R e f r i g e r a t o r
O w n e r  s
G u i d e
the LOOK of better performance
Product Registration .............................................. 2
Versión en español ................................................ 2
Important Safety Instructions ................................ 2
First Steps ............................................................. 3
Energy Saving Ideas ............................................. 4
Setting the Controls ............................................... 4
Temperatures ..................................................... 4
Energy Saver Switch ........................................... 4
Moisture .............................................................. 4
Fresh Food Storage ........................................... 5-6
Care and Cleaning ............................................. 6-7
Automatic Ice Maker.............................................. 7
Reversible Door Instructions ............................ 8-10
Avoid Service Checklist.................................. 11-13
Normal Operating Sounds ................................... 13
Warranty (United States)..................................... 14
Service Information (Canada) ............................. 15
Warranty (Canada) .............................................. 16
P/N 218926000 (9902)
T o p F r e e z e r
F r o s t P r o o f

Product Registration ................................... 2
Versión en español ..................................... 2
Important Safety Instructions ..................... 2
First Steps ................................................... 3
Energy Saving Ideas .................................. 4
Setting the Controls .................................... 4
Temperatures ........................................ 4
Energy Saver Switch ............................ 4
Moisture................................................. 4
Fresh Food Storage................................. 5-6
Care and Cleaning................................... 6-7
Automatic Ice Maker................................... 7
Reversible Door Instructions................. 8-10
Avoid Service Checklist....................... 11-13
Normal Operating Sounds........................ 13
Warranty in the United States .................. 14
Service Information in Canada ................ 15
Warranty in Canada .................................. 16
P/N 218926000 (9902)

2
Record the Model Number and Serial Number of this refrigerator in the space
providedbelow.Thesenumbers are foundontheserialplatelocated on the topleft
walloftherefrigerator compartment.
Model Number:
Serial Number:
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD should be filled in completely,
signedandreturnedtoFrigidaire,orinCanada,FrigidaireCanada.
Product Registration
Versión en español
Si desea obtener una copia en español
deeste Manual del Usuario, sírvase
escribiraladirecciónqueseincluye a
continuación.SolicitelaP/N218926100.
Spanish Owner's Guides
FrigidaireHome Products
P.O. Box 212378
Augusta, GA 30917
Important Safety
Instructions
Proper Disposal of
Your Refrigerator/Freezer
DANGER
Riskofchildentrapment.
Child entrapment and suffocation are
not problems of the past. Junked or
abandonedrefrigeratorsorfreezersare
stilldangerous—eveniftheywillsitfor
"justafewdays."Ifyouaregettingridof
youroldrefrigeratororfreezer,please
followinstructionsbelowtohelpprevent
accidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
* Takeoff
doors.
* Leave
shelves
inplace,
so
children
may not
easily
climb
inside.
Avoid fire hazard or
electricshock.Donotuseanextension
cord or an adapter plug. Do not remove
any prong from the power cord.
© 1999 White Consolidated Industries, Inc.
Allrightsreserved.
Readallinstructionsbefore using this refrigerator.
For Your Safety
Donotstoreor use gasoline or other flammable vapors andliquidsinthe vicinity
ofthisoranyotherappliance.Readproductlabelsforflammabilityandotherwarnings.
Child Safety
• Destroycarton,plastic bags, and any exterior wrapping materialimmediately
afterthe refrigerator is unpacked. Children should never usetheseitems for
play.Cartonscoveredwithrugs, bedspreads, plastic sheets orstretchwrapmay
become airtight chambers and can quickly cause suffocation.
• Remove all staples from the carton. Staples can cause severe cuts and destroy
finishesifthey come incontactwithotherappliancesor furniture.
• An empty, discarded ice box, refrigerator or freezer is a very dangerous
attraction to children. Remove the door of any appliance that is not in use,
even if it is being discarded.
Electrical Information
These guidelines must be followed to ensure that safety mechanisms in the
design of this refrigerator will operate properly.
•The refrigerator must be plugged into its own 115 Volt, 60 Hz, AC only
electrical outlet. The power cord of the appliance is equipped with a 3-prong
grounding plug for your protection against shock hazards. It must be plugged
directly into a properly grounded 3-prong receptacle. The receptacle must be
installed in accordance with local codes and ordinances. Consult a qualified
electrician. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG.
• If voltage varies by 10 percent or more, performance of your refrigerator may
beaffected.Operatingtherefrigeratorwithinsufficientpowercandamagethe
compressor. Such damage is not covered under your warranty. If you suspect
your voltage is high or low, consult your power company for testing.
• Topreventtherefrigeratorfrombeingturnedoffaccidentally,donotplugthe
unitintoanoutletcontrolledbya wall switch or pull cord.
• Do not pinch, knot, or bend the power cord in any manner.
Other Precautions
• Never unplug the refrigerator by pulling on the power cord. Always grip the
plugfirmlyandpull straight out fromthereceptacle.
• Toavoidelectricalshock,unplugtherefrigeratorbeforecleaningandbefore
replacingalightbulb.Note:TurningthecontroltoOFFturnsoffthecompressor,
butdoesnotdisconnect power tothelightbulborother electrical components.
• Do not operate the refrigerator in the presence of explosive fumes.
• Iftherefrigeratorhasanautomaticicemaker,avoidcontactwithanymovingparts.

