FRIULAIR ACT VS Series Guide

Refrigerating air dryer
ACT VS
800 - 2500
Air – water cooled
EN - User’s maintenance and spare parts manual
74MD0059A4-EN_00

2 – EN ACT VS 800 - 2500
Dear Customer,
thank you for choosing our product. In order to get the best performances out of this product, please read this manual
carefully.
To avoid incorrect operation of the equipment and possible physical risk to the operator, please read and strictly follow
the instructions contained in this manual.
Note, these instructions are in addition to the safety rules that apply in the country where the dryer is installed.
Before packing for shipment each ACT VS series refrigerated air dryer undergoes a rigorous test to ensure the absence
of any manufacturing faults and to demonstrate that the device can perform all the functions for which it has been
designed.
Once the dryer has been properly installed according to the instructions in this manual, it will be ready for use without
any further adjustment. The operation is fully automatic, and the maintenance is limited to few controls and some cleaning
operations, as detailed in the following chapters.
This manual must be maintained available in any moment for future references and it has to be intended as
inherent part of the relevant dryer.
Due to the continuous technical evolution, we reserve the right to introduce any necessary change without giving previous
notice.
Should you experience any trouble, or for further information, please do not hesitate to contact us.

ACT VS 800 - 2500 3 – EN
Contents
1Safety instructions 5
1.1Safety pictograms in accordance with DIN 4844 6
1.2Signal words in accordance with ANSI 8
1.3Overview of the safety instructions 8
2Proper use of the dryer 11
3Exclusion from a field of application 11
4Instructions for the use of pressure equipment according to PED directive 2014/68/EU 11
5Transport 12
6Storage 12
7Installation 13
7.1Place of installation 13
7.2Installation layout 14
7.3Correction factors 15
7.4Connection to the compressed air system 16
7.4.1Inlet / outlet flanged air connections (only ACT VS 800 – 1250) 16
7.5Connection to the cooling water network (Water-Cooled) 17
7.6Minimum cooling water requirements: 18
7.7Electrical connections 19
7.8Condensate drain 20
8Start-up 20
8.1Preliminary operation 20
8.2First start-up 21
8.3Start-up and shut down 22
9Technical data 23
9.1Technical data ACT VS 800 – 2500 3/460/60 23
10Technical description 24
10.1Control panel 24
10.2Operation 24
10.3Flow diagram (Air-Cooled) 25
10.4Flow diagram (Water-Cooled) 25
10.5Refrigerating compressor 26
10.6Condenser (Air-Cooled) 26
10.7Condenser (Water-Cooled) 26
10.8Condenser water regulating valve (Water-Cooled) 26
10.9Filter dryer 26
10.10Electronic Expansion Valve (EEV) 27
10.11Alu-Dry module 27
10.12Refrigerant pressure switches HPS 27
10.13Compressor crankcase heater 27
10.14Electrical panel fan 27
10.15DMC55 electronic control unit 28
10.15.1Starting the dryer (“ON” mode) 28
10.15.2Stopping the dryer (“STANDBY” mode) 28
10.15.3Performing the condensation drain test 28
10.15.4Chilling circuit process values 29
10.15.5WARNING condition 30
10.15.6ALARM condition 32
10.15.7Alarm history 34
10.15.8Installing and Removing the USB storage drive 35
10.15.9Compressor and fan drive process values 35
10.15.10Electronic expansion valve process values 36
10.15.11Energy saving data and operating hours 37
10.15.12Remote start/stop, remote reset of faults/alarms 38
10.15.13“Alarm” and "dryer running" signal contacts 38
10.15.144-20mA analogue output 38
10.15.15RS485 MODBUS RTU communication port 39
10.15.16Changing process user parameters 39

4 – EN ACT VS 800 - 2500
10.15.17List of spare parts 41
10.15.18System settings and weekly timer 42
10.16Electronic drainer 43
11Maintenance, troubleshooting, spare parts and dismantling 44
11.1Checks and maintenance 44
11.2Troubleshooting 45
11.3Spare parts 55
11.4Maintenance operation on the refrigeration circuit 56
11.5Dismantling of the dryer 56
12Attachments 57
Exploded views – List of components 57
Electric diagrams – List of components 57
12.1Dryers dimension 58
12.1.1ACT VS 800 – 1250 58
12.1.2ACT VS 1500 – 2500 58
12.2Exploded views 58
12.2.1ACT VS 800 – 1250 Air Cooled 58
12.2.2ACT VS 800 – 1250 Water Cooled 58
12.2.3ACT VS 1500 – 2500 Air Cooled 58
12.2.4ACT VS 1500 – 2500 Water Cooled 58
12.3Electric diagrams 58
12.3.1ACT VS 800 – 1250 58
12.3.2ACT VS 1500 – 1750 58
12.3.3ACT VS 2000 - 250 58

