Bresser 7007201 User manual

Weather Station · Wetterstation ·
ClimaTemp TB + Sensor
EN Instruction manual
DE Bedienungsanleitung

DE Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu nden.
EN Visit our website via the following QR Code or web link to nd further information on this product
or the available translations of these instructions.
FR Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode
d’emploi en d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien
correspondant.
NL Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit
product of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES ¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT Desidera ricevere informazioni esaustive su questo prodotto in una lingua specica? Venga a
visitare il nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
RU Посетите наш сайт, отсканировав QR-код, или перейдите ссылке, чтобы больше узнать об
этом товаре или скачать руководство по эксплуатации на другом языке.
www.bresser.de/P7007201
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA · ГАРАНТИЯ
DE Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu nden.
EN Visit our website via the following QR Code or web link to nd further information on this product
or the available translations of these instructions.
FR Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode
d’emploi en d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien
correspondant.
NL Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit
product of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES ¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT Desidera ricevere informazioni esaustive su questo prodotto in una lingua specica? Venga a
visitare il nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
RU Посетите наш сайт, отсканировав QR-код, или перейдите ссылке, чтобы больше узнать об
этом товаре или скачать руководство по эксплуатации на другом языке.
www.bresser.de/P7007201
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA · ГАРАНТИЯ

English ............................. 4
Deutsch ........................... 21

4
Table of contents
1 Imprint.......................................................................................................6
2 Validity note ..............................................................................................6
3 About this Instruction Manual ...............................................................7
4 General safety instructions.....................................................................7
5 Parts overview and scope of delivery ....................................................9
6 Screen display .........................................................................................11
7 Before commissioning ...........................................................................12
8 Setting up power supply........................................................................13
9 Automatic time setting..........................................................................14
10 Manual time setting...............................................................................14
11 Alarm setting ..........................................................................................14
12 Snooze function ......................................................................................15
13 Receiving measurements automatically.............................................16
14 Display change........................................................................................16
15 HI/LO Alert...............................................................................................16
16 Moon phases ...........................................................................................18
17 Trend arrow indicators ..........................................................................18
18 Barometric pressure display .................................................................19
19 Disposal....................................................................................................19

5
20 Warranty................................................................................................ 20
21 EC declaration of conformity .............................................................. 20
22 UKCA declaration of conformity ......................................................... 20

6 / 44
1 Imprint
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
www.bresser.de
For any warranty claims or service inquiries, please refer to
the information on "Warranty" and "Service" in this docu-
mentation. We ask for your understanding that unsolicited
returns cannot be processed.
Errors and technical changes excepted.
© 2022 Bresser GmbH
All rights reserved.
The reproduction of this documentation - even in extracts -
in any form (e.g. photocopy, print, etc.) as well as the use
and distribution by means of electronic systems (e.g. image
file, website, etc.) without the prior written permission of
the manufacturer is prohibited.
The designations and brand names of the respective com-
panies used in this documentation are generally protected
by trade, trademark and/or patent law in Germany, the
European Union and/or other countries.
2 Validity note
This documentation is valid for the products with the follow-
ing article numbers:
7007201
Manual version: 0123
Manual designation:
Manual_7007201_ClimaTemp-TB_en-de_BRESSER_v012023a
Always provide information when requesting service.

7 / 44
3 About this Instruction Manual
NOTICE
These operating instructions are to be considered a
component of the device.
Read the safety instructions and the instruction manual
carefully before using this device.
Keep these instruction manual in a safe place for future ref-
erence. If the device is sold or passed on, the instruction
manual must be passed on to any subsequent owner/user
of the product.
4 General safety instructions
DANGER
Danger of suffocation!
Improper use of this product may result in suffocation, es-
pecially for children. It is therefore imperative that you ob-
serve the following safety information.
• Keep packaging materials (plastic bags, rubber bands,
etc.) away from children! There is a danger of choking!
• This product contains small parts that can be swal-
lowed by children! Choking hazard!
DANGER
Risk of an electric shock!
This device contains electronic parts that are powered by a
power source (AC adapter and/or batteries). Improper use
of this product may result in electric shock. Electric shock
can cause serious or fatal injuries. It is therefore imperative
that you observe the following safety information.

