Frigidaire FRT18G5A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR
FRT18G5AQ4 FRT18G5A R134a bisque
FRT18G5AW4 FRT18G5A R134a white
MARKET ENERGY GUIDE
North America 218791433
Publication No.
5995379848
021017
-EN/SERVICE /ECL
390
TOP MOUNT
REFRIGERATOR
Model No.
FRT18G5A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - # 240379010
OWNER’S GUIDE - # 240400107
SERVICE DATA SHEET - # 240379010

10/02 2
Publication No. FRT18G5A
5995379848
DOOR

# = Fast-moving Parts 3 10/02
* = Non-Illustrated Parts
FRT18G5A Publication No.
5995379848
A = FRT18G5A (FRT18G5AW4)
B = FRT18G5A (FRT18G5AQ4)
POS. NO PART NO DESCRIPTION
1 240542103 A B Gasket-frzr door,white ,magnetic
2 240542106 A B Gasket-refr door,white ,magnetic
4 240534901 A B Rack-door
4B 240534701 A B Rack-door,4A
7 240337703 A B Door-dairy,w/o graphics ,clear
8 240534801 A B Rack-door
10 240381301 A - Plug-button,white ,hinge brg hole ,(2)
10 240381302 - B Plug-button,bisque ,hinge brg hole ,(2)
11 240410201 A - Door-frzr,white ,complete assy
11 240410202 - B Door-frzr,bisque ,complete assy
12 240415201 A - Label-nameplate,white
12 240415203 - B Label-nameplate,bisque
13 240312403 A - Door Stop,white ,ref
13 240312407 - B Door Stop,bisque ,ref
13A 240312404 A - Door Stop,white ,frzr
13A 240312408 - B Door Stop,bisque ,frzr
14 240494001 A - Plug-button,white
14 240494002 - B Plug-button,bisque
15 240410301 A - Door-refr,white ,complete assy
15 240410302 - B Door-refr,bisque ,complete assy
18 218668001 A - Handle-door,white
18 218668004 - B Handle-door,bisque
21 240383401 A B Screw,truss hd quad ,#10-16 x .500
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240527101 A B Bearing-hinge,natural color ,(8)
37 215870629 A - Trim-handle,2.47" ,white ,w/satin AL band
37 215870633 - B Trim-handle,2.47" ,bisque ,w/satin AL band
37* 218676004 A B Band-decorative,satin aluminum ,handle trim
DOOR

03/02 4
Publication No. FRT18G5A
5995379848
CABINET

# = Fast-moving Parts 5 03/02
* = Non-Illustrated Parts
FRT18G5A Publication No.
5995379848
A = FRT18G5A (FRT18G5AW4)
B = FRT18G5A (FRT18G5AQ4)
POS. NO PART NO DESCRIPTION
1 240355401 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 240367401 A B Damper-fan cover
5 # 5308000010 A B Fan Blade,red ,evaporator fan
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240462008 A B Cover-evap coil
10* 240532102 A B Seal-coil cover
10*# 240524701 A B Wiring Harness,freezer section
11 5303208309 A B Plug-hole,factory test
12 240366801 A B Plug-ice maker harness,rectangular
12A 240374401 A B Plug-wtr inlet tube,round ,1"
13 # 240369701 A B Motor-evap fan
13* 215474201 A B Washer,"slinger" ,nylon ,evap fan shaft
13* 218931001 A B Clamp-motor wiring,nylon ,w/adhesive tape
14 5303292397 A B Bracket-motor mtg,rear
14* 240433201 A B Screw,hex washer head ,8-18 x 0.375
18 240411901 A B Support-evap cover,(2)
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 215774901 A - Plug-button,white ,upr hinge holes
22 215774919 - B Plug-button,bisque ,upr hinge holes
28 240335501 A B Bolt-roller adj,hex washer head ,1/4-20 x 4.020,(2) ,special
30 240314002 A - Bracket-lower hinge,white
30 240314004 - B Bracket-lower hinge,bisque
34 240311301 A B Washer,hinge ,nylon ,(2)
35 240313802 A - Bracket-ctr hinge,white
35 240313804 - B Bracket-ctr hinge,bisque
35A 240336801 A B Spacer-hinge,center
36 240516401 A B Pin-center hinge
37 240337601 A - Trim-cabinet corner,white ,(2)
37 240337604 - B Trim-cabinet corner,bisque ,(2)
38 240313701 A B Bracket-upper hinge
40 240354401 A - Cover-upper hinge,white
40 240354403 - B Cover-upper hinge,bisque
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 240423601 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw,hex washer head ,8-15A x 0.500
59 240442702 A - Screw-#10-32 X 3/4,white
59 240442704 - B Screw-#10-32 X 3/4,bisque
72 240368205 A - Grille/Kickplate,white
72 240368206 - B Grille/Kickplate,bisque
81 5308016566 A B Screw,hex washer head ,8-15A x 0.625 ,low profile
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
89 240326115 A B Cover-access,with label
89* 241500302 A B Screw,hex washer head ,8-18AB x 0.625
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 240479601 A B Plug,button ,cab liner holes
* 5303305324 A - Paint,touch-up ,white
* 5304414035 - B Paint,touch-up ,bisque
CABINET

