USER MANUAL MODEL:B0340WST2H2R-V7
WIRELESS WEATHER STATION
WITH TOUCH BUTTONS
Email: [email protected]
USA Tel.: [phone]
Thank you for your purchasing of BALDR Wireless Weather Station.
To ensure proper use, please read the user manual carefully before
use. If you have any problems during use, please feel free to contact
us for support.
ALWAYSDST

11
Contents
1. PRODUCT OVERVIEW 2
2
3
4
4
5
6
5
12
7
9
12
13
15
15
14
13
13
14
15
15
16
17
19
1.1 WEATHER STATION（MAIN UNIT）
1.2 BUTTONS INTRODUCTION
1.3 REMOTE SENSOR
2.PACKAGING INCLUDES
3.1 POWER UP
3.2 RCC FUNCTION
3.QUICK SET-UP GUIDE
3.6 SNOOZE MODE
3.5 ALARM SETTING
3.4 REMOTE SENSOR INSTALLATION
3.3 MANUAL SETTINGS
3.7 MAX/MIN TEMPERATURE & HUMIDITY RECORDS
9.1 TECHNICAL SPECIFICATIONS
9.2 MEASUREMENT SPECIFICATIONS
4.TEMPERATURE & HUMIDITY TREND ARROWS
5.COMFORT LEVEL INDICATOR
6. WEATHER FORECAST
7. BACKLIGHT FUNCTION
8. LOW BATTERY INDICATOR
9. SPECIFICATIONS
10. TROUBLESHOOTING GUIDE
11. PRECAUTIONS
13. WARRANTY
18
12. FCC STATEMENT

ALWAYSDST
1.1 WEATHER STATION（MAIN UNIT）
1.PRODUCT OVERVIEW
2
1.Outdoor Sensor Channel Indicator
From CH1,CH2,CH3 to Circular Channels model
2.Current Outdoor Temperature and Humidity
3.“CH/▲” Button
Switch channel, re-connect to sensor or increase
the value
4.“RCC/SET” Button
RCC function or enter into time setting
5.“MEM/▼” Button
Check or clear MAX/MIN records,
decrease the value
6.“ ” Button
Check or enter into alarm setting
7.Low Battery Indicator
Remind to replace the new batteries
8.Current Indoor Temperature and Humidity
9.Temperature Trend Arrow
10.Weekday abbreviation in 7 Languages
11.Calendar Display
Month/date or date/month optional
12.Comfort Level Indicator
13.Humidity Trend Arrow
14.Weather Forecast Icon
Weather forecast for next 12-24 hours
15.RCC Function Symbol
16.Backlight/Snooze Button (at top position)
Backlight auto off after 20 seconds,
5 minutes snooze time
17.Current Time
12/24 hours display format optional
18.AM/PM for 12H Display Format
19.Max/Min Records of Indoor/Outdoor
Temperature and Humidity
Auto update at 0:00 each day
20.Hanging Hole
21.Battery Compartment Cover
22.Removable Stand
Stored in the battery compartment
20
2221
1
15
2
3
4 5 6 7
5
6
8 9
10
11
12
14
13
16171819

1.2 BUTTONS INTRODUCTION
3
BUTTONS FUNCTIONS
Normal Mode:
1.PRESS to switch channel from CH1, CH2, CH3, or Circular
Channels Mode “ ”.
2.PRESS AND HOLD 3 seconds to re-connect the sensor.
1.PRESS to search WWVB radio signal automatically.
2.PRESS AND HOLD 3 seconds to enter time setting.
Normal Mode:
1.PRESS to check MAX/MIN indoor/outdoor temperature and
humidity.
2.PRESS AND HOLD 3 seconds to clear the MAX/MIN
records.
Time Setting or Alarm Setting:
1.PRESS to decrease the value by 1.
2.PRESS AND HOLD 3 seconds to decrease the value
continuously.
1.PRESS to view alarm time, turn ON/OFF alarm.
2.PRESS AND HOLD 3 seconds to enter into alarm setting.
1.BACKLIGHT: press to turn ON the backlight (auto off after 20s).
2.When alarm rings, press to enter into snooze mode.
TOP BUTTON
Time Setting or Alarm Setting:
1.PRESS to increase the value by 1.
2.PRESS AND HOLD 3 seconds to increase the value
continuously.