8 / 44
• Never leave children unattended when handling the
device! Follow the instructions carefully and do not at-
tempt to power this device with anything other than
power sources recommended in this instruction
manual, otherwise there is a danger of an electric
shock!
DANGER
Explosion hazard!
Improper use of this product may result in fire. It is essen-
tial that you observe the following safety information in or-
der to avoid fires.
• Do not expose the device to high temperatures. Use
only the recommended batteries. Do not short-circuit
the device or batteries, or throw them into a fire! Ex-
cessive heat or improper handling could trigger a
short-circuit, a fire or an explosion!
NOTICE
Danger of material damage!
Improper handling may result in damage to the unit and/or
accessories. Therefore, use the device only in accordance
with the following safety information.
• Do not disassemble the device! In the event of a defect,
please contact your dealer. They will contact the Service
Center and can arrange the return of this device for re-
pair if necessary.
• Do not immerse the unit in water!
• Do not expose the device to impacts, vibrations, dust,
constant high temperatures or excessive humidity. This
can result in malfunctions, short-circuits or damage to
the batteries and components.

9 / 44
• Use only the recommended batteries. Always replace
weak or empty batteries with a new, complete set of
batteries at full capacity. Do not use batteries from dif-
ferent brands or types or with different capacities. Re-
move batteries from the device if it is not to be used for
a longer period of time!
NOTICE
Risk of voltage damage!
The manufacturer is not liable for damage related to im-
properly installed batteries!
5 Parts overview and scope of delivery
RESET
1 2 3
AAA 1.5V AAA 1.5V
1
2
13
9
12
11
10 6
5
4
7
8
14
15
20
16
17
19
18
3
A
B
Illustration1: All parts of base station (top) and wireless sensor (bottom)
1 Housing (weather station) 2 Colour display
3 SNZ/LIGHT button (set snooze
function / display brightness)
4 UP/CF key (increase value or
change between °C and °F)

10 / 44
5 MODE button (switch between
current time and alarm time dis-
play or setting mode)
6 DOWN/RCC button (decrease
value or initiate RCC signal recep-
tion)
7 Battery compartment cover
(weather station)
8 Stand, fold-out
9 Battery compartment (weather
station)
10 CH button (channel selection)
11 ALARM button (enable wake-up
alarm)
12 ALERT button (temperature
alarm setting)
13 Wall mount fixture 14 Housing (wireless sensor)
15 Data transmission function light 16 Wall mount fixture
17 RESET button (reset all settings) 18 Slider for channel selection (set
transmission channel 1, 2 or 3)
19 Battery compartment (wireless
sensor)
20 Battery compartment cover
(wireless sensor)
Delivery content:
Base station (A), radio sensor (B)
Required batteries (not included):
5 pcs. batteries (Type AAA/LR03, 1.5V)

11 / 44
6 Screen display
119
17
18
20
21
16
4
3
2
5
6
7
8
10
911
14
15
13
12
Illustration2: Screen display of the base station
1 Graphical weather forecast
display (24 hours)
2 Standard: Current time,
Alarm: Wake-up time
3 Symbol for the radio signal 4 Symbol for active daylight
saving time
5 Symbol for active wake-up
alarm (wake-up time 1, 2 or
both)
6 Weekday information
7 Current date (day/month) 8 Current air pressure value
9 Air pressure measuring unit
(in HPA)
10 Symbol for air pressure
tendency (rising, constant or
falling)

12 / 44
11 Moon phase 12 Symbol for active max-
imum or minimum indoor
temperature alarm
13 Indoor humidity (in %) 14 Symbol for indoor temperat-
ure alarm (function see 12)
15 Indoor temperature (°C or
°F)
16 Symbol for active max-
imum or minimum outdoor
temperature alarm
17 Outdoor humidity (in %) 18 Symbol for outdoor temper-
ature alarm (function see
16)
19 Outdoor temperature (°C
or °F)
20 Current wireless sensor
channel (1, 2 or 3)
21 Transmission signal inform-
ation (current wireless
sensor)
7 Before commissioning
NOTICE
Avoid connection faults!
In order to avoid connection problems between the devices,
the following points must be observed during commission-
ing.
1. Place the base unit (receiver) and sensor (transmitter)
as close together as possible.
2. Connect the power supply to the base unit and wait un-
til the indoor temperature is displayed.
3. Establish power supply for the sensor.
4. Set up/operate the base unit and sensor within the ef-
fective transmission range.
5. Make sure that the base unit and the radio sensor are
set to the same channel.