10/02 6
Publication No. FRT18G5A
5995379848
SHELVES

# = Fast-moving Parts 7 10/02
* = Non-Illustrated Parts
FRT18G5A Publication No.
5995379848
A = FRT18G5A (FRT18G5AW4)
B = FRT18G5A (FRT18G5AQ4)
POS. NO PART NO DESCRIPTION
10 215667501 A B Tray,ice cube ,plastic
11 240358002 A B Shelf-freezer,full width
11* 5303299664 A B Spacer,shelf
12 240545001 A B Diffuser,air ,top
13 240362601 A B Diffuser,air ,bottom
13* 240371304 A B Seal,foam ,air diffuser
14 # 240505801 A B Switch,light/lamp
15 240436702 A B Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature
16 241500701 A B Socket-light/lamp
17 240352701 A B Control Box
17*# 240388701 A B Wiring Harness,control box
18 240360801 A B Knob,temp control
21 # 5304421256 A B Control,temperature
22A 240468201 A B Tube,sensor sleeve ,31 inch ,plastic ,white
23 # 215846606 A B Timer,defrost ,60 Hz ,0.25 W ,120 V ,10 hour/30 min
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 240372409 A B Frame,sliding shelf ,full width
24A 240372410 A B Frame,sliding shelf ,full width ,w/hanger tabs
25 240364713 A B Cover-crisper pan,with beam ,humid cont
25B 240361202 A B Control-humidity
25C 240361301 A B Damper,humidity cont.
26 240337103 A B Pan-crisper,clear ,(2) ,no graphics
29 240357704 A B Trim-shelf,front
31 240530803 A B Pan-meat,w/o graphics ,clear
40 240350620 A B Glass-shelf,23.78" x 16.34"
41 240561502 A B Trim-shelf,rear
42 240530601 A B Track,meat pan hanger ,LH
42* 240530701 A B Track,meat pan hanger ,RH
47 240350608 A B Insert-pan cover,23.82" x 15.50" ,glass
81 5308016566 A B Screw,hex washer head ,8-15A x 0.625 ,low profile
123 215005100 A B Screw,hanger/rlr mtg ,8-10 x 0.438
* 218791433 A B Energy Guide
SHELVES

10/02 8
Publication No. FRT18G5A
5995379848
SYSTEM

# = Fast-moving Parts 9 10/02
* = Non-Illustrated Parts
FRT18G5A Publication No.
5995379848
A = FRT18G5A (FRT18G5AW4)
B = FRT18G5A (FRT18G5AQ4)
POS. NO PART NO DESCRIPTION
1 # 240444401 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240496101 A B Wiring Harness,machine compt ,w/electric cord
6* # 240524701 A B Wiring Harness,freezer section
6* # 240388701 A B Wiring Harness,control box
14 # 5303918208 A B Defrost Heater Kit
15 # 5303918274 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434002 A B Trough-drain
20 240518401 A B Insulation,evap block ,foam ,LH/RH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330001 A B Plate-compr mtg
22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B Grommet-compr mtg,(4)
25 240491501 A B Screw-comp,hx wshr hd ,1/4-28 x 1.16,shoulder,typ CF
26 240332605 A B Pan-defrost drain
29 # 5303918264 A B Compressor,w/electricals
30 # 218721120 A B Starter,PTC
32 240493301 A B Clamp,elec cont mtg ,compressor ,bale wire
34 240405201 A B Grommet,rubber ,black ,cond tube/wire
41 218897001 A B Screw,hex washer head ,8-32 x 1/4
41* 5308000039 A B Screw,hex washer head ,8-32CA x 0.500 ,serrated head
44 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
55 # 218909901 A B Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
57 240542601 A B Clip-wiring harness
58 240346801 A B Screw-cond fan mtr,hx serr wshr hd ,8-32 x 7/16,(3)
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal,shroud
59* 240359401 A B Screw-fan shroud,(2)
59A 240346501 A B Bracket-support,cond mtr ,(3)
59B 240346601 A B Grommet-bracket,(3)
60 240397101 A B Motor-condenser fan
61 # 240315401 A B Fan Blade,galv steel ,condenser fan
61* 240397201 A B Connector-shaft
61A 218956700 A B Nut,speed
61B 218956801 A B Grommet-silencer
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
84 240500801 A B Tube-drain,rubber ,lower
85 240493101 A B Tube-connector,suction
86 240409302 A B Spacer-cond tube,black
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* # 5303918222 A B Hot Tube Repair Kit,Service
* 5303918263 A B Heat Exchanger Kit,suction line
SYSTEM

10/02 10
Publication No. FRT18G5A
5995379848
WIRING SCHEMATIC

# = Fast-moving Parts 11 10/02
* = Non-Illustrated Parts
FRT18G5A Publication No.
5995379848
WIRING DIAGRAM
