301 A B C D E F Cover-fan
2 240367001 A B C D E F Knob-damper control
3 5303001028 A B C D E F Nut, push-on
4 241523701 A B C D E F Damper-fan cover
5 # 5308000010 A B C D E F Fan Blade, red, evaporator fan
8 5300157666 A B C D E F Bushing-motor mtg, (2)
10 241652214 A B C D E F Cover-evap coil
10* 240568601 A B C D E F Seal-coil cover
10* 241520701 A B C D E F Harness-wiring, freezer
11 5303208309 A B C D E F Plug-hole, factory test
12 241557601 A B C D E F Plug-ice maker harness, rectangular
12A 240374401 A B C D E F Plug-wtr inlet tube, round, 1"
12A* 241586701 A B C D E F Plug-foam-wtr-inlet, round
13 # 241854301 A B C D E F Motor-fan
13* 215474201 A B C D E F Washer, "slinger", nylon, evap fan shaft
14 5303292397 A B C D E F Bracket-motor mtg, rear
14* 240433204 A B C D E F Screw, hex washer head, 8-18 x5/16
21C 218252201 A B C D E F Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 A B C - E - Plug-button, black, upr hinge holes
22 215774919 - - - D - - Plug-button, bisque, upr hinge holes
22 215774901 - - - - - F Plug-button, white, upr hinge holes
28 241708801 A B C D E F Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314003 A B C - E - Bracket-lower hinge, black
30 240314011 - - - D - F Bracket-lower hinge, zinc
34 240311303 A B C D E F Washer, hinge, nylon, (2)
35 240313803 A B C - E - Bracket-ctr hinge, black
35 240313806 - - - D - F Bracket-ctr hinge, zinc
35A 240336803 A B C - E - Spacer-hinge, center, black
35A 240336802 - - - D - F Spacer-hinge, center
36 240516402 A B C D E F Pin-center hinge
37 241611303 A B C - E - Trim-cabinet corner, black, (2)
37 241611304 - - - D - - Trim-cabinet corner, bisque, (2)
37 241611301 - - - - - F Trim-cabinet corner, white, (2)
38 240313701 A B C D E F Bracket-upper hinge
40 240354404 A B C - E - Cover-upper hinge, black
40 240354403 - - - D - - Cover-upper hinge, bisque
40 240354401 - - - - - F Cover-upper hinge, white
41 5308009759 A B C D E F Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 A B C D E F Screw, hex head, 1/4-20 x 5/8
43 241882901 A B C D E F Roller Assy, adjustable, front, (2)
56 240516502 A B C D E F Pin-lower hinge
58 5304456287 A B C D E F Screw, hex washer head, 8-15A x 0.500
59 240442707 A B C - E - Screw-#10-32 X 3/4, black
59 240442706 - - - D - F Screw-#10-32 X 3/4, zinc
72 241839407 A B C - E - Grille/Kickplate, black

Publication No: 5995506713 FRT18HS6J
02/08 6
CABINET

FRT18HS6J Publication No: 5995506713
# Functional Parts 7 02/08
* Non-Illustrated Parts
CABINET
Model Index: AFRT18HS6J (FRT18HS6JB0)
BFRT18HS6J (FRT18HS6JK0)
CFRT18HS6J (FRT18HS6JM0)
DFRT18HS6J (FRT18HS6JQ0)
EFRT18HS6J (FRT18HS6JS0)
FFRT18HS6J (FRT18HS6JW0)
POS. NO PART NO. DESCRIPTION
72 241839406 - - - D - - Grille/Kickplate, bisque
72 241839405 - - - - - F Grille/Kickplate, white
81 5304455650 A B C D E F Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C D E F Roller, compressor base, rear, (2)
83 5304455655 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241733907 A B C D E F Cover-access, with label
89* 241500304 A B C D E F Screw, hex washer head, 8-18AB x 0.625
92 241710601 A B C D E F Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 240479601 A B C D E F Plug, button, cab liner holes
* 5303321321 A B C - E - Paint, touch-up, black
* 5304414035 - - - D - - Paint, touch-up, bisque
* 5303321319 - - - - - F Paint, touch-up, white

Publication No: 5995506713 FRT18HS6J
02/08 8
SHELVES
11
24A
24
25
47
26
26
23
21
22A
13
12
14
18
17
15
16
58
58
31
25B
25C
N05SAAAFI21

