Frigidaire FRT18B5A User manual

Product No. FRT18B5AWG
Series R134a
Color white
Volts 115
Wiring Diagram 240398801
Owner's Guide 240400112
Market North America
Energy Guide 218791432
Service Data Sheet 240379015
Installation Instructions 240568300
N05L00004.eps N05DBDCKA0.eps N05BBAABA17.eps N05SAADDA11.eps
N05CABBAB5.eps 240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378
Augusta, GA 30917
Publication No.
5995429890
05/02/24
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18B5A
Copyright ©2005 Home Pr oducts, Inc.
All rights reserved.

Publication No: 5995429890 FRT18B5AWG
02/05 2
DOOR
10
22
22
11
12
73
74
21A
18A
21
22
14
22
22
13A
13
21C
21C
10
22 18A
14
22
1
2
22
15
73
74
21A
N05DBDCKA0
8
4
4
4B
7

FRT18B5AWG Publication No: 5995429890
# Functional Parts 3 02/05
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 # 240542103 Gasket-frzr door, white, magnetic
2 # 240542106 Gasket-refr door, white, magnetic
4 240534901 Rack-door
4B 240534701 Rack-door, 4B
7 240337701 Door-dairy, w/o graphics, white
8 240534801 Rack-door
10 240381301 Plug-button, white, hinge brg hole, (2)
11 240410201 Door-frzr, white, complete assy
12 240415201 Label-nameplate, white
13 240312403 Door Stop, white, ref
13A 240312404 Door Stop, white, frzr
14 240494001 Plug-button, white
15 240410301 Door-refr, white, complete assy
18A 218428101 Handle-door, white, w/block & screw
21 240383401 Screw, truss hd quad, #10-16 x .500
21A 240521301 Screw, #10-16 x 1/2
21C 218252200 Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 Bearing-hinge, natural color
73 218396700 Block-handle mtg, dovetail
74 215503200 Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995429890 FRT18B5AWG
02/05 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA17
43 21C
41
41
41
8
8
9
14
81
34
22
21C
40
89
28

FRT18B5AWG Publication No: 5995429890
# Functional Parts 5 02/05
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 240355401 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut, push-on
4 241523701 Damper-fan cover
5 # 5308000010 Fan Blade, red, evaporator fan
8 5300157666 Bushing-motor mtg, (2)
9 5303292396 Bracket-motor mtg, front
10 240462010 Cover-evap coil
10* 240568601 Seal-coil cover
10* 241520701 Harness-wiring, freezer
11 5303208309 Plug-hole, factory test
12 241557601 Plug-ice maker harness, rectangular
12* 218843800 Screw, hex wshr hd, 8-15A x 0.500
12A 240374401 Plug-wtr inlet tube, round, 1"
12A* 241586701 Plug-foam-wtr-inlet, round
13 # 240369701 Motor-evap fan
13 # 240369702 Motor-evap fan
13* 215474201 Washer, "slinger", nylon, evap fan shaft
13* 218931001 Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg, rear
14* 240433202 Screw, hex washer head, 8-18 x 5/16
21C 218252200 Screw, #8 truss hd, 10-32CA x 0.500
22 215774901 Plug-button, white, upr hinge holes
28 240335501 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314002 Bracket-lower hinge, white
34 240311303 Washer, hinge, nylon, (2)
35 240313802 Bracket-ctr hinge, white
35A 240336802 Spacer-hinge, center
36 240516401 Pin-center hinge
37 241611301 Trim-cabinet corner, white, (2)
38 240313701 Bracket-upper hinge
40 240354401 Cover-upper hinge, white
41 5303001609 Grommet, shelf mtg, 0.69", RH
41* 5308009759 Grommet, shelf mtg, 1.25", LH, (4)
42 240578901 Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 Roller Assy, front, (2)
56 240516501 Pin-lower hinge
58 5303001343 Screw, hex washer head, 8-15A x 0.500
59 240442702 Screw-#10-32 X 3/4, white
72 240368205 Grille/Kickplate, white
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574607 Cover-access, w/label
89* 241500302 Screw, hex washer head, 8-18AB x 0.625
92 5303001479 Screw-hinge mtg, hex hd, 1/4-20 x 0.875
* 240479601 Plug, button, cab liner holes, (2)
* 5303305324 Paint, touch-up, white

Publication No: 5995429890 FRT18B5AWG
02/05 6
SHELVES

FRT18B5AWG Publication No: 5995429890
# Functional Parts 7 02/05
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
10 215667501 Tray, ice cube, plastic
11 5303282284 Shelf-freezer, "table type"
11* 5303299664 Spacer, shelf
12 241542001 Diffuser, air, top
13 240362601 Diffuser, air, bottom
14 # 241554901 Switch-light/lamp
15 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature
16 241559801 Socket-light
17 240352701 Control Box
17* 240568607 Seal
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304421256 Control, temperature
22A 5303916855 Tube, sensor sleeve, plastic, clear
23 # 241621501 Timer-defrost
23* 5303001259 Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240360905 Shelf, sliding, wire
25 240364701 Cover-crisper pan, w/ beam, less insert
26 240337101 Pan-crisper, white, (2), no graphics
30 240361801 Cover, meat pan hanger, drop through
31 240530801 Pan-meat, w/o graphics, white
47 240350608 Insert-pan cover, 23.82" x 15.50", glass
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995429890 FRT18B5AWG
02/05 8
SYSTEM
17
21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CABBAB5
22
23
23
85
4
6
29
26
84
56
45
57
25
25
30
31

FRT18B5AWG Publication No: 5995429890
# Functional Parts 9 02/05
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 240444401 Condenser, dynamic
4 # 218944001 Drier-filter, R134a System
6 240581701 Harness-wiring, machine compt
6* 240581801 Harness-wiring, compressor
6* 241520701 Harness-wiring, freezer
6* # 240388701 Wiring Harness, control box
14 # 5303918208 Defrost Heater Kit
15 # 5303918274 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 241551801 Trough-drain
20 241551901 Insulation Block
21 # 5303918202 Thermostat-defrost, kit
22 241602001 Base-compressor
22* 218252200 Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 Grommet-compr mtg, (4)
25 240491501 Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332605 Pan-defrost drain
29 # 5303918297 Compressor, w/electricals
30 # 5304433579 Relay
31 # 5304433578 Overload Protector
34 240405201 Grommet, rubber, black, cond tube/wire
41 240433202 Screw, hex washer head, 8-18 x 5/16
44 5303001199 Clamp-wiring harness, strain relief, galv steel
45 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
56 240582001 Cover-terminal
57 240542601 Clip-wiring harness
58 218897002 Screw, hex washer head, 8-32 x 0.375
59 5304430246 Bracket-cond motor assy
59* 240346701 Tape-foam seal, shroud
59* 240359401 Screw-fan shroud, (2)
60 # 240525402 Motor, condensor fan
61 # 240524101 Fan Blade, galv steel, condenser fan
82 5304418225 Roller, compressor base, rear, (2)
83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 Tube-drain, rubber, lower
85 240493101 Tube-connector, suction
* 5303918222 Hot Tube Repair Kit, service
* 5303918263 Heat Exchanger Kit, suction line

Publication No: 5995429890 FRT18B5AWG
02/05 10
WIRING SCHEMATIC
