Fritsch PULVERISETTE 19 User manual

Read the instrucons prior to performing any task!
Operating instructions
UNIVERSAL CUTTING MILL
PULVERISETTE 19
Valid starting with: 19.3000/00005, 19.3010/00101,
19.3020/00571, 19.3030/00585, 19.3040/00509,
19.3060/00555 - 19.3100/00502, 19.3110/00001,
19.3120/00003, 19.3130/00502, 19.3140/00502,
19.3160/00516
Valid starting with : 19.4000/00001, 19.4020/00003,
19.4040/00005, 19.4060/00006
Translaon of the original operang instrucons

Version 10/2022 Index 006
Fritsch GmbH
Milling and Sizing
Industriestraße 8
55743 Idar-Oberstein, Germany
Telephone: [phone]
Email: inf[email protected]
Internet: www.fritsch.de

3
Cercaons and CE conformity
Cercaon
CE Conformity
Cercaons and CE conformity
Fritsch GmbH has been cered by the SGS-TÜV Saar GmbH.
An audit cered that Fritsch GmbH conforms to the requirements of the DIN EN
ISO 9001:2015.
The enclosed Conformity Declaraon lists the guidelines the FRITSCH instrument
conforms to, to be able to bear the CE mark.

4
Table of contents
Table of contents
1 Basic structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2Safety informaon and use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Requirements for the user. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Scope of applicaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2.1 Operang principle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Obligaons of the operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4 Informaon on hazards and symbols used in this manual. . . . . . . . . . . . 11
2.5 Device safety informaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.6 Protecve equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.6.1 Securing the collecng vessel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.6.2 Opening the cung mill without mains connecon. . . . . . . . . . . . . . . 15
2.7 Hazardous points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.8 Electrical safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.8.1 Protecon against restart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.8.2 Overload protecon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.1 Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3 Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.4 Operang noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.5 Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.6 Protecon class. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.7 Current consumpon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.8 Power consumpon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.9 Rotor torque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.10 Electrical fuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.11 Material. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.12 Final neness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4Installaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.1 Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.2 Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.3 Seng up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4 Ambient condions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.5 Fastening the Universal Cung Mill. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5
Table of contents
4.6 Selecng and converng the funnels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.6.1 Selecng the funnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.6.2 Converng from standard funnel to protected funnel. . . . . . . . . . . . . 22
4.6.3 Converng from protected funnel to standard funnel. . . . . . . . . . . . . 24
4.6.4 Funnel for bulk solids PULVERISETTE 19 large . . . . . . . . . . . . . . . . . . . . 25
4.7 Electrical connecon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.8 Set-up mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5Inial start-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.1 Switching on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.2 Funcon check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.3 Switching o. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6Using the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.1 Preparing a comminuon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.1.1 Opening the cung mill. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.1.2 Inserng / changing the xed knives. . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.1.3 Seng the gap width of the knives. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.1.4 Inserng / changing a rotor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.1.5 Inserng / changing a sieve cassee. . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.1.6 Closing the cung mill. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.1.7 Checking if the rotor is turning freely. . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.2 Comminuon procedure with standard funnel. . . . . . . . . . . . . . . . . . . . . 34
6.2.1 Using the plunger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.3 Comminuon procedure with the protected funnel. . . . . . . . . . . . . . . . . 35
6.4 Overload of the cung mill. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5 Sample exhaust system with cyclone separator. . . . . . . . . . . . . . . . . . . . 36
6.5.1 High-performance cyclone separator. . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.5.2 Small volume Cyclone separator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.5.3 Connect the switch box of the exhaust system. . . . . . . . . . . . . . . . . . . 42
7 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.1 Housing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.2 Cung chamber. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.3 Funnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.3.1 Standard funnel (15). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.3.2 Protected funnel (24). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.3.3 Funnel for bulk solids PULVERISETTE 19 large . . . . . . . . . . . . . . . . . . . . 45
7.4 Collecng vessel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.5 Cleaning the lter foam mat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

6
Table of contents
7.6 Cleaning the labyrinth seal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.7 Cleaning the labyrinth seal in the closing lid. . . . . . . . . . . . . . . . . . . . . . . 48
8 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9 Repairs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.1 Checklist for troubleshoong. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.2 Error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
11 Guarantee terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
12 Exclusion of liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
13 Safety logbook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
14 Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

7
Basic structure
1 Basic structure
1 Upper part of housing
2 Fixed knife 1
3 Closing lid
4 Fixed knife 2
5Collecng vessel
5a Securing the collecng vessel
6 Safety switch / Safety switch bracket
7U-prole
8 Lower part of housing
9 Sieve cassee
10 Rotor
11 Lock
12 Fixed knife 2
13 Latch clamp
14 Motor cover
15 Standard funnel

8
Basic structure
15 Standard funnel
14 Motor cover
16 Plunger, standard funnel
17 Venlaon grid
18 External 3-pole connecon
19 USB interface
20 Mains plug
21 Sample pusher
22 Plunger (protected funnel)
23 Funnel lid
24 Protected funnel
25 Control panel
26 Fuse
a Display for speed and me
b Toggle funcon for the display
c Tooling Mode (P19 versions with speeds of 300 - 3000 rpm)
d Start motor
e Main switch with integrated overload protecon
f Increase speed / Extend me
g Decrease speed / Shorten me
h Stop motor

9
Safety informaon and use
2 Safety informaon and use
2.1 Requirements for the user
This operang manual is intended for persons assigned with operang and mon-
itoring the Fritsch PULVERISETTE 19. The operang manual and especially its
safety instrucons are to be observed by all persons working on or with this
device. In addion, the applicable rules and regulaons for accident prevenon
at the installaon site are to be observed. Always keep the operang manual at
the installaon site of the PULVERISETTE 19.
People with health problems or under the inuence of medicaon, drugs, alcohol
or exhauson must not operate this device.
The PULVERISETTE 19 may only be operated by authorised persons and serviced
or repaired by trained specialists. All commissioning, maintenance and repair
work may only be carried out by technically qualied personnel. Qualied per-
sonnel are persons who, because of their educaon, experience and training as
well as their knowledge of relevant standards, regulaons, accident prevenon
guidelines and operang condions, are authorised by those responsible for the
safety of the machine to carry out the required work and are able to recognize
and avoid possible hazards as dened for skilled workers in IEC 364.
In order to prevent hazards to users, follow the instrucons in this manual.
Malfuncons that impair the safety of persons, the PULVERISETTE 19 or other
material property must be reced immediately. The following informaon
serves both the personal safety of operang personnel as well as the safety
of the products described and any devices connected to them: All maintenance
and repair work may only be performed by technically qualied personnel.
This operang manual is not a complete technical descripon. Only the details
required for operaon and maintaining usability are described.
Fritsch has prepared and reviewed this operang manual with the greatest care.
However, no guarantee is made for its completeness or accuracy.
Subject to technical modicaons.
2.2 Scope of applicaon
NOTICE
This laboratory instrument is designed for an 8-hour shi oper-
aon at 30 % duty cycle and not for connuous operaon.
The duty cycle is dened as the rao of load duraon to run
me. The run me is dened as load duraon plus pause me.
According to DIN EN 60034-1 (VDE 0530, IEC34-1) a connuous
operaon already takes place aer a standardised run me of
10 minutes. At 30 % duty cycle (DC = rao of load duraon to
run me) a load duraon of 3 minutes and a pause me of 7
minutes would be within standard.
If the standardised run me of 10 minutes is exceeded, then,
by denion, there would be a connuous operaon and
disproporonate temperature increases may occur, possibly
involving increased wear.

10
Safety informaon and use
The Universal Cung Mill can be used for the fast comminuon of so, medium-
hard, brile, tough and brous materials like:
Sheet rubber, plascs, refuse-derived fuel, dry meat, leather, wood, coal, malt,
paper/cardboard, peat, animal feed, pasta, tablets, leaves, pellets, spices, fabric,
straw, maize, bones, roots, tobacco...
2.2.1 Operang principle
The material is fed through a funnel (example in image with standard funnel) into
the cung chamber. There, rotang knives (10) in combinaon with xed knives
(2,4,12) cut the material. The ne ground material falls through a sieve cassee
(9) into the collecng vessel (5).
For ne comminuon, the Fritsch high-performance cyclone separator (oponal
accessory 19.1907.00) can be used for the sample exhauson. For a combinaon
with the PULVERISETTE 19 L, ask Fritsch or your sales partner.
2.3 Obligaons of the operator
Before using the PULVERISETTE 19, this manual is to be carefully read and
understood. The use of the PULVERISETTE 19 requires technical knowledge; only
commercial use is permied.
The operang personnel must be familiar with the content of the operang
manual. For this reason, it is very important that these persons actually receive
the present operang manual. Ensure that the operang manual is always near
the device.
The PULVERISETTE 19 may exclusively be used within the scope of applicaons
set down in this manual and within the framework of guidelines put forth in this
manual. In case of non-compliance or improper use, the customer assumes full
liability for the funconal capability of the PULVERISETTE 19 and for any damage
or injury arising from failure to full this obligaon.
By using the PULVERISETTE 19 the customer agrees with this and recognizes
that defects, malfuncons or errors cannot be completely excluded. To prevent
risk of damage to persons or property or of other direct or indirect damage,
resulng from this or other causes, the customer must implement sucient and
comprehensive safety measures for working with the PULVERISETTE 19.
Neither compliance with this manual nor the condions and methods used
during installaon, operaon, use and maintenance of the PULVERISETTE 19
can be monitored by Fritsch GmbH. Improper execuon of the installaon can
result in property damage and thus endanger persons. Therefore, we assume

11
Safety informaon and use
Special safety informaon
absolutely no responsibility or liability for loss, damage or costs that result from
errors at installaon, improper operaon or improper use or improper mainte-
nance or are in any way connected to these.
The applicable accident prevenon guidelines must be complied with.
Generally applicable legal and other obligatory regulaons regarding environ-
mental protecon must be observed.
2.4 Informaon on hazards and symbols used in this manual
Safety informaon
Safety informaon in this manual is designated by symbols. Safety informaon is
introduced by keywords that express the extent of the hazard.
DANGER
This symbol and keyword combinaon points out a directly
hazardous situaon that can result in death or serious injury if
not avoided.
WARNING
This symbol and keyword combinaon points out a possibly
hazardous situaon that can result in death or serious injury if
not avoided.
CAUTION
This symbol and keyword combinaon points out a possibly
hazardous situaon that can result in slight or minor injury if
not avoided.
NOTICE
This symbol and keyword combinaon points out a possibly
hazardous situaon that can result in property damage if not
avoided.
To call aenon to specic hazards, the following symbols are used in the safety
informaon:
DANGER
This symbol and keyword combinaon points out a directly haz-
ardous situaon due to electrical current. Ignoring informaon
with this designaon will result in serious or fatal injury.

12
Safety informaon and use
Safety informaon in the procedure instrucons
Tips and recommendaons
DANGER
This symbol and keyword combinaon designates contents and
instrucons for proper use of the machine in explosive areas
or with explosive substances. Ignoring informaon with this
designaon will result in serious or fatal injury.
DANGER
This symbol and keyword combinaon designates contents
and instrucons for proper use of the machine with combus-
ble substances. Ignoring informaon with this designaon will
result in serious or fatal injury.
WARNING
This symbol and keyword combinaon points out a directly
hazardous situaon due to movable parts. Ignoring informaon
with this designaon can result in hand injuries.
WARNING
This symbol and keyword combinaon points out a directly
hazardous situaon due to hot surfaces. Ignoring informaon
with this designaon can result in serious burn injuries due to
skin contact with hot surfaces.
Safety informaon can refer to specic, individual procedure instrucons. Such
safety informaon is embedded in the procedure instrucons so that the text can
be read without interrupon as the procedure is being carried out. The keywords
described above are used.
Example:
1. Loosen screw.
2. CAUTION
Risk of entrapment at the lid.
Close the lid carefully.
3. Tighten screw.
This symbol emphasises useful ps and recommendaons as
wells as informaon for ecient operaon without malfunc-
on.

13
Safety informaon and use
Please observe!
2.5 Device safety informaon
■Only use original accessories and original spare parts. Failure to observe this
instrucon can compromise the safety of the machine.
■Accident-proof conduct is to be strictly followed during all work.
■Comply with all currently applicable naonal and internaonal accident pre-
venon guidelines.
CAUTION
Wear hearing protecon!
If a noise level of 85 dB(A) is reached or exceeded, ear protec-
on should be worn to prevent hearing damage.
WARNING
The maximum accepted concentraon (MAC) levels of the rel-
evant safety guidelines must be observed; if necessary, venla-
on must be provided or the machine must be operated under
an extractor hood.
DANGER
Explosion hazard!
−When Comminuon oxidizable substances, e.g. metals or
coal, there is a risk of spontaneous combuson (dust
explosion) if the share of ne parcles exceeds a cer-
tain percentage. When Comminuon these kinds of sub-
stances, special safety measures must be taken and the
work must be supervised from a specialist.
−The PULVERISETTE 19 is not explosion protected and is not
designed to missing denion for variable 'to_materialbearbeitung' explosive
materials.
■Do not remove the informaon signs.
NOTICE
Immediately replace damaged or illegible informaon signs.
■Unauthorised alteraon of the PULVERISETTE 19 will void Fritsch's declara-
on of conformity to European direcves and void the guarantee.
■Only use the PULVERISETTE 19 when it is in proper working order, as
intended and in a safety- and hazard-conscious manner adhering to the
operang manual. In parcular, immediately recfy any malfuncons that
could pose a safety hazard.
■If, aer reading the operang manual, there are sll quesons or problems,
please do not hesitate to contact our specialised personnel.

14
Safety informaon and use
2.6 Protecve equipment
■Protecve equipment must be used as intended and may not be disabled or
removed.
■All protecve equipment must be checked regularly for integrity and proper
funconing.
■The Universal Cung Mill is equipped with a safety lock (11) which also
protects the operator. This locks the front closing lid (3) during operaon.
■The safety switches (11, 6) prevent operaon of the Universal Cung Mill,
if the cung chamber is not closed or a collecng vessel (8) has not been
inserted.
■Do not operate the device without a funnel (15 or 24)!
Funnels (15, 24) are mechanical safety devices that enable hazard-free lling.
■When changing the funnels (15, 24), disconnect the device from the mains
and install the new funnel (15, 24) immediately! (⮫
Chapter 4.6 ‘Selecng
and converng the funnels’ on page 22 )
2.6.1 Securing the collecng vessel
The collecng vessel can only be removed once the closing lid
has been opened.
Proceed as follows to open the cung mill:
1. Connect the mill to the power supply.
2. Switch the mill on by the main switch.
3. Release the closing lid with the latch clamp and open the lid.
4. The bolt for securing the collecng vessel is released and the vessel can be
removed.
To close the mill, proceed in the reverse order:
1. Posion the collecng vessel.
2. Once the cung accessories are installed, close the closing lid and tension
the latch clamp. By closing the closing lid the securing bolt is pushed
downward and the collecng vessel is thus secured.

15
Safety informaon and use
2.6.2 Opening the cung mill without mains connecon
DANGER
The lock must only be released manually when the closing lid is
closed.
The latch clamp of the door must be locked!
Only open the cung mill in this way if there are problems
with your mains supply or with the safety lock. Opening the
mill during the grinding process could damage the device.
1. Insert the supplied triangular key into the bore hole under the safety lock
(11) and turn it clockwise.
2. The closing lid (3) can be opened aer opening the latch clamp (13).
3. At this me, it is not possible to switch on the Universal Cung Mill. To
switch it on, the safety lock (11) must be acvated by turning the triangular
key to the le, the closing lid (3) must be closed and the latch clamp (13) in
locked posion.
2.7 Hazardous points
■The closing lid (3) can be lied out of the hinges. When opening the upper
part of the housing (1), it is possible to leave the closing lid (3) in the hinge. If
this is the case, make sure that the closing lid (3) does not li out of the hinge
when opening the upper part of the housing (1).

16
Safety informaon and use
■When opening the upper part of the housing (1), there is an inial resistance.
■Make sure that the closing lid (3) is fully open!
■When opening the upper part of the housing (1), slowly swivel it open unl
the upper part of the housing (1) is resng on the rubber buer – do not let it
fall into end posion.
■There is a crushing hazard when closing the upper part of the housing (1).
Close it slowly!
■Aer checking if the rotor (10) is turning freely (⮫ Chapter 6.1.7 ‘Checking if
the rotor is turning freely’ on page 34 ), the required hexagon socket screw
key has to be removed immediately.
2.8 Electrical safety
2.8.1 Protecon against restart
If there is a power failure and subsequent return of the voltage during operaon,
the mill stops and the lock of the grinding chamber opens automacally.
2.8.2 Overload protecon
■The main switch turns itself o automacally in case of an overload. The
PULVERISETTE 19 must be switched on again by the user.