3
FirstSteps Before starting the refrigerator, follow these important first steps:
Location
• Choose a place that is near a grounded electrical outlet. DO NOT use an
extensioncord or an adapterplug.
• Ifpossible,placetherefrigeratoroutofdirectsunlightandawayfromtherange,
dishwasherorotherheatsources.
• Therefrigerator must be installed on a floor that is level and strong enough
tosupportafullyloadedrefrigerator.
• Considerwatersupplyavailabilityfor models equipped with an automatic ice
maker.
Installation
• If you need to remove the handles to move the refrigerator through narrow
doorways,followsteps7and8 in the "Reversible Door Instructions."
• Do not install the refrigerator where the temperature will drop below 60°F
(15°C)orrise above 110°F (43°C). The compressorwill not be able to maintain
propertemperatures.
• Inarecessedinstallation,allowanextra1/2inch (10-15 mm) on each side for
easeofinstallation.
• If the hinge side of the unit will be placed against a wall, allow a 1 3/4 inch
(44 mm) space between the wall and the refrigerator.
Door Opening
The doors should open to allow easy access to a counter when removing food.
• Donotpositiontherefrigeratorsoyouhavetowalkaroundtherefrigeratordoors.
• Reversethedoorsifnecessary.See"ReversibleDoorInstructions."
Leveling
Allfourcornersoftherefrigeratormustrestfirmlyonasolidfloor.
1. Openrefrigeratordoorandremovetoegrill.
2. Use a 3/8" socket wrench or nutdriver to adjust rollers as shown. RAISE THE
FRONT of cabinet enough so doors will close freely when opened halfway.
3. Levelcabinetsidetoside.
4. Replacetoegrill,lineupclipswithholes,andpushgrillstraighton.
Cleaning
• Wash the inside, all removable parts and the outside with mild detergent and
warm water. Wipe dry. DO NOT USE HARSH CLEANERS ON THESE SURFACES.
• Do not use razor blades or other sharp instruments which can scratch the
appliance surface, when removing adhesive labels. Any glue left from the
tape or energy label can be removed with a mixture of warm water and mild
detergent,or,touchthe residue with thestickysideoftapealreadyremoved.
• DO NOT REMOVE THE SERIAL PLATE.
ReplacingToeGrill
AdjustingFrontRollers
ROLLER ADJUSTING
BOLT

4
• Locatetherefrigeratorinthecoolestpartoftheroom,outofdirectsunlightand
awayfromheatingductsorregisters.Donotplacetherefrigeratornexttoheat-
producingappliancessuchasarange,ovenordishwasher.Ifthisisnotpossible,
a section of cabinetry or an added layer of insulation between the two
applianceswillhelptherefrigeratoroperatemoreefficiently.
• Leveltherefrigeratorsothedoorsclosetightly.
• Refertothis Owner's Guideforthesuggestedrefrigerator settings.
• Periodiccleaningofthecondenserwillhelp the refrigerator run more
efficiently.SeeOutsideinthe "Care and Cleaning" section.
• Do not overcrowd the refrigerator or block cold air vents. Doing so causes
therefrigeratortorunlongeranduse more energy. Shelves should not belined
withaluminumfoil,waxpaperor papertoweling.Linersinterferewithcoldair
circulation,making the refrigerator lessefficient, which could cause food
spoilage.
• Coverfoods and wipe containers dry before placing them inthe refrigerator.
Thiscuts down on moisture build-up inside theunit.
• Organize the refrigerator to reduce door openings. Remove as many items as
needed at one time and close the door as soon as possible.
Energy Saving Ideas
Setting the Controls Cool Down Period
Toensure safefoodstorage,allowtherefrigeratortooperatewiththedoorsclosed
for at least 8 to 12 hours before loading with food.
Refrigerator and Freezer Controls
• Tostartout,setcontroldials tothemidpointfor atrialperiodof 24hours.
Temperatures
• After 24 hours, adjust the controls as needed. Adjust temperatures one
number at a time. For colder temperatures, turn the dial toward COLDEST.
For warmer temperatures, turn the dial toward COLD. The temperature will
increaseordecrease,butnotnecessarilyby1,2, or 3 degrees.
An adjustment made to one compartment may require an adjustment to the other.
• Turning the refrigerator control will change the temperature in BOTH
compartments. If the refrigerator control is turned to OFF, cooling
stops in both compartments.
• Turningthefreezercontrolwillchangeonlythetemperatureinthefreezer
compartment.
To maintain temperatures, a fan circulates air in the refrigerator and freezer
compartments. For good circulation, do not block cold air ventswith food items.
Energy Saver Switch (some models)
Ifyourrefrigeratorisequipped with an Energy Saver Switch, keepitsetonENERGY
SAVER for lowest energy usage.
Moisture
During humid weather, or if moisture appears on the cabinet between the doors,
set switch to REDUCE EXTERIOR MOISTURE. A heater will warm the surface and
allowmoisturetoevaporate.
G05C0086
RefrigeratorControl
G05C0085
FreezerControl
FREEZER
COLDEST
COLD
2
3
EnergySaver