Safety instructions
ACT VS 800 - 2500 5 – EN
1 Safety instructions
Pos: 2 /Beko Technis che Dokumentation/ Globale Texte/Allgem einer Hinweis BM @ 0\mod_1183615 737313_6.doc @ 4004
Pos: 3 /Beko Technis che Dokumentation/ Sicherheit/Hinweis Anl eitung BEKO @ 0\mod_1184147787 557_6.doc @ 5758
Please check whether or not these instructions correspond to the device type.
Please adhere to all advice given in these operating instructions. They include essential information which
must be observed during installation, operation and maintenance. Therefore, it must be ensured that these
operating instructions are read by the fitter and the responsible operator / certified skilled personnel prior
to installation, start-up and maintenance.
The operating instructions must be accessible at all times at the place of application of the compressed-
air refrigeration dryer.
In addition to these operating instructions, local and national regulations need to be observed, where
required.
Ensure that operation of the compressed-air refrigeration dryer only takes place within the permissible
limit values indicated on the name plate. Any deviation from these limit values involves a risk for persons
and for the material, and may result in malfunction or a breakdown.
After installing the device correctly and in accordance with the instructions in this manual, the dryer is
ready to operate, further settings are not required. Operation is fully automatic and maintenance is limited
to several examinations and cleaning measures which are described in the following chapters.
This manual must be available at all times for future reference and is a constituent part of the dryer.
If you have any queries regarding these installation and operating instructions, please contact
manufacturer.

Safety instructions
6 – EN ACT VS 800 - 2500
1.1 Safety pictograms in accordance with DIN 4844
Observe operating instructions
General danger symbol
Supply voltage
Danger: component or system under pressure
Hot surfaces
Non-breathable air
Do not use water to extinguish the fire
Do not operate with open cover (housing)
Maintenance works or controlling measures must only be carried out by qualified personnel 1
Do not smoke
Note
Pos: 4 /Beko Technis che Dokumentation/ Sicherheit/Gefahr Dr uckluft @ 0\mod_1184148143 854_6.doc @ 577
6
Connection point compressed-air inlet
Connection point compressed-air outlet
Connection point condensate drain
Connection point cooling-water inlet (water-cooled)
Connection point cooling-water outlet (water-cooled)
1Certified skilled personnel are persons who are authorised by the manufacturer, with experience and technical training, who are well-
grounded in the respective provisions and laws and capable of carrying out the required works and of identifying and avoiding any
risks during the machine transport, installation, operation and maintenance.
Qualified and authorised operators are persons who are instructed by the manufacturer regarding the handling of the refrigeration
system, with experience and technical training, and who are well-grounded in the respective provisions and laws.
ARIA
AIR
LUFT
AIR
ARIA
AIR
LUFT
AIR

Safety instructions
ACT VS 800 - 2500 7 – EN
Works can be carried out by the operator of the plant, provided that they are skilled accordingly 2.
NOTE: Text that contains important specifications to be considered – does not refer to safety precautions.
The device was carefully designed with particular attention paid to environmental protection:
CFC-free refrigerants
CFC-free insulation material
Energy-saving design
Limited acoustic emissions
Dryer and packaging comprise reusable materials
This symbol advises the user to observe the environmental aspects and comply with the recommendations
connected with this s
y
mbol.
2Certified skilled personnel are persons who are authorised by the manufacturer, with experience and technical training, who are well-
grounded in the respective provisions and laws and capable of carrying out the required works and of identifying and avoiding any
risks during the machine transport, installation, operation and maintenance.
Qualified and authorised operators are persons who are instructed by the manufacturer regarding the handling of the refrigeration
system, with experience and technical training, and who are well-grounded in the respective provisions and laws.

