Frigidaire PLRS267ZAB0 User manual

Si " by Side
Refrigerator
i
I
I
14
= \ .................................................................................. ;_ -
Espafiol ........... 25
Fran_ais ........... 50
Welcome ....................... 2
_ -- =
Safety Instructions.._= ........ 3
Installation - IncludesConnecting
ice Maker To Water Supply ............ 4 - 5
Door Removal
instructions ................... 6
Features at a Glance ......... 7
Temperature Controls ....... 8
Looking inside .......... 9-11
Automatic ice and Water
Dispenser ................ 12 -15
Food Storage
Normal O_ Sounds.. 17
Care & Cleaning ........ 18 -19
Warranty ...................... 20
Before You Call
Solutions to
commonProb=e,-a.............. 21 -24
READ AND SAVE THESE INSTRUCTIONS P/N240389301(olo3)

Congratulations on your purchase of a new refrigerator! We
here at Electrolux Home Products are very proud of our
product and we are completely committed to providing you
with the best service possible. Your satisfaction is our #1
priority.
Please read this Use & Care Manual very carefully. Itcontains
valuable information on how to properly maintain your new
refrigerator.
We know you'll enjoy your new refrigerator and Thank You
for choosing our product. We hope you consider usfor future
purchases,
PLEASE READ AND SAVE THESEINSTRUCTIONS
This Use & Care Manual provides specific operating
instructions for your model. Use your refrigerator only as
instructed in this manual. These instructions are not meant
to cover every possible condition and situation that may
occur. Common sense and caution must be practiced when
installing, operating and maintaining any appliance.
Please record your model and serial numbers below for
future reference. This information is found on the serial
plate located inside the refrigerator compartment.
NOTE: Use only soap and water to clean serial plate.
Model Number:
Serial Number:
Purchase Date:
Questions?
1-800-944-9044
(United States)
1-866-213-9397
(Canada)
Extend Your Warranty Protection
With An
Eiectrolux Service Contract
CALL 1-706-860-4110
To Enjoy These Benefits:
Total freedom from repair bills so
unexpected repairs won't upset your
budget.
Fast, convenient toll=free service is just
a phone call away.
Top-quality repairs by factory-trained
experts.
Quick access to genuine replacement
parts so you can rest assured your
refrigerator is repaired with the proper
components.
PIease attach sales receipt
here for future reference.
Please complete and mail in the Product
Registration Card included with your
refrigerator.
2

PleaseReadA, nstruct OnSBeforeUsingTh sRefr=geratorl
FOR YOUR SAFETY
• Do not store or use gasoline, or other flammable liquids
in the vicinity of this or any other appliance. Read
product labels for warnings regarding flammability and
other hazards.
• Do not operate the refrigerator in the presence of
explosive fumes.
• Avoid contact with any moving parts of automatic ice
maker.
• Remove all staples from the carton. Staples can cause
severe cuts, and also destroy finishes if they come in
contact with other appliances or furniture.
CHILD SAFETY
Destroy or recycle the carton, plastic bags, and any exterior
wrapping material immediately after the refrigerator is
unpacked. Children should NEVER use these items to play.
Cartons covered with rugs, bedspreads, plastic sheets or
stretch wrap may become airtight chambers, and can quickly
cause suffocation.
PROPER DISPOSAL OF YOUR REFRIGERATOR
OR FREEZER
Risk of child entrapment
Child entrapment and suffocation
are not problems of the past.
Junked or abandoned refrigerators
or freezers are still dangerous -
even ifthey will sit for "just a few
days." Ifyou are getting rid of your
old refrigerator or freezer, please
follow the instructions below to
help prevent accidents.
Before you throw away your old refrigerator/freezer:
• Remove doors.
•Leave shelves in place so children may not easily climb
inside.
•Have refrigerant removed by a qualified service
technician.
These Guidelines Must Be Followed To Ensure That Safety Mechanisms in This Refrigerator
ELECTRICAL iNFORMATiON
= The refrigerator must be plugged into its own
dedicated 115 Volt, 60 Hz., AC only electric outlet.
The power cord of the appliance isequipped with a
three-prong grounding plug for your protection against
electrical shock hazards. It must be plugged directly
intoa properly grounded three-prong receptacle. The
receptacle must be instaJJedin accordance with local
codes and ordinances. Consult a qualified electrician.
Do not use an extension cord or adapter plug.
= immediately repair or replace any power cord that
becomes frayed or damaged.
= Never unplug the refrigerator by pulling on the power
cord. Always grip the plug firmly, and pull straight out
from the receptacle to prevent damaging the power cord.
= Unplug the refrigerator before cleaning and before
replacing a light bulb to avoid electrical shock.
= Performance may be affected ifthe voltage varies by
10% or more. Operating the refrigerator with insufficient
power can damage the compressor. Such damage is
not covered under your warranty.
= Do not plug the unit intoan outlet controlled by a wall
switch or pull cord to prevent the refrigerator from being
turned off accidentally.
= Avoid connecting refrigerator to a Ground Fault Interruptor
(GFI) circuit.
NOTE: Turning the freezer temPerature control toOFF
turns off the compressor, but does not disconnect
electrical p0wer t0 the light bulb or Other electrica I
components_
Grounding type
wall receptacle
Do not,under "1
any circumstances, I
cut_ relnove_
or bypass the |
grounding prong, t)
............................................................
Power co
3-prong grounded plug