5
Fresh Food Storage
ChilledAirControl
CantileverShelf
Shelf Adjustment
Refrigeratorshelvesareeasilyadjustabletosuitindividualneeds.Beforeadjusting
shelves,removeallfood.Theshippingclipswhichstabilizetheshelvesforshipping
may be removed and discarded.
Toadjustcantilevershelves (shelvessupportedattherearoftherefrigerator),liftthe
backoftheshelfupandout.Replaceshelfbyinsertinghooksatrearintoslots.Lower
andlockintoposition. Some modelshave Spillsafe glassshelveswhichcatchand
holdaccidentalspills.
Door Storage
Doorbinsandshelvesprovideconvenientstorageofjars,bottles,andcans.Itemsused
oftenareavailableforquickselection.
Thedoorbinscan be movedtosuitindividualneeds.Remove bins by liftingstraight
up.Placebinsin the desired position andloweroverthesupports.
The Dairy Compartment(s) is warmer than the general food storage section and is
intendedfor shorttermstorageofcheese,spreads,orbutter.
Tall Bottle Retainer (some models)
TheTallBottleRetainerkeepstall containers in the binfromfallingforwardwhen
openingorclosingtherefrigeratordoor.Toinstall,holdtheretaineratthetop,and
slideit overtheoutsidewallofthebin,asshown.Notethattheretainerworksbest
with the use of a bin snugger.
Micro-Serve Dishes (some models)
Food can be stored, cooked*, and served in Micro-Serve Dishes provided in some
models.Thesedishesslide easily into theirowntray,whichhangsbelow a doorbin,
convenientlyfreeingshelfspaceforotheritems.
* Remove plastic lid before cooking. Lid is intended for storage only.
Crispers
TheCrispers, locatedunderthebottomrefrigeratorshelf,aredesignedforstoring
fruits,vegetables, and other fresh produce. Washitems in clear water and remove
excesswater beforeplacingintheCrispers. Itemswithstrongodorsorhighmoisture
shouldbewrappedbeforestoring.
TheHumidityControlsallowyouto adjust the humidity within theCrisper.Thiscan
extendthelifeoffreshvegetableswhichkeepbestinhighhumidity.Leafyvegetables,
however,keep best when storedwith the Humidity Controlset on high moisture,or
in a drawer without a Humidity Control. This keeps incoming air to a minimum and
maintains maximum moisture content.
Meat Keeper (some models)
The temperature in the Meat Keeper drawer can be made colder than the rest of the
refrigeratorcompartmentbyadjustingtheChilledAirControl.Meatwillbepartially
frozenandmaybe kept fresh longerthanifstoredona refrigerator shelf.
BeforeplacingitemsintheMeatKeeper,followthesestepstokeepthemeatfresh:
1. Carefully handle meat with clean hands and always keep the compartment
clean.
2. Storemeatinitsoriginalwrapper.Ifnecessary,overwrapinplasticwraporfoil
topreventdrying.Wrapfishtightlytopreventodortransfertootherfoods.
3. Ifspoilage everoccurs,disinfectthe compartmentwithliquidchlorinebleach
followinglabeldirections.Then,rinsewithasolutionofbakingsodaandwater.
Rinsewithclearwaterand dry.
Adjustable Chilled Air Duct (some models)
TheChilledAir Duct, which distributes cold airtothe Meat Keeper drawer, can be
adjustedto accommodaterepositioningof theshelf.However, theshelfhasalimited
rangeofpositionsinwhichtheChilledAirDuctwillreach.Theshelfisshippedinthe
highestpositionandmust be lowered to reach the Chilled Air Duct.
HumidityControl
FRESH FRUITS & VEGETABLES
LOWER
FRUITS
HIGHER
HUMIDITY CONTROL
VEGETABLES
TallBottleRetainer