To get accurate readings, please keep the main unit away from any
unusual source of heat or cold and make sure that the outdoor sensor
is also protected from direct sunlight, rain, or the heat it may experi-
ence from being mounted on a warm wall, or be closed near to a warm
wall.
1.Signal Indicator Light 3. Battery Compartment
2.Hanging Hole 4. Channel 1-2-3 Switch
Following contents are included in the packaging:
1 x Weather Station Main Unit (not included 3 x AAA batteries)
1 x Remote Sensor (not included 2x AA batteries)
1 x User Manual
1.3 REMOTE SENSOR
2. PACKAGING INCLUDES
4

Notes:
(1). Make sure outside sensor and weather station main unit at the same
channel.
(2). Do not touch any buttons in the 3 MINUTES to avoid sensor searching
be terminated.
(3). The main unit will automatically receive sensor’s RF signal in 3
MINUTES after it powered on. During receiving ,signal icon will
flashing, if no signal received within 3 minutes, it will stop receiving, and
you can press and hold the “CH/▲” Button 3 seconds to receive again.
1.1. Remove the main unit’s battery compartment cover, insert 3 new AAA
batteries in the back of the display console (please take note of the battery
polarity before inserting the batteries).
3.1 POWER UP
2.Take out the metal stand inside the battery compartment and screw it
into the hole at the main unit’s backside. Install the battery compartment
cover.
3.Remove the sensor’s battery compartment cover, set the channel to CH1,
then insert 2 new AA batteries of sensor within 3 MINUTES.
NOTE: Prepare new and high quality alkaline batteries. Do not mix
old and new batteries. Heavy duty or rechargeable batteries are not
recommended.
3. QUICK SET-UP GUIDE
5
Note: The display will beep once and all of the LCD segments will light up
for few seconds to verify all segments are operating properly, then display
indoor temperature and humidity immediately.

NOTES:
(1).Make sure the RCC function is ON or you can set it by 3.3 MANUAL
SETTINGS → Detailed Steps → refers to point 2.
(2).Make sure the time zone is correct (Default time zone is Eastern
Standard Time) or you can set the time zone by 3.3 MANUAL
SETTINGS → Detailed Steps → refers to point 3.
(3).When receiving RCC signal, please keep the weather station close
to the window or receive RCC signal outdoors to enhance the signal
reception.
*RCC Symbol Display:
a.When receiving signal , RCC symbol “ ” will be flashing.
b.When signal successfully received, LCD will display the complete RCC
symbol “ ” and exit RCC receiving.
c.If no signal is received, the RCC symbol will disappear.
After the 3 MINUTES RF signal receiving, the main unit will start searching
WWVB radio signal for 7 minutes.
1. The antenna symbol “ ” will flashing during receiving time, if signal
received, the main unit will display the received time/month/date/weekday
with symbol “ ”displaying on screen.
2. Auto receiving RCC signal at UTC 7:00, 8:00, 9:00, 10:00, and 11:00
each day. It starts receiving RCC signal at UTC 7:00 everyday, once signal
is received at any above time, it will stop receiving signal that day.
3. Manual receiving: press and hold “RCC/SET” button to enter RCC signal
receiving.
4.During receiving, no response if press other buttons, you can press and
hold “RCC/SET” button to exit RCC receiving.
3.2 RCC FUNCTION
6

1.Press and hold “RCC/SET” button to enter time set mode.
2.Press “CH/▲” and “MEM/▼” buttons to adjust the value. Hold to adjust
quickly.
3.Press “RCC/SET” button to confirm and move to the next setting.
4.Press the top button anytime to exit setting.
RCC ON/OFF→Time Zone (if RCC ON)→DST ON/OFF→12/24H Time
Format→Hour→Minute→Year →Month & Date Display→Month→Date→
Weekday abbreviation Language→Temperature Unit→ Exit.
1.Press and hold “RCC/SET” button for 5 seconds to enter setting.
2.RCC ON/OFF part: Press “CH/▲” or “MEM/▼” button to select ON or
OFF. (Note: If RCC OFF is selected, it will skip Time Zone setting and
move to 12/24 Hour setting.)
3.Press “RCC/SET” button to TIME ZONE part. Press “CH/▲” or “MEM/▼”
button to select : AST, EST, CST, MST, PST, AKST, HST. (Default setting:
-5 EST).
3.3 MANUAL SETTINGS
TIPS:
Setting Order:
Detailed Steps:
NOTE: After RCC signal received, if there is no need for other
settings, you can skip the manual settings part. If no RCC signal
received or you need to set other settings, please follow the bellow
steps to finish setting.
7

