RASOR FP861V User manual

USE MANUAL english
CUTTINGUNIT
MOD.FP861V
ED.1-02/12
SERIALNUMBER

EN
2
THECOMPANY
ACKNOWLEDGMENT
Rasor®ElettromeccanicaS.r.l.wasestablishedinMilanin1946 bythetwopromotingpartners
Spinelli andCiminaghi.Formorethansixtyyearsithasbeenproducingautomaticcutting
systems,cuttingunits fortextileapplications andelectricandpneumaticcutters.
Initiallyconsideredasapointof referenceforcuttingsystemsinthe
textileapplications,theRasor®products arenowadayswidelyusedin
otherfields:chemical,automotive,nauticalandsportsectorsandin
furnituremanufacturing.
Rasor®canrelyontheprofessionalcontinuityof three generations,
thankstotheprecioussupportofthepromotingpartner,to hispassion,dedicationand
greatexperienceof seventyyears.
Themaincharacteristicof Rasor®isthateachworkingphase,startingfromthemanufacturing
of theproductupto its packinganddeliveryiscarriedoutinRasor®premisesbyqualified
operatorswhohaveprofessionalygrownupfollowingthespiritof thecompanyandof its
founders.ThisensuresthehighqualitywhichRasor® hasalwaysconsideredasessentialsince
thebeginningof its activity.
Followingtheinnovativespiritmentionedabove,ourcompanyisconstantlyfocusedonthe
improvementof theproductquality,onthestudyanddevelopmentof newmaterialsand
technologies.
DearCustomer,
thankyouforchoosingaRasor®ElettromeccanicaS.r.l.product.
Rasor®hasbeenareferencepointinthefieldofcuttingsystemsinthetextile,clothing,
furniture,tailoring,sport,chemical,automotive,nauticalandinsulatingmaterialsectorsfor
years.Itsproductionhasbeenalwayssynonymouswithreliabilityattestedbymanyof
satisfiedcustomers.
Rasor®qualitysystem supervisesall thecompanyactivitiesinorderto providetheCustomer
withaservicethatmeets its needsandexpectations intermsof productquality,delivery
reliabilityandstock of finishedproducts.
Allthepartsofthedeviceshavebeenplannedandproducedto guaranteeanoptimum
performance.InordertokeepthehighqualitylevelandthelongreliabiltyoftheRasor®
products,itisrecommendedtouseonlyoriginalsparepartsandto contactthehead
officeforanymaintenancework.

EN
3
1.GENERALSAFETY RULES
ThismanualisanintegralpartofcuttingunitFP861Vandmustbecarefully
readbeforeusingitsinceitgivesimportantindicationswithregardstoits safe
installation,useandmaintenance.Keepitwithcare.
BeforeusingcuttingunitFP861V,readcarefullythefollowinggeneralsafety
rules.
•PACKAGING.
Aftertakingoffthepackagingmakesurethatthecuttingunitisintact.Incaseof
doubtdonotuseitandcontactanauthorizedservicecentre.Donotleavepiecesof
packaging(plasticbags,foampolystyrene,boxes,etc.)withinthereachofchildren
ordisabledpersonssincetheyarepotentialsourcesofdanger.
•AVOIDDANGEROUSENVIRONMENTS.
•KEEPCHILDRENAWAY.
Unauthorizedpersons,inparticularchildren,mustbekeptawayfromtheworking
area.
•KEEPTHE WORKINGAREAALWAYSINORDER.
Theworkplacemustalwaysbekeptinorderandwelllightened.
•ALWAYSUSECUTTINGUNITFP861VPROPERLY.
Usethecuttingunitonlytocarryouttheworkstheyhavebeendesignedfor;do
notusethemimproperly.
•OBSERVETHEUSEOFTHE TOOLS.
Donotcutexcessivelythickmaterialsandalwayscheckbladeconditions.
•AVOIDACCIDENTALSTARTINGS.
BeforeconnectingcuttingunitFP861V,makesurethateverythingisinstalledproperly.
•CLOTHING.
Donotuselargeclothesoraccessoriesthatmightgetstuck inthemovingparts.
•GOGGLESANDPROTECTIVEMETALMESHGLOVES.
Alwaysusegoggles,protectivemetalmesh glovesapprovedbyRasor®duringuse
andmaintenanceoperations(accordingtoUNIEN388:2004standard).
•SPAREPARTS.
Duringmaintenanceandreplacementoperations useonlyoriginalspareparts.
Blademaintenancemust beonlyperformedbyRasor®technicians.
•INSTALLATION.
Anyinstallationthatisnot inconformitywiththesespecifications couldjeopardize
yoursafetyandcancelsthewarranty.