This Use & Care Manual provides specific operating
instructions for your model. Use the refrigerator only as
instructed in this Use & Care Manual. Before starting the
refrigerator, follow these important first steps.
LOCATION
•Choose a place that isnear a grounded electrical outlet.
Do Not use an extension cord or an adapter plug.
•if possible, place the refrigerator out of direct sunlight
and away from the range, dishwasher or other heat
sources.
•The refrigerator must be installed on a floor that is level
and strong enough to support a fully loaded refrigerator.
•Consider water supply availability for models equipped
with an automatic ice maker.
iNSTALLATiON
•Do Not install the refrigerator where the temperature
will drop below 55°F (13°C) or rise above 110°F (43°C).
The compressor will not be able to maintain proper
temperatures inside the refrigerator.
ooNotb ockthetoeg.,eo°
lower front refrigerat0r:sufficient air
circulatio n is essential for the proper operation of
your refrigerator.
Installation Clearances
•Allow the following clearances for ease of installation
proper air circulation, and plumbing and electrical
connections:
Sides & Top 3/8"
Back 1"
DOOR OPENING
NOTE: If your refrigerator is Placed with the door hinge
side against a Wall, y0u may have to allow additional
space so the door can be opened wider.
Your refrigerator should be positioned to allow easy access
to a counter when removing food. For best use of drawers
and freezer baskets, the refrigerator should be in a position
where both the refrigerator and freezer doors can be fully
opened.
LEVELING
All four corners of your refrigerator must rest firmly on a
solid floor. Your refrigerator is equipped with adjustable front
rollers to help level your unit.
To Level Your Refrigerator:
1. Remove toe grille.
2. Use flat-blade screwdriver or 3/8" socket wrench
to adjust front rollers.
NOTE: The refrigerator doors are designed to shut by
themselves within a 20 degree 0peningl
Raise
3. Check both doors to be sure seals touch cabinet on all
four sides.
4