*DST symbol display:
a. Select “DST ALWAYS” , means DST function is always ON all the year
round.
b. Select “DST ”, means DST function will be ON during daylight saving
time.
c. Select “DST OFF”, means DST function is OFF.
4.Press “RCC/SET” button to DST ON/OFF part. Default setting: ON.
Press “CH/▲” or “MEM/▼” button to select DST ON if you do observe
Daylight Saving Time.
8
Hours from GMT Time Zone Description
-4 AST Atlantic Standard Time
Eastern Standard Time
Central Standard Time
Mountain Standard Time
Pacific Standard Time
Alaska Standard Time
Hawaii Standard Time
EST
CST
MST
PST
AKST
HST
-5
-6
-7
-8
-9
-10
5.Press “RCC/SET” button to 12/24H TIME FORMAT part. Default setting
:12H format.Press “CH/▲” or “MEM/▼” button to select 12-hour format or
24-hour format.
6.Press “RCC/SET” button to HOUR part. Press “CH/▲” or “MEM/▼” button
to adjust the value.
7.Press “RCC/SET” button to MINUTE part. Press “CH/▲” or “MEM/▼”
button to adjust the value.
8.Press “RCC/SET” button to YEAR part (year range: 2000-2099). Press
“CH/▲” or “MEM/▼” button to adjust the value.
9.Press “RCC/SET” button to MONTH & DATE DISPLAY FORMAT part.

3.4 REMOTE SENSOR INSTALLATION
9
NOTE:
When RCC OFF is selected, will move directly to 12/24 hour time
setting.
Weekday will shows automatically after Year, Month and Date are set.
During setting, if no operation for 20 seconds, it will automatically save
and exit setting.
Press “CH/▲” or “MEM/▼” button to select M/D or D/M format (M: Month ,D:
Date).
10.Press “RCC/SET” button to MONTH part. Press “CH/▲” or “MEM/▼”
button to adjust the value.
11.Press “RCC/SET” button to DATE part. Press “CH/▲” or “MEM/▼” button
to adjust the value.
12.Press “RCC/SET” button to WEEKDAY ABBREVIATION LANGUAGE
part. Press “CH/▲” or “MEM/▼” button to select the language: ENG(English),
DUT(Dutch), DAN (Danish), SPA (Spanish), ITA (Italian), GER(German),
FRE(French).
13.Press “RCC/SET” button to TEMPERATURE UNIT part. Press “CH/▲” or
“MEM/▼”button to select Celsius℃ or Fahrenheit ℉.
14.Press “RCC/SET” button to confirm and exit.
The data of weather forecast and outdoor humidity & temperature come from
outdoor sensors. Make sure the outdoor sensor place in proper place. Take
an example:

(1).This is forbidden, if the outdoor sensor is directly exposed to rain, facing
direct sunlight and close to any heat source.
(2).Keep well-ventilated and leave a certain space of gap between the sensor
and the wall to avoid blocking the vent of the sensor.
10
If place the sensor there,
the temperature goes up,
the humidity goes down.
If place the sensor here,
the temperature goes down,
the humidity goes up.

(3).Place the sensor at a height about 1.2-2.5 meters/3.93-8.20 feet vertically.
≥5ft
11
(4).You are near the sensor to connect the main unit. Avoid thick walls
between the units or or strong interference source using same signal
frequency(433Ghz).
(such as TVs, microwaves, computers, etc).
(5).If the main unit disconnects most likely the sensor is too far from the main
unit. Please place it nearer to the sensor. Transmission Range: 100m/330ft
Open Air.
(The sensor is the unit that connects to the main unit and transfer the signal
to the main unit.)
(6).Vertically placement is required:
Note: Allow the main unit and the sensor together at the same
position for 30 minutes to establish a strong connection.
Lift with a rope
Place on a
stable surface
Hang from the back
hole using a nail

3.5.1 Set Alarm Clock in Order: Hour > Minute> Exit.
3.5.2 Check Alarm Time
3.5.3 Alarm OFF/ON
3.6 SNOOZE MODE
3.5 ALARM SETTING
12
(1).Press and hold “ ” button for 3-4 secs to start.
(2).The “Hour” symbol begins to flash. Press “CH/▲” or “MEM/▼” button to
set up “Hour”. Press “ ” button to confirm.
(3).The “Minute” symbol begins to flash. Press “CH/▲” or “MEM/▼” button to
adjust the required minute. Press “ ” button to save and exit it.
(4).Alarm symbol “ ” will display on screen after successfully setting.
(1).Press “ ” button to check alarm time after setting.
(2).Press top button to exit .
(1).Press “ ” button to turn OFF/ON alarm when in alarm time mode.
(2).Alarm symbol “ ” will disappear on screen when in OFF mode or show
on screen when in ON mode.
(3).Press top button to exit.
(4).When the alarm is ringing, The alarm symbol “ ” will flashing and
ascending “Bibi” alarm sound will last for 2 minutes.Press any other button
except top button to stop the alarm. And the alarm will restart next day.
(1).When alarm is ring,press the TOP BUTTON to enter snooze mode, The
alarm will ring again in 5 minutes snooze interval. And the “ ” symbol will be
flashing on screen to indicate the snooze mode. Press any other button
except top button to exit the snooze mode. And the alarm will restart next
day.
(2).When alarm rings, the ascending “Bibi” alarm sound will last for 2 minutes
if no operation,or you can press any other button except top button to stop
the alarm.

