Frigidaire GLRT212ID User manual

N05L00003.eps N05DCDBCA1.eps N05BAAAAA0.eps N05SACAFI13.eps
N05CABBAB2.eps 115-1.eps 240398801.eps 240398601.eps
Product No. GLRT212IDB0 GLRT212IDQ0 GLRT212IDW0
Series R134a R134a R134a
Color black bisque white
Volts 115 115 115
Wiring Diagram 240398801 240398801 240398801
Owner's Guide 240400110 240400110 240400110
Market North America North America North America
Energy Guide 240598645 240598645 240598645
Service Data Sheet 240379012 240379012 240379012
Installation Instructions 240568300 240568300 240568300
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995409215
04/05/04
(EN/SERVICE/DCS)
357
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
GLRT212ID
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995409215 GLRT212ID
05/04 2
DOOR

GLRT212ID Publication No: 5995409215
# Functional Parts 3 05/04
* Non-Illustrated Parts
DOOR
Model Index: AGLRT212ID (GLRT212IDB0)
BGLRT212ID (GLRT212IDQ0)
CGLRT212ID (GLRT212IDW0)
POS. NO PART NO. DESCRIPTION
1 # 240514611 A - - Gasket, seal, black, frzr door, magnetic
1 # 240514607 - B C Gasket, seal, white, frzr door, magnetic
2 # 240514612 A - - Gasket, seal, black, refr door, magnetic
2 # 240514608 - B C Gasket, seal, white, refr door, magnetic
7 240337703 A B C Door-dairy, w/o graphics, clear
10 240381303 A - - Plug-button, black, hinge brg hole
10 240381302 - B - Plug-button, bisque, hinge brg hole, (2)
10 240381301 - - C Plug-button, white, hinge brg hole, (2)
11 240450312 A - - Door, frzr, black
11 240450306 - B - Door, frzr, bisque
11 240450302 - - C Door, frzr, white
12 240449703 A - - Nameplate, black
12 240449702 - B - Nameplate, bisque
12 240449701 - - C Nameplate, white
13 240312405 A - - Door Stop, black, refr
13 240312407 - B - Door Stop, bisque, ref
13 240312403 - - C Door Stop, white, ref
13A 240312406 A - - Door Stop, black, frzr
13A 240312408 - B - Door Stop, bisque, frzr
13A 240312404 - - C Door Stop, white, frzr
14 240494003 A - - Plug-button, black
14 240494002 - B - Plug-button, bisque
14 240494001 - - C Plug-button, white
14B 240383603 A - - Plug-button, black, door handle
14B 240383602 - B - Plug-button, bisque, door handle
14B 240383601 - - C Plug-button, white, door handle
15 240450412 A - - Door, refr, black
15 240450406 - B - Door, refr, bisque
15 240450402 - - C Door, refr, white
18 240339203 A - - Handle-door, black
18 240339204 - B - Handle-door, bisque
18 240339201 - - C Handle-door, white
18A 240339208 A - - Handle-door, black
18A 240339209 - B - Handle-door, bisque
18A 240339206 - - C Handle-door, white
21 240383401 A B C Screw, truss hd quad, #10-16 x .500
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 A - - Bearing-hinge, black
22 240527101 - B C Bearing-hinge, natural color
48 240338101 A B C Bin-door, pseudo, bottom
48A 240337901 A B C Bin-door, refr
48B 240338001 A B C Bin-door, pseudo, gallon, refr
49 240495804 A B C Bin-door, pseudo, frzr

Publication No: 5995409215 GLRT212ID
05/04 4
CABINET
83
82
89
11
10
1
81
4
58
2
3
40
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BAAAAA0
43
28
21C
21C
41
41
41
8
8
9
14
81
34
18
18
22
15
16
74
114

