Frigidaire FRT15B3J Instruction Manual

N05L00004.eps N05DBDCJA1.eps N05BBAABA21.eps N05SADDCA21.eps
N05CBABAB5.eps W241582401.eps S241582801.eps
Product No. FRT15B3JQ2 FRT15B3JW2 FRT15B3JZ2
Series R134a R134a R134a
Color bisque (right) white (right) white (left)
Volts 115 115 115
Wiring Diagram 241582401 241582401 241582401
Owner's Guide 241857201 241857201 241857201
Market North America North America North America
Energy Guide 241613767 241613767 241613767
Service Data Sheet 241588203 241588203 241588203
Installation Instructions 241568303 240568303 240568303
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995525424
08/10/02
(EN/SERVICE/DCS)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT15B3J
Copyright ©All rights reserved.

Publication No: 5995525424 FRT15B3J
10/08 2
DOOR
10
22
22
11
22
14
22
22
13A
13
21C
21C
10
22
14
22
1
7
2
22
15
N05DBDCJA1
73
74
18A
21
18A
73
74
12
21A
21A
4
4B
4A
8

FRT15B3J Publication No: 5995525424
# Functional Parts 3 10/08
* Non-Illustrated Parts
DOOR
Model Index: AFRT15B3J (FRT15B3JQ2)
BFRT15B3J (FRT15B3JW2)
CFRT15B3J (FRT15B3JZ2)
POS. NO PART NO. DESCRIPTION
1 241872501 A B C Gasket-frzr door, white,magnetic
2 241872502 A B C Gasket-refr door, white, magnetic
4 240535101 A B C Rack-door
4A 240535301 A B C Rack-door
4B 240535201 A B C Rack-door
7 240337712 A B C Door-dairy
8 240535001 A B C Rack-door
10 240381302 A - - Plug-button, bisque, hinge brg hole, (2)
10 240381301 - B C Plug-button, white, hinge brg hole, (2)
11 240415402 A - - Door, frzr, bisque
11 240415401 - B C Door, frzr, white
12 241808601 A B C Label-nameplate
13 240312407 A - - Door Stop, bisque, ref
13 240312403 - B C Door Stop, white, ref
13A 240312408 A - - Door Stop, bisque, frzr
13A 240312404 - B C Door Stop, white, frzr
14 240494002 A - - Plug-button, bisque
14 240494001 - B C Plug-button, white
15 240415502 A - - Door, refr, bisque
15 240415501 - B C Door, refr, white
18A 218428119 A - - Handle-door, bisque, w/block & screw
18A 218428101 - B C Handle-door, white, w/block & screw
21 240383406 A B C Screw, truss hd quad, #10-16 x .500, zinc
21A 240521303 A B C Screw, #10-16 x 1/2
21C 218252201 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 A B C Bearing-hinge, natural color
73 218396701 A B C Block-handle mtg, dovetail
74 215503203 A B C Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995525424 FRT15B3J
10/08 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
40
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA21
43
28
21C
21C
41
41
41
8
8
9
14
81
34
22

FRT15B3J Publication No: 5995525424
# Functional Parts 5 10/08
* Non-Illustrated Parts
CABINET
Model Index: AFRT15B3J (FRT15B3JQ2)
BFRT15B3J (FRT15B3JW2)
CFRT15B3J (FRT15B3JZ2)
POS. NO PART NO. DESCRIPTION
1 241652301 A B C Cover-fan
2 240367001 A B C Knob-damper control
3 5303001028 A B C Nut, push-on
4 241523701 A B C Damper-fan cover
5 # 5308000010 A B C Fan Blade, red, evaporator fan
8 5300157666 A B C Bushing-motor mtg, (2)
9 5303292396 A B C Bracket-motor mtg, front
10 241652215 A B C Cover-evap coil
10* 240568601 A B C Seal-coil cover
11 5303208309 A B C Plug-hole, factory test
12 241557601 A B C Plug-ice maker harness, rectangular
12A 240374401 A B C Plug-wtr inlet tube, round, 1"
12A* 241586701 A B C Plug-foam-wtr-inlet, round
13 # 241854301 A B C Motor-fan
13* 215474201 A B C Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B C Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C Bracket-motor mtg, rear
14* 240433204 A B C Screw, hex washer head, 8-18 x 5/16
21C 218252201 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 215774919 A - - Plug-button, bisque, upr hinge holes
22 215774901 - B C Plug-button, white, upr hinge holes
28 241708801 A B C Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240357106 A B C Bracket-lower hinge
34 240311303 A B C Washer, hinge, nylon, (2)
35 240357006 A B C Bracket-ctr hinge
35A 240336802 A B C Spacer-hinge, center
36 240516402 A B C Pin-center hinge
37 241611304 A - - Trim-cabinet corner, bisque, (2)
37 241611301 - B C Trim-cabinet corner, white, (2)
38 240356901 A B C Bracket, upper hinge
40 240354403 A - - Cover-upper hinge, bisque
40 240354401 - B C Cover-upper hinge, white
41 5308009759 A B C Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 A B C Screw, hex head, 1/4-20 x 5/8
43 241882901 A B C Roller Assy, adjustable, front, (2)
56 240516502 A B C Pin-lower hinge
58 5304456287 A B C Screw, hex washer head, 8-15A x 0.500
59 240442706 A B C Screw-#10-32 X 3/4, zinc
72 240368302 A - - Grille/Kickplate, bisque, lower front
72 240368301 - B C Grille/Kickplate, white
81 5304455650 A B C Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5304455655 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
92 241710601 A B C Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 240479601 A B C Plug, button, cab liner holes
* 5304414035 A - - Paint, touch-up, bisque
* 5303321319 - B C Paint, touch-up, white