Safety instructions
8 – EN ACT VS 800 - 2500
1.2 Signal words in accordance with ANSI
Danger! Imminent hazard
Consequences of non-observance: serious injury or death
Warning! Potential hazard
Consequences of non-observance: possible serious injury or death
Caution! Imminent hazard
Consequences of non-observance: possible injury or property damage
Notice! Potential hazard
Consequences of non-observance: possible injury or property damage
Important! Additional advice, info, hints
Consequences of non-observance: disadvantages during operation and maintenance, no danger
1.3 Overview of the safety instructions
Certified skilled personnel
Installation works must exclusively be carried out by authorised and qualified skilled personnel. Prior to
undertaking any measures on the compressed-air refrigeration dryer, the certified skilled personnel shall
read up on the device by carefully studying the operating instructions. The operator is responsible for the
adherence to these provisions. The respective directives in force apply to the qualification and expertise
of the certified skilled personnel.
For safe operation, the device must only be installed and operated in accordance with the indications in
the operating instructions. In addition, the national and operational statutory provisions and safety
regulations, as well as the accident prevention regulations required for the respective case of application,
need to be observed during employment. This applies accordingly when accessories are used.
Danger!
Compressed air!
Risk of serious injury or death through contact with quickly or suddenly escaping compressed air
or through bursting and/or unsecured plant components.
Compressed air is a highly dangerous energy source.
Never work on the dryer when the system is under pressure.
Never direct the compressed-air outlet or condensate drain hoses at persons.
The user is responsible for the proper installation of the dryer. Non-observance of the instructions in the
"Installation" chapter leads to the expiration of the guarantee. Improper installation may result in
dan
g
erous situations for the personnel and/or the device.
Pos: 5 /Beko Technis che Dokumentation/ Sicherheit/Maßnahmen Druc kluft BM @ 0\mod_1184148284 291_6.doc @ 5812
Pos: 6 /Beko Technis che Dokumentation/ Sicherheit/Gefahr Net zspannung @ 0\mod_11841481869 48_6.doc @ 5794
Danger!
Supply voltage!
Contact with non-insulated parts carrying supply voltage involves the risk of an electric shock
resulting in injuries and death.
Only qualified and skilled personnel are authorised to run electrically-operated devices. Prior to
undertaking maintenance measures at the device, the following requirements must be met:
Make sure that the power supply is switched off and that the device is off and marked for maintenance
measures. Please also ensure that the power suppl
y
cannot be re-established durin
g
the works.
Prior to carrying out maintenance works at the dryer, switch it off main switch (control panel pos.1) and
wait for at least 30 minutes.
Pos: 7 /Beko Technis che Dokumentation/ Sicherheit/Maßnahmen Netzs pannung BM 31/32/33 @ 0\ mod_1216898430699_6.doc @ 11319
Caution!
Refrigerant!
The compressed-air refrigeration dryer uses HFC-containing refrigerants as a coolant.
Please observe the correspondin
g
para
g
raph entitled "Maintenance works at the refri
g
eration c
y
cle".

Safety instructions
ACT VS 800 - 2500 9 – EN
Warning!
Refrigerant leak!
A refrigerant leak involves the danger of serious injury and damage to the environment.
The compressed-air refrigeration dryer contains fluorinated greenhouse gas/refrigerant.
Installation, repair and maintenance works at the refrigeration system must only be carried out by certified
skilled personnel (specialists). A certification in accordance with EC regulation 303/2008 must be
available.
The requirements of the EC 842/2006 directive must be met under all circumstances.
Please refer to the indications on the name plate as regards the type and amount of refrigerant.
Comply with the following protective measures and rules of conduct:
1. Storage: Keep the container tightly closed. Keep it in a cool and dry place. Protect it against heat and
direct sunlight. Keep it away from ignition sources.
2. Handling: Take measures against electrostatic charging. Ensure good ventilation/suction at the
workplace. Check fittings, connections and ducts for tightness. Do not inhale the gas. Avoid contact
with the eyes or the skin.
3. Prior to carrying out works on refrigerant-carrying parts, remove the refrigerant to such an extent that
safe working is possible.
4. Do not eat, drink or smoke during work. Keep out of the reach of children.
5. Breathing protection: ambient-air-independent respirator (at high concentrations).
6. Eye protection: sealing goggles.
7. Hand protection: protective gloves (e.g. made of leather).
8. Personal protection: protective clothing.
9. Skin protection: use protective cream.
In addition, the safety data sheet for the refrigerant needs to be observed!
Caution!
Hot surfaces!
During operation, several components can reach surface temperatures of more than +60°C. There
is the risk of burns.
All components concerned are installed inside of the closed housing. The housing must only be opened
by certified skilled personnel 3.
Caution!
Improper use!
The device is intended for the separation of water in compressed air. The dried compressed air cannot be
used for breathing-air purposes and is not suitable for the direct contact with food.
This dryer is not suitable for the treatment of contaminated air or of air containing solids.
3Certified skilled personnel are persons who are authorised by the manufacturer, with experience and technical training, who are well-
grounded in the respective provisions and laws and capable of carrying out the required works and of identifying and avoiding any
risks during the machine transport, installation, operation and maintenance.
Qualified and authorised operators are persons who are instructed by the manufacturer regarding the handling of the refrigeration
system, with experience and technical training, and who are well-grounded in the respective provisions and laws.

