Frigidaire FRT18KB2D User manual

Product No. FRT18KB2DWD
Series
Color white
Volts 115
Wiring Diagram 241582401
Owner's Guide 241857201
Market North America
Energy Guide 240598694
Service Data Sheet 241588203
Installation Instructions 240568303
N05L00004.eps N05DBDCKA0.eps N05BBAABA19.eps N05SAADDA11.eps
N05CBABAB4.eps W241582401.eps S241582801.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995514089
08/05/13
(EN/SERVICE/KHB)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18KB2D
Copyright ©All rights reserved.

Publication No: 5995514089 FRT18KB2DWD
05/08 2
DOOR
10
22
22
11
12
73
74
21A
18A
21
22
14
22
22
13A
13
21C
21C
10
22 18A
14
22
1
2
22
15
73
74
21A
N05DBDCKA0
8
4
4
4B
7

FRT18KB2DWD Publication No: 5995514089
# Functional Parts 3 05/08
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 # 241872503 Gasket-frzr door, white, magnetic
2 # 241872506 Gasket-refr door, white, magnetic
4 240534901 Rack-door
4B 240534701 Rack-door, 4B
7 240337701 Door-dairy, w/o graphics, white
8 240534801 Rack-door
10 240381301 Plug-button, white, hinge brg hole, (2)
11 240412501 Door, frzr, white, completeassy
12 241808601 Label-nameplate
13 240312403 Door Stop, white, ref
13A 240312404 Door Stop, white, frzr
14 240494001 Plug-button, white
15 240412601 Door, refr, white, complete assy
18A 218428101 Handle-door, white, w/block & screw
21 240383406 Screw, truss hd quad, #10-16 x .500, zinc
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 Bearing-hinge, natural color
73 218396701 Block-handle mtg, dovetail
74 215503203 Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995514089 FRT18KB2DWD
05/08 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA19
43 21C
41
41
41
8
8
9
14
81
34
22
21C
40

FRT18KB2DWD Publication No: 5995514089
# Functional Parts 5 05/08
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 241652301 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut, push-on
4 241523701 Damper-fan cover
5 # 5308000010 Fan Blade, red, evaporator fan
8 5300157666 Bushing-motor mtg, (2)
9 5303292396 Bracket-motor mtg, front
10 241652214 Cover-evap coil
10* 240568601 Seal-coil cover
11 5303208309 Plug-hole, factory test
12 241557601 Plug-ice maker harness, rectangular
12A 240374401 Plug-wtr inlet tube, round, 1"
12A* 241586701 Plug-foam-wtr-inlet, round
13 # 241854301 Motor-fan
13* 215474201 Washer, "slinger", nylon, evap fan shaft
13* 218931001 Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg, rear
14* 240433201 Screw, hex washer head, 8-18 x 0.375
21C 218252200 Screw, #8 truss hd, 10-32CA x 0.500
22 215774901 Plug-button, white, upr hinge holes
30 240314001 Bracket-lower hinge, zinc
34 240311303 Washer, hinge, nylon, (2)
35 240313801 Bracket-ctr hinge, zinc
35A 240336802 Spacer-hinge, center
36 240516402 Pin-center hinge
37 241611301 Trim-cabinet corner, white, (2)
38 240313701 Bracket-upper hinge
40 240354401 Cover-upper hinge, white
41 5308009759 Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 Screw, hex head, 1/4-20 x 5/8
43 241889002 Roller Assy, front LH, (2)
43* 241889001 Roller Assy, front RH, (2)
56 240516502 Pin-lower hinge
58 5304456287 Screw, hex washer head, 8-15A x 0.500
59 240442706 Screw-#10-32 X 3/4, zinc
72 241839405 Grille/Kickplate, white
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
92 241710601 Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 218515401 Clip
* 240479601 Plug, button, cab liner holes
* 240542601 Clip-wiring harness
* 5303321319 Paint, touch-up, white

Publication No: 5995514089 FRT18KB2DWD
05/08 6
SHELVES

FRT18KB2DWD Publication No: 5995514089
# Functional Parts 7 05/08
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
10 215667501 Tray, ice cube, plastic
11 5303282284 Shelf-freezer, "table type"
12 241542001 Diffuser, air, top
13 240362601 Diffuser, air, bottom
14 # 241554901 Switch-light/lamp
15 241555401 Light Bulb
16 241559801 Socket-light
17 240352702 Control Box
17* 240568607 Seal
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304421256 Control, temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 Timer-defrost
23* 5304455649 Screw, pan hd, 6-20 x 0.438
24 240360905 Shelf, sliding, wire
25 240364701 Cover-crisper pan, w/ beam, less insert
26 240337101 Pan-crisper, white, (2), no graphics
30 240361801 Cover, meat pan hanger, drop through
31 240530801 Pan-meat, w/o graphics, white
47 240350608 Insert-pan cover, 23.82" x 15.50", glass
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
* 241588203 Service Data Sheet

Publication No: 5995514089 FRT18KB2DWD
05/08 8
SYSTEM
20
20
17
45
1
2
21
15
14
16
83
83
44
41
82
82
87
N05CBABAB4
22
23
23
30
32
85
55
4
6
29
57
25
25
25
26
84
45
24
24
24

FRT18KB2DWD Publication No: 5995514089
# Functional Parts 9 05/08
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 241861903 Condenser, static
1* 240405201 Grommet, rubber, black, cond tube/wire
1* 5303208866 Spacer, condenser tube, black
2 241658801 Bracket, condenser mtg
4 218944002 Drier-filter, R134a System
6 # 241949801 Harness-wiring, machine compt
6* # 240388701 Wiring Harness, control box
6* # 240581801 Harness-wiring, compressor
14 # 240356221 Heater-defrost
15 # 5303918274 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 241801301 Trough-drain
20 241551902 Insulation Block
21 # 5303918202 Thermostat-defrost, kit
22 241665503 Base-compressor
22* 218252201 Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 Grommet-compr mtg, (4)
24 241812301 Washer-compr mtg
25 216056401 Clip-compressor mtg
26 241949701 Pan-defrost
29 # 5303918347 Compressor Kit
30 # 241707702 Starter, PTC
32 241715901 Strap-cover
41 240433204 Screw, hex washer head, 8-18 x 5/16
44 5304456288 Clamp-wiring harness, strain relief, galv steel
45 241500304 Screw, hex washer head, 8-18AB x 0.625
45* 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
55 218909913 Capacitor, run, 220 VAC, 15 microfarad
57 240542601 Clip-wiring harness
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 241949901 Tube-drain, lower
85 241844601 Tube-connector, suction
87 241949601 Tube-Condensate, 87
* 240396801 Clamp, tube/wiring, nylon, black/natural
* 5303918263 Heat Exchanger Kit, suction line
* 5303918234 Hot Tube Repair Kit, service

Publication No: 5995514089 FRT18KB2DWD
05/08 10
WIRING SCHEMATIC

FRT18KB2DWD Publication No: 5995514089
# Functional Parts 11 05/08
* Non-Illustrated Parts
WIRING DIAGRAM
