Frigidaire FRT22RGJ User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT22RGJB0 FRT22RGJ R134a black 115V
FRT22RGJD0 FRT22RGJ R134a almond 115V
FRT22RGJW0 FRT22RGJ R134a white 115V
MARKET
North America
Publication No.
5995336400
000413
-EN/SERVICE /DJH
357
REFRIGERATOR
Model No.
FRT22RGJ
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - #218663500
OWNER’S GUIDE - #218971800
SERVICE DATA SHEET - # 218901900
101 Masters Blvd.
Anderson, SC 29624

04/00 2
Publication No. FRT22RGJ
5995336400
DOOR

# = Fast-moving Parts 3 04/00
* = Non-Illustrated Parts
FRT22RGJ Publication No.
5995336400
DOOR
A = FRT22RGJ (FRT22RGJW0)
B = FRT22RGJ (FRT22RGJD0)
C = FRT22RGJ (FRT22RGJB0)
POS. NO PART NO DESCRIPTION
1 # 215608915 A B - Gasket-frzr door,white ,magnetic
1 # 215608925 - - C Gasket-frzr door,black ,magnetic
2 # 218730614 A B - Gasket-refr door,white ,magnetic
2 # 218730616 - - C Gasket-refr door,black ,magnetic
3 # 218979001 A B C Door-Refr interior,panel
4 218763647 A B C Rack-door
4A 218763648 A B C Rack-door
4B 218763649 A B C Rack-door
5 218809701 A B C Support-door rack,LH
5A 218809801 A B C Support-door rack,RH
7 5303304569 A B C Door-dairy,12.96" wide ,clear ,no graphics
8 218763641 A B C Rack-door
9 215278301 A B C Panel-inner door,frzr
10 218696501 A - - Plug-button,white ,lg closer hole
10 218696502 - B - Plug-button,almond ,lg closer hole
10 218696503 - - C Plug-button,black ,lg closer hole
11 5303918024 A - - Panel-frzr door,white ,w/foam insulatn
11 5303918025 - B - Panel-frzr door,almond ,w/foam insulatn
11 5303918080 - - C Panel-frzr door,black ,w/foam insulatn
12 218156538 A - - Nameplate Assy,white ,with magnet
12 218156539 - B - Nameplate Assy,almond ,with magnet
12 218156540 - - C Nameplate Assy,black ,with magnet
12* 215008613 A - - • Label-nameplate,white
12* 215008614 - B - • Label-nameplate,almond
12* 215008615 - - C • Label-nameplate,black
12* 218364001 A - - • Frame-nameplate,white
12* 218364002 - B - • Frame-nameplate,almond
12* 218364003 - - C • Frame-nameplate,black
12* 215518000 A B C • Magnet-nameplate
13 5303289522 A B C Door Stop
13A 215030001 A - - Door Stop,white ,frzr
13A 215030011 - B - Door Stop,almond ,frzr
13A 215030018 - - C Door Stop,black ,frzr
14 218915701 A - - Plug-button,white
14 218915702 - B - Plug-button,almond
14 218915703 - - C Plug-button,black
15 5303918022 A - - Panel-refr door,white ,w/foam insulatn
15 5303918023 - B - Panel-refr door,almond ,w/foam insulatn
15 5303918081 - - C Panel-refr door,black ,w/foam insulatn
18 218668001 A - - Handle-door,white
18 218668002 - B - Handle-door,almond
18 218668003 - - C Handle-door,black
21A 218578600 A B C Screw-door stop mtg,phl truss hd ,10-16 x 3/4
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 5303289320 A B C Bearing-hinge
37 218811636 A - - Trim-handle,1.74" ,white ,upper
37 218811637 - B - Trim-handle,almond ,upper ,w/gold band
37 218811638 - - C Trim-handle,1.74" ,black ,upper
37* 218676003 A B C • Band-decorative,gold
37* 218906701 A B C • Lock-handle trim,stick-on
58 218781100 A B C Screw,pan head ,8-18 x 0.625
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)