Safety instructions
10 – EN ACT VS 800 - 2500
Note!
Contaminated intake air!
In the event that the intake air is strongly contaminated (ISO 8573.1 class 3.-3 or poorer quality), we
recommend the additional installation of a prefilter (5 micron minimum), to avoid clogging of the heat
exchanger.
Caution!
Heating-up through fire!
In the event of a heating-up through fire, the containers and pipes of the refrigerant system can
burst.
In this case, please proceed as follows:
Switch off the refrigeration plant.
Switch off the mechanical ventilation of the machinery compartment.
Use ambient-air-independent respirators.
Containers and plants which are filled with refrigerant can burst violently in the event of fire.
The refrigerants themselves are incombustible, but they are degraded to very toxic products at high
temperatures.
Remove the container/plant from the fire zone, as there is the risk of bursting!
Cool down containers and bottles via a directed water jet from a safe position.
In the event of fire, please use an approved fire extinguisher. Water is not a suitable agent to extinguish
an electrical fire.
This must only be carried out by persons who are trained and informed about the hazards emanating
from the product.
Caution!
Unauthorised intervention!
Unauthorised interventions may endanger persons and plants and lead to malfunction.
Unauthorised interventions, modification and abuse of the pressure devices are prohibited.
The removal of sealings and leadings at safety devices is prohibited.
Operators of the devices must observe the local and national pressure equipment regulations in the
countr
y
of installation.
Note!
Ambient conditions!
In the event that the dryer is not installed under suitable ambient conditions, the ability of the device to
condense refrigerant gas is impaired. This can result in a higher load of the refrigerating compressor, and
in a loss of efficiency and performance of the dryer.
This in turn leads to overheated condenser fan motors, to malfunction of electric components and to a
breakdown of the dryer. Failures of this type will affect warranty considerations.
Do not install the dryer in an environment in which chemicals with a corrosive effect, explosive gases,
toxic
g
ases, evaporation heat, hi
g
h ambient temperatures or extreme dust and dirt can be found.
Pos: 8 /Beko Technis che Dokumentation/ Sicherheit/Sicher heitshinweise, weit ere BM (nicht Ex) @ 0\mod_11836161 03770_6.doc @ 4009os : 9/ Beko Technische Dok umentation/Sicher heit/Zusatz Sicherhei tshinweise BM33 @ 0\mod_12319268 87620_6.doc @ 12829s: 10 /Beko Technisc he Dokumentation/Sic herheit/Vorsic htFehl funktion @ 0\mod_1214378096 290_6.doc @ 9359