ltTstaHatiort - connecting ice Maker To Water Supply
To avoid electric shock, which can cause death or severe personal injury,disconnect the refrigerator
from electrical power before connecting awater supply line to the refrigerator.
To Avoid Property Damage:
•Copper tubing is recommended for the water supply line. Water supply tubing made of ¼" plastic is not
recommended since it greatly increases the potential for water leaks. Manufacturer will not be responsible
for any damage if plastic tubing is used for supply line.
- DO NOT install water supply tubing in areas where temperatures fall below freezing.
- Chemicals from a malfunctioning softener can damage the ice maker, if the ice maker isconnected to soft
water, ensu re that the softener is maintained and working properly.
IMPORTANT: Ensure that your water suppry line connections comply with all local plumbing codes.
Before Installing The Water Supply Line, You Will Need
• Basic Tools: adjustable wrench, flat-blade screwdriver, and PhillipsTM screwdriver
• Access to a household cold water line with water pressure between 20 and 100 psi.
• A water supply line made of ¼ inch (6.4 mm) OD, copper tubing. To determine the length of copper tubing needed,
you will need to measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water
pipe. Then add approximately 7 feet (2.1 meters), so the refrigerator can be moved out for cleaning (as shown).
• A shutoff valve to connect the water supply line to your household water system. DO NOT use a self-piercing type
shutoff valve.
• A compression nut and ferrule (sleeve) for connecting the water supply line to the ice maker inlet valve.
NOTE:Water!ine kit number 53039i 7950, available from your appliance dealer at additional costl Contains 25 feet (7_6
meters) of ¼inch QD Copper tubing, a saddle type shutoff valve (nonpiercing), (2)¼ inch brass compression nuts; (2)
ferrules/sleeves, and instructions for installing a Water SUpply line:
To Connect Water Supply Line To ice Maker inlet Valve to Ice Maker
1. Disconnect refrigerator from electric power source. \\ _Z=--FilTube Clamp
2. Place end of water supply line into sink or bucket. Turn ON water supply _" BraSS
and flush supply line until water is clear. Turn OFF water supply at shut , Compression
off valve.
3. Unscrew plastic cap from water valve inlet and discard cap. Ferrule
4. Slide brass compression nut, then ferrule (sleeve) onto water supply line, .(Sleeve)
as shown.
5. Push water supply line into water valve inlet as far as it will go (¼ inch), waterline
Slide ferrule (sleeve) into valve inlet and finger tighten compression nut WaterValve
onto valve. Tighten another half turn with a wrench; DO NOT over tighten.
6. With steel clamp and screw, secure water supply line to rear panel of ValveInlet
refrigerator as shown. _rValve
7. Coil excess water supply line (about 2Y2turns) behind refrigerator as shown
and arrange coils so they do not vibrate or wear against any other surface.
8. Turn ON water supply at shutoff valve and tighten any connections that Copper water line
leak. from household water supply
9. Reconnect refrigerator to electrical power source. (Includeenoughtubinginloopto allow
10. Toturn ice maker on, lower wire signal arm (see ice maker front cover for movingrefrigeratorout for cleaning.)
ON/OFF position of arm).
iMPORTANT: It takes approximately 24 hours for the ice maker t° begin producing ice. Air in new plumbing lines may
cause icemaker tOcyc!etwo 0[ three times before making a full tray of ice, New plumbing may cause ice to be discolored
or have poor flavor. Discard ice made during the first 24 hours.
5

Door Removal instructions
Tools Necessary;
Phillios neac
Cover Screw
Top Hinge
.Cover
Hinge
Screw
/_,op Hinge
J
Hinge
Assembly
Screws/'/"
(
DOOR REMOVAL iNSTRUCTiONS:
if it is necessary to move the refrigerator through narrow doorways,
fo#ow these steps to remove the doors.
iMPORTANT: Before you begin, turn freezer temperature control to
OFF and remove electrical power cord from wall outlet. Remove any
food from door shelves.
1. Disconnect electrical supply.
2. Open both doors, then remove toe grille.
3. Close doors.
To Remove Refrigerator Door:
1. Remove top hinge cover screw on refrigerator door and remove cover.
2. Trace around hinge with soft lead pencil. This will make it easier to
realign doors when they are replaced.
3. Remove top hinge and lift refrigerator door off bottom hinge pin. Set
door aside.
4. Remove bottom hinge, if necessary.
5. Reverse this procedure to reinstall refrigerator door.
To Remove Freezer Door:
1. Disconnect water line coming from lower hinge offreezer door atconnection
located under front offreezer: grip water tube firmly in one hand. then with
3/8"wrench or fingers, push in on gray collar to release water connector.
2. Remove top hinge cover screw on freezer door and remove cover.
3. Disconnect wiring harness connector plug attop hinge: place your thumbs
on fiat sides of each connector and bend both parts back and forth
then with firm grasp, pull both pieces apart.
4. Trace around hinge with soft lead pencil. This will make it easier to
realign doors when they are replaced.
5. Remove top hinge,allowingwiring harness to pull through hinge and liftfreezer
door off of bottom hinge pin. Lay door down fiat toavoid kinking water line.
6. Remove bottom hinge, if necessary.
7. Reverse this procedure to reinstall freezer door.
When both doors have been reinstalled replace toe grille and plug in electrical
power cord. Turn both temperature controls to center position. Adjust settings
as necessary.
__ _ Water
Line
Hinge /Tubing
-\
Assembly "Screws
6

Freezer and Refrigerator
Controls
ice Cream
SpiliSafe T_
_gShelf
Water Filter
Door Bin
ice Container
Pizza Shelf
Wire Shelf
Small items
Door Bin
Wire Shelf
Door Bin
Small Basket
Large Basket
Door Bin
Large Basket
Door Bin
Dairy Door
Door Bin
Wine Rack
Door Bin
Meat Keeper
and Cover
SpinSafe T"
Fixed Shelf
Door Bin
Egg Tray
Special item
Rack
Tail Bottle
Retainer
Snugger
Crisper Pan
and Cover
Fixed
Door Bin
Toe Grille
Features may vary according to model