EN
4
Theoriginalconfigurationofthe cuttingunit mustnotbechangedatall.
Onreceivingthemachinemakesurethesupplycorrespondstowhathasbeenordered.
In caseofnon-complianceimmediatelyinform Rasor®.
Alsomakesurethecuttingunithas notbeendamagedduringtransport.
CustomerCareTechnicalService
WARNING
Informativeletter
WARNING
Theinstallerandthemaintenancemanmustknowthecontentof thismanual.Although
themainfeaturesof themachinedescribedinthismanualarenot subjecttochange,
Rasor®ElettromeccanicaS.r.l.reservestherightto modifythecomponents,details
andaccessories itdeems necessaryto improvethemachineorto meetmanufacturingor
commercialrequirements atanytimeandwithoutbeingobligedto updatethismanual
immediately.
ALLRIGHTSARERESERVEDACCORDINGTOTHE
INTERNATIONALCOPYRIGHTCONVENTIONS,
Thereproductionof anypartof thismanual, inanyform,isforbiddenwithoutthe
priorwrittenauthorizationof Rasor®ElettromeccanicaS.r.l.
Thecontentof thisguidecanbemodifiedwithoutpriornotice.Greatcarehas
beentakenincollectingandcheckingthedocumentationcontainedinthismanual
to makeitascompleteandcomprehensibleaspossible.
Nothingcontainedinthismanualcanbeconsideredasawarranty,either
expressedorimplied-including,not inarestrictiveway,thesuitabilitywarrantyfor
anyspecialpurpose.Nothingcontainedinthismanualcanbeinterpretedasa
modificationorconfirmationof thetermsof anypurchasecontract.
Rasor®ElettromeccanicaS.r.l.machineshavenot beenconceivedtoworkinareasatriskof
explosions andathighriskof fire.
Incaseofdamageormalfunction,cuttingunitFP861Vmustnotbeuseduntil theCustomer
CareTechnicalServicehasrepairedthem.
Foranyinformation,pleasecontact
RASOR®ELETTROMECCANICAS.r.l.
ViaV.Caldesi,6;20161,MILANO(MI)-ITALY
Phone:[phone];Fax:[phone]
e-mail: [e-mail]
web: www.rasor-cutters.com

EN
5
2.TRANSPORTAND PACKING
3.PLATE DATA
1
Serialnumber
Yearofproduction
Model
Motor
data
READTHEINSTRUCTIONMANUAL
USE METALGLOVES
USEGOGGLES
SHEARINGRISK
DONOTREMOVE THESAFETY
DEVICES
FP861V
900
H__________
2
2
3
1
Thecuttingunitis deliveredin acardboardboxwhich contains therearevarious options.The
codeof theorderedproductandits serialnumberareindicatedoutsidethepackage(see
picture1).Thefollowingaccessoriesarecontainedinabaginsidethepackage(see picture
2):
1) HSS steelpolygonalblade;
2) Butterflykeyforbladenutdisassembly;
3) Driftforbladedisassembly.
Themanufacturer'sidentificationand2006/42/ECSTANDARDconformityplate(see picture
below) islocatedonthefrontpartof thecuttingunit.
The plate mustnotbe removedatall,evenifthe machine isresold.Alwaysreferto
theserialnumber(writtenontheplateitself)whencontactingthemanufacturer.
Severalsafetywarningsareprintedonacardwhichisappliedto thecuttingunitfeeding
cable;suchwarningsmust bestrictlyfollowedbyeveryonedealingwiththemachine. The
companyisnottobeheldresponsiblefordamagetopropertyoraccidentsto
peoplewhich might occur iftheabove-mentionedwarnings arenotobserved.In
such acase,theoperatoristheonlypersonresponsible.