The temperature and humidity trend arrows indicates the temperature or
humidity’s change trend.
Indoor comfort level indicator keeps you informed the comfort level in your
home, and when to dehumidify or humidify.
3.7 MAX/MIN TEMPERATURE & HUMIDITY RECORDS
4. TEMPERATURE & HUMIDITY TREND ARROWS
5. COMFORT LEVEL INDICATOR
13
(1).Check: Press “MEM /▼” button to switch MAX or MIN readings. The
readings will shows for 5 seconds and then will turn back to normal model.
(2).Manually Clear: Press “MEM /▼” button to enter “MAX/MIN” Record
Mode. Then press and hold “MEM /▼” button 3-4 seconds to clear all the
Max/Min data.
The screen of indoor and outdoor temperature & humidity will show “--”.
(3).Automatically Clear: The records will be cleared at 00:00 automatically
daily.
TemperatureArrows Indicator Humidity
Down Arrow
Up Arrow
Increase by 3%
RH within one
hour or compared
with last reading.
Increase by 1.8℉
within one hour or
compared with last
reading.
Decrease by 1.8℉
within one hour or
compared with last
reading.
Decrease by 3%
RH within one
hour or compared
with last reading.

6. WEATHER FORECAST
7. BACKLIGHT FUNCTION
Note: “Sunny To Cloudy” is default after power-on.
Cloudy Rainy SnowySunny Partly Cloudy
14
(1).The weather icon, where data hourly calculated from indoor/outdoor
temperature and humidity forecasts the weather in the next 12 hours.
(2).IT IS NOT THE CURRENT WEATHER. The accuracy will be 70%-75% .
(3).Please note that this forecast can’t compare with professional weather
services supported by satellites and high-performance computers.
(4).It merely provides an approximate indication of current developments.
Please give priority to the weather forecast of the local weather forecast
service.
When powered on, press the top button to turn on the backlight, and the
backlight will last 20 seconds to save power.
DRY: Humidity ≤44%
COMFORT: 45% ≤Humidity≤ 65%
68°F ≤Temperature≤ 79°F
WET: Humidity ≥ 66%
Weather Icons

9.1 TECHNICAL SPECIFICATIONS
9.2 MEASUREMENT SPECIFICATIONS
8. LOW BATTERY INDICATOR
9. SPECIFICATIONS
15
(1).When Battery Indicator shows next to the Outdoor Temperature,
replace batteries in your remote sensor.
(2).When Battery Indicator shows next to the Indoor Temperature, replace
batteries in your weather station main unit.
Indoor Temperature Range: 14 °F~ 122 °F(-10℃~ 50.0℃).
Outdoor Temperature Range: -40 °F~140 °F(-40℃~60℃).
Humidity Range: 1% to 99% RH.
Transmission Range: 328 ft (100 meters), 433MHZ (open air).
Power Requirements:
Main Unit: 3 x AAA Alkaline batteries (not included),
Remote Sensor: 2 x AA Alkaline batteries (not included).
The following table provides the specifications of the measurement parame-
ters.
ResolutionMeasurement Range Accuracy
Indoor Temperature ±2 °F (temperature between
32~122°F, if out of this range: ±3.6 °F)
±2 °F (temperature between
32~122°F, if out of this range: ±3.6 °F)
± 5% (humidity between 30-80%, if out
of this range: ±7%)
± 5% (humidity between 30-80%, if out
of this range: ±7%)
14 °F~ 122 °F 0.1 °F
0.1 °F
1%
1%
-40 °F~140 °F
1% to 99%
1% to 99%
Outdoor Temperature
Indoor Humidity
Outdoor Humidity