Proper use of the dryer
ACT VS 800 - 2500 11 – EN
2 Proper use of the dryer
This dryer has been designed, manufactured and tested for the purpose of separating the humidity normally contained
in compressed air. Any other use has to be considered improper.
The Manufacturer will not be responsible for any problem arising from improper use; the user will bear responsibility for
any resulting damage.Moreover, the correct use requires the adherence to the installation instructions, specifically:
Voltage and frequency of the main power.
Pressure, temperature and flow-rate of the inlet air.
Pressure, temperature and cooling water capacity (Water-Cooled).
Ambient temperature.
This dryer is supplied tested and fully assembled. The only operation left to the user is the connection to the plant in
compliance with the instructions given in the following chapters.
Pos: 15 /Beko Techni sche Dokumentation/ Überschriften/ 1/Ausschluss vom Anwendungs bereich @ 0\mod_12125003439 359_6.doc @ 13709
3 Exclusion from a field of application
Pos: 16 /Beko Technisc he Dokumentation/Best iungsgemäße Verwendung/ BEKOMAT/Ausschluß Anwendung BM 31/32/33 @ 0\mod_12360038 37511_6.doc @ 13736
Note!
Improper use!
The device is intended for the separation of water in compressed air. The dried compressed air cannot
be used for breathing-air purposes and is not suitable for the direct contact with food.
This dryer is not suitable for the treatment of contaminated air or of air containing solids.
4 Instructions for the use of pressure equipment according to PED directive 2014/68/EU
To ensure the safe operation of pressure equipments, the user must conform strictly to the above directive and the
following:
The equipment must only be operated within the temperature and pressure limits stated on the manufacturer’s data
nameplate.
Welding on heat-exchanger is not recommended.
The equipment must not be stored in badly ventilated spaces, near a heat source or inflammable substances.
Vibration must be eliminated from the equipment to prevent fatigue failure.
Automatic condensate drains should be checked for operation every day to prevent a build up of condensate in the
pressure equipment.
The maximum working pressure stated on the manufacturer’s data nameplate must not be exceeded. Prior to use,
the user must fit safety / pressure relief devices.
All documentation supplied with the equipment (manual, declaration of conformity etc.) must be kept for future
reference.
Do not apply weights or external loads on the vessel or its connecting piping.
TAMPERING, MODIFICATION AND IMPROPER USE OF THE PRESSURE EQUIPMENT ARE
FORBIDDEN. Users of the equipment must comply with all local and national pressure equipment
legislation in the country of installation.

Transport
12 – EN ACT VS 800 - 2500
5 Transport
Check for visible loss or damage, if no visible damage is found place the unit near to the installation point and unpack
the contents.
To move the packaged unit we recommend using a suitable trolley or forklift truck. Hand carrying is not recommended
Always keep the dryer in the upright vertical position. Damage to components could result if unit is laid on its side or if
placed upside down.
Handle with care. Heavy blows could cause irreparable damage.
6 Storage
Even when packaged, keep the machine protected
from severity of the weather.
Keep the dryer in vertical position, also when stored.
Turning it upside down some parts could be irreparably
damaged.
If not in use, the dryer can be stored in its packaging in
a dust free and protected site at a temperature of +1°C
… +50°C (34°F…122°F), and a specific humidity not
exceeding 90%. Should the stocking time exceed 12
months, please contact the manufacturer.
The packaging materials are recyclable. Dispose of material in compliance with the rules and
regulations in force in the destination country.
SCC0001

Installation
ACT VS 800 - 2500 13 – EN
7 Installation
7.1 Place of installation
Note!
Ambient conditions!
In the event that the dryer is not installed under suitable ambient conditions, the ability of the device to
condense refrigerant gas is impaired. This can result in a higher load of the refrigerating compressor, and
in a loss of efficiency and performance of the dryer.
This in turn leads to overheated condenser fan motors, to malfunction of electric components and to a
breakdown of the dryer. Failures of this type will affect warranty considerations.
Do not install the dryer in an environment in which chemicals with a corrosive effect, explosive gases, toxic
gases, evaporation heat, high ambient temperatures or extreme dust and dirt can be found.
Minimum installation requirements:
Choose an area which is clean and dry, free from dust and protected against atmospheric disturbances.
The load-bearing zone must be even, horizontal and able to bear the weight of the dryer.
Minimum ambient temperature +1°C (34°F).
Maximum ambient temperature +45°C (113°F).
Ensure a proper cooling air replacement.
Allow a sufficient clearance on each side of the dryer for proper ventilation and to facilitate maintenance operations.
The dryer does not require attachment to the floor surface.
Do not obstruct the ventilation grille (not even partially).
Prevent any recirculation of the outgoing cooling air.
Protect the dryer against draughts.