6
Fresh Food Storage
(continued)
Followtheseinstructions:
• Remove the Meat Keeper drawer and shelf.
• Slidelowerportionof air duct downwardtothelowestposition.
• Replacetheshelfinapositionabove the air duct opening.
• Slidelowerportionofairduct upwarduntiltheopeninghitstheshelf bottom.
• Insertthedrawer.Theairductopeningwill fit between the shelf and the back
ofthedrawer.
TheChilledAirDuctcanalsoswitchsides,shouldyouwishtomovethesplitcantilever
shelf.Tochangesides:
• Removethe Meat Keeper drawer and shelf.Grasp the air duct near topand slide
towardyouuntil ductisfreefrom grooves.
• Slideoffholecoveronoppositeside.Insertthelipoftheairduct ingroovesof
new hole and slide back.
• Slideholecoveroveroriginalhole.
• Replaceshelf andinsertdrawer.
Care and Cleaning
To avoid damage and help
therefrigeratorrun as efficiently as
possible, clean the condenser and air
ventsperiodically.
Adjustingthe ChilledAirDuct
Hole Cover
Air Duct
Lower portion of
air duct slides up
or down.
Air Outlet Box
Hole cover and air duct
slide into grooves on
bottom of air outlet box.
Keepyourrefrigeratorandfreezercleantoprevent odor build-up. Wipe up any spills
immediately and clean both sections at leasttwice a year. Neveruse metallic scouring
pads,brushes,abrasivecleanersorstrongalkalinesolutionsonanysurface.Donotwash
any removable parts in a dishwasher.
Always unplug the power cord from the wall outlet before cleaning. Turning the
refrigeratorcontroltoOFFdoesnotdisconnectpowertothecontrols,lightbulb,orother
electricalcomponents.
Inside
Washinsidesurfacesoftherefrigeratorandfreezer with a solution of 2 tablespoons
baking soda in 1 quart warm water. Rinse and dry thoroughly. Be sure to wring excess
water out of sponge or cloth before cleaning around the controls, light bulb, or
anyelectrical parts.
Wash removable parts such as shelves and drawers with baking soda solution or mild
detergent and warm water. DO NOT USE HARSH CLEANERS ON THESE SURFACES.
Rinseanddry thoroughly. Clean thedoorgasketswith mild suds,rinsewithclear water
and wipe dry. Do not use razor blades or other sharp instruments which can scratch the
appliancesurfacewhenremoving adhesive labels. Any glue leftfromthetape or energy
label can be removed with a mixture of warm water and mild detergent, or, touch the
residue with the sticky side of tape already removed. DO NOT REMOVE THE SERIAL
PLATE.
Outside
Washthecabinetand handles with warm water and mildliquiddetergent.Rinsewell and
wipe dry with a clean soft cloth. Do not use commercial household cleaners, ammonia,
oralcohol toclean handles.
Remove any dust or dirt from the front of the toe grill using a vacuum cleaner with its
dustingtoolattachment.Removethetoegrillbypullingitstraightout.Whilethegrillis
removed, vacuum the backside of the grill and wipe with a sudsy cloth or sponge.
Periodicallycleanthecondenser(blacktubesandwiresbeneaththe refrigerator,behind
thetoegrill).Donotallowlint ordust toaccumulateonthecoils.Inserta longhandled
brushorvacuumattachment between the two coils to bringthelintforward.To replace
thetoegrill,lineuptabswithholesandpushgrillstraighton. Usecaution
when cleaning in the area of the coils. Surfaces there may be sharp.
Theair ventsonthe loweraccesspanelatthe rearofthe refrigeratorshould becleaned
periodically.Cleantheventsbyusinga vacuumcleaner withitsdustingtoolattachment.
Whenmovingtherefrigerator,pullstraightout.Donotshifttherefrigeratorfrom side
toside asthis maytearorgougethe floorcovering. Iftherefrigeratorhasan automatic
ice maker, be careful not to move the refrigerator beyond plumbing connections.
Damp objects stick to cold
metalsurfaces.Donottouchrefrigerated
surfaces with wet or damp hands.

7
Care and Cleaning
(continued)
Replacing the Light Bulb
To replace the light bulb:
1. Unplugtherefrigerator.
2. Wearglovesasprotection against possible brokenglass.
3. Replace old bulb with an appliance bulb of the same wattage.
4. Remember to plug the refrigerator back in.
Vacation and Moving Tips
Shortvacations: Leavethe refrigerator operatingduringvacationsof 1 to 3weeks.
Useupallperishableitemsfromtherefrigeratorsection.Wrapandstoreotheritems
inthefreezer.If the unit hasanautomaticicemaker, turn off the icemaker.
Long vacations: Remove all food and ice if you will be gone 1 month or more. Turn
the refrigerator control to OFF and disconnect the power. If the unit has an
automaticicemaker,turnoffthe ice maker and turn the water supply valvetothe
closedposition. Defrostandclean theinteriorthoroughly.Leavebothdoorsopen
to prevent odor and mold buildup. Block open if necessary.
Moving: Whenmoving the refrigerator, follow these guidelines to preventdamage:
• Remove all food and other items from both the refrigerator and freezer
compartments. Empty the ice storage bin. Defrost and clean the interior
thoroughly.
• Ifahand truck is usedinmoving,load the refrigerator fromtheside.
• Turnfrontrollersasfarupaspossible.Thiswillprotectthemduringslidingor
moving.
• The cabinet should be well padded and handled with care. DO NOT DROP.
Ifyourrefrigeratorhasanautomaticicemaker,itwillprovideacontinuoussupplyof
ice for normal use. The automatic ice maker is an optional accessory which may be
installedinmostmodelsatanytime.Callyourlocaldealerforinstallation.
Aftertheplumbingconnectionshavebeencompleted,thewatersupplyvalvemustbe
opened.Placetheicecontainerundertheicemaker,pushingitasfarbackaspossible.
Lower the wire signal arm to its "down" or ON position. Because of new plumbing
connections,thefirstproductionoficecubesmaybediscoloredorhaveanoddflavor.
Throw the ice away until the cubes made are free of discoloration and taste.
Tostoptheicemaker,liftthewiresignalarm untilitclicks andlocksinthe "up"or
OFFposition.Theicemakerturnsoffautomaticallywhentheicecontainerisfull.Ifyour
modelhasanadjustablefreezershelf,placetheshelfsothewiresignalarmwillhitthe
icewhentheicecontainerisfull.
Ice Maker Tips
1. Icestoredtoolongmaydevelopan odd flavor. Empty the container and besurethe
wire signal arm is in its "down" or ON position. The ice maker will then produce
moreice.
2. Occasionallyshakethe containertokeep iceseparated.
3. Keep the wire signal arm in its "up" or OFF position until the refrigerator is
connected to the water supply or whenever water supply is turned off.
4. Certain sounds are normal when the ice maker is operating. They are:
Motor operation
Ice being loosened from the tray
Icebeingdroppedintothecontainer
Running water
Water valve opening and closing
For more information on these operations, see "Normal Operating Sounds."
5. Wash ice container in warm water with mild detergent. Rinse well and dry.
6. Stoptheicemakerwhencleaningthefreezerorforshortvacations.
7. Iftheice maker will beturnedofffor a longperiodoftime,turn the watersupply
valvetotheclosedposition.
Automatic Ice Maker
Wire
Signal Arm