04/00 4
Publication No. FRT22RGJ
5995336400
CABINET

# = Fast-moving Parts 5 04/00
* = Non-Illustrated Parts
FRT22RGJ Publication No.
5995336400
A = FRT22RGJ (FRT22RGJW0)
B = FRT22RGJ (FRT22RGJD0)
C = FRT22RGJ (FRT22RGJB0)
POS. NO PART NO DESCRIPTION
1 215937600 A B C Shroud-evap fan mtg
5 # 5303292398 A B C Fan Blade
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303292396 A B C Bracket-motor mtg,front
10 5303294238 A B C Cover-evap coil
11 5303208309 A B C Plug-hole,factory test
12 5303292393 A B C Plug-decorative,ice maker holes
13 # 218661700 A B C Motor-evap fan
13* 215474201 A B C Washer,"slinger" ,nylon ,evap fan shaft
13* 215935700 A B C Nut-anchor
14 5303292397 A B C Bracket-motor mtg,rear
17 5304415955 A B C Trough-drain
18 215245000 A B C Support-evap cover,(2)
22 215774901 A - - Plug-button,white ,upr hinge holes
22 215774911 - B - Plug-button,almond ,upr hinge holes
22 215774918 - - C Plug-button,black ,upr hinge holes
23 215266301 A B C Tube-drain,w/seal ring
24 5303207353 A B C Seal Ring,drain tube
25 5303292412 A B C Spout-drain tube
28 5303289062 A B C Bolt-roller adj,hex head ,5/16-24 x 7/8
29 215003200 A B C Washer,.40 x .63 x .16 ,nylon
29 215314301 A B C Washer,.40 x .75 x .06 ,nylon
29* 215314300 A B C Washer,.40 x .75 x .06 ,nylon
30 5303289060 A B C Bracket-lower hinge,RH/LH ,w/hinge pin
30* 218979601 A B C Tapping Plate,lower hinge
30* 218979701 A B C Tapping Plate,lower hinge
34 218737000 A B C Washer-ctr hnge pin
35 218220101 A - - Bracket-ctr hinge,light gray
35 218220102 - B - Bracket-ctr hinge,almond
35 218220103 - - C Bracket-ctr hinge,black
36 218971101 A B C Pin-center hinge
37 5303321081 A - - Trim-cabinet corner,white
37 5303321082 - B - Trim-cabinet corner,almond
37 5303321083 - - C Trim-cabinet corner,black
38 218215243 A - - Bracket-upper hinge,with closer ,white ,LH
38 218215251 - B - Bracket-upper hinge,with closer ,almond
38 218215244 - - C Bracket-upper hinge,with closer ,black ,LH
38* 5304403492 A B C Tapping Plate,upper hinge ,(2)
40 5303318773 A - - Cover-upper hinge,white
40 5303318774 - B - Cover-upper hinge,almond
40 5303323268 - - C Cover-upper hinge,black
41 5303294246 A B C Grommet-shelf mtg,1.25" long
41* 5303294247 A B C Grommet-shelf mtg,.69" long
43 218615300 A B C Roller Assy,front ,(2)
43* 5308017044 A B C Screw-roller mtg,spcl ind hex hd ,5/16-18(23)x7/8
44 218738300 A B C Roller Assy,rear ,(2)
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
45* 218754500 A B C Screw,hex hd ser wshr ,8-18 x 0.375
47 218233300 A B C Channel-shelf mtg,side ,(2)
48 5303292395 A B C Channel-shelf mtg,center
52 215454600 A B C Tube-water,ice mold fill ,elbow
52* 215058000 A B C Plug-wtr inlet tube
58 5308002748 A B C Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B C Screw,pan hd ,10-32 x 0.625 ,hinge/mullion,thread forming
60 218362500 A B C Screw,hex washer head ,8-18AB x 1.250
65 5303001361 A B C Pin-mounting,push-in ,plastic
72 218359604 A - - Grille/Kickplate,white
72 218359608 - B - Grille/Kickplate,almond
72 218359612 - - C Grille/Kickplate,black
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C Bracket-connector
89 5303288947 A B C Cover-machine compt
CABINET