Installation
14 – EN ACT VS 800 - 2500
7.2 Installation layout
1 Air compressor
2 Aftercooler
3 Condensate separator
4 Pre-Filter (min. 5 micron)
5 By-pass group
6 Dryer
7 Compressed air tank
8 Final filter
9 Condensate drain
Dryer’s compressor and fan (air cooled) speed are adjusted to adapt power consumption to the dryer load. Although
system is quite reactive, it cannot adapt its setting immediately to sudden load variation leading to dewpoint
spikes/fluctuations.
To avoid this behaviour it is recommended to install the dryer in systems where load variations happens but are damped.
Compressed air receivers can be used as dampers: installed before the dryer if compressors capacity varies suddenly
and frequently, after the dryer if the air consumption variation is very wide, frequent and sudden or both to have the best
load variation dampness.
Compressed air tanks can be installed as capacity dampers: installed before the dryer (Type A) if the compressor
capacity varies suddenly and often, after the dryer (Type B) if the change in air consumption is very large, frequent and
sudden or both to have the improved dampening of the flow variation.
Do not obstruct the ventilation grille (not even partially).
Prevent any recirculation of the outgoing cooling air.
Protect the dryer against draughts.
Note!
Contaminated intake air!
In the event that the intake air is strongly contaminated (ISO 8573.1 class 3.-3 or poorer quality), we
recommend the additional installation of a prefilter (5 micron minimum), to avoid clogging of the heat
exchanger.
2
2
1
IN
OUT
7
- A -
- B -
1
7
6
IN
OUT
5
9
8
9
4
9
3
9
9 9
3 4
9
9
8
6
5

Installation
ACT VS 800 - 2500 15 – EN
7.3 Correction factors
Correction factor for operatin
g
pressure chan
g
es:
Inlet air pressure psi
g
60 80 100 120 140 160 180 203
bar
g
4 5.5 7 8 10 11 12 14
Factor
(
F1
)
0.79 0.91 1.00 1.07 1.13 1.18 1.23 1.27
Correction factor for ambient temperature chan
g
es
(
Air-Cooled
)
:
A
mbient temperature ºF 80 90 95 100 105 110 115
ºC 27 32 35 38 40 43 45
Factor
(
F2
)
1.11 1.09 1.06 1.00 0.94 0.87 0.78
Correction factor for inlet air temperature chan
g
es:
A
ir temperature ºF 90 100 110 122 130 140 150 158
ºC 32 38 43 50 55 60 65 70
Factor
(
F3
)
1.16 1.00 0.82 0.68 0.61 0.52 0.45 0.40
Correction factor for DewPoint chan
g
es:
DewPoint ºF 38 41 45 50
ºC 3 5 7 10
Factor
(
F4
)
1.00 1.08 1.20 1.36
How to find the air flow capacity:
Air flow capacity = Nominal duty x Factor (F1) x Factor (F2) x Factor (F3) x Factor (F4)
Example:
An ACT VS 800 has a nominal duty of 800 scfm (1358 m³/h). What is the maximum allowable flow through the dryer
under the followin
g
operatin
g
conditions:
Inlet air pressure = 120 psig (8 barg)
Ambient temperature = 115°F (45°C)
Inlet air temperature = 122°F (50°C)
Pressure DewPoint = 50°F (10°C)
Factor (F1) = 1.07
Factor (F2) = 0.78
Factor (F3) = 0.68
Factor (F4) = 1.36
Each item of data has a correspondin
g
numerical factor which multiplied b
y
the desi
g
n air flow is as follows:
Air flow capacity = 800 x 1.07 x 0.78 x 0.68 x 1.36 = 617 scfm (1048 m³/h)
617 scfm (1048 m³/h) This is the maximum flow rate that the dryer can accept under these operating conditions.
How to select a suitable dryer for a given duty:
Minimum std. air flow rate = Design air flow
Factor (F1) x Factor (F2) x Factor (F3) x Factor (F4)
Example:
With the following operating parameters:
Design air flow = 750 scfm (1274 m3/h)
Inlet air pressure = 120 psig (8 barg)
Ambient temperature = 115°F (45°C)
Inlet air temperature = 122°F (50°C)
Pressure DewPoint = 50°F (10°C)
Factor (F1) = 1.07
Factor (F2) = 0.78
Factor (F3) = 0.68
Factor (F4) = 1.36
In order to select the correct dryer model the required flow rate is to be divided by the correction factors relating to
above mentioned parameters:
Minimum std. air flow rate = 750 = 972 scfm (1652 m³/h)
1.07 x 0.78 x 0.68 x 1.36
Therefore the model suitable for the conditions above is ACT VS 1000 (1000 scfm [1698 m³/h] - nominal duty).