FRT18HS6J Publication No: 5995506713
# Functional Parts 9 02/08
* Non-Illustrated Parts
SHELVES
Model Index: AFRT18HS6J (FRT18HS6JB0)
BFRT18HS6J (FRT18HS6JK0)
CFRT18HS6J (FRT18HS6JM0)
DFRT18HS6J (FRT18HS6JQ0)
EFRT18HS6J (FRT18HS6JS0)
FFRT18HS6J (FRT18HS6JW0)
POS. NO PART NO. DESCRIPTION
11 240358005 A B C D E F Shelf, freezer, full-width, wire
12 241542001 A B C D E F Diffuser, air, top
13 240362601 A B C D E F Diffuser, air, bottom
14 # 241554901 A B C D E F Switch-light/lamp
15 241555401 A B C D E F Light Bulb
16 241559801 A B C D E F Socket-light
17 240352701 A B C D E F Control Box
17* 240568607 A B C D E F Seal
17*# 240388701 A B C D E F Wiring Harness, control box
18 240360801 A B C D E F Knob, temp control
21 # 5304421256 A B C D E F Control, temperature
22A 240468201 A B C D E F Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 A B C D E F Timer-defrost
23* 5304455649 A B C D E F Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240358905 A B C D E F Shelf-"Spill-Safe", sliding
24A 240358906 A B C D E F Shelf-"Spill-Safe", sliding, w/pan hanger
25 240364714 A B C D E F Cover-crisper pan
25B 241613501 A B C D E F Control-humidity, RH
25C 241613502 A B C D E F Control-humidity, LH
26 240337107 A B C D E F Pan-crisper, clear, (2), no graphics
31 240530811 A B C D E F Pan-meat, w/o graphics, clear
47 241711219 A B C D E F Insert-pan cover, glass
58 5304455650 A B C D E F Screw, hex washer head, 8-15A x 0.625, low profile
* 241868083 A B C D E F Energy Guide

Publication No: 5995506713 FRT18HS6J
02/08 10
SYSTEM
17 21
15
20
14
20
16
1
34
34
83
44
41
82
83
82
N05CAABAD4
22
23
23
30
32
85
55
4
6
29
25
25
24
24 25
24
26
84
45
57
59
61
60
59B
59B
59A
59A
59A 58
86

FRT18HS6J Publication No: 5995506713
# Functional Parts 11 02/08
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT18HS6J (FRT18HS6JB0)
BFRT18HS6J (FRT18HS6JK0)
CFRT18HS6J (FRT18HS6JM0)
DFRT18HS6J (FRT18HS6JQ0)
EFRT18HS6J (FRT18HS6JS0)
FFRT18HS6J (FRT18HS6JW0)
POS. NO PART NO. DESCRIPTION
1 # 241785404 A B C D E F Condenser, dynamic
4 218944002 A B C D E F Drier-filter, R134a System
6 # 241607001 A B C D E F Harness-wiring, machine compt
6* # 240388701 A B C D E F Wiring Harness, control box
14 # 240356221 A B C D E F Heater-defrost
15 # 5303918274 A B C D E F Evaporator Kit
16 5308000110 A B C D E F Strap-evap/heater, aluminum, (2)
17 241801301 A B C D E F Trough-drain
20 241551902 A B C D E F Insulation Block
21 # 5303918202 A B C D E F Thermostat-defrost, kit
22 241665606 A B C D E F Base-compressor
22* 218252201 A B C D E F Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B C D E F Grommet-compr mtg, (4)
24 241812301 A B C D E F Washer-compr mtg
25 216056401 A B C D E F Clip-compressor mtg
26 241683601 A B C D E F Pan-defrost
29 # 5303918350 A B C D E F Compressor Kit
30 # 241707703 A B C D E F Starter, PTC
32 216649100 A B C D E F Clamp, elec cont mtg, compressor
34 240405201 A B C D E F Grommet, rubber, black, cond tube/wire
41 240433204 A B C D E F Screw, hex washer head, 8-18 x 5/16
44 5304456288 A B C D E F Clamp-wiring harness, strain relief, galv steel
45 241500304 A B C D E F Screw, hex washer head, 8-18AB x 0.625
55 218909913 A B C D E F Capacitor, run, 220 VAC, 15 microfarad
57 240542601 A B C D E F Clip-wiring harness
58 240569201 A B C D E F Screw, 8-18 x 0.500
59 240315502 A B C D E F Shroud-cond fan
59* 240346701 A B C D E F Tape-foam seal, shroud
59* 240359403 A B C D E F Screw-fan shroud, (2)
59A 240346501 A B C D E F Bracket-support, cond mtr, (3)
59B 240346601 A B C D E F Grommet-bracket, (3)
60 241584301 A B C D E F Motor-condenser fan
61 241639501 A B C D E F Blade-condenser fan
82 5304418225 A B C D E F Roller, compressor base, rear, (2)
83 5304455655 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B C D E F Tube-drain, rubber, lower
85 241856901 A B C D E F Tube-connector, suction
86 240409302 A B C D E F Spacer-cond tube, black
* 240396801 A B C D E F Clamp, tube/wiring, nylon, black/natural
* 5303918263 A B C D E F Heat Exchanger Kit, suction line
* 5303918222 A B C D E F Hot Tube Repair Kit, service

Publication No: 5995506713 FRT18HS6J
02/08 12
WIRING SCHEMATIC

FRT18HS6J Publication No: 5995506713
# Functional Parts 13 02/08
* Non-Illustrated Parts
WIRING DIAGRAM