COOL DOWN PERIOD
Toensure safe food storage, allow the refrigerator to operate with the doors closed for at least 8 to 12 hours before loading
it with food.
REFRIGERATOR & FREEZER CONTROLS
NOTE: when first turning refrigerat0_ on, mOve refrigerator c01dcontrol toYWhich iSthe recommended initial setting:
TEMPERATURE ADJUSTMENT
•After 24 hours, adjust the controls as needed. Adjust
temperatures gradually: move the knob in small
increments, allowing the temperature to stabilize.
•For colder temperatures, turn the knob towards Colder.
•For warmer temperatures, turnthe knob towards Warmer.
To maintain temperatures, a fan circulates air in the
refrigerator and freezer compartments. For good circulation
do not block cold air vents with food items. Refrigerator & Freezer Controls
iMPORTANT: Turning the freezer temperature contr01t0 off turns 0ff the c0mpress0r, but d0eS n0t disc0nnec t the
power to the light bulb and other electrical components;
TEMPERATURE ADJUSTMENT GUIDE
If Refrigerator Compartment Is Too Warm Turn Refrigerator Control Slightly Towards Colder.
If Refrigerator Compartment Is Too Cold Turn Refrigerator Control Slightly Towards Warmer.
If Freezer Compartment Is Too Warm Turn Freezer Control Slightly Towards Colder.
If Freezer Compartment Is Too Cold Turn Freezer Control Slightly Towards Warmer.
To Turn Refrigerator Off Turn Freezer Control To Off.
8

PIZZASHELF(SOMEMODELS)
Thisshelfisattachedtothefreezerwallbesidetheicedispensercontainer.
Thisconvenientareaallowsforstorageofpizzaandothertallitemsplaced
verticallybetweentheicedispensercontainerandthefreezerwall.
iCECREAMSHELF(SOMEMODELS)
Thisshelfattachestothetopoftheicedispensercontainer.Itallowsstorage
ofbothroundandrectangularcartonsofyourfavoriteicecream.
TIP-UP SHELF (SOME MODELS)
A Tip-Up shelf in the freezer section allows tall items to be easily stored.
Toavo=dpersonaojur p,0pe,tydamagelhandle
tempered glass shelves carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden temperature change.
CANTILEVER SHELF ADJUSTMENT
Refrigerator shelves are easily adjusted to suit individual needs. Before
adjusting the shelves, remove all food. Cantilever shelves are supported at
the back of the refrigerator.
To adjust cantilever shelves:
0 Lift front edge up.
0 Pull shelf out.
Replace the shelf by inserting the hooks at rear of the shelf into the wall
bracket. Lower the shelf into the desired slots and lock into position.
Spi//Safe TM glass shelves (some models) catch and hold accidental spills. In
some models, the SpillSafe TMshelves slide out for easy access to food and
forfast cleaning. The shelves slideout independently oftheir mounting brackets.
Just pull the front of the shelf forward. Shelves can be extended as far as the
stopper will allow but are not removable from their mounting brackets.
Cantilever Glass Shelf
\
Pizza Shelf
Ice Cream Shelf
Cantilever Sliding Glass Shelf

DOOR STORAGE
Door bins and shelves are 3rovided for convenient storage
of jars, bottles, and cans. Frequently used items can be
quickly selected.
Some models have door bins that can accommodate gallon-
sized plastic drink containers and economy-sized jars and
containers. Some bins are adjustable for maximum storage
capacity.
The dairy compartment, which is warmer than the general
food storage section, is intended for short term storage of
cheese, spreads, or butter.
TALL BOTTLE RETAINER (SOME MODELS)
The Tall Bottle Retainer keeps tall containers in the bin from
failing forward when opening or closing the refrigerator door.
To install, hold the retainer at the top, and slide it over the
outside wall of the bin, as shown in the diagram. The Tall
Bottle Retainer works best with a Bin Snugger.
Fixed Door Bin
ADJUSTABLE DOOR BINS
Some models have adjustable door bins that can be moved
to suit individual needs.
Tomove door bins
1. Lift bin straight up.
2. Remove bin.
3. Place bin in desired position.
4. Lower bin onto supports until locked in place.
Tall Bottle Retainer (left) and Bin Snugger (right)
SPECIAL ITEM RACK (SOME MODELS)
The innovative design of the Special Item Rack allows you
to store a six-pack of 12 ounce drink cans. a bottle of wine.
a two-liter soft drink bottle, or a carton of eggs. The Special
Item Rack mounts on the left side of your refrigerator. To
install, just slide the Special Item Rack onto any shelf as
shown in the drawing.
Special ItemRack
10
