Frigidaire FRT15B3A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT15B3AQ2 FRT15B3A R134a bisque-RH 115
FRT15B3AT2 FRT15B3A R134a bisque-LH 115
FRT15B3AW2 FRT15B3A R134a white-RH 115
FRT15B3AZ2 FRT15B3A R134a white-LH 115
MARKET
North America
Publication No.
5995372959
020528
-EN/SERVICE /KC
390
TOP MOUNT
REFRIGERATOR
Model No.
FRT15B3A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - 240379007
OWNER’S GUIDE - 240400105
SERVICE DATA SHEET - 240379007

05/02 2
Publication No. FRT15B3A
5995372959
DOOR

# = Fast-moving Parts 3 05/02
* = Non-Illustrated Parts
FRT15B3A Publication No.
5995372959
A = FRT15B3A (FRT15B3AQ2)
B = FRT15B3A (FRT15B3AT2)
C = FRT15B3A (FRT15B3AW2)
D = FRT15B3A (FRT15B3AZ2)
POS. NO PART NO DESCRIPTION
1 # 240514601 A B C D Gasket,frzr door seal ,white ,magnetic
2 # 240514602 A B C D Gasket,refr door seal ,white ,magnetic
4 240331404 A B C D Rack-door,18.65"
4A 240331407 A B C D Rack-door,9.04"
5 240311502 A B C D Support-door rack,2 liter ,RH
5A 240331502 A B C D Support-door rack,gallon ,RH
6 240311501 A B C D Support-door rack,2 liter ,LH
6A 240331501 A B C D Support-door rack,gallon ,LH
7 240337701 A B C D Door-dairy,w/o graphics ,white
8 240331405 A B C D Rack-door,16.21"
10 240381302 A B - - Plug-button,bisque ,hinge brg hole ,(2)
10 240381301 - - C D Plug-button,white ,hinge brg hole ,(2)
11 240415402 A B - - Door,frzr ,bisque
11 240415401 - - C D Door,frzr ,white
12 240415203 A B - - Label-nameplate,bisque
12 240415201 - - C D Label-nameplate,white
13 240312407 A B - - Door Stop,bisque ,ref
13 240312403 - - C D Door Stop,white ,ref
13A 240312408 A B - - Door Stop,bisque ,frzr
13A 240312404 - - C D Door Stop,white ,frzr
14 240494002 A B - - Plug-button,bisque
14 240494001 - - C D Plug-button,white
15 240415502 A B - - Door,refr ,bisque
15 240415501 - - C D Door,refr ,white
18A 218428119 A B - - Handle-door,bisque ,w/block & screw
18A 218428101 - - C D Handle-door,white ,w/block & screw
21 240383401 A B C D Screw,truss hd quad ,#10-16 x .500
21A 240521301 A B C D Screw,#10-16 x 1/2
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 240311201 A B C D Bearing-hinge,natural color ,(8)
73 218396700 A B C D Block-handle mtg,dovetail
74 215503200 A B C D Screw,cr pan hd ,10-16 x 0.500
DOOR

05/02 4
Publication No. FRT15B3A
5995372959
CABINET

# = Fast-moving Parts 5 05/02
* = Non-Illustrated Parts
FRT15B3A Publication No.
5995372959
A = FRT15B3A (FRT15B3AQ2)
B = FRT15B3A (FRT15B3AT2)
C = FRT15B3A (FRT15B3AW2)
D = FRT15B3A (FRT15B3AZ2)
POS. NO PART NO DESCRIPTION
1 240355401 A B C D Cover-fan
2 240367001 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 240367401 A B C D Damper-fan cover
5 # 5308000010 A B C D Fan Blade,red ,evaporator fan
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303292396 A B C D Bracket-motor mtg,front
10 240462004 A B C D Cover-evap coil
10* 240532101 A B C D Seal,coil cover
10*# 240385401 A B C D Wiring Harness,freezer section
11 5303208309 A B C D Plug-hole,factory test
12 240366801 A B C D Plug-ice maker harness,rectangular
* 218843800 A B C D Screw,hex wshr hd ,8-15A x 0.500
12A 240374401 A B C D Plug-wtr inlet tube,round ,1"
13 # 240369701 A B C D Motor-evap fan
13* 215474201 A B C D Washer,"slinger" ,nylon ,evap fan shaft
13* 218931001 A B C D Clamp-motor wiring,nylon ,w/adhesive tape
14 5303292397 A B C D Bracket-motor mtg,rear
18 240411901 A B C D Support-evap cover,(2)
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 215774919 A B - - Plug-button,bisque ,upr hinge holes
22 215774901 - - C D Plug-button,white ,upr hinge holes
28 240335501 A B C D Bolt-roller adj,hex washer head ,1/4-20 x 4.020,(2) ,special
30 240357104 A B - - Bracket-hinge,bisque ,bottom
30 240357102 - - C D Bracket-hinge,white ,bottom
34 240311301 A B C D Washer,hinge ,nylon ,(2)
35 240357004 A B - - Bracket-ctr hinge,bisque
35 240357002 - - C D Bracket-ctr hinge,white
35A 240336801 A B C D Spacer-hinge,center
36 240516401 A B C D Pin-center hinge
37 240337604 A B - - Trim-cabinet corner,bisque ,(2)
37 240337601 - - C D Trim-cabinet corner,white ,(2)
38 240356901 A B C D Bracket-upper hinge
40 240354403 A B - - Cover-upper hinge,bisque
40 240354401 - - C D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,1.25" ,LH
42 240423601 A B C D Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B C D Roller Assy,front ,(2)
56 240516501 A B C D Pin-lower hinge
58 240433201 A B C D Screw,hex washer head ,8-18 x 0.375
59 240442704 A B - - Screw-#10-32 X 3/4,bisque
59 240442702 - - C D Screw-#10-32 X 3/4,white
72 240368302 A B - - Grille/Kickplate,bisque ,lower front
72 240368301 - - C D Grille/Kickplate,white
78 5303274237 A B C D Screw,hex washer head ,8-32CA x 0.500 ,motor bracket
81 5308016566 A B C D Screw,hex washer head ,8-15A x 0.625 ,low profile
82 5304418225 A B C D Roller,compressor base ,rear ,(2)
83 5303316859 A B C D Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 240479601 A B C D Plug,button ,cab liner holes
* 5304414035 A B - - Paint,touch-up ,bisque
* 5303305324 - - C D Paint,touch-up ,white
CABINET