8
G05I0006
G05I0098
G05I0013 G05I0003
Yourrefrigeratorisequippedwithconvertibledoorhinges.Hingingofthedoor can
be changed to the opposite side any time you wish. An envelope containing extra
plastichole plugsisincluded insomemodels. Turntherefrigerator controltoOFF.
Remove all food, bottles,and other items from the door. Beginwithfreezer door.
Completely remove one door before beginning the other.
2. Open the freezer door enough to allow
ittobeliftedoffthecenterhinge. 3. Withtherefrigeratordoorclosed,remove
center hinge pin. (Note the arrangement of
the upper and lower washers on the hinge
pin. The washers must be assembled later in
the same manner.) Open refrigerator door
enough to allow door to be lifted off the
lower hinge. Remove the two screws
attaching the center hinge. The third
outermost screw under the center hinge
shouldbe leftinplace. Save hinge,pin,and
washers for reassembly later. Reinstall
screwsinoriginalholes.
Reversible Door
Instructions
Hinge Pin
Washer
Screws
Hinge
Washer
Hinge Pin
G05I0008
G05I0007
4. Remove hole plugs from the non-hinge
sideofthefollowing:
• the top of the cabinet
• the top of the freezer door
• thethird,outermostscrewholeincentermullion
Reinstallonopposite side. If damagedfrom
removal,usenewplugsincludedinliterature
pack (some models).
Washer
Hinge
Bolt
Washer
Hinge
Bolt
5. Remove the toe grill from front of
refrigeratorby pullingstraightforward.
Remove the two hex head bolts attaching
the lower hinge. Save the hinge and
washer(s) for reassembly.
6. Boltlower hingetocabinetonopposite
side.Installwasher(s)onthelower hinge
pin.
(Third, outer-most
screw is left in place.)
Hole Plug
Hole Plugs
1. Snapoffhingecover at top of cabinet.
With the freezer door closed, remove the
three screws attaching upper hinge to
cabinet.Note:Hingehasaminimalspring
load. Hold bracket when removing last
screw. Lift the hinge up and off. Be sure
to save screws and hinge for
reassembly later.

9
Reversible Door
Instructions (continued)
G05I0118
7. Reverse handles while doors are off. Remove the two screws
attaching the handle to the bottom of the freezer door. Remove
shorttrimpieceby sliding thetrimstraightupandoffof handle
bracket.Removethe screwattachingthetopof thehandletodoor,
andreinstallonotherside, usingthehole foundbehindthe self-
adhesive nameplate. To move nameplate to the other side, peel
offthenameplate andreapplyovertheold handleholes. Reattach
handleto bottomof door.Slidethetrimpiecestraightdownonto
handlebracket.
FreezerDoor
G05I0111
RefrigeratorDoor
8. Trim Removal (Full-Length Trim models only)
Insomemodels,therefrigeratordoor has a full lengthtrim
piece which continues from the bottom of the handle to the
bottomofthedoor. The topofthetrimattachestothe handle
bracket.Anadhesive"trimlock"is positioned about half-
way down. The bottom of the trim is held in place by either
anadhesivetrimlock,oratrim lockwithtwoprongsinserted
intoaholeonthefaceofthe door. Remove the trim by gently
pullingthetrim lock areas out and away from thedoor.When
thetrimisfreefromthedoor,slidethetrimstraightdownand
away from the handle bracket.
For models with short handle trim, remove by sliding the
trimstraightdownandoffofhandlebracket.
To remove handles: Remove the three screws attaching the
handleto therefrigeratordoor.Carefullyremove holeplugs
from corresponding holes on opposite side of doors and
reattachhandle.
Toreattachtrim:Slidebothtrimlocksoutoftrim.Insertthe
newadhesivetrimlocks contained in your literature pack.
NOTE: Trim lock must be removed and installed by sliding
OVER the two donut shaped areas. Install trim to handle by
sliding up overbottom of handle. Carefully align trim and
press down at trim lock locations. Replace hole plug on
opposite side. Use rubbing alcohol to remove any adhesive
residuefromoldtrimlocklocation(s).
Formodels with shorthandletrim, slidethetrim straightup
ontohandlebracket.