GLRT212ID Publication No: 5995409215
# Functional Parts 5 05/04
* Non-Illustrated Parts
CABINET
Model Index: AGLRT212ID (GLRT212IDB0)
BGLRT212ID (GLRT212IDQ0)
CGLRT212ID (GLRT212IDW0)
POS. NO PART NO. DESCRIPTION
1 240355402 A B C Cover-fan
2 240367001 A B C Knob-damper control
3 5303001028 A B C Nut, push-on
4 240367401 A B C Damper-fan cover
5 # 5308000010 A B C Fan Blade, red, evaporator fan
8 5300157666 A B C Bushing-motor mtg, (2)
9 5303292396 A B C Bracket-motor mtg, front
10 240313609 A B C Cover-evap coil, w/light
10* 240568606 A B C Seal-coil cover
10*# 241537701 A B C Wiring Harness, freezer section, with light
11 5303208309 A B C Plug-hole, factory test
13 # 240369701 A B C Motor-evap fan
13* 218931001 A B C Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C Bracket-motor mtg, rear
14* 240433201 A B C Screw, hex washer head, 8-18 x 0.375
15 215812200 A B C Light Bulb/Lamp, 25W
16 241513901 A B C Socket-light
18 240411901 A B C Support-evap cover, (2)
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 A - - Plug-button, black, upr hinge holes
22 215774919 - B - Plug-button, bisque, upr hinge holes
22 215774901 - - C Plug-button, white, upr hinge holes
28 240335501 A B C Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314003 A - - Bracket-lower hinge, black
30 240314004 - B - Bracket-lower hinge, bisque
30 240314002 - - C Bracket-lower hinge, white
34 240311303 A B C Washer, hinge, nylon, (2)
35 240313803 A - - Bracket-ctr hinge, black
35 240313804 - B - Bracket-ctr hinge, bisque
35 240313802 - - C Bracket-ctr hinge, white
35A 240336802 A B C Spacer-hinge, center
36 240516401 A B C Pin-center hinge
37 240337603 A - - Trim-cabinet corner, black, (2)
37 240337604 - B - Trim-cabinet corner, bisque, (2)
37 240337601 - - C Trim-cabinet corner, white, (2)
38 240313701 A B C Bracket-upper hinge
40 240354404 A - - Cover-upper hinge, black
40 240354403 - B - Cover-upper hinge, bisque
40 240354401 - - C Cover-upper hinge, white
41 5303001609 A B C Grommet, shelf mtg, 0.69", RH
41* 5308009759 A B C Grommet, shelf mtg, 1.25", LH
42 240578901 A B C Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B C Roller Assy, front, (2)
56 240516501 A B C Pin-lower hinge
58 5303001343 A B C Screw, hex washer head, 8-15A x 0.500
59 240442703 A - - Screw-#10-32 X 3/4, black
59 240442704 - B - Screw-#10-32 X 3/4, bisque
59 240442702 - - C Screw-#10-32 X 3/4, white

Publication No: 5995409215 GLRT212ID
05/04 6
CABINET
83
82
89
11
10
1
81
4
58
2
3
40
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BAAAAA0
43
28
21C
21C
41
41
41
8
8
9
14
81
34
18
18
22
15
16
74
114

GLRT212ID Publication No: 5995409215
# Functional Parts 7 05/04
* Non-Illustrated Parts
CABINET
Model Index: AGLRT212ID (GLRT212IDB0)
BGLRT212ID (GLRT212IDQ0)
CGLRT212ID (GLRT212IDW0)
POS. NO PART NO. DESCRIPTION
72 240368207 A - - Grille/Kickplate, black
72 240368206 - B - Grille/Kickplate, bisque
72 240368205 - - C Grille/Kickplate, white
74 240354301 A B C Shield-light, frzr
81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326115 A B C Cover-access, with label
89* 241500301 A B C Screw, hex washer head, 8-18AB x 0.500
92 216850900 A B C Screw, hex washer hd, 1/4 x 7/8, hinge mtg
114# 241554901 A B C Switch-light/lamp
* 5303305345 A - - Paint, touch-up, black
* 5304414035 - B - Paint, touch-up, bisque
* 5303305324 - - C Paint, touch-up, white

Publication No: 5995409215 GLRT212ID
05/04 8
SHELVES

GLRT212ID Publication No: 5995409215
# Functional Parts 9 05/04
* Non-Illustrated Parts
SHELVES
Model Index: AGLRT212ID (GLRT212IDB0)
BGLRT212ID (GLRT212IDQ0)
CGLRT212ID (GLRT212IDW0)
POS. NO PART NO. DESCRIPTION
11 240358003 A B C Shelf, freezer, full-width, wire
12 240545901 A B C Diffuser-air, top
13 240362601 A B C Diffuser, air, bottom
14 # 241554901 A B C Switch-light/lamp
15 240436702 A B C Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature
16 241500701 A B C Socket-light/lamp
17 240368101 A B C Control Box
17*# 240388701 A B C Wiring Harness, control box
18 240360801 A B C Knob, temp control
21 # 5304421256 A B C Control, temperature
22A 5303916855 A B C Tube, sensor sleeve, plastic, clear
23 # 215846606 A B C Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240358921 A B C Shelf-"Spill-Safe", sliding
24A 240358922 A B C Shelf-"Spill-Safe", sliding, w/pan hanger
25 240364718 A B C Cover-crisper pan
25B 240361201 A B C Control-humidity
25C 240361301 A B C Damper, humidity cont.
26 240343803 A B C Pan, crisper, (2)
31 240530903 A B C Pan-meat, w/o graphics, clear
34 240385201 A B C Container, ice bin
47 240443301 A B C Panel, pan cover, glass
58 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
* 240598645 A B C Label-energy