13 / 44
When changing the batteries, always remove the batteries
from both the base unit and the sensor and reinsert them in
the correct order so that the radio link can be re-estab-
lished. If one of the two devices is operated via a mains
power connection, the power connection must also be
briefly disconnected for this device when the batteries are
changed. If, for example, only the batteries in the sensor
are replaced, the signal may subsequently not be received
at all or not be received correctly.
Note that the actual range depends on the respective con-
struction materials used for the buildings as well as the re-
spective position of the base unit and the outdoor sensor.
External influences (various radio transmitters and other
sources of interference) can greatly reduce the possible
range. In such cases, we recommend finding other locations
for both the base unit and the outdoor sensor. Sometimes
moving the sensor by just a few centimeters is enough!
8 Setting up power supply
Base unit
1. Remove the battery compartment cover.
2. Insert batteries into the battery compartment. Make
sure that the batteries are correctly aligned (+/- poles).
3. Replace the battery compartment cover.
4. Wait until indoor temperature is displayed on the base
unit.
Wireless sensor
5. Remove the battery compartment cover.
6. Move the CH slider to the position for the desired trans-
mission channel (setting CH1, CH2 or CH3 with indica-
tion on the display).
7. Insert batteries into the battery compartment. Make
sure that the batteries are correctly aligned (+/- poles).
8. Replace the battery compartment cover.

14 / 44
9. Press the SET button for approx. 2 seconds.
NOTICE!When operating only one wireless sensor, channel
1 is recommended as the default setting.
9 Automatic time setting
After the powering it on, the unit automatically searches for
the radio signal. It takes about 3-8 minutes to complete this
process.
If the radio signal is received correctly, the date and time
are set automatically and the reception symbol is displayed.
If no radio signal is received, proceed as follows:
1. Press the RCC button for approx. 2 seconds to initiate
the reception of the radio signal again.
2. If no radio signal is still received, the time must be set
manually.
10 Manual time setting
1. In normal display mode, press the MODE button for
about 3 seconds to enter the time settings mode.
2. Digits to be set are flashing.
3. Press UP/CF or DOWN/RCC button to change the value.
4. Press the MODE button to confirm the and switch to
the next setting.
5. Settings sequence: Time zone > Hours > Minutes > Year
> Month > Day > Language
6. Finally, press the MODE button to save the settings and
exit settings mode.
11 Alarm setting
1. Press the MODE button several times to select the de-
sired alarm function: AL 1) or AL 2. The display changes
to the set alarm time.

15 / 44
2. Press the MODE button for about 3 seconds to switch
to the setting mode for the corresponding alarm time.
3. The value to be set flashes.
4. Press the UP/CF or DOWN/RCC button to change the
value.
5. Press the MODE button to confirm and switch to the
next setting.
6. Sequence of the settings: Hours > minutes
7. Finally, press the MODE button to save the settings and
exit settings mode.
8. In normal display mode, press the MODE button to dis-
play the desired alarm time.
9. To activate the alarm, press the ALARM button in nor-
mal display mode until the corresponding alarm sym-
bol (alarm clock) is displayed.
10. To deactivate the alarm, press the ALARM button in
normal display mode until the corresponding alarm
symbol (alarm clock) is no longer displayed.
12 Snooze function
1. Press the SNZ/LIGHT button for about 3 seconds to
enter the snooze time interval setting. The preset digit
flashes (03-20 minutes)
2. Press the UP/CF or DOWN/RCC button to change the
value.
3. Finally, press the SNZ/LIGHT button to save the settings
and exit settings mode.
4. When the alarm sounds, press the SNZ/LIGHT button to
activate the snooze function. The alarm will sound
again at the end of the previously set time interval.
5. When the alarm sounds, press any other button to stop
the alarm until the set alarm time is reached again.

