Frigidaire FRT17HB3C User manual

Product No. FRT17HB3CW5
Series R134a
Color white
Volts 115
Wiring Diagram 240398801
Owner's Guide 241694400
Market North America
Energy Guide 240592273
Service Data Sheet 240379018
Installation Instructions 240568301
N05L00004.eps N05DBDCKA0.eps N05BBAABA16.eps N05SADDCA21.eps
N05CAAAAA18.eps 240398801.eps 240398801.eps
u x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995468633
06/06/21
(EN/SERVICE/RLF)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT17HB3C
Copyright ©2006 Home Pr oducts, Inc.
All rights reserved.

Publication No: 5995468633 FRT17HB3CW5
06/06 2
DOOR
10
22
22
11
12
73
74
21A
18A
21
22
14
22
22
13A
13
21C
21C
10
22 18A
14
22
1
2
22
15
73
74
21A
N05DBDCKA0
8
4
4
4B
7

FRT17HB3CW5 Publication No: 5995468633
# Functional Parts 3 06/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 # 240554113 Gasket-frzr door, white, magnetic
2 240542116 Gasket-refr door, white, magnetic
4 240535101 Rack-door
4B 240535201 Rack-door
7 240337701 Door-dairy, w/o graphics, white
8 240535001 Rack-door
10 240381301 Plug-button, white, hinge brg hole, (2)
11 240420101 Door, frzr, white
12 240415201 Label-nameplate, white
13 240312403 Door Stop, white, ref
13A 240312404 Door Stop, white, frzr
14 240494001 Plug-button, white
15 240420201 Door, refr, white
18A 218428101 Handle-door, white, w/block & screw
21 240383406 Screw, truss hd quad, #10-16 x .500, zinc
21A 240521303 Screw, #10-16 x 1/2
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 Bearing-hinge, natural color
73 218396700 Block-handle mtg, dovetail
74 215503203 Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995468633 FRT17HB3CW5
06/06 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA16
43 21C
41
41
41
8
8
9
14
81
34
22
21C
40
89

FRT17HB3CW5 Publication No: 5995468633
# Functional Parts 5 06/06
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 241652301 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut, push-on
4 241523701 Damper-fan cover
5 # 5308000010 Fan Blade, red, evaporator fan
8 5300157666 Bushing-motor mtg, (2)
9 5303292396 Bracket-motor mtg, front
10 241652211 Cover-evap coil
10* 240568601 Seal-coil cover
10*# 241520701 Harness-wiring, freezer
11 5303208309 Plug-hole, factory test
12 241557601 Plug-ice maker harness, rectangular
12A 240374401 Plug-wtr inlet tube, round, 1"
12A* 241586701 Plug-foam-wtr-inlet, round
13 # 240369702 Motor-evap fan
13* 215474201 Washer, "slinger", nylon, evap fan shaft
13* 218931001 Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg, rear
14* 5303274237 Screw, hex washer head, 8-32CA x 0.500, motor bracket
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 215774901 Plug-button, white, upr hinge holes
30 240357106 Bracket-lower hinge
34 240311303 Washer, hinge, nylon, (2)
35 240357001 Bracket-ctr hinge, zinc
35A 240336802 Spacer-hinge, center
36 240516402 Pin-center hinge
37 241611301 Trim-cabinet corner, white, (2)
38 240356901 Bracket, upper hinge
40 240354401 Cover-upper hinge, white
41 5308009759 Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 241559604 Roller Assy, fixed, front LH
43* 241559603 Roller Assy, fixed, front RH
56 240516502 Pin-lower hinge
58 5304456287 Screw, hex washer head, 8-15A x 0.500
59 240442706 Screw-#10-32 X 3/4, zinc
72 240368301 Grille/Kickplate, white
81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574606 Cover-access, w/label
89* 241500304 Screw, hex washer head, 8-18AB x 0.625
92 241710601 Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 240479601 Plug, button, cab liner holes
* 5303321319 Paint, touch-up, white

Publication No: 5995468633 FRT17HB3CW5
06/06 6
SHELVES

FRT17HB3CW5 Publication No: 5995468633
# Functional Parts 7 06/06
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
11 5303282284 Shelf-freezer, "table type"
12 241542001 Diffuser, air, top
13 240362601 Diffuser, air, bottom
14 # 241554901 Switch-light/lamp
15 241555401 Light Bulb
16 241559801 Socket-light
17 240368001 Control Box
17* 240568607 Seal
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304421256 Control, temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 Timer-defrost
23* 5304455649 Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240360902 Shelf, sliding, wire
25 240364706 Cover, crisper pan
26 240364501 Pan, crisper, (2)
81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995468633 FRT17HB3CW5
06/06 8
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAAAAA18
22
23
23
30
32
85
55
4
6
29
26
84
45
57
25
25

FRT17HB3CW5 Publication No: 5995468633
# Functional Parts 9 06/06
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 241665701 Condenser, dynamic
4 # 218944001 Drier-filter, R134a System
6 240496101 Wiring Harness, machine compt, w/electric cord
6* 240388701 Wiring Harness, control box
6* 241520701 Harness-wiring, freezer
14 # 240356213 Heater-defrost
15 # 5303918275 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 241551802 Trough-drain
20 241551901 Insulation Block
21 # 5303918202 Thermostat-defrost, kit
22 241665403 Base-compressor
22* 218252200 Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 Grommet-compr mtg, (4)
25 240491503 Screw-compressor mtg, 1/4-28 x 1.16, (4)
26 241683601 Pan-defrost
29 # 5303918332 Compressor Kit
30 # 241527805 Starter
32 241544101 Clamp, elec cont mtg, compressor, bale wire
34 240405201 Grommet, rubber, black, cond tube/wire
41 240433204 Screw, hex washer head, 8-18 x 5/16
44 5304456288 Clamp-wiring harness, strain relief, galv steel
45 241500304 Screw, hex washer head, 8-18AB x 0.625
55 218909915 Capacitor, run, 220 VAC, 15 microfarad
57 240542601 Clip-wiring harness
58 218897004 Screw, hex washer head, 8-32 x 0.375
59 5304430246 Bracket-cond motor assy
59* 240346701 Tape-foam seal, shroud
59* 240359403 Screw-fan shroud, (2)
60 240525402 Motor, condensor fan
61 # 240524101 Fan Blade, galv steel, condenser fan
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 Tube-drain, rubber, lower
85 240553501 Tube-connector, suction
* 240396801 Clamp, tube/wiring, nylon, black/natural
* # 5303918263 Heat Exchanger Kit, suction line
* 218843801 Screw, hex wshr hd, 8-15A x 0.500
* 5303918222 Hot Tube Repair Kit, service

Publication No: 5995468633 FRT17HB3CW5
06/06 10
WIRING SCHEMATIC

FRT17HB3CW5 Publication No: 5995468633
# Functional Parts 11 06/06
* Non-Illustrated Parts
WIRING DIAGRAM