EN
6
4. PRODUCTDESCRIPTION
1
3
2
7
5
6
8
4
10
11
12
13
14
9
ThefixturedescribedinthismanualisapneumaticcuttingunitmodelFP861Vwhichcanbe
assembledonautomaticmachines(e.g.spreaders,computerizedcutting,etc...)bymeans of
aproperbracket.Thanksto areferencepinonthefrontpartandof aneffectivecutting
systemwithpolygonalblade,thiscuttingunitcan beusedformanyapplications:inparticular,
thiscuttingunithasbeendesignedtocuthardmaterialssuchasmoquette,polymericmaterials,
fiberglass,insulatingmaterialsandleather(evenrawhide).
Onespecialfeatureof cuttingFP861Visits abilityto sharpenthebladeineachmoment
withoutdisassemblingitbymeans of agrindingwheelmountedonthecuttingunithead.
Aftercarryingoutthisoperation,itispossibleto startcuttingagain.Thepneumaticcutting
unitisprovidedwithathreadedconnectionto themajorityof theairpipes.Theturbine,
perfectlybalanced,withahighnumberof revolutions andtotallyfree of maintenance,reduces
thevibrations andthenoiseto theminimum.Thecuttingunitcanbeusedto cutdampor
wetmaterialsandthereforeparticularlyrecommendedintannery,dyeworks,etc... Theuse
ofcompressedairassourceofenergyallowsworkingcontinuouslywithoutproblemsof
heatingormotoroverload.Themechanicalparts aremadeupof steel,highresistantbronze
andaluminium andrequirealubricationaftermanyworkinghours.
11/4"gas connectionfor theair
connector 8Frontguard
2AluminujbasecoverewithTeflon
â
9Motorsupport
3Polygonalblade 10 Silencer
4Greaser 11 Rear guard
5Pneumaticmotor 12 Referencedrift
6Sharpener 13 Hardmetalcounterblade
7Sharpeningpushbutton 14 Springlockingthethread
Devicecomponents

EN
7
7.FIELDOFAPPLICATION
6.NOISE LEVEL
5.TECHNICALFEATURES
Thetechnicaldata areonlyindicativeandtheycanbe
changedwithoutnotice.
86 mmwith hard-metalcounterblade
900rev/min
about25 mm
380Wwithmax.pressure
max.6 bar
1100 g
2000 g
9litres/sec.
LUX200
<2,5m/s2
0 ~55°C
10~95%withoutcondensate
Cuttingworkingdepth
Power
Weight
PneumaticscissorsFP861Vfeatures
Blade diameter
Blade speed
Workingpressure
Temperature
Humidity
Weightwithpackage
Airconsumption
Minimumluminosityforworking
operations
Vibrationsatthestartup
8sidebladeØ86 mm, H.S.S. steel
5sidebladeØ86mm, H.S.S. steel
8sidebladeØ86mm, H.S.S. steelcoated
withtitanium
8sidebladeØ86 mm, H.S.S.steelcovered
withTeflon
5sidebladeØ86 mm, H.S.S.steelcovered
withTeflon
8sidebladeØ86 mm, madeofintegralhard
metal(Widia)
5sidebladeØ86 mm, H.S.S.steelcovered
withTeflon
86PHSSTF
Featuresoftheavailable blades
86THSS
86THSSTN
86TMD
86PHSSTN
86THSSTF
86PHSS
Themaximum acousticpressurelevelemittedbycuttingunitFP861Visabout60 dB(A).
Noisetests havebeencarriedoutincompliancewithStandardISO11202. Thedevicenoise
levels,measuredatdifferentdistances(withoutanysoundwavefilteringsystem),varyinthe
extentof fewdb(A).Thenoiselevelhasbeeendetectedwiththesilencersuppliedwith
thefixtureassembledontheexhaust.Thesilencermust neverberemoved.
NOTE
It isadvisableforcuttingunitFP861Vownersto verifythecompliancewiththestandard
concerningsafetyof workers:referto theLocalLaw.Theuseof earprotectingdevicesis
compulsory.
CuttingunitFP861Vhasbeendesigned,manufacturedandassembledto cuttextileor
technicalfabrics,withtheexceptionof metal,plasticorwood,bymeans of rotaryblades.
Thisequipmentmust not work:
-inareasproneto explosions;
-inpresenceof finedustorcorrosivegases;
-to cutplastic,metalandwoodenmaterials.
Itisforbiddentousecuttingunit FP861V for purposesdifferent
fromtheabove-mentionedones.
bladecenter