Problem Possible Solution
10. TROUBLESHOOTING GUIDE
16
Outdoor sensor signal is
lost or showing dashes
(- -) on the display
Outdoor temperature and
humidity keeps cycling
display/how to exit the
Circular Channels Model
1.Press and hold the "CH/▲” button for 5-6 seconds to resynchronize
(Please make sure the sensor and main unit are in same channel).
2.If the the synchronization fails, bring the sensor with main unit
together and try the bellow steps:
3.Check if the sensor is out of battery and replace with new batteries.
4.The maximum transmission range is 328ft/100m, move the sensor
closer to the main unit .
5.Make sure both main unit and sensor are placed at least 3ft/0.9m
away from electronics that may interfere with the wireless communica-
tion, such as computers, TVs, microwaves, other wireless transmitters
or receivers, etc.
6.It’s much important to install the sensor properly,please refer to
REMOTE SENSOR INSTALLATION part.
“ ”cycle symbol means that main unit enter Circular Channels
Model, it will display the datas of 3 channels in order every 10
seconds.
You can press the "CH/▲” button 1-3 times to exit Circular Channels
Model and fix the channel to CH1,CH2 or CH3.
Temperature reads too
high in the daytime
Inaccurate temperature or
humidity readings
Make sure both the main unit and sensor are placed out of direct
sunlight and away from any heat sources or vents.
When the temperature/humidity is inaccurate, it is often due to the
location of the display or overpowered/under powered batteries. You
can test the accuracy at you home.
Side-by-side test: Bring the sensor in the house and place it next to the
weather station for 2 hours.
1.Temperature:Compare indoor and outdoor temperature. The
temperature should be within 4 ℉to be within tolerance.
2.Humidity:Compare indoor and outdoor humidity. The temperature
should be within 5%RH to be within tolerance.
Factory Restart: (1).Remove all the batteries of sensor and
main unit.(2).Set the sensor channel to "CH1". (3).Insert the
batteries of main unit and press "CH/▲” button and fix the
channel to "CH1". (4).Insert the batteries of sensor,allow the
whole set device to sit together for 30 minutes to establish a
strong connection.

11. PRECAUTIONS
If your BALDR weather station still can't be worked well after trying the above troubleshooting
steps, please contact the seller on your order page or visit https://www.baldr.com or email us by
[email protected] for help.
17
Do not mix old and new batteries.
Do not mix Alkaline, Standard, Lithium, or Rechargeable batteries with
this product.
Remove the batteries if storing this product for a long period of time.
Ensure the batteries are installed with correct polarity (+ and -).
Do not clean any part of the product with benzene, thinner or other
solvent chemicals. Use a soft cloth to clean it when necessary.
Never immerse the product in water. This can cause electrical shock
and damage the product.
Do not expose the product to extreme force, shock or temperature or
humidity fluctuations.
Do not tamper with internal components.
Inaccurate weather
forecast
No response of press any
button on the main unit
The weather forecast is an estimate or generalization of weather
changes in the next 12 to 24 hours, with an accuracy rate of about
70-75%. It is simply a tool for projecting weather conditions and is
never to be relied upon as an accurate method to predict weather.
Battery is dying,please replace a new set of batteries.
Incorrect weekday display
Indoor/Outdoor
temperature shows
"HH.H/LL.L" on display
Press and hold “RCC/SET” button to set the correct Year (year range:
2000-2099).
1.If indoor temperature is lower than 14 °F/-10℃, the reading will be
"LL.L". If higher than 122 °F/+50.0℃, the reading will be “HH.H”.
2.If outdoor temperature is lower than -40 °F/-40℃, the reading will be
"LL.L". If higher than 140 °F/+60℃, the reading will be “HH.H”.

12. FCC Statement
18
This device complies with part 15 of FCC rules. Operation is subject to the
following two conditions:
1- This device may NOT cause harmful interference, and
2- This device must accept any interference received, including interfer-
ence that may cause undesired operation.
WARNING: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: The manufacturer is not responsible for any radio or TV interfer-
ence caused by unauthorized modifications to this equipment.
Such modifications could void the user authority to operate the equipment.

Email: [email protected]
Direct Contact Amazon Store: Within 24 Hours
US TEL: [phone]
(Support Hours：Monday-Friday, 9:00A.M.-5:00P.M. PST)
13. WARRANTY
19
Dear customer,
Thank you for choosing BALDR. We provide 1-year limited warranty on
this product from the date of purchase. This product has undergone
thorough quality inspection at the factory to ensure that the product is in
good condition. We will remedy all defects in workmanship or materials
within the warranty period.
In order for the warranty to be granted, all warranty claims must be
accompanied by proof of purchase from an authorized distribution partner.
Damages due to improper installation or use, unauthorized removal/modi-
fy/repair are not covered by the warranty.
If you have any problems with this product or during use, please do not
hesitate to contact us, we will try our best to solve it and offer you
satisfactory service including replacement or refund.
For Full Warranty Details, contact us by:
