Frigidaire 308-2414FR Instruction Manual

Model: 308-2414FR www.lacrosseclock.com/support Page | 1
Model: 308-2414FR
Instruction Manual
DC: 103015
LED ALARM WEATHER STATION
WITH IN/OUT TEMPERATURE
LED
Reset
Stand
Battery
Compartment
2 AAA batteries
TW004
Outdoor Sensor
BUTTONS
Note: This product display
temperature in Fahrenheit only.
AC Adapter 4.5V
KU1B-045-0200D
Stand Lock
Stand
(please attach
stand to station)

Model: 308-2414FR www.lacrosseclock.com/support Page | 2
WWVB Atomic Time Signal Search
After your clock is powered up, it searches for the Atomic time signal for
seven minutes. The icon flashes.
Note: During Atomic time signal search, the buttons will not function. The
LED will change to low brightness and will return to high brightness after
the Atomic time search search.
•Receiving Atomic signal ( icon flashing)
•Successful Reception ( icon becomes static)
•Failed Reception ( icon disappears)
Hold / WAVE button until your clock gives a short beep to stop or start
the Atomic time signal reception.
During the search, press / WAVE button once to show reception mode
and signal strength Indication:-
•When a strong signal is detected, display shows with 3 bars
•During reception, the signal strength may move from 1 bar to 2 bars
to 3 bars. This is normal since the clock is detecting Atomic time
signal and other signals in the air at the same time.
Press SET will return to the time display with icon flashing.
For information about WWVB Atomic time visit:
www.nist.gov/pml/div688/grp40/wwvb.cfm
Get Started
Step 1: Insert the AC/DC adaptor to an outlet, then into the back
of the clock.
Step 2 (Optional): Insert 1 x CR2032 Lithium battery (not
included) to the battery compartment on the back of the
clock. The + side of the battery should face up.
Step 3: Slide open the battery cover at the back of the wireless
TW004 sensor, make sure the channel selector is set at
position 1 (top position), then insert 2 x AAA batteries (not
included) into the outdoor sensor. Observe the correct
polarity.
Step 4: Peel off the protective label on the front.
Restart: If the outdoor temperature is not displayed after 3
minutes, remove AC power and batteries from the weather station
& outdoor sensor. Press any button on the temperature station 20
times. After 5 minutes, return to Step 1 above.

Model: 308-2414FR www.lacrosseclock.com/support Page | 3
Manual Set Time
1. Hold the SET button to enter time set mode.
2. Press the ▼ or ▲ buttons to adjust the values.
3. Press the SETbutton to confirm adjustments and move to the next
item.
Time setting order:
1. Time Zone - 4 time zones (04 Default)
2. DST (Daylight Saving Time ON/OFF)
3. Hour
4. Minutes
5. Snooze Time (05 -60 minutes)
Press the SET button to exit, or wait 10 seconds without pressing
buttons to return to the normal time display.
Set Time Alarm
1. Hold the AL button to enter alarm set mode.
2. Press the ▼ or ▲ buttons to adjust the values.
3. Press the AL button to confirm adjustments.
Time setting order: 1. Hour 2. Minutes
Press the AL button to exit, or wait 8 seconds
without pressing buttons to return to the normal time display.
Note: The alarm will sound for two minutes, then shut off completely.
Activate/Deactivate time Alarm
•Press the AL button once to activate the alarm.
•The letters “AL” will appear above the time when the alarm is active.
•Press the AL button once again to deactivate the alarm.
Snooze Time
•When the alarm sounds, press once to stop the
alarm temporarily. The letters “AL” will flash. The alarm will
beep again in 5 minutes or after the previously set snooze
duration.
•To stop the daily alarm, press any button EXCEPT the when
alarm is beeping. The alarm will stop and “AL: icon becomes solid;
alarm will beep again same time next day.
Dimmer Function
Press the button to dim the display or to brighten the display.
TIME ZONES:
04 Pacific
03 Mountain
02 Central
01 Eastern

Model: 308-2414FR www.lacrosseclock.com/support Page | 4
Forecast Icons
•There are 4 different forecast icons that change according to
barometric pressure.
Reset Button
•If the weather station display appears distorted or is not responding
to buttons, use a pen or paperclip to press RESET button one time.
•This will reset the weather station to default settings.
•Press the reset button on the outdoor sensor to reset the
sensor.
Position the Weather station
The weather station may be wall mounted or placed on a desk or table
when using the stand.
Set on table or desk:
1. Insert the round stand into the back of the weather station.
2. Turn the stand to the right ¼ turn, to lock into place.
Wall Mount:
1. Turn stand to the left to remove it from weather station.
2. Place a screw (not included) into the wall where you wish to hang the
weather station.
3. Place the weather station on the screw and pull down so it locks in.
Search for Outdoor Sensor
•Hold the ▲ button for five seconds to search for the outdoor sensor.
The outdoor temperature area will flash.
•Remove batteries and reinsert them into the outdoor sensor.
•The sensor should reconnect with the weather station.
Position Outdoor Sensor
•Mount the outdoor sensor on a north-facing wall or in any well shaded area.
Under an eave or deck rail is preferred.
•The maximum transmitting range to the wireless weather station is over 196
feet (60 meters) in open air, not including walls.
Care and Maintenance
•Do not mix old and new batteries
•Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries
•Always purchase the correct size and grade of battery most suitable for the
intended use.

Model: 308-2414FR www.lacrosseclock.com/support Page | 5
•Replace all batteries of a set at the same time.
•Clean the battery contacts and also those of the device prior to battery
installation.
•Ensure the batteries are installed correctly with regard to polarity (+and -).
•Remove batteries from equipment with is not to be used for an extended
period of time.
•Remove expired batteries promptly.
Specifications
Indoor:
Temperature Range: +32°F to +99°F
Outdoor:
Temperature Range: -40°F to +140°F
Distance:
Over 196 ft. (60 meters) RF 433MHz (open air)
Power:
Weather Station AC Primary:
4.5V AC Cord KU1B-045-0200D
CR2032 backup battery (optional, not included)
TW004 Sensor: 2-AAA, IEC, LR3 batteries (not included)
Battery Life:
Weather station:
Around 12-15 months
TW004 Sensor:
Around 6-9 months
Dimensions:
Weather station:
5.55" x 5.19" x .87" (141 H x 132 W x 22 D) mm
TW004 Sensor:
4.1H x 1.95” W x 0.95” D (without bracket)
(104.14 H x 49.53 W x 24.13 D mm)
Warranty and Support Information
La Crosse McCormick, LLC provides a 1-year limited warranty on this product
against manufacturing defects in materials and workmanship.
For warranty work, technical support, or information contact customer support
online or write:
La Crosse McCormick, LLC
Warranty Dept.
2830 S. 26th St.
La Crosse WI, 54601
Before returning a product, please contact our friendly customer support with
questions:
Phone: [phone]
Online Product Support: www.lacrosseclock.com/support

Model: 308-2414FR www.lacrosseclock.com/support Page | 6
Protected under U.S. Patents:
5,978,738 | 6,076,044 |RE43903
“Frigidaire is a registered trademark used under license
from Electrolux Home Products, Inc.”
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device must not be co-located or operating in conjunction with any other antenna
or transmitter.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user
authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or
duplicated or processed using electronic, mechanical or chemical process without the
written permission of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly
checked and corrections are included in subsequent editions. We disclaim any
responsibility for any technical error or printing error, or their consequences.
All trademarks and patents are recognized.
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:(1) This device may not cause interference;
and(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