EN
8
9. RESIDUALRISKS
8.USE WARNINGS
We recommendfollowingtheindications belowinorderto alwaysworkinsafetyconditions.
·All theoperations must becarriedoutcomplyingstrictlywiththesafetyrulesof the
countrywherethefixtureissold.
·ItisSTRICTLYFORBIDDENto smokeduringtheinstallationoradjustmentoperations of
thecuttingunit.
·TheCustomerundertakesto complywithandmakehisstaffobservealltherulesand
regulationsinforceconcerningsafety,preventionof accidentsandhealthinthework
place.Therefore,theCustomerassumestheresponsibilitytostrictlyfollowalltherulesand
regulations inforce,as wellasthespecialprovisionsinforceinsportandpublicinstallations
theCustomerdeclaresto knowafterreceivingall therelativenecessaryinformation.
·Thecuttingunitworksalsowithouttheirsafetyprotectivedevice. Thisprotectivedevice
mustNEVERbe removed.
·Alwayschecktheresistanceof thematerialto becutandthekindofbladewhichisbeing
used.
·TheCustomershallequiphisownpersonnelwithalltheindividualsafetyprotectionsfor
theexecutionoftheworks,aswellaswiththeoneswhichmightbeprescribedbythe
Manufacturerduetospecificdangerconditionsoftheplantoroftheareawherethe
personnelmust work.
·Donotcarryoutanyadjustmentwhilethebladeisworking.
·Alwayspayattentionto thepositionof theairpipeto preventitfrombeingcutor
damagedbytheblade.
·Itispossibleto assemblecuttingunitFP861VonmachinesO.E.M.onlyiftheiroriginal
structureisnotmodified.Otherwise,theinterventionmustbecertifiedbyRasor®.
LThecuttingbladecanworkevenwhentheprotectivedeviceisdisassembled.
Eventhoughthecuttingunitissafe,operatorsmust payattentionto preservetheirand
otherpeople’ssafety.

EN
9
10.INSTALLATION AND USE
Toinstall andusethecuttingunitdoasfollows:
1)Fixthecuttingunitto themachinebymeans of aflatorangle
bracketto mountontheupperpartof themotorsupportof
theunit.
NOTE
Thecuttingunitcanbeinstalledinanypositionorangle:vertical,
usidedown,lateral.Thealuminium basedoes not haveto touch the
machinetable.
2)Laydownthematerialto becut;
3)Connecttheairhosetoquickconnection“A”(notsupplied)
(see picture4);
4)Setthepressuregauge(option)to 6bar;
5)Putthematerialonthecuttingbase(see picture5);
6)Adjustthemovingfrontprotectionaccordingto thethickness of thematerialto cut;
7)Enabletheairremotelyandcarryoutthecuttingoperation.
NOTE
It ispossibleto usecuttingunitFP861Vbothkeepingitfixedand
makingthematerialslideandviceversa.It isimportantto keepthe
materialto cutasstretchedaspossibleto preventitfromcurling
WARNING
Donotusethetwoboltswhich connectthemotortothe
cuttingpart tofix cuttingunit FP861V,otherwisethemotor
shaftcouldbreak.Inthiscasethewarrantywill be void.
4
5
A
11.AIRPRESSUREGAUGE(OPTION)
5
1
2
3
4
6
7
8
6
Thecuttingunitmust benecessarilyfedwithlubricated
airwithapressureof 4-6bar.
Rasor®offers,asoption,areductionunitfilterwitha
pressuregaugealreadycalibratedwiththequantityof
oil to bedeliveredasoption.
Theunitshownalsoinpicture6ismadeupof:
1-pressurereducer;
2-valveto drainthecondensate;
3-drip-feedoilerunit;
4-oil tank;
5-pressuregauge;
6-condensatetank;
7-pipefittingtoconnectthequickconnectionto
thenetwork;
8-pipefittingto connectthequick connectionto thescissor.
Fortheuseandmaintenancereadtheinstructionsheetsuppliedwith
thefilter.

