Frigidaire FRT18KD3A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18KD3AW2 FRT18KD3A R134a white 115
MARKET
North America
Publication No.
5995357091
010803
-EN/SERVICE/KHB
390
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KD3A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - # 240379007
OWNER’S GUIDE - # 240400104
SERVICE DATA SHEET - # 240379007

08/01 2
Publication No. FRT18KD3AW2
5995357091
DOOR

# = Fast-moving Parts 3 08/01
* = Non-Illustrated Parts
FRT18KD3AW2 Publication No.
5995357091
POS. NO PART NO DESCRIPTION
1 # 240370905 Gasket-frzr door,white ,magnetic
2 # 240370906 Gasket-refr door,white ,magnetic
4 240331401 Rack-door,20.27" x 1.72"
5 240311502 Support-door rack,2 liter ,RH
5A 240331502 Support-door rack,gallon ,RH
6 240311501 Support-door rack,2 liter ,LH
6A 240331501 Support-door rack,gallon ,LH
7 240337701 Door-dairy,w/o graphics ,white
8 240331402 Rack-door,17.99" x 1.72"
10 240381301 Plug-button,hinge brg hole ,white ,(2)
11 240412501 Door,frzr ,white ,complete assy
12 240415201 Label-nameplate,white
13 240312403 Door Stop,white ,ref
13A 240312404 Door Stop,white ,frzr
14 218915701 Plug-button,white
14A 240428301 Plug-button,screw type ,white
15 240412601 Door,refr ,white ,complete assy
18A 218428121 Handle-door,gray ,w/block & screw
21 240383401 Screw,truss hd quad ,#10-16 x .500
21C 218252200 Screw,#8 truss hd ,10-32CA x 0.500
22 240311201 Bearing-hinge,natural color ,(8)
72 218397000 Button-handle mtg,dovetail
73 218396700 Block-handle mtg,dovetail
74 215503200 Screw,cr pan hd ,10-16 x 0.500
96 240345503 Plug-foam hole,white
DOOR

08/01 4
Publication No. FRT18KD3AW2
5995357091
CABINET

# = Fast-moving Parts 5 08/01
* = Non-Illustrated Parts
FRT18KD3AW2 Publication No.
5995357091
POS. NO PART NO DESCRIPTION
1 240355401 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut,push-on
4 240367401 Damper-fan cover
5 # 5308000010 Fan Blade,red ,evaporator fan
8 5300157666 Bushing-motor mtg,(2)
9 5303292396 Bracket-motor mtg,front
10 240462005 Cover-evap coil
10* 240371302 Seal-coil cover
10*# 240385401 Wiring Harness,freezer section
11 5303208309 Plug-hole,factory test
12 240366801 Plug-ice maker harness,rectangular
12A 240374401 Plug-wtr inlet tube,round ,1"
13 # 240369701 Motor-evap fan
13* 218931001 Clamp-motor wiring,nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg,rear
14* 240433201 Screw-8-18 x 3/8,hex washer head,
18 240345801 Support-evap cover,(2)
21C 218252200 Screw,#8 truss hd ,10-32CA x 0.500
22 215774901 Plug-button,white ,upr hinge holes
28 240335501 Bolt-roller adj, hex washer head, 1/4-20 x 4.020,(2) ,special
30 240314002 Bracket-lower hinge,white
34 240311301 Washer,hinge ,nylon ,(2)
35 240313802 Bracket-ctr hinge,white
35A 240336801 Spacer-hinge,center
36 240516401 Pin-center hinge
37 240337601 Trim-cabinet corner,white ,(2)
38 240313701 Bracket-upper hinge
40 240354401 Cover-upper hinge,white
41 5303001609 Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 Grommet,shelf mtg ,1.25" ,LH
42 240423601 Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 Roller Assy,front ,(2)
56 240516501 Pin-lower hinge
58 5303001343 Screw,hex washer head ,8-15A x 0.500
59 240442702 Screw-#10-32 X 3/4,white
72 240368201 Grille/Kickplate,white
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller,compressor base ,rear ,(2)
83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
92 5303001479 Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 240479601 Plug,button ,cab liner holes
* 5303305324 Paint,touch-up ,white
CABINET

