Frigidaire PLRT217TA User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
PLRT217TAB0 PLRT217TA R134a Professional black (right) 115
PLRT217TAK0 PLRT217TA R134a Professional black (left) 115
MARKET
North America
Publication No.
5995354445
010608
-EN/SERVICE/KHB
357
TOP MOUNT
REFRIGERATOR
Model No.
PLRT217TA
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - # 240398801
OWNER’S GUIDE - # 240400103
SERVICE DATA SHEET -# 240379005

06/01 2
Publication No. PLRT217TA
5995354445
DOOR

# = Fast-moving Parts 3 06/01
* = Non-Illustrated Parts
PLRT217TA Publication No.
5995354445
A = PLRT217TA (PLRT217TAB0)
B = PLRT217TA (PLRT217TAK0)
POS. NO PART NO DESCRIPTION
1 # 240390705 A B Gasket-frzr door,black ,magnetic
2 # 240390704 A B Gasket-refr door,black ,magnetic
7 240338303 A B Door-dairy
11 240450317 A - Panel-frzr door, stainless steel, complete assy
11 240450318 - B Panel-frzr door, stainless steel, complete assy
12 240449704 A B Nameplate,black
13 240312405 A B Door Stop,black ,ref
13A 240312406 A B Door Stop,white ,frzr
15 240450419 A - Panel-refr door, stainless steel, complete assy
15 240450420 - B Panel-refr door, stainless steel, complete assy
18 240413701 A B Handle-door, stainless steel, with insert
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240311202 A B Bearing-hinge,black ,(8)
27A 240396102 A B Retainer,tall bottle
48 240338101 A B Bin-door,Pseudo ,bottom
48A 240430301 A B Bin-door,gallon
49 240337802 A B Bin-door,clear ,frzr
79 218755402 A B Screw-set,10-32 x 0.375
80 218755501 A B Screw-shoulder,#10 AB ,handle mounting
96 240345504 A B Plug-foam hole,black
* 218490900 A B Cleaner,stainless steel
DOOR

06/01 4
Publication No. PLRT217TA
5995354445
CABINET

# = Fast-moving Parts 5 06/01
* = Non-Illustrated Parts
PLRT217TA Publication No.
5995354445
A = PLRT217TA (PLRT217TAB0)
B = PLRT217TA (PLRT217TAK0)
POS. NO PART NO DESCRIPTION
1 240355404 A B Cover-fan
5 # 5308000010 A B Fan Blade,red ,evaporator fan
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240313603 A B Cover-evap coil
10* 240371303 A B Seal-coil cover
10*# 240385302 A B Wiring Harness,freezer section
11 5303208309 A B Plug-hole,factory test
13 # 240369701 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg,rear
14* 240433201 A B Screw-8-18 x 3/8, hex washer head
15 215812200 A B Light Bulb/Lamp,25W
16 218906801 A B Socket-light/lamp
18 240345801 A B Support-evap cover,(2)
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 215774918 A B Plug-button,black ,upr hinge holes
28 240335501 A B Bolt-roller adj, hex wshr hd,1/4-20 x 4.020, (2), special
30 240314003 A B Bracket-lower hinge
34 240311301 A B Washer,hinge ,nylon ,(2)
35 240313803 A B Bracket-ctr hinge,black
35A 240336801 A B Spacer-hinge,center
36 240313901 A B Pin-center hinge
37 240337603 A B Trim-cabinet corner,black
38 240313701 A B Bracket-upper hinge
40 240354404 A B Cover-upper hinge,black
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1.250
56 240314101 A B Pin-lower hinge
58 5303001343 A B Screw,hex washer head ,8-15A x 0.500
59 240442703 A B Screw-#10-32 X 3/4,black
72 240368203 A B Grille/Kickplate,black
74 240354301 A B Shield-light,frzr
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
82 5304418225 A B Roller,comp base ,rear ,(2)
83 215164200 A B Pin-roller,(2)
89 240326115 A B Cover-access,w/label
89* 241500301 A B Screw,#8 18 x .500 ,(3)
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
114# 240413601 A B Switch-light/lamp
* 218990901 A B Clip-wire
* 5303305345 A B Paint,touch-up ,black
CABINET