04/00 6
Publication No. FRT22RGJ
5995336400
CABINET

# = Fast-moving Parts 7 04/00
* = Non-Illustrated Parts
FRT22RGJ Publication No.
5995336400
CABINET
A = FRT22RGJ (FRT22RGJW0)
B = FRT22RGJ (FRT22RGJD0)
C = FRT22RGJ (FRT22RGJB0)
POS. NO PART NO DESCRIPTION
92 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
93 218362601 A - - Plug-grille,white
93 218362602 - B - Plug-grille,almond
93 218362603 - - C Plug-grille,black
94 5303319993 A B C Cover-air duct
94* 218044800 A B C Seal-air duct cover
95 218663101 A B C Gasket-air duct cvr
96 215775901 A B C Cover-fan access
97 5303289299 A B C Bracket-IM plug
98 215099701 A - - Plug-button,white
98 215099711 - B - Plug-button,almond
98 215099718 - - C Plug-button,black
100 5303288973 A B C Support-pan cover
* 215848000 A B C Spacer-air channel
* 5303305324 A - - Paint,touch-up ,white
* 5303305325 - B - Paint,touch-up ,almond
* 5303321321 - - C Paint,touch-up ,black
* 5308016571 A B C Plug-button,cab liner holes

04/00 8
Publication No. FRT22RGJ
5995336400
SHELVES

# = Fast-moving Parts 9 04/00
* = Non-Illustrated Parts
FRT22RGJ Publication No.
5995336400
SHELVES
A = FRT22RGJ (FRT22RGJW0)
B = FRT22RGJ (FRT22RGJD0)
C = FRT22RGJ (FRT22RGJB0)
POS. NO PART NO DESCRIPTION
1 218652300 A B - Mullion,white
1 218652310 - - C Mullion,black
5 # 218752300 A B C Heater-mullion
6 218845601 A B C Tapping Plate,mullion mtg ,(2)
7 218907501 A B C Top Panel-refr,HASC
8 218909707 A B C Divider,styrofoam ,w/foil tape
8* # 218965501 A B C Harness-wiring,main
9 215058300 A B C Bottom Panel-frzr
10 215667501 A B C Tray-ice,plastic
11 5304409141 A B C Shelf-freezer,w/trim
11* 5303299664 A B C Spacer-shelf
12 218634902 A B C Deflector-air,"paddle"
12* 215363801 A B C Spacer-air deflectr
12* 215363901 A B C Washer-air deflectr
13 218629900 A B C Cover-air deflector
13* 215935700 A B C Nut-anchor
14 # 5309918806 A B C Switch-light/lamp
15 # 5303001179 A B C Light Bulb/Lamp,40 W
16A 218906801 A B C Socket-light/lamp
17 215932906 A B C Control Box
17* 5308016567 A B C Nut-anchor
18 5304414917 A B C Knob-temp control,refr
18A 5304414918 A B C Knob-temp control,(damper)
19 # 5303286905 A B C Switch-energy saver,rocker type
21 # 5304402184 A B C Control-temperature
21* 5303001260 A B C Screw-control mtg,pan hd ,6-32 x 0.250
22 218660701 A B C Tube,insulator ,plastic ,on temp sensor
23 # 215846606 A B C Timer-defrost,60 Hz ,120 V ,10 hour/30 min
23* 215277000 A B C Cover-defrost timer,top
23* 5303001259 A B C Screw-timer mtg,pan hd ,6-20 x 0.438
23* 5303289058 A B C Shield-defrost timr,btm
24 215406138 A B C Shelf-"Spill-Safe",fixed ,(3)
25 215216651 A B C Cover-crisper pan
26 5303292386 A B C Pan-crisper,(2)
28 215341200 A B C End Cap-shelf,protector
31 5303292388 A B C Pan-meat
34 5303212918 A B C Container-ice
42 215002301 A B C Hanger-pan/tray,LH
42* 215002401 A B C Hanger-pan/tray,RH
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
46 5304405084 A B C Front-crisper pan
47 218498180 A B C Insert-pan cover
59 218188000 A B C Screw,pan hd ,10-32 x 0.625 ,hinge/mullion,thread forming
67 5304405086 A B C Front-meat pan
77 5303001216 A B C Washer-nylon,3/16 x 5/8 OD
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
120 218019201 A B C Seal-refr top
121 215364001 A B C Cable-damper contrl
121* 215209400 A B C Nut,push-on ,damper cable
122 218561201 A B C Block-air deflector,RH
122 218561203 A B C Block-air deflector,LH
123 215005100 A B C Screw-roller/hanger,8-10 x 0.438
145 218660800 A B C Clip,plastic ,temp sensor mtg ,snap-in
* 215339100 A B C Seal-divider throat
* 215359900 A B C Seal-divider front
* 215848000 A B C Spacer-air channel