Publication No: 5995409215 GLRT212ID
05/04 10
SYSTEM

GLRT212ID Publication No: 5995409215
# Functional Parts 11 05/04
* Non-Illustrated Parts
SYSTEM
Model Index: AGLRT212ID (GLRT212IDB0)
BGLRT212ID (GLRT212IDQ0)
CGLRT212ID (GLRT212IDW0)
POS. NO PART NO. DESCRIPTION
1 # 240444401 A B C Condenser, dynamic
4 # 218944001 A B C Drier-filter, R134a System
6 # 240581701 A B C Harness-wiring, machine compt
6* # 240388701 A B C Wiring Harness, control box
6* # 240581801 A B C Harness-wiring, compressor
6* # 241537701 A B C Wiring Harness, freezer section, with light
14 # 5303918247 A B C Defrost Heater Kit
15 # 5303918274 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater, aluminum, (2)
17 240434004 A B C Trough-drain
20 240518402 A B C Insulation, evap block, foam, LH/RH
21 # 5303918202 A B C Thermostat-defrost, kit
22 240330001 A B C Plate-compr mtg
22* 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg, (4)
25 240491501 A B C Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332602 A B C Pan-defrost drain
29 # 5303918297 A B C Compressor, w/electricals
30 # 5304433579 A B C Relay
31 # 5304433578 A B C Overload Protector
34 240405201 A B C Grommet, rubber, black, cond tube/wire
41 240555001 A B C Screw-#8-32 X 3/8
44 215174700 A B C Clamp-service cord, strain relief, galv steel
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
56 240582001 A B C Cover-terminal
57 240542601 A B C Clip-wiring harness
58 215004600 A B C Screw, hx serr wshr hd, 8-36 x 7/16, cond fan motor, (2)
59 240315501 A B C Shroud-cond fan
59* 240346701 A B C Tape-foam seal, shroud
59* 240359401 A B C Screw-fan shroud, (2)
59A 240346501 A B C Bracket-support, cond mtr, (3)
59B 240346601 A B C Grommet-bracket, (3)
60 # 240334001 A B C Motor, condenser fan
61 # 240315401 A B C Fan Blade, galv steel, condenser fan
61A 215004700 A B C Nut, speed
61B 215004800 A B C Grommet-silencer
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
85 240493101 A B C Tube-connector, suction
86 240409302 A B C Spacer-cond tube, black
* 240396801 A B C Clamp, tube/wiring, nylon, black/natural
* # 5303918210 A B C Heat Exchanger Kit, suction line
* # 5304421289 A B C Hot Tube Repair Kit, Service

Publication No: 5995409215 GLRT212ID
05/04 12
ICE MAKER

GLRT212ID Publication No: 5995409215
# Functional Parts 13 05/04
* Non-Illustrated Parts
ICE MAKER
Model Index: AGLRT212ID (GLRT212IDB0)
BGLRT212ID (GLRT212IDQ0)
CGLRT212ID (GLRT212IDW0)
POS. NO PART NO. DESCRIPTION
1 218976901 A B C Tube-water inlet, inlet valve, to ice maker
2 5304420650 A B C Spring, shut-off arm
3 3206299 A B C Label, ID plate
4 3206301 A B C Gear
5 3206303 A B C Plate-mounting
6 3206305 A B C Screw-ground wire, 8-32 x 0.250
7 # 3206306 A B C Motor-ice maker
8 3206312 A B C Spacer-hold switch
9 3206313 A B C Cam
10 3206315 A B C Clamp
11 # 3206319 A B C Thermal Cutoff, ICE MAKER, complete assy
12 # 5304420651 A B C Wiring Harness, ICE MAKER, internal, with plug
13 # 3206322 A B C Thermostat Assy, ICE MAKER
14 5304420652 A B C Screw, 4 x 0.750, switch mtg.
15 # 3206324 A B C Switch, (3)
16 5304420653 A B C Support, phenolic
17 # 5303320545 A B C Mold-ice maker, Radius Cube, with heater
18 3206328 A B C Ejector-ice
19 3206330 A B C Bearing & Inlet
20 5304408581 A B C Screw, 8-32 x 0.375
21 3206332 A B C Ice Stripper
22 3206333 A B C Shut-off Arm
23 5304408582 A B C Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B C Lever Arm
25 3206336 A B C Screw, 8-18 x 0.562, lever arm/sprt
26 5304420654 A B C Screw-thermo/sprt, 4-24 x 0.375, (4)
27 3206338 A B C Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B C Screw-timing stop, 4-40 x 0.375
29 3206323 A B C Screw, 4-24 x 0.750, (6)
30 3206341 A B C Screw-timing adj, 8-32 x 1.000
31 3206342 A B C Insulator
32 3206343 A B C Plate-valve switch
33 5304408583 A B C Spring-timing adj
34 5304420655 A B C Screw, plazscrew, 8-10, (3)
35 5304408585 A B C Screw
36 3206347 A B C Cover-ice maker
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
45* 218843800 A B C Screw, hex wshr hd, 8-15A x 0.500
51 240387101 A B C Tube-water, ice mold fill, extension
55 # 240519601 A B C Valve-water, single solenoid, 60 Hz, 105/120 V
60 218362500 A B C Screw, hex washer head, 8-18AB x 1.250
61 218721500 A B C Bracket-leveling, ICE MAKER
62 218737900 A B C Screw-IM brkt mtg, hex washer head, 8-32D x 0.375
64 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line
* 218888001 A B C Adapter-water supply, nut & sleeve, compression ftg
* 240352409 A B C Ice Maker, Radius Cube, 115 V, no instl parts

Publication No: 5995409215 GLRT212ID
05/04 14
WIRING SCHEMATIC

GLRT212ID Publication No: 5995409215
# Functional Parts 15 05/04
* Non-Illustrated Parts
WIRING DIAGRAM