06/01 6
Publication No. PLRT217TA
5995354445
SHELVES

# = Fast-moving Parts 7 06/01
* = Non-Illustrated Parts
PLRT217TA Publication No.
5995354445
A = PLRT217TA (PLRT217TAB0)
B = PLRT217TA (PLRT217TAK0)
POS. NO PART NO DESCRIPTION
11 240358003 A B Shelf-freezer
11* 5303299664 A B Spacer-shelf
12 240417802 A B Diffuser-air,top
13 240362601 A B Diffuser-air,bottom
14 # 240413601 A B Switch-light/lamp
15 # 5303001179 A B Light Bulb/Lamp,40 W
16 241500701 A B Socket-light/lamp
17 240407301 A B Box-control
17*# 240388701 A B Wiring Harness,control box
18 240360801 A B Knob-control
21 # 5304421256 A B Control-temperature
22A 240468201 A B Tube,sensor sleeve ,plastic ,white
23 # 215846606 A B Timer-defrost, 60 Hz, 120 V, 10 hour/30 min
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240355228 A B Shelf-"Spill-Safe", cantilever, half width, fixed
24A 240350119 A B Shelf-"Spill-Safe",cantilever ,sliding
25 240364718 A B Cover-crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper-humidity control
26 240343803 A B Pan-crisper,(2)
28 3201150 A B End Cap-shelf,protector ,frzr shelf
31 240371403 A B Pan-meat
34 240385201 A B Container-ice
42 240356501 A B Hanger-meat pan,RH
42 240365401 A B Hanger-meat pan,white ,LH
47 240443301 A B Insert-pan cover,glass
66 5303295947 A B Rack-wine
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
120 240366401 A B Guide-follower
121 240366602 A B Cam follower
122 240366501 A B Cam-damper
123 215005100 A B Screw-roller/hanger,8-10 x 0.438
130 240366101 A B Damper-control box
131 240366201 A B Retainer-damper
132 240366302 A B Control Rod,damper
* 3205266 A B Edge Protector,wiring harness
* 240443401 A B Seal-air supply
SHELVES

06/01 8
Publication No. PLRT217TA
5995354445
SYSTEM

# = Fast-moving Parts 9 06/01
* = Non-Illustrated Parts
PLRT217TA Publication No.
5995354445
A = PLRT217TA (PLRT217TAB0)
B = PLRT217TA (PLRT217TAK0)
POS. NO PART NO DESCRIPTION
1 # 240345601 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240375301 A B Wiring Harness, machine compt, w/service cord
6* # 240385302 A B Wiring Harness,freezer section
6* # 240388701 A B Wiring Harness,control box
14 # 5303918247 A B Defrost Heater Kit
15 # 5303918250 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434002 A B Trough-drain
18 240362301 A B Insulation Block,RH
20 240362401 A B Insulation Block,LH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330001 A B Plate-compr mtg
22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B Grommet-compr mtg,(4)
25 240491501 A B Screw-compressor mtg,1/4-28 x 1.16,shoulder,typ CF
26 240332602 A B Pan-defrost drain
29 # 5303918249 A B Compressor,w/electricals
30 # 218721113 A B Starter-PTC
32 218740800 A B Clamp,elec cont mtg ,compressor
34 240405201 A B Grommet-cond mtg,(4)
41 218897001 A B Screw,hex washer head ,8-32 x 1/4
41* 5308000039 A B Screw, hex wshr hd, 8-32CA x 0.500, (7), serrtd hd
44 5303001199 A B Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
55 # 218909901 A B Capacitor-run,220 VAC ,15 microfarad
57 240403601 A B Clip-wiring harness
58 215004600 A B Screw-cond fan mtr, hx serr wshr hd, 8-36 x 7/16, (2)
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal,shroud
59* 240359401 A B Screw-fan shroud,(2)
59A 240346501 A B Bracket-support,cond mtr ,(3)
59B 240346601 A B Grommet-bracket,(3)
60 # 240334001 A B Motor-condenser fan
61 # 240315401 A B Fan Blade,galv steel ,condenser fan
61A 215004700 A B Nut,speed
61B 215004800 A B Grommet-silencer
82 5304418225 A B Roller,comp base ,rear ,(2)
83 215164200 A B Pin-roller,(2)
84 240359601 A B Tube-drain,lower
85 240346201 A B Tube-connector,suction
86 240409302 A B Spacer-cond tube,black
* 218843800 A B Screw,hex wshr hd ,8-15A x 0.500, wiring clamps
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* # 5303918210 A B Heat Exchanger Kit,suction line
* 5304421289 A B Hot Tube Repair Kit,Service
SYSTEM