04/00 10
Publication No. FRT22RGJ
5995336400
SYSTEM

# = Fast-moving Parts 11 04/00
* = Non-Illustrated Parts
FRT22RGJ Publication No.
5995336400
SYSTEM
A = FRT22RGJ (FRT22RGJW0)
B = FRT22RGJ (FRT22RGJD0)
C = FRT22RGJ (FRT22RGJB0)
POS. NO PART NO DESCRIPTION
1 218787700 A B C Condenser
1* 5303208866 A B C Spacer-cond tube,black
1* 5303289026 A B C Spacer-tube
2 5303289029 A B C Clip-cond mtg,(4)
4 # 218944001 A B C Drier-filter,R134a System
5 # 218965501 A B C Harness-wiring,main
6 # 218965901 A B C Wiring Harness,compressor
7 # 215459201 A B C Cord-electric power
8 218803400 A B C Cover-wiring
13 # 218168602 A B C Heat Exchanger,suction line
14 # 5317842502 A B C Heater-defrost
15 # 5303321220 A B C Evaporator
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
17 5316651102 A B C Insulator-evap,plastic
18 5303292407 A B C Insulation Block,RH
19 218631200 A B C Tube,rubber
20 5303292406 A B C Insulation Block,LH
20A 5303292405 A B C Insulation Plug,LH
21 # 5316269001 A B C Thermostat-defrost
22 218811100 A B C Base-compressor mtg,(drain pan)
23 218513300 A B C Grommet-compr mtg,(4)
25 218773500 A B C Screw-compressor mtg,hex washer head ,10Bx11/4
29 # 218894801 A B C Compressor,R134a ,w/o electricals
30 # 218721109 A B C Starter-PTC
32 216649100 A B C Clamp,elec cont mtg ,compressor
41 5308000039 A B C Screw,hex washer head ,8-32CA x 0.500 ,(7),serrated head
43 215174700 A B C Clamp-service cord,strain relief ,galv steel
43* 5303001199 A B C Clamp-wiring harness,strain relief ,galv steel
43* 5308000133 A B C Clamp,nylon ,.625 ID
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
54 5303289027 A B C Rail-cabinet base,rear
54A 5303289311 A B C Rail-compr support
54B 5303289292 A B C Rail-cabinet base,front
55 # 218909901 A B C Capacitor-run,220 VAC ,15 microfarad
55* 218897001 A B C Screw,hex washer head ,8-32 x 1/4
56 218769300 A B C Insert-compressor mtg
57 218247300 A B C Clip-wiring harness
58 215004600 A B C Screw-cond fan mtr,hx serr wshr hd ,8-36 x 7/16,(2)
59 5303289031 A B C Shroud-cond fan mtr
59* 215226700 A B C Seal-foam,cond fan shroud
60 # 215501901 A B C Motor-condenser fan
61 5303289032 A B C Blade-cond fan
61* 215004700 A B C Nut,speed
61* 215004800 A B C Grommet-silencer
* 5303917214 A B C Hot Tube Repair Kit,Service

04/00 12
Publication No. FRT22RGJ
5995336400
WIRING SCHEMATIC

# = Fast-moving Parts 13 04/00
* = Non-Illustrated Parts
FRT22RGJ Publication No.
5995336400
WIRING DIAGRAM