Installation
16 – EN ACT VS 800 - 2500
7.4 Connection to the compressed air system
Danger!
Compressed air!
All works must only be carried out by qualified skilled personnel.
Never work on compressed-air systems which are under pressure.
The operator or the user must ensure that the dryer is never operated with a pressure exceeding the
maximum pressure value indicated on the name plate.
Exceedin
g
the maximum operatin
g
pressure can be dan
g
erous for the operator but also for the device.
The air temperature and the flow entering the dryer must comply within the limits stated on the data nameplate. The
system connecting piping must be kept free from dust, rust, chips and other impurities, and must be consistent with the
flow-rate of the dryer. In case of treatment of air at particularly high temperature, the installation of a final refrigerator
could result necessary. In order to perform maintenance operations, it is recommended to install a dryer by-pass system.
In realising the dryer, particular measures have been taken in order to limit the vibration which could occur during the
operation. Therefore we recommend to use connecting pipes able to insulate the dryer from possible vibrations
originating from the line (flexible hoses, vibration damping fittings, etc.).
Note!
Contaminated intake air!
In the event that the intake air is strongly contaminated (ISO 8573.1 class 3.-3) or poorer quality, we
recommend the additional installation of a prefilter (5 micron minimum), to avoid clogging of the heat
exchan
g
er.
7.4.1 Inlet / outlet flanged air connections (only ACT VS 800 – 1250)
Inlet / oulet flanged air connections and clamp joints are located inside the box under the dryer (see Fig.1).
Assembly flange (B) and clamp joint (A) as shown in Fig.2
Pay particular attention in not damaging the gasket of clamp joint (A).
Fully tighten the two bolts of clamp joint (see Fig.3)
Fig.1 Fig.2
Fig.3
LGT0056 LGT0057
B
A

Installation
ACT VS 800 - 2500 17 – EN
7.5 Connection to the cooling water network (Water-Cooled)
Danger!
Compressed air!
All works must only be carried out by qualified skilled personnel.
Never work on compressed-air systems which are under pressure.
The operator or the user must ensure that the dryer is never operated with a pressure exceeding the
maximum pressure value indicated on the name plate.
Exceedin
g
the maximum operatin
g
pressure can be dan
g
erous for the operator but also for the device.
The temperature and the amount of cooling water must comply with the limits indicated on the technical characteristics
chart. The cross section of the connection pipes, preferably flexible, must be free from rust, chips and other impurities.
We recommend to use connecting pipes able to insulate the dryer from possible vibrations originating from the line
(flexible hoses, vibration damping fittings, etc.).

Note!
Contaminated intake water!
In the event that the intake water is strongly contaminated we recommend the additional installation of a
prefilter (500 micron), to avoid clogging of the heat exchanger.

Installation
18 – EN ACT VS 800 - 2500
7.6 Minimum cooling water requirements:
Copper brazed stainless steel condenser
Temperature +15°C…+30°C (+59°F…+86°F) *1
Pressure 3…10 barg (43.5…145 psig) *2
Delivery pressure > 3 bar (43.5 psi) *2 *3
PH 7.5…9.0
Total hardness 6.0…15 °dH
Conductivity 10…500 μS/cm
Sulphates (SO42-) < 100 mg/l or ppm
Hydrogen Carbonate / Sulphates (HCO3 / SO42-) > 1.0 mg/l or ppm
Ammonia (NH3) < 0.5 mg/l or ppm
Free aggressive carbonic acid < 20 mg/l or ppm
Ammonium (NH4+)< 2 mg/l or ppm
Saturation Index SI -0.2 < 0 < 0.2
Hydrogen carbonate (HCO3) < 300 mg/l or ppm
Residual solid particles < 30 mg/l or ppm
Chlorides (Cl-) < 5 mg/l or ppm
Free chlorine (Cl2) < 0.5 mg/l or ppm
Oxygen content < 0.1 mg/l or ppm
Carbon dioxide (CO2) < 50 mg/l or ppm
Hydrogen sulphide (H2S) < 0.05 mg/l or ppm
Phosphate (PO43-) < 2 mg/l or ppm
Iron (Fe) < 0.2 mg/l or ppm
Manganese (Mn) < 0.1 mg/l or ppm
Nitrate (NO3-) < 100 mg/l or ppm
Nitrite (NO2-) < 0.1 mg/l or ppm
Sulphide (S2-) < 1 mg/l or ppm
Tube bundle condenser
Temperature +15°C…+30°C (+59°F…+86°F) *1
Pressure 3…10 barg (43.5…145 psig) *2
Delivery pressure > 3 bar (43.5 psi) *2 *3
PH 7.5…9.0
Total hardness 6.0…15 °dH
Conductivity 10…1000 μS/cm
Sulphates (SO42-) < 100 mg/l or ppm
Hydrogen carbonate / Sulphates (HCO3 / SO42-) > 1.0 mg/l or ppm
Ammonia (NH3) < 0.5 mg/l or ppm
Manganous ion (Mn2+) < 0.05 mg/l or ppm
Chlorides (Cl-) < 50 mg/l or ppm
Free chlorine (Cl2) < 0.5 mg/l or ppm
Oxygen content < 0.1 mg/l or ppm
Carbon dioxide (CO2) < 50 mg/l or ppm
Hydrogen sulphide (H2S) < 0.05 mg/l or ppm
Phosphate (PO43-) < 2 mg/l or ppm
Ferric ion (Fe3+) < 0.5 mg/l or ppm
*1 Other temperatures upon request – check the data on the name plate.
*2 Other pressures upon request – check the data on the name plate.
*3 Pressure difference at the water connection of the dryer at maximum water flow. Other prevalences upon request.
CAUTION!
During the piping of the dryer, the inlet and outlet connections need to be supported as is shown in the
illustration.
Non-observance will cause damage.

