Frigidaire FRT18P6C User manual

N05L00003.eps N05DCDBCA1.eps N05BBAABD0.eps N05SAAAFE10.eps
N05CABBAB1.eps 240398801.eps 240398601.eps
Product No. FRT18P6CQ2 FRT18P6CW2
Series R134a R134a
Color bisque white
Volts 115 115
Wiring Diagram 240398801 240398801
Owner's Guide 240400110 240400110
Market North America North America
Energy Guide 240598614 240598614
Service Data Sheet 240379015 240379015
Installation Instructions 240568300 240568300
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995407672
04/04/15
(EN/SERVICE/DCS)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18P6C
Copyright ©All rights reserved.

Publication No: 5995407672 FRT18P6C
04/04 2
DOOR

FRT18P6C Publication No: 5995407672
# Functional Parts 3 04/04
* Non-Illustrated Parts
DOOR
Model Index: AFRT18P6C (FRT18P6CQ2)
BFRT18P6C (FRT18P6CW2)
POS. NO PART NO. DESCRIPTION
1 240542103 A B Gasket-frzr door, white, magnetic
2 240542106 A B Gasket-refr door, white, magnetic
7 240337703 A B Door-dairy, w/o graphics, clear
10 240381302 A - Plug-button, bisque, hinge brg hole, (2)
10 240381301 - B Plug-button, white, hinge brg hole, (2)
11 240409904 A - Panel-frzr door, bisque, complete assy
11 240409903 - B Panel-frzr door, white, complete assy
12 240572601 A B Label-nameplate
13 240312407 A - Door Stop, bisque, ref
13 240312403 - B Door Stop, white, ref
13A 240312408 A - Door Stop, bisque, frzr
13A 240312404 - B Door Stop, white, frzr
14 240494002 A - Plug-button, bisque
14 240494001 - B Plug-button, white
14B 240383602 A - Plug-button, bisque, door handle
14B 240383601 - B Plug-button, white, door handle
15 240410112 A - Panel-refr door, bisque, complete assy
15 240410111 - B Panel-refr door, white, complete assy
18 240339204 A - Handle-door, bisque
18 240339201 - B Handle-door, white
18A 240339209 A - Handle-door, bisque
18A 240339206 - B Handle-door, white
21 240383401 A B Screw, truss hd quad, #10-16 x .500
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 A B Bearing-hinge, natural color
48 240338101 A B Bin-door, pseudo, bottom
48A 240337901 A B Bin-door, refr
48B 240338001 A B Bin-door, pseudo, gallon, refr
49 240495804 A B Bin-door, pseudo, frzr

Publication No: 5995407672 FRT18P6C
04/04 4
CABINET

FRT18P6C Publication No: 5995407672
# Functional Parts 5 04/04
* Non-Illustrated Parts
CABINET
Model Index: AFRT18P6C (FRT18P6CQ2)
BFRT18P6C (FRT18P6CW2)
POS. NO PART NO. DESCRIPTION
1 240355401 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut, push-on
4 241523701 A B Damper-fan cover
5 # 5308000010 A B Fan Blade, red, evaporator fan
8 5300157666 A B Bushing-motor mtg, (2)
9 5303292396 A B Bracket-motor mtg, front
10 240462010 A B Cover-evap coil
10* 240568601 A B Seal-coil cover
10* 241520701 A B Harness-wiring
11 5303208309 A B Plug-hole, factory test
12 240366801 A B Plug-ice maker harness, rectangular
12* 218843800 A B Screw, hex wshr hd, 8-15A x 0.500
12A 240374401 A B Plug-wtr inlet tube, round, 1"
13 # 240369701 A B Motor-evap fan
13* 215474201 A B Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg, rear
14* 240433202 A B Screw, hex washer head, 8-18 x 5/16
18 240411901 A B Support-evap cover, (2)
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 215774919 A - Plug-button, bisque, upr hinge holes
22 215774901 - B Plug-button, white, upr hinge holes
28 240335501 A B Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314004 A - Bracket-lower hinge, bisque
30 240314002 - B Bracket-lower hinge, white
34 240311303 A B Washer, hinge, nylon, (2)
35 240313804 A - Bracket-ctr hinge, bisque
35 240313802 - B Bracket-ctr hinge, white
35A 240336802 A B Spacer-hinge, center
36 240516401 A B Pin-center hinge
37 240337604 A - Trim-cabinet corner, bisque, (2)
37 240337601 - B Trim-cabinet corner, white, (2)
38 240313701 A B Bracket-upper hinge
40 240354403 A - Cover-upper hinge, bisque
40 240354401 - B Cover-upper hinge, white
41 5303001609 A B Grommet, shelf mtg, 0.69", RH
41* 5308009759 A B Grommet, shelf mtg, 1.25", LH
42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B Roller Assy, front, (2)
47 218233300 A B Channel-shelf mtg, side, (2)
48 5303292395 A B Channel-shelf mtg, center
49 218362500 A B Screw, hex washer head, 8-18AB x 1.250
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw, hex washer head, 8-15A x 0.500
59 240442704 A - Screw-#10-32 X 3/4, bisque
59 240442702 - B Screw-#10-32 X 3/4, white
72 240368206 A - Grille/Kickplate, bisque
72 240368205 - B Grille/Kickplate, white