17
Technical data
3 Technical data
3.1 Dimensions
without funnel: 440 mm x 790 mm x 350 mm
(width x depth x height)
3.2 Weight
300 - 3000 rpm:
■60 kg without funnel, cung tool set, sieve cassee, collecng vessel, and
stand
■68 kg incl. standard accessories
50 - 700 rpm:
■79 kg without funnel, cung tool set, sieve cassee, collecng vessel, and
stand
■87 kg incl. standard accessories
PULVERISETTE 19 large
300 - 3000 rpm:
■63 kg without funnel, cung tool set, sieve cassee, collecng vessel, and
stand
50 - 700 rpm:
■82 kg without funnel, cung tool set, sieve cassee, collecng vessel, and
stand
3.3 Speed
Serial number Rotaonal speed
19.3000.00 50 - 700 rpm
19.3010.00 50 - 700 rpm
19.3020.00 300 - 3000 rpm
19.3030.00 300 - 3000 rpm
19.3040.00 50 - 700 rpm
19.3060.00 300 - 3000 rpm
19.3100.00 50 - 700 rpm
19.3110.00 50 - 700 rpm
19.3120.00 300 - 3000 rpm
19.3130.00 300 - 3000 rpm

18
Technical data
Serial number Rotaonal speed
19.3140.00 50 - 700 rpm
19.3160.00 300 - 3000 rpm
19.4000.00 50 - 700 rpm
19.4020.00 300 - 3000 rpm
19.4040.00 50 - 700 rpm
19.4060.00 300 - 3000 rpm
3.4 Operang noise
The noise level is approx. 78 dB (A) when idle and 95 dB (A) when idle incl.
cyclone separator. The value uctuates strongly depending on the comminuon
material.
3.5 Voltage
19.3000.00 220-240 V / 1~ 50 - 60 Hz
19.3010.00 100-120 V / 1~ 50 - 60 Hz
19.3020.00 200-240 V / 1~ 50 - 60 Hz
19.3030.00 100-120 V / 1~ 50 - 60 Hz
19.3040.00 380-460 V / 3~ 50 - 60 Hz
19.3060.00 380-460 V / 3~ 50 - 60 Hz
19.3100.00 220-240 V / 1~ 50 - 60 Hz
19.3110.00 100-120 V / 1~ 50 - 60 Hz
19.3120.00 200-240 V / 1~ 50 - 60 Hz
19.3130.00 100-120 V / 1~ 50 - 60 Hz
19.3140.00 380-460 V / 3~ 50 - 60 Hz
19.3160.00 380-460 V / 3~ 50 - 60 Hz
19.4000.00 200-240 V / 1~ 50 - 60 Hz
19.4020.00 200-240 V / 1~ 50 - 60 Hz
19.4040.00 380-460 V / 3~ 50 - 60 Hz
19.4060.00 380-460 V / 3~ 50 - 60 Hz

19
Technical data
3.6 Protecon class
IP 21
3.7 Current consumpon
■19.3000.00 - 13 A
■19.3010.00 - 16 A
■19.3020.00 - 13 A
■19.3030.00 - 16 A
■19.3040.00 - 6 A
■19.3060.00 - 13.5 A
■19.3100.00 - 13 A
■19.3110.00 - 16 A
■19.3120.00 - 13 A
■19.3130.00 - 16 A
■19.3140.00 - 6 A
■19.3160.00 - 13.5 A
■19.4000.00 - 13 A
■19.4020.00 - 13 A
■19.4040.00 - 6 A
■19.4060.00 - 13.5 A
Transient overvoltages in accordance with overvoltage category II are permied.
3.8 Power consumpon
■19.3000.00 - 2350 W
■19.3010.00 - 1725 W
■19.3020.00 - 2350 W
■19.3030.00 - 1725 W
■19.3040.00 - 2800 W
■19.3060.00 - 5000 W
■19.3100.00 - 2350 W
■19.3110.00 - 1725 W
■19.3120.00 - 2350 W
■19.3130.00 - 1725 W
■19.3140.00 - 2800 W
■19.3160.00 - 5000 W
■19.4000.00 - 2350 W
■19.4020.00 - 2350 W
■19.4040.00 - 2800 W
■19.4060.00 - 5000 W
3.9 Rotor torque
The torque depends on the device type.

20
Technical data
300 - 3000 rpm:
■Up to 30 Nm
50 - 700 rpm:
■Up to 67 Nm
3.10 Electrical fuses
The fuses are integrated into the mains switch and in the back side.
3.11 Material
Feed size
Depending on material and funnel (15,24), up to 70 x 80 mm. Harder material
max. 10 mm.
Batch-wise sample feeding!
Throughput
Depending on material property and sieve used, up to 60 l/h.
Feed size PULVERISETTE 19 L
large
Depending on material and funnel, up to 120 x 85 mm. Harder material max. 20
mm.
Batch-wise sample feeding!
Throughput amount PULVERISETTE 19 L
large
Depending on material property and sieve used, up to 85 l/h.
3.12 Final neness
Achievable average nal neness depending on sieve insert, 0.2 - 6 mm.