16 / 44
13 Receiving measurements automatically
Once the power supply is enabled, the base station will dis-
play the measurement readings for indoors. Readings from
the outdoor sensor will be displayed within 3 minutes after
powering it on.
If no signal is received, proceed as follows:
Press the CH button for about 3 seconds to initate reception
of measurements again.
14 Display change
In normal display mode, press the DOWN/RCC button to
switch the time display between 12-hour and 24-hour mode.
In 12-hour mode, "PM" is displayed for the time between
12:00 and 0:00, and no information is displayed for the
other times.
In normal display mode, press the UP/CF button to toggle
between °C and °F when displaying the temperature unit.
In normal display mode, press the CH button several times
to display channels 1, 2, 3 or automatically alternating one
after another.
NOTICE!The display of values for different channels re-
quires the connection of several suitable wireless sensors
(not included).
In normal display mode, press the ALERT button several
times to display the values set for temperature alarm one
after another.
15 HI/LO Alert
Set highest/lowest value alarm
1. In normal display mode, press the ALERT button for
about 3 seconds to enter the temperature alarm set-
tings mode. The first value to be set flashes.

17 / 44
2. Press the UP/CF or DOWN/RCC button to change the
value.
3. Press the ALERT button to confirm and switch to the
next setting.the next setting.
4. Settings sequence: Maximum outdoor temperature
value > Minimum outdoor temperature value > Max-
imum indoor temperature value > Minimum indoor
temperature value
5. Finally, press the ALERT button to save the settings and
return to normal mode.
Enable or disable highest/lowest value alarm
6. In normal display mode, press the ALERT button re-
peatedly to select the desired temperature alarm type
(HIGH or LOW). The temperature alarm type is dis-
played below the range info (cottage with OUT or IN).
7. When the temperature alarm is selected, press the UP/
CF button to enable or disable the alarm. When the
temperature alarm is enabled, the alarm symbol (bell)
appears next to the respective temperature alarm type
(HIGH or LOW).
8. The temperature alarm sounds as soon as the preset
temperature is reached for the respective range (IN or
OUT).
9. Press any key to stop the alarm.

18 / 44
16 Moon phases
This weather station is able to display the moon phases for
the northern hemisphere. Here the moon grows from the
right. This is because the sunlit side of the moon in the
northern hemisphere moves from right to left. The follow-
ing table shows the representations of the moon phases.
1
2
3
4
5
6
7
8
Illustration3: Moon phases for the northern hemispere.
1 New moon 2 Waxing crescent
3 First quarter 4 Waxing gibbous
5 Full moon 6 Waning gibbous
7 Third quarter 8 Waning crescent
17 Trend arrow indicators
The air pressure trend for the next 60 minutes is indicated
by corresponding arrows next to the current air pressure
value:

19 / 44
123
1 rising 2 stable:
3 falling
18 Barometric pressure display
The barometric pressure can be displayed in the units "HPA"
and "inHg".
To change the unit, press the UP/CF button for approx. 3
seconds.
19 Disposal
Dispose of the packaging materials according to its type. In-
formation on proper disposal can be obtained from the muni-
cipal waste disposal service provider or environmental agency.
Do not dispose of electronic devices in the household
garbage!
According to the European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment and its transposition into
national law, used electrical equipment must be collected sep-
arately and recycled in an environmentally sound manner.
Batteries and rechargeable batteries must not be disposed of
with household waste. You are legally obliged to return used
batteries and accumulators and can return them after use
either at our sales outlet or in the immediate vicinity (e.g. in the
trade or in municipal collection points) free of charge.
Batteries and accumulators are marked with a crossed-out
dustbin and the chemical symbol of the pollutant, "Cd" stands
for cadmium, "Hg" stands for mercury and "Pb" stands for lead.

20 / 44
20 Warranty
The regular warranty period is 2 years and starts on the day
of purchase. To benefit from an extended voluntary war-
ranty period as indicated on the gift box, registration on our
website is required.
You can consult the full guarantee terms as well as informa-
tion on extending the guarantee period and details of our
services at www.bresser.de/warranty_terms.
21 EC declaration of conformity
Bresser GmbH hereby declares that the radio equipment
type with item number 7007201 is in compliance with Direct-
ive 2014/53/EU. The full text of the EC Declaration of Con-
formity is available at the following web address:
www.bresser.de/download/7007201/CE/7007201_CE.pdf
22 UKCA declaration of conformity
A "Declaration of Conformity" in accordance with the applic-
able directives and relevant standards has been issued by
Bresser GmbH The full text of the UKCA Declaration of Con-
formity is available at the following web address:
www.bresser.de/download/7007201/
UKCA/7007201_UKCA.pdf
Bresser UK Ltd. • Suite 3G, Eden House, Enterprise Way,
Edenbridge, Kent TN8 6HF, Great Britain