Publication No: 5995407672 FRT18P6C
04/04 6
CABINET

FRT18P6C Publication No: 5995407672
# Functional Parts 7 04/04
* Non-Illustrated Parts
CABINET
Model Index: AFRT18P6C (FRT18P6CQ2)
BFRT18P6C (FRT18P6CW2)
POS. NO PART NO. DESCRIPTION
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326115 A B Cover-access, with label
89* 241500302 A B Screw, hex washer head, 8-18AB x 0.625
92 5303001479 A B Screw-hinge mtg, hex hd, 1/4-20 x 0.875
* 240479601 A B Plug, button, cab liner holes, (2)
* 5304414035 A - Paint, touch-up, bisque
* 5303305324 - B Paint, touch-up, white

Publication No: 5995407672 FRT18P6C
04/04 8
SHELVES
25
25B
25C
26
47
N05SAAAFE10
26
11
10
10
31
42
42
123
123
37
36
43
44
24
29
40
41
37
36
43
44
23
21
22A
13
12
14
18
17
15
16
81
81
25B
25C

FRT18P6C Publication No: 5995407672
# Functional Parts 9 04/04
* Non-Illustrated Parts
SHELVES
Model Index: AFRT18P6C (FRT18P6CQ2)
BFRT18P6C (FRT18P6CW2)
POS. NO PART NO. DESCRIPTION
10 215667501 A B Tray, ice cube, plastic
11 240358002 A B Shelf-freezer, full width
12 240545001 A B Diffuser, air, top
13 240362601 A B Diffuser, air, bottom
14 # 241554901 A B Switch-light/lamp
15 240436702 A B Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature
16 241559801 A B Socket-light
17 240352701 A B Control Box
17*# 240388701 A B Wiring Harness, control box
18 240360801 A B Knob, temp control
21 # 5304421256 A B Control, temperature
22A 240468201 A B Tube, sensor sleeve, 31 inch, plastic, white
23 # 240371001 A B Timer-defrost
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240373102 A B Frame-full shelf, cantilever
25 240364714 A B Cover-crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper, humidity cont.
26 240337103 A B Pan-crisper, clear, (2), no graphics
29 240357701 A B Trim-shelf, 24.48", front
31 240530803 A B Pan-meat, w/o graphics, clear
36 240373103 A B Frame-half shelf, cantilever
37 240357702 A B Trim, shelf, 11.95", front
40 240443908 A B Glass-shelf, 24.45" x 15.92", full width
41 240357801 A B Trim-shelf, 24.48", rear
42 240530601 A B Track, meat pan hanger, LH
42 240530701 A B Track, meat pan hanger, RH
43 240443905 A B Glass-shelf, 11.92" x 15.92", half shelf
44 240357802 A B Trim, shelf, 11.95", rear
47 240350643 A B Insert-pan cover, glass
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
123 215005100 A B Screw, hanger/rlr mtg, 8-10 x 0.438
* 240598614 A B Label-energy

Publication No: 5995407672 FRT18P6C
04/04 10
SYSTEM

FRT18P6C Publication No: 5995407672
# Functional Parts 11 04/04
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT18P6C (FRT18P6CQ2)
BFRT18P6C (FRT18P6CW2)
POS. NO PART NO. DESCRIPTION
1 # 240444401 A B Condenser, dynamic
4 # 218944001 A B Drier-filter, R134a System
6 # 240581701 A B Harness-wiring, machine compt
6* 241520701 A B Harness-wiring
6* # 240388701 A B Wiring Harness, control box
6* # 240581801 A B Harness-wiring, compressor
14 # 5303918208 A B Defrost Heater Kit
15 # 5303918274 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater, aluminum, (2)
17 241551801 A B Trough-drain
20 240518402 A B Insulation, evap block, foam, LH/RH
21 # 5303918202 A B Thermostat-defrost, kit
22 240330001 A B Plate-compr mtg
22* 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B Grommet-compr mtg, (4)
25 240491501 A B Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332605 A B Pan-defrost drain
29 # 5303918297 A B Compressor, w/electricals
30 # 5304433579 A B Relay
31 # 5304433578 A B Overload Protector
34 240405201 A B Grommet, rubber, black, cond tube/wire
41 240433202 A B Screw, hex washer head, 8-18 x 5/16
44 5303001199 A B Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
56 240582001 A B Cover-terminal
57 240542601 A B Clip-wiring harness
58 218897002 A B Screw, hex washer head, 8-32 x 0.375
59 5304430246 A B Bracket-cond motor assy
59* 240346701 A B Tape-foam seal, shroud
59* 240359401 A B Screw-fan shroud, (2)
60 # 240525401 A B Motor-condenser fan
61 # 240524101 A B Fan Blade, galv steel, condenser fan
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B Tube-drain, rubber, lower
85 240493101 A B Tube-connector, suction
* 5303918222 A B Hot Tube Repair Kit, Service
* # 5303918263 A B Heat Exchanger Kit, suction line

Publication No: 5995407672 FRT18P6C
04/04 12
WIRING SCHEMATIC

FRT18P6C Publication No: 5995407672
# Functional Parts 13 04/04
* Non-Illustrated Parts
WIRING DIAGRAM