10
Reversible Door
Instructions (continued)
G05I0070
G05I0113
9. Turn center hinge upside down and
secure to cabinet as shown, using the
screwswhichareinthenewholes.Install
refrigerator door on lower hinge pin.
Align door with edge of cabinet. Hold
thedoor on front of cabinet.
10.Placeoriginalwasher over hole in
refrigerator door and line up hole in
centerhinge.Inserthinge pin through
both holes. Place washer on hinge pin,
then position freezer door on center
hinge.
12.Beforereplacingthetoegrill,remove
theplasticgrillplugfromthetoegrill.
Rotate the grill plug so it fits on the
oppositesideofthe toegrill.Replace
toegrill.
11. Assemble upper hinge to top of
cabinet and door. Use opposite set of
holes. Do not completely tighten
screws.
Check door alignment. Space between
door and cabinet should be 3/4" at top
hinge, the width of an ordinary penny.
Returnfood,bottles,andotherarticles
to doors. Additional adjustment may be
necessary after loading the door
shelves.Turntherefrigeratorcontrol
on and to the previous setting.

11
Beforecallingforservice,reviewthis list.Itmaysave youbothtime andexpense.
This list includes common occurrences that are not the result of defective
workmanshipormaterialsinthisappliance.
Avoid Service Checklist
OCCURRENCE
Refrigeratorcontrolisoff. Set refrigerator control.SeeSettingtheControls.
Refrigeratorisindefrostcycle.Thisisnormalforafullyautomaticdefrostingrefrigerator.Thedefrost
cycleoccursperiodically,lastingabout20minutes.
Plugat wall outletis disconnected. Makesureplug is tightlypushedinto outlet.
House fuse has blown or circuit breaker has tripped. Check and/or replace fuse with a 15 amp time-
delayfuse.Resetcircuitbreaker.
Power outage. Check house lights. Call local electric company.
Roomoroutside weatherishot.It isnormal fortherefrigerator to worklongerunder these conditions.
Refrigerator has recently been disconnected for a period of time. It takes about 8-12 hours for the
refrigeratorto cool downcompletely.
Automatic ice maker is operating (some models). Operation of the ice maker causes the refrigerator
torun slightly more.
Doorsare openedtoo frequently ortoo long. Warmair enteringthe refrigerator causesit to runmore.
Open the doors less often.
Refrigerator or freezer door may be slightly open. Make sure refrigerator is level. Keep food and
containers from blocking door. See Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Refrigeratorcontrolissettoocold.Settherefrigeratorcontroltoawarmersettinguntiltherefrigerator
temperature is satisfactory. Allow 24 hours for the temperature to stabilize. Then, if the freezer
temperatureisnotright, set the freezercontrol toa colder setting.
Refrigeratororfreezer gasket isdirty, worn,cracked, orpoorlyfitted.Clean or changegasket. Leaks
indoor sealwillcause refrigeratorto run longerin order tomaintain desired temperatures.
Thermostatiskeepingthe refrigerator ata constanttemperature.Thisis normal. Refrigerator goeson
and off to keep temperature constant.
Freezercontrol is set toocold.Setthefreezercontroltoawarmersettinguntilthe freezer temperature
issatisfactory.Allow 24 hours for the temperature to stabilize.
Refrigeratorcontrol issettoocold.Settherefrigeratorcontroltoawarmersetting. Allow 24 hoursfor
temperaturestostabilize.Then,ifthefreezertemperatureisnotright,setthefreezercontroltoacolder
setting.
Refrigeratorcontrolissettoo cold. See abovesolution.
Meatshould bestored ata temperaturejust below the freezingpoint ofwater (32°F,0°C) for maximum
fresh storage time. It is normal for ice crystals to form due to the moisture content of meat.
ChilledAir Control settoocold. Adjustthe ChilledAir Control toalower setting.
Doors are opened too frequently or too long. Warm air enters the refrigerator whenever the door is
opened. Open the door less often.
Door is open slightly. See Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Condenser is dirty. Clean condenser. See "Outside" in Care and Cleaning.
Refrigerator runs too much or too
long.
Refrigerator compressor goes on and
offfrequently.
Temperature in the freezer is too cold
and the refrigerator temperature is
satisfactory.
Temperature in the refrigerator is too
cold and the freezer temperature is
satisfactory.
Food stored in drawers freezes.
Food stored in Meat Keeper (some
models) freezes.
Temperature in the freezer or
refrigerator is too warm.
TEMPERATURES ARE TOO COLD
SOLUTION
TEMPERATURES ARE TOO WARM
RUNNING OF REFRIGERATOR
Refrigerator compressor does not run.