Installation
ACT VS 800 - 2500 19 – EN
7.7 Electrical connections
Danger!
Supply voltage!
The connection to the electric mains should only be carried out by qualified skilled personnel and must
correspond to the le
g
al provisions in force in
y
our re
g
ion.
Before connecting the unit to the electrical supply, verify the data nameplate for the proper electrical information. Voltage
tolerance is +/- 10%. The installer is responsible for supplying and installing the power cable. Be sure to provide the
proper fuses or breakers based on the data information located on the nameplate.
ACT VS 800 – 1250 ACT VS 1500 – 2500
A residual-current device (RCD) with In =0.3A Class B
is suggested. The cross section of the power supply
cables must comply with the consumption of the dryer,
while keeping into account also the ambient temperature,
the conditions of the mains installation, the length of the
cables, and the requirements enforced by the local Power
Provider.
Compressor and fan(s) proper rotation direction are
managed automatically by the inverters.
It is not necessary to observe the phases sequence when
connecting the power cable to the main switch.
Danger!
Supply voltage and missing earth connection!
Important: ensure that the plant is connected to earth.
Do not use plug adapters at the power plug.
Possible replacement of the power plu
g
must onl
y
be carried out b
y
a qualified electrician.

Note!
This dryer is not suitable for employment on IT-systems.
This dryer is not suitable for employment on grounded-delta systems

Start-up
20 – EN ACT VS 800 - 2500
7.8 Condensate drain
Danger!
Compressed air and condensate under pressure!
The condensate is discharged at system pressure.
The drain pipe needs to be secured.
Never direct the condensate drain pipe at persons.
The dryer comes already fitted with an electronic condensate drainer.
Connect and properly fasten the condensate drain to a collecting plant or container.
The drain cannot be connected to pressurized systems.
Don’t dispose the condensate in the environment.
The condensate collected in the dryer contains oil particles released in the air by the compressor.
Dispose the condensate in compliance with the local rules.
We recommend to install a water-oil separator where to convey all the condensate drain coming from
compressors, dryers, tanks, filters, etc.
8 Start-up
8.1 Preliminary operation
Note!
Exceeding of the operating parameters!
Ensure that the operating parameters comply with the nominal values indicated on the name plate of the
dr
y
er
(
volta
g
e, frequenc
y
, air pressure, air temperature, ambient temperature etc.
)
.
This dryer has been thoroughly tested, packaged and inspected prior to shipment. Nevertheless, the unit could be
damaged during transportation, check the integrity of the dryer during first start-up and monitor operation during the first
hours of operation.
The initial start-up must be carried out by qualified personnel.
During the installation and operation of this device, all national regulations regarding electronics and any
other federal and state ordinances, as well as local provisions, need to be adhered to.
The operator and the user must ensure that the dryer is not operated without panels.