EN
10
12. BLADESHARPENING
Afterusingthecuttingunitforsomehourswithout
interruption,orifits cuttingcapacityisreduced,itisnecessary
to sharpentheblade.
Tocarryoutthisoperation,startthebladeandpress sharpener
“2”onthebladeitself(bymeans of push button“1”,asshown
in picture7)for3-4seconds.Repeatthisoperation 2-3times.
Check periodicallythatthegrindingwheelisnot wornordirty.
Ifitis worn orits surfaceis irregular,replaceit.
13. LUBRICATION
Theremust not bestains of greaseoroil ontheblade. 8
WARNING
2
7
A
1
Every3-4workingdays,itisnecessaryto lubricatethegear
pair.Inorderto carryoutthisoperation,removeprotective
plug“A”locatedontheheadof thecuttingunitandfill it
withRasorlubricatinggrease.Screwplug“A”againafew
turns.Screwplug“A”afewturns every2-3workingdays
(seepicture8).
Oncetheplugisscreweduntil theend,fill itagain.

EN
11
14.BLADEREPLACEMENT
9
C
D
B
A
E
10
11
G
1
H
12
F
3
2
1
Ifthebladeisnomoreableto cut(evenafterrepeating
thesharpeningoperationseveraltimes)itisnecessary
to replaceit.Inorderto carryoutthisoperation,use
butterflykey“1”anddrift“3”lockingtheblade(shown
inpicture9).
Inorderto replacetheblade,proceedasfollows:
1)Usesomeprotectiveglovesincompliancewith
theLocalLawof theCountrywherethecutting
unitistobeused(useofpersonalprotection
devices);
2)Removefixedsafetyprotection“A”(see picture10)
byunscrewingthecross screw“C”witha
screwdriver(notsuppliedbythemanufacturer),as
showninpicture11.
Removethemovingfrontsafetyprotection“B”
(see picture11)byunscrewingpin“D”andtaking
outthetwowashers“E”asshowninpicture11.
3)Insertdrift“3”(see picture11)into hole“F”in
ordertolocktheblade(theholeintheblade
must correspondto theholeinthestructure).
4)Usebutterflykey“1”inordertounscrewnut
“H”andremoveblade“G”(see picture12).
5)Replacethewornbladewiththenewone“2”,
beingcarefultocenterthebladeontheshaft,in
thecorrectposition,andremembertoassembleit
sothattheoperatorcansee thewriting“Rasor”.
6)Assembleall thecomponents againandsharpen
theblade.