05/02 6
Publication No. FRT15B3A
5995372959
SHELVES

# = Fast-moving Parts 7 05/02
* = Non-Illustrated Parts
FRT15B3A Publication No.
5995372959
A = FRT15B3A (FRT15B3AQ2)
B = FRT15B3A (FRT15B3AT2)
C = FRT15B3A (FRT15B3AW2)
D = FRT15B3A (FRT15B3AZ2)
POS. NO PART NO DESCRIPTION
10 215667501 A B C D Tray,ice cube ,plastic
11 5303282284 A B C D Shelf-freezer,"table type"
12 240362502 A B C D Diffuser,air ,top
13 240362601 A B C D Diffuser,air ,bottom
13* 240371304 A B C D Seal,foam ,air diffuser
14 240505801 A B C D Switch,light/lamp
15 240436702 A B C D Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature
16 # 241500701 A B C D Socket-light/lamp
17 240368001 A B C D Control Box
17*# 240388701 A B C D Wiring Harness,control box
18 240360801 A B C D Knob,temp control
21 # 5304421256 A B C D Control,temperature
22A 240468201 A B C D Tube,sensor sleeve ,31 inch ,plastic ,white
23 # 215846606 A B C D Timer,defrost ,60 Hz ,0.25 W ,120 V ,10 hour/30 min
23* 5303001259 A B C D Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 240360902 A B C D Shelf,sliding ,wire
25 240364706 A B C D Cover,crisper pan
26 240364501 A B C D Pan,crisper ,(2)
81 5308016566 A B C D Screw,hex washer head ,8-15A x 0.625 ,low profile
SHELVES

05/02 8
Publication No. FRT15B3A
5995372959
SYSTEM

# = Fast-moving Parts 9 05/02
* = Non-Illustrated Parts
FRT15B3A Publication No.
5995372959
A = FRT15B3A (FRT15B3AQ2)
B = FRT15B3A (FRT15B3AT2)
C = FRT15B3A (FRT15B3AW2)
D = FRT15B3A (FRT15B3AZ2)
POS. NO PART NO DESCRIPTION
1 # 240406403 A B C D Condenser,static
1* 240405201 A B C D Grommet,rubber ,black ,cond tube/wire
1* 5303208866 A B C D Spacer,condenser tube ,black
2 5308000296 A B C D Bracket,condenser mtg ,(4)
4 # 218944001 A B C D Drier-filter,R134a System
6 # 240375401 A B C D Wiring Harness,machine compt ,w/service cord
6* # 240388701 A B C D Wiring Harness,control box
6* # 240385401 A B C D Wiring Harness,freezer section
* 240396801 A B C D Clamp,tube/wiring ,nylon ,black/natural
* 218843800 A B C D Screw,hex wshr hd ,8-15A x 0.500
14 # 5303918203 A B C D Defrost Heater Kit
15 5303918275 A B C D Evaporator Kit
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 240434001 A B C D Trough-drain
18 240362301 A B C D Insulation Block,RH
20 240362401 A B C D Insulation Block,LH
21 # 5303918202 A B C D Thermostat-defrost,kit
22 240330005 A B C D Base-compressor
22* 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C D Grommet-compr mtg,(4)
25 240491501 A B C D Screw-compressor mtg, 1/4-28 x 1.16,shoulder,typ CF
26 240332603 A B C D Pan-defrost drain
29 # 5303918264 A B C D Compressor,w/electricals
30 # 218721120 A B C D Starter,PTC
32 240493301 A B C D Clamp,elec cont mtg ,compressor ,bale wire
41 218897001 A B C D Screw,hex washer head ,8-32 x 1/4
44 5303001199 A B C D Clamp-wiring harness,strain relief ,galv steel
45 5308016566 A B C D Screw,hex washer head ,8-15A x 0.625 ,low profile
55 # 218909901 A B C D Capacitor-run,220 VAC ,15 microfarad
57 240542601 A B C D Clip-wiring harness
82 5304418225 A B C D Roller,compressor base ,rear ,(2)
83 5303316859 A B C D Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
84 240500801 A B C D Tube-drain,lower
85 240493101 A B C D Tube-connector,suction
* # 5303918263 A B C D Heat Exchanger Kit,suction line
* # 5303918234 A B C D Hot Tube Repair Kit,Service
SYSTEM

05/02 10
Publication No. FRT15B3A
5995372959
WIRING SCHEMATIC

# = Fast-moving Parts 11 05/02
* = Non-Illustrated Parts
FRT15B3A Publication No.
5995372959
WIRING DIAGRAM