06/01 10
Publication No. PLRT217TA
5995354445
ICE MAKER

# = Fast-moving Parts 11 06/01
* = Non-Illustrated Parts
PLRT217TA Publication No.
5995354445
A = PLRT217TA (PLRT217TAB0)
B = PLRT217TA (PLRT217TAK0)
POS. NO PART NO DESCRIPTION
1 218976901 A B Tube-water inlet,inlet valve to ice maker
2 5304420650 A B Spring,shut-off arm
2* 5308000039 A B Screw, hex wshr hd, 8-32CA x 0.500, (7),serrated head
3 3206299 A B Label,ID plate
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire,8-32 x 0.250
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-hold switch
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff, ice maker, complete assy
12 # 5304420651 A B Wiring Harness, ice maker, internal, with plug
13 # 3206322 A B Thermostat Assy,ice maker
14 5304420652 A B Screw,4 x 3/4 ,switch mtg.
15 # 3206324 A B Switch,(3)
16 5304420653 A B Support,phenolic
17 # 5303320545 A B Mold-ice maker,Radius Cube ,with heater
18 3206328 A B Ejector-ice
19 3206330 A B Bearing & Inlet
20 5304408581 A B Screw,8-32 x 0.375
21 3206332 A B Ice Stripper
22 3206333 A B Shut-off Arm
23 5304408582 A B Screw,8-32 x 0.875 ,mold-to-support, (3)
24 3206335 A B Lever Arm
25 3206336 A B Screw,8-18 x 0.562 ,lever arm/sprt
26 5304420654 A B Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B Screw-timing stop,4-40 x 0.375
29 3206323 A B Screw,4-24 x 0.750 ,(6)
30 3206341 A B Screw-timing adj,8-32 x 1.000
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 5304408583 A B Spring-timing adj
34 5304420655 A B Screw,plazcrew ,8-10 ,(3)
35 5304408585 A B Screw
36 3206347 A B Cover-ice maker
42 5303001199 A B Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
45* 218843800 A B Screw, hex wshr hd, 8-15A x 0.500, wiring clamps
46 5303001193 A B Clamp,.50 ID ,steel ,water tube
51 240387101 A B Tube-water,ice mold fill ,extension
55 # 240380301 A B Valve-water, single solenoid, 50/60 Hz, 105/120 V
60 218362500 A B Screw,hex washer head ,8-18AB x 1.250
61 218721500 A B Bracket-leveling,ice maker
62 218737900 A B Screw-IM brkt mtg, hex wshr hd, 8-32D x 0.375
64 5303001549 A B Clamp,0.31 ID ,steel ,copper wtr line
* 240352403 A B Ice Maker, Radius Cube, 115 V, no instl parts
ICE MAKER

06/01 12
Publication No. PLRT217TA
5995354445
WIRING SCHEMATIC

# = Fast-moving Parts 13 06/01
* = Non-Illustrated Parts
PLRT217TA Publication No.
5995354445
WIRING DIAGRAM