EN
12
16.SPAREPARTS /EXPLODEDVIEW
15.TROUBLESHOOTING
ACCESSORIES
àSOLUTION
Checkthecounterbladeintegrity
Checkthekindoffabric
Sharpentheblade
Checkthefabricthickness
Checkthecompatibilitybetweenbladeandfabric
Makesurethattheturbineturnscorrectly
Reducethefeedingspeed
Carryoutthelubrication
Disassemblethebladeandremovethematerialresidues
Checkthesilencer
Checkthewearofthegearpair
Checkthepneumaticcircuitintegrity
Adjusttheworkingpressureat6bar
Thecuttingunitstartsslowly,works
intermittentlyor does notstart
6PROBLEM
Thecuttingunitisnoisy
Thefabricisnotcutoritgetsstuck betweenthe
bladeandthecounterblade
CODE DESCRIPTION CODE DESCRIPTION
P169 FLEXIBLEPIPEFITTING Ø8mm-1/4"
GASFEMALE P171 MALE QUICKCOUPLING -1/4"GAS
P170 FEMALEQUICKCOUPLING -1/4"GAS P171CPL MALE QUICKCOUPLING -1/4"GAS
(COMPLETE)
P170CPL FEMALEQUICKCOUPLING -1/4"GAS
(COMPLETE) P173 AIRPIPEØ 8x6mm
P174CPL COMPLETECOUPLINGWITHTHREAD-
1/4"GAS
CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION
86THSS 8-SIDEBLADE86 mm,H.S.S.STEEL FP86113 FRONTFLANGE FP86159CPL COMPLETERING GEAR T104300 4MA SCREWFIXING THEREARGUARD
FP86009 COUPLING FLANGE FP86114 ROTOR FP86500 SCREWFIXING SPRING LOCKING THETHREAD T104500 SCREWFIXING THEFRONTGUARD
FP86010 PISTONGUIDE FP86115 ROTORBLADE FP86800 COUNTERBLADE T104501 PAIROFCONVEXWASHERS
FP86011 PISTONGUIDEO'RING FP86116 POSITIONING PIN S8676S SPRING WITHDOWEL T104700 GREASERCAP
FP86014 STOPRING FP86117 REARFLANGE S867900 COUNTERBLADESUPPORTFIXING SCREWT104800 GREASER
FP86017 VALVE FP86118 REARFLANGEBEARING S868300 SHARPENINGPIN T105100 SHARPENERPINFIXING SCREW
FP86018 VALVEO' RING FP86119 REARFLANGECAP S868500 SHARPENER SIMPLEBLOCK T105200 SUPPORTFIXINGSCREW
FP86019 STEELBALL FP86120 CYLINDER S868501 DOWELFIXING SHARPENERBLOCK T105300 WASHER
FP86020 SPRING FP86120CPL COMPLETETURBINE S8685CPL COMPLETESHARPENER BLOCK T105600 SHAVING WASHER
FP86021 SILENCERHOUSING O'RING FP86121 O'RING GASKET SW104102 OILERRING T105700 BEARINGFIXING RING NUT
FP86022 SILENCERHOUSING FP86122 MOTORFRAME SW104103 OILERSPRING T105800 GEARRING BEARING
FP86025 BRONZESILENCERFILTER FP8612301 CONTROLHEAD SW108100 HARD METALCOUNTERBLADE T106000 LEFTSCREWFORGEARFIXING
FP86026 REDUCTIONUNITO' RING FP86130 1/4"CONNECTORWITHFILTERSW108200 COUNTERBLADEFIXING SCREW T106100 SUBBLADERING
FP86028 REDUCTIONUNIT FP86139 STEELFOOT SW108600 EMERYTYPEØ25x9 x6 T106300 BLADEFIXING RING NUT
FP86101 GEARWORMSCREW FP86140L FOOTFIXING SCREWS SW108700 EMERYPIN T107500 BLADEDISASSEMBLING WRENCH
FP86101CPLCOMPLETEPAIROFGEAR FP86140R TOOTHEDWASHER SW108800 EMERYSPRING Ø11 mm T107600 BLADELOCKING DRIFT
FP86102 ELASTICPIN FP86141 ALUMINIUM SIMPLEBASE SW108900 SHARPENER BUSH T107900 LUBRICATING GREASE
FP86103 SHAFTFRONTBEARING FP86141CPL ALUMINIUM COMPLETEBASE SW109000 EMERYSPRING Ø6mm T864100 REARGUARD
FP86104 SNAPRING FP86142 BASEFIXING SCREW10 mm SW109100 SHARPENER CAPWITHBEARING T8641CPL REARGUARDSET
FP86106 SHAFTREARBEARING FP86143 BASEFIXING SCREW18 mm SW109200 SHARPENER CAPFIXING SCREW T8644V FRONTGUARD
FP86107 JOINT FP86149 SPRING LOCKING THETHREAD SW109300 STEELWASHER T8644VCPL FRONTGUARDSET
FP86108 THREADEDRING NUT FP86150 COUPLING SHAFT T104200 2.6MA SCREWFIXING THEREARGUARD T865400 ANTI-FRICTIONBUSH
FP86110 COMPENSATORRING FP86150CPL COMPLETECOUPLING SHAFT T104201 WASHER T8655VCPL COMPLETEMOTORSUPPORT
FP86112 MOTORFLANGEBEARING