08/01 6
Publication No. FRT18KD3AW2
5995357091
SHELVES

# = Fast-moving Parts 7 08/01
* = Non-Illustrated Parts
FRT18KD3AW2 Publication No.
5995357091
POS. NO PART NO DESCRIPTION
10 215667501 Tray-ice,plastic
11 240358002 Shelf-freezer,full width
11* 5303299664 Spacer-shelf
12 240362502 Diffuser-air,top
13 240362601 Diffuser-air,bottom
13* 240392601 Seal-diffuser
14 240505801 Switch-light/lamp
15 240436701 Light Bulb/Lamp, A-15, 40 W, 120 V, miniature
16 241500701 Socket-light/lamp
17 240352701 Control Box
17*# 240388701 Wiring Harness,control box
18 240360801 Knob-control
21 # 5304421256 Control-temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 215846606 Timer-defrost, 60 Hz , 120 V, 10 hour/30 min
23* 5303001259 Screw-timer mtg,pan hd ,6-20 x 0.438, (2)
24 240360905 Shelf,sliding ,wire
25 240364701 Cover-crisper pan,w/ beam ,less insert
26 240337101 Pan-crisper,white ,(2) ,no graphics
28 3201150 End Cap-shelf,protector ,frzr shelf
30 240361801 Hanger-meat pan,drop thru
31 240354203 Pan-meat,w/o graphics ,clear
47 240350608 Insert-pan cover,23.82" x 15.50" ,glass
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
SHELVES

08/01 8
Publication No. FRT18KD3AW2
5995357091
SYSTEM

# = Fast-moving Parts 9 08/01
* = Non-Illustrated Parts
FRT18KD3AW2 Publication No.
5995357091
POS. NO PART NO DESCRIPTION
1 # 240406401 Condenser,static
1* 240405201 Grommet, mounting, rubber, black, holds tube/wire
1* 5303208866 Spacer-cond tube,black
2 5308000296 Bracket,condenser mtg ,(4)
2* 5308009617 Washer,ext tooth lock ,#10 ,grounding
4 # 218944001 Drier-filter,R134a System
6 # 240375401 Wiring Harness,machine compt, w/service cord
6* # 240385401 Wiring Harness,freezer section
6* # 240388701 Wiring Harness,control box
14 # 5303918208 Defrost Heater Kit
15 # 5303918250 Evaporator Kit
16 5308000110 Strap-evap/heater,aluminum ,(2)
17 240434002 Trough-drain
18 240362301 Insulation Block,RH
20 240362401 Insulation Block,LH
21 # 5303918202 Thermostat-defrost,kit
22 240330001 Plate-compr mtg
22* 218252200 Screw,#8 truss hd ,10-32CA x 0.500
23 216498900 Grommet,compressor
25 240420301 Screw,shoulder typ CF,1/4-28 x 0.965, hex washer head
26 240346901 Pan-defrost drain
27 5303001348 Nut,lock ,1/4-20 ,drain pan mtg
28 5303916001 Pan Retainer Kit,Service
29 # 5303918233 Compressor,R134a ,w/ electricals
30 # 218721113 Starter-PTC
32 218740800 Clamp,elec cont mtg ,compressor
41 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
41* 218897001 Screw,hex washer head ,8-32 x 1/4
44 5303001199 Clamp-wiring harness, strain relief, galv steel
55 # 218909901 Capacitor-run,220 VAC ,15 microfarad
57 240403601 Clip-wiring harness
82 5304418225 Roller, compressor base, rear, (2)
83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240367101 Tube-drain,lower
85 240346202 Tube-connector,suction
* 240396801 Clamp,tube/wiring ,nylon ,black/natural
* # 5303918263 Heat Exchanger Kit,suction line
* # 5303918234 Hot Tube Repair Kit,Service
SYSTEM

08/01 10
Publication No. FRT18KD3AW2
5995357091
WIRING SCHEMATIC

# = Fast-moving Parts 11 08/01
* = Non-Illustrated Parts
FRT18KD3AW2 Publication No.
5995357091
WIRING DIAGRAM
