Frigidaire FRT18KB2D User manual

Product No. FRT18KB2DW2
Series R134a System
Color white
Volts 115
Wiring Diagram 240398801
Owner's Guide 240400112
Market North America
Energy Guide 240598694
Service Data Sheet 240379015
Installation Instructions 240568300
N05L00004.eps N05DBDCKA0.eps N05BBAABA22.eps N05SAADDA11.eps
N05CBBBAC1.eps 240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378
Augusta, GA 30917
Publication No.
5995432779
05/03/29
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18KB2D
Copyright ©All rights reserved.

Publication No: 5995432779 FRT18KB2DW2
03/05 2
DOOR
10
22
22
11
12
73
74
21A
18A
21
22
14
22
22
13A
13
21C
21C
10
22 18A
14
22
1
2
22
15
73
74
21A
N05DBDCKA0
8
4
4
4B
7

FRT18KB2DW2 Publication No: 5995432779
# Functional Parts 3 03/05
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 240542103 Gasket-frzr door, white, magnetic
2 240542106 Gasket-refr door, white, magnetic
4 240534901 Rack-door
4B 240534701 Rack-door, 4B
7 240337701 Door-dairy, w/o graphics, white
8 240534801 Rack-door
10 240381301 Plug-button, white, hinge brg hole, (2)
11 240412501 Door, frzr, white, completeassy
12 240415201 Label-nameplate, white
13 240312403 Door Stop, white, ref
13A 240312404 Door Stop, white, frzr
14 240494001 Plug-button, white
15 240412601 Door, refr, white, complete assy
18A 218428101 Handle-door, white, w/block & screw
21 240383401 Screw, truss hd quad, #10-16 x .500
21A 240521301 Screw, #10-16 x 1/2
21C 218252200 Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 Bearing-hinge, natural color
73 218396700 Block-handle mtg, dovetail
74 215503200 Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995432779 FRT18KB2DW2
03/05 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA22
43 21C
41
41
41
8
8
9
14
81
34
22
21C
89
28

FRT18KB2DW2 Publication No: 5995432779
# Functional Parts 5 03/05
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 240355401 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut, push-on
4 241523701 Damper-fan cover
5 # 5308000010 Fan Blade, red, evaporator fan
8 5300157666 Bushing-motor mtg, (2)
9 5303292396 Bracket-motor mtg, front
10 240462010 Cover-evap coil
10* 240568601 Seal-coil cover
11 5303208309 Plug-hole, factory test
12 241557601 Plug-ice maker harness, rectangular
12* 218843800 Screw, hex wshr hd, 8-15A x 0.500
12A 240374401 Plug-wtr inlet tube, round, 1"
12A* 241586701 Plug-foam-wtr-inlet, round
13 240369702 Motor-evap fan
13* 215474201 Washer, "slinger", nylon, evap fan shaft
13* 218931001 Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg, rear
14* 240433201 Screw, hex washer head, 8-18 x 0.375
21C 218252200 Screw, #8 truss hd, 10-32CA x 0.500
22 215774901 Plug-button, white, upr hinge holes
28 240335501 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314001 Bracket-lower hinge, zinc
34 240311303 Washer, hinge, nylon, (2)
35 240313801 Bracket-ctr hinge, zinc
35A 240336802 Spacer-hinge, center
36 240516401 Pin-center hinge
37 241611301 Trim-cabinet corner, white, (2)
38 241622601 Hinge-up-plastc-wht, plastic, white
41 5308009759 Grommet, shelf mtg, 1.25", LH, (4)
42 240578901 Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 Roller Assy, front, (2)
56 240516501 Pin-lower hinge
58 5303001343 Screw, hex washer head, 8-15A x 0.500
59 240442701 Screw-#10-32 X 3/4, zinc
72 240368205 Grille/Kickplate, white
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89* 241500302 Screw, hex washer head, 8-18AB x 0.625
92 241624301 Screw-hinge mtg, hex head, 1/4-20 x 1.00
* 240479601 Plug, button, cab liner holes, (2)
* 240542601 Clip-wiring harness
* 5303305324 Paint, touch-up, white

Publication No: 5995432779 FRT18KB2DW2
03/05 6
SHELVES

FRT18KB2DW2 Publication No: 5995432779
# Functional Parts 7 03/05
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
10 215667501 Tray, ice cube, plastic
11 5303282284 Shelf-freezer, "table type"
11* 5303299664 Spacer, shelf
12 241542001 Diffuser, air, top
13 240362601 Diffuser, air, bottom
14 # 241554901 Switch-light/lamp
15 241555401 Light Bulb
16 241559801 Socket-light
17 240352701 Control Box
17* 240568607 Seal
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304421256 Control, temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 Timer-defrost
23* 5303001259 Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240360905 Shelf, sliding, wire
25 240364701 Cover-crisper pan, w/ beam, less insert
26 240337101 Pan-crisper, white, (2), no graphics
30 240361801 Cover, meat pan hanger, drop through
31 240530801 Pan-meat, w/o graphics, white
47 240350608 Insert-pan cover, 23.82" x 15.50", glass
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995432779 FRT18KB2DW2
03/05 8
SYSTEM
20
20
17
45
1
2
21
15
14
16
83
83
44
41
82
82
N05CBBBAC1
22
23
23
85
4
6
26
29
57
25
25
84
30 56
31

FRT18KB2DW2 Publication No: 5995432779
# Functional Parts 9 03/05
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 240406408 Condenser, static
1* 240405201 Grommet, rubber, black, cond tube/wire
1* 5303208866 Spacer, condenser tube, black
2 5308000296 Bracket, condenser mtg, (4)
4 # 218944001 Drier-filter, R134a System
6 # 240581601 Harness-wiring, machine compt
6* # 241520701 Harness-wiring, freezer
6* # 240388701 Wiring Harness, control box
6* # 240581801 Harness-wiring, compressor
14 # 5303918208 Defrost Heater Kit
15 # 5303918274 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 241551801 Trough-drain
20 241551901 Insulation Block
21 # 5303918202 Thermostat-defrost, kit
22 241602001 Base-compressor
22* 218252200 Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 Grommet-compr mtg, (4)
25 240491501 Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240598501 Pan-defrost drain
26* 5304434992 Thermal Mastic
29 # 5303918297 Compressor, w/electricals
30 # 5304433579 Relay
31 # 5304433578 Overload Protector
41 240433202 Screw, hex washer head, 8-18 x 5/16
44 5303001199 Clamp-wiring harness, strain relief, galv steel
45 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
56 240582001 Cover-terminal
57 240542601 Clip-wiring harness
82 5304418225 Roller, compressor base, rear, (2)
83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 241505701 Tube-drain, lower
85 241544301 Tube-connector, suction
* 240396801 Clamp, tube/wiring, nylon, black/natural
* 5303918234 Hot Tube Repair Kit, service
* 5303918263 Heat Exchanger Kit, suction line

Publication No: 5995432779 FRT18KB2DW2
03/05 10
WIRING SCHEMATIC

FRT18KB2DW2 Publication No: 5995432779
# Functional Parts 11 03/05
* Non-Illustrated Parts
WIRING DIAGRAM