S867900
FP86143
FP86150CPL
FP86108
FP86112
FP86113
FP86120CPL
FP86120
FP86115
FP86114
FP86116
FP86117
FP86118
FP86119
FP86009
FP86110
FP86101
FP86102
FP86101CPL
FP86011
FP86014
FP86010
T 104300
T 864100
SW 104102
T 104201
T 8641CPL
SW 104103
T 104200
FP86800
FP86149
S 868500
S 868501
S 8685CPL
FP86121
FP86122
FP8612301
FP86021
FP86022
FP86025
FP86018
FP86017
FP86019
FP86020
FP86026
FP86028
FP86026
FP86130
FP86150
FP86103
FP86104
FP86106
FP86107
T 107500
T 104501
T 104501
T 104500
T 105800
T 105700
FP86140R
FP86140L
T 106100
T 105200
T 105300
T 104800
T 104700
SW108900
SW108800
SW109300
SW109000
SW109100
SW109200
P171
P170
P173
P171CPL
P170CPL
P174CPL
T 107900
T 107600
ACCESSORI
TUBO ARIA
T 8644V
T 8644VCPL
SW108600
SW108700
S 868300
86THSS
T106300
T 105100
T 865400
T 106000
T 105600
T 8655VCPL
FP86500
FP86139
FP86141CPL
S8676S
FP86141
SW108200
SW108100
®
dal 1946
FP86159CPL
FP86142

WARRANTY
Rasor®ElettromeccanicaS.r.l. cuttingunithasa12 monthwarrantyfromthedateindicated
onthelast pageof thismanual,exceptincaseof differentwrittenagreements.
Thewarrantycoversallmanufacturingandmaterialdefects.Replacementandrepairoperations
arecoveredonlyifcarriedoutbyourcompanyandatourworkshop.
Incaseofreturnedgoodsforrepairunderwarranty, theCustomermust always sendto
Rasor® thecompletemachine.Repairsunderwarrantyofsinglefaultycomponents
arenotaccepted.
Thematerialto berepairedmust besentCARRIAGEFREE.
Oncethemachinehasbeenrepaired,itwill besentCARRIAGEFORWARDto thecustomer.
Thewarrantycoversneithertechnicians'interventiononsitenorthemachinedisassembly
fromtheinstallationplace.
Ifforpracticalreasons,oneof ourtechnicians issentto thepremises,thecustomerwill be
chargedthecosts plus thetravellingexpenses.
Thewarrantydoesnot include:
+failurecausedbywronguseorassembly,
+failurecausedbyexternalagents,
+failurecausedbylack of maintenanceorneglicence;
+bladesandcomponents subjectto wear.
WARRANTYFORFEITURE:
+Incaseof arrearageorotherbreachesof contract,
+Wheneverchangesorrepairsarecarriedoutonourcuttingunitwithoutourprior
authorization,
+Whenevertheserialnumberistamperedwithorcancelled,
+Wheneverthedamageiscausedbyimproperuse,badtreatment,bumps,fallsand
othercausesnot dueto normalworkingconditions,
+Whenevertheunitseemstamperedwith,dismantledorpreviouslyrepairedby
unauthorizedstaff,
+Incasethecuttingunitisusedforpurposesthataredifferentfromtheonesdescribed
inthismanual.
All repair operations carriedoutunderwarrantydonotinterruptits duration.
All disputeswill be settledin thecourt ofjusticeofMilan(Italy).
We thankyouinadvancefortheattentionyouwill payto thismanualandweinviteyouto
informus of anychangeyoudeemnecessaryto improveitandmakeitmorecomplete.

DECLARATIONOFCONFORMITY
RASORELETTROMECCANICAS.R.L.
CUTTING EQUIPMENTS
We herebycertifythatthedevicespecifiedhereundercomplieswiththerequirements of
MachineryDirective2006/42/ECandto technicalrulingsUNIEN414:2002,UNIENISO
12100-1:2005 eUNIENISO12100-2:2005.
Noisetests havebeencarriedoutaccordingto UNIENISO11202.
Thecuttingunithasbeenproducedaccordingto workmanlikestandards.
We declarethattheabove-mentionedgoodscomplywiththestandardsinforceconcerning
safetyandhygieneatworkthatcanbeappliedto thematerialitself(referto theLocal
Law);theabove-mentionedgoodsarenot includedinthegoodsindicatedinannexIVof
MachineryDirective2006/42/EC.
1.Category: CUTTINGUNIT
2.Manufacturer: RASOR®ELETTROMECCANICA S.R.L.
3.Type: FP861V
4.Serialnumber:............................................................................................
5.Yearof manufacture:.................................................................................
6.Countryof manufacture: ITALY
7.Additionalinformation:...............................................................................
Date:
Warrantyexpiry:
12 months invoicedateorreceipt
(Signature)

Authorizeddealer
(Stamp)