Publication No: 5995525424 FRT15B3J
10/08 6
SHELVES

FRT15B3J Publication No: 5995525424
# Functional Parts 7 10/08
* Non-Illustrated Parts
SHELVES
Model Index: AFRT15B3J (FRT15B3JQ2)
BFRT15B3J (FRT15B3JW2)
CFRT15B3J (FRT15B3JZ2)
POS. NO PART NO. DESCRIPTION
11 5303282284 A B C Shelf-freezer, "table type"
12 241542001 A B C Diffuser, air, top
13 240362601 A B C Diffuser, air, bottom
14 # 241554901 A B C Switch-light/lamp
15 241555401 A B C Light Bulb
16 241559801 A B C Socket-light
17 240368002 A B C Control Box
17* 240568607 A B C Seal
17*# 240388701 A B C Wiring Harness, control box
18 240360801 A B C Knob, temp control
21 # 5304421256 A B C Control, temperature
22A 240468201 A B C Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 A B C Timer-defrost
23* 5304455649 A B C Screw, pan hd, 6-20 x 0.438
24 240360902 A B C Shelf, sliding, wire
25 240364706 A B C Cover, crisper pan
26 240364501 A B C Pan, crisper, (2)
81 5304455650 A B C Screw, hex washer head, 8-15A x 0.625, low profile
* 241613767 A B C Energy Guide

Publication No: 5995525424 FRT15B3J
10/08 8
SYSTEM
20
20
17
45
1
2
21
15
14
16
83
83
44
41
82
82
87
N05CBABAB5
22
23
23
30
32
85
55
4
6
29
57
25
25
25
26
84
45A
24
24
24

FRT15B3J Publication No: 5995525424
# Functional Parts 9 10/08
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT15B3J (FRT15B3JQ2)
BFRT15B3J (FRT15B3JW2)
CFRT15B3J (FRT15B3JZ2)
POS. NO PART NO. DESCRIPTION
1 241927302 A B C Condenser
1* 5303208866 A B C Spacer, condenser tube, black
1* 5304406721 A B C Spacer-cond tube, round, 5/8 OD x .81"lg
2 5308000296 A B C Bracket, condenser mtg, (4)
4 218944002 A B C Drier-filter, R134a System
6 # 241949801 A B C Harness-wiring, machine compt
6* # 240388701 A B C Wiring Harness, control box
14 # 241940101 A B C Heater-defrost
15 5303918275 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater, aluminum, (2)
17 241801302 A B C Trough-drain
20 241551902 A B C Insulation Block
21 # 5303918202 A B C Thermostat-defrost, kit
22 241665605 A B C Base-compressor
22* 218252201 A B C Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg, (4)
24 241812301 A B C Washer-compr mtg
25 216056401 A B C Clip-compressor mtg
26 241949701 A B C Pan-defrost
29 # 5303918373 A B C Compressor Kit
30 # 241707715 A B C Starter-PTC
32 241715901 A B C Strap-cover
41 240433204 A B C Screw, hex washer head, 8-18 x 5/16
44 5304456288 A B C Clamp-wiring harness, strain relief, galv steel
45 5304455650 A B C Screw, hex washer head, 8-15A x 0.625, low profile
45* 241500304 A B C Screw, hex washer head, 8-18AB x 0.625
45A 240359403 A B C Screw-fan shroud, (2)
55 218909913 A B C Capacitor, run, 220 VAC, 15 microfarad
57 240542601 A B C Clip-wiring harness
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5304455655 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 241949901 A B C Tube-drain, lower
85 241844601 A B C Tube-connector, suction
87 241949601 A B C Tube-Condensate, 87
* 240396801 A B C Clamp, tube/wiring, nylon, black/natural
* 5303918234 A B C Hot Tube Repair Kit, service
* 5303918263 A B C Heat Exchanger Kit, suction line

Publication No: 5995525424 FRT15B3J
10/08 10
WIRING SCHEMATIC

FRT15B3J Publication No: 5995525424
# Functional Parts 11 10/08
* Non-Illustrated Parts
WIRING DIAGRAM