12
Freezercontrol issettoowarm.Set thefreezercontroltoacoldersettinguntilthefreezertemperature
issatisfactory.Allow 24 hours for the temperature to stabilize.
Refrigeratorcontrol isset too warm. Refrigeratorcontrol hassome effect onfreezer temperature.
Settherefrigeratorcontroltoacoldersetting.Allow24hoursfor the temperature to stabilize.Then,
ifthe freezer temperature isnotright,setthefreezercontroltoawarmer setting. RefertoSettingthe
Controls.
ChilledAir Control isset too warm.Adjust the ChilledAirControltoa colder setting.
Weatheris hot andhumidwhich increases rateoffrost buildup andinternalsweating. Thisis normal.
Door is slightly open. See Occurrence section
OPENING/CLOSING OF DOORS/DRAWERS.
Door is opened too often or too long. Open the door less often.
Vegetables contain and give off moisture. It is not unusual to have moisture on the bottom side of
thecover.
Washed vegetables and fruits drain while in the drawer. Dry items before putting them into drawer.
Water collecting in bottom of drawer is normal.
Weather is humid. This is normal in humid weather. When humidity is lower, the moisture should
disappear. Set Energy Saver switch to the Reduce Exterior Moisture position.
Doorisslightlyopen,causingcold air from insidethe refrigerator to meetwarm airfrom outside. See
Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Icemaker wire signalarm is in"up" or OFFposition. Move wire signal arm to "down" or ON position.
Household water line valve is not open. Turn on household water line valve.
Watersupply valve inrefrigerator is beingblocked by foreignmaterial.Unplug therefrigeratorand
turnoffwatersupply.Sliderefrigeratoroutandlocatewherewaterisconnectedtothevalve.Unscrew
the brass fitting and pull out the screen from inside the valve mesh. Clean the screen of foreign
material. Replace screen and brass fitting and turn the water supply on; check for leaks. Plug in
refrigeratorandslideintoplace.
Freezer is not cold enough. See Occurrence section TEMPERATURES ARE TOO WARM.
Saddlevalveon cold waterpipe isblockedorrestricted by foreignmaterial.Turn off household water
linevalve.Remove,cleanor replace valve.
Ice maker is producing less ice than you expect. Ice maker should produce approximately
2 1/2 to 4 pounds of ice every 24 hours.
Freezer is not cold enough. See Occurrence section TEMPERATURES ARE TOO WARM.
Household water line valve is not completely open. Turn on household water line valve.
Watersupply valvein refrigerator isbeing blockedby foreign material.See Occurrence, "Icemaker
is not making any ice" above.
Ice maker wire arm is being held down by an item in the freezer. Remove item and release arm.
Remove any ice cubes which are frozen together over arm.
Ice cubes are not being used frequently enough. Remove and shake ice bucket to separate cubes.
Icehas pickedupodororflavorfromstrong foodstoredinrefrigeratororfreezer.Cover foodstightly.
Discardstaleice. Ice makerwill producefreshsupply.
Waterrunning toice maker haspoor tasteor odor.Add filter toice maker.Consult a waterpurifying
company.
Temperature in the freezer is too warm.
Temperature in the refrigerator is too
warm and the freezer temperature is
satisfactory.
Temperature in the Meat Keeper (some
models) is too warm.
SOLUTION
TEMPERATURES ARE TOO WARM
Moisture collects on inside of refrigerator
walls.
Water collects on bottom side of drawer
cover.
Water collects in bottom of drawer.
Moisture forms on outside of refrigerator
or between doors.
Ice maker is not making any ice.
AUTOMATIC ICE MAKER (some models)
Ice maker is not making enough ice.
Ice maker will not stop making ice.
Ice maker is not separating the cubes.
Ice has bad odor and taste.
OCCURRENCE
WATER/MOISTURE/FROST INSIDE REFRIGERATOR
WATER/MOISTURE/FROST OUTSIDE REFRIGERATOR

13
Interior needs to be cleaned. Clean interior with sponge, warm water and baking soda.
Foodwithstrong odor isin refrigerator.Cover foodtightly.
Door is not designed to swing shut automatically. Close door securely.
Door was closed too hard, causing other door to open slightly. Close both doors gently.
Refrigeratorisnotlevel.Itrockson the floor whenit is movedslightly. Be sure flooris level and
solidand can adequatelysupportrefrigerator. Adjustrollersas needed.
Floorisunevenorweak.Refrigeratorrocksonthefloorwhenitismovedslightly.Besurefloorislevel
andcan adequatelysupportrefrigerator.Contactcarpentertocorrectsaggingor sloping floor.
Refrigerator is touching the wall or cabinets. Be sure floor is level and can adequately support
refrigerator.Contactcarpentertocorrectsagging or sloping floor.
Food is touching shelf on top of drawer. Keep less food in drawer.
Trackthat drawersslideson isdirty.Clean drawerand track.
Light bulb is burned out. See "Replacing the Light Bulb" in Care and Cleaning.
Lightswitch is stuck.Light switch islocatedon the ceilingof the refrigeratorcompartment near
thetemperature controlbox.Push inlight switch torelease.
No electric current is reaching refrigerator. See Occurrence section RUNNING OF REFRIGERATOR.
ODORS IN REFRIGERATOR
SOLUTION
OPENING/CLOSING OF DOORS/DRAWERS
Door(s) will not close.
Drawers are difficult to move.
OCCURRENCE
LIGHT BULB IS NOT ON
Normal Operating
Sounds

14
REFRIGERATOR WARRANTY (United States)
YourFrigidaireproductisprotectedbythiswarranty
THE CONSUMER WILL BE
RESPONSIBLE FOR:
Costs of service calls that are listed under NORMAL
RESPONSIBILITIES OF THE CONSUMER.*
Costs for pick up and delivery of the appliance
required because of service. Costs for labor, parts
and transportation other than with respect to the
cabinet liner or Sealed Refrigeration System.
Costs of the technician's travel to the home and any
costs for pick up and delivery of the appliance
required because of service.
FRIGIDAIRE, THROUGH ITS AUTHORIZED
SERVICERS, WILL:
Pay all costs for repairing or replacing any parts of this
appliance which prove to be defective in materials or
workmanship.
Repair or replace any parts in the cabinet liner or Sealed
Refrigeration System (compressor, condenser, evaporator,
drier and tubing) which prove to be defective in materials
or workmanship.
All of the provisions of the full warranties above and the
exclusions listed below apply.
FULL ONE-YEAR
WARRANTY
LIMITED 2ND - 5TH
YEAR WARRANTY
(Cabinet Liner and
Sealed System)
LIMITED
WARRANTY
(Applicable to the
State of Alaska)
WARRANTY
PERIOD
One year from original
purchase date.
Second through fifth years
from original purchase
date.
Time periods listed above.
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED
SERVICE
This warranty applies only to products in ordinary household use, and the consumer is responsible for the
items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in
accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which
are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING
FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation
or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary
household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Frigidaire or its authorized servicers; use of parts other
than genuine Frigidaire Home Products parts; obtained from persons other than such servicers; or external causes
such as abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill establishes the warranty
period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This
written warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under
this warranty must be obtained by contacting Frigidaire Home Products:
800•944•9044
Frigidaire Home Products
P.O. Box 212378
Augusta, GA 30917
Product features or specifications as described or illustrated are subject to change without notice. All warranties are made
by White Consolidated Industries, Inc. This warranty applies only in the 50 states of the U.S.A. and Puerto Rico.
Your appliance is warranted by White Consolidated Industries, Inc. We authorize no person to change or add to any of our obligations under this
warranty. Our obligations for service and parts under this warranty must be performed by Frigidaire or an authorized Frigidaire servicer.

15
To avoid unnecessary cost and inconvenience, make a few simple checks before
calling for service. Common occurrences and their solutions can be found in the
AvoidServiceChecklist.Be sureyouhavefollowedtheinstructionsin thismanual.
Ifyouareunabletolocatethecauseofaproblem,callforservice.Insistonfactory
service by an authorized FRIGIDAIRE PARTS AND SERVICE depot.
FRIGIDAIRE PARTS AND SERVICE
All Frigidaire appliances are backed by FRIGIDAIRE PARTS AND SERVICE, one of
Canada'slargestparts and servicenetworks.
TheFrigidairereputationmeansyoucan enjoy complete professional service from
oneofour hundredsoftrainedtechniciansacross the country.AskyourFrigidaire
dealer for details about the Extended Service Plan offered by FRIGIDAIRE PARTS
ANDSERVICEto all purchasers of Frigidaire appliances in Canada.
FRIGIDAIRE PARTS AND SERVICE
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
Place the name, address and telephone number of your service depot in the
spacesbelow.
Product and feature specifications as described or illustrated are subject to
change without notice.
Service Information
(Canada)

16
WARRANTOR:
FrigidaireHome Products
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
This refrigerator is a branded product of Frigidaire
Canada.
WARRANTY PERIOD:
Fortwoyearsafter purchase bytheoriginalconsumer/
owner:
Fortenyears after purchase bytheoriginalconsumer/
owner:
Forserviceunderthiswarranty,contactyourlocaldealer/
retailer,authorizedFRIGIDAIREPARTSAND SERVICE depot,or:
FRIGIDAIRE HOME PRODUCTS
PARTS AND SERVICE
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
Tel: [phone]
Fax: [phone]
WARRANTOR WILL THROUGH ITS AUTHORIZED
SERVICE DEPOT:
Paycosttorepairorreplaceanydefectiveparts(including
serviceandlabourcharge).
Paycost(includingserviceandlabourcharge)torepairor
replacedefectivepartsofthesealedrefrigerationsystem
consisting of the compressor, evaporator, condenser,
interconnectingtubingdrierandrefrigerationcharge.
W A R R A N T Y (CANADA)
REFRIGERATORS (FROST FREE)
WARRANTY APPLIES TO:
a) Productspurchased andinstalledinCanadaforpersonalsinglefamilyhouseholduse.
b) Defectsresultingorarisingoutofthemanufacturingprocess.
c) Productsbearinglegiblemanufacturer'smodel and serial numbers.
d) Replacementparts only for the remainder of the original warranty.
WARRANTY DOES NOT APPLY TO:
a) Transportationdamage.
b) Supplyand replacement ofporcelain,fuses,glassandlight bulbs.
c) Parts and service supplied or obtained from other than FRIGIDAIRE PARTS AND SERVICE or FRIGIDAIRE PARTS SERVICE
authorizeddepots.
d) Properinstallation,controlsettingandcareoffinish.
CONSUMER/OWNER RESPONSIBILITY:
a) Toprovideproofof theoriginaldate ofpurchasebymeansofabillofsaleorpaymentrecordverifyingpurchasedate.
b) Supplyand replacement ofporcelain,fuses,glassandlight bulbs.
c) To ensure proper power supply and connection of the appliance to same.
d) Properinstallation,controlsettingandcareoffinish.
Thiswarrantyisinadditiontoanystatutorywarrantiescontainedinanyapplicablelegislation. Thetermsandconditions
ofthiswarrantyarenotintended to exclude or limit yourrightsunderthosestatutes. Thewarrantorhoweverreserves
therighttochargetransportationandtravellingcostsfordistancesinexcessof48kilometres(30miles)fromthenearest
FRIGIDAIRE PARTS AND SERVICE authorized service depot.
This warranty plus the statutory warranties mentioned are the only warranties given to the consumer/owner for this
product.

NOTES
