SUNTEC ST600 User manual

Suntec Industries (H.K.) Ltd.
Te l : [phone]
Fax: [phone]
URL: www.suntecind.com
READ AND STUDY MANUAL BEFORE USE
LGR Mobile Dehumidifier
220~240V Model: ST600 / ST1000
OPERATING MANUAL

DECLARATION OF CONFORMITY
We, declare under sole responsibility that our models (ST600 and ST1000)
to which this declaration relates are in conformity with the following
standards:
EMC:
EN 55014 - 1:2006
，
EN 55014-2:1997+A1:2001
Electromagnetic Compatibility: emission requirement
EN 61000 - 3 - 2:2006
，
EN 61000-3-3:1995+A1:2001+A2:2005
Electromagnetic Compatibility: emission requirement.
LVD:
EN 60335 - 1: 2002+A1:2004+A11:2004+A12:2006+A2:2006
Safety of household and similar electrical appliance
- General requirements.
EN 60335 - 2-40: 2003+A11:2004+A12:2005+A1:2006
Particular requirements for electric heat pumps,
air conditioners and dehumidifiers.
Suntec Industries (H.K.) Ltd.
Design and Development

Specifications
Model
ST600
ST1000
Water Removal (32°C/90%RH)
138Pints / 65L per day
222Pints / 100L per day
Water Removal (27°C/60%RH)
83Pints / 39L per day
129Pints / 61L per day
Water Removal (10°C/70%RH)
32Pints / 15L per day
54Pints / 27L per day
Temp. Range
1° - 38° C
1° - 38° C
Compressor / Refrigerant
Rotary / 410A
Rotary / 410A
Power Consumption
920 Watt
1650 Watt
Voltage / Cycle
220-240V / 50Hz
220-240V / 50Hz
Ampere
4.0 Amps
6.5 Amps
Rated Air Flow
600 m3/h
750 m3/h
Control Panel
Touch-pad
Touch-pad
Timer Control
Yes
Yes
Defrost Type
Hot-gas bypass
Hot-gas bypass
Air Filter
Pleated Filter
Pleated Filter
Water Pump
Centrifugal
Centrifugal
Housing
Rotomolded
Rotomolded
Large Wheels
Semi-pneumatic
Semi-pneumatic
Drain Hose Length
10m
10m
Cable Length
8m
8m
Height
840mm
840mm
Width
500mm
500mm
Depth
485mm
485mm
Use Weight
40kg
50kg
Specifications are subject to change without notice. Some values are approximate.
Suntec ST Series dehumidifiers are used for professionals drying out wet
materials such as carpets, carpet cushions, floors, walls, building contents and
more. They reduce the water in enclosed structural environments like building
or part of a building by removing water vapor from the air.
Safety Instructions
l Do not allow children to play with or around the operating unit.
l Keep wiring and motor dry. Never operate the unit in standing water, rain
and snow, as this may create a risk of injury from electric shock.
l Do not use the adaptor.
l Do not operate the unit with a damaged power cable.
l Always operate the unit with an earthed plug and with an earthed supply.
l Extension cables must be earthed and be able to deliver the appropriate
voltage to the unit.
l Do not drop or throw the unit.
l Always operate the unit on a stable, level surface.
l Do not clog or block air intakes.
l Always to keep the filter clean.
l Do not attempt to disassemble or repair the unit if you are not qualified to
do so.
How to Use Dehumidifiers
Setting Up a Drying Area
Create a closed drying chamber
The dehumidifier should be operated in an enclosed space, as this creates a
drying chamber. Close all doors, windows or areas that open to the outside to
maximize the unit’s water removal efficiency. Inside the drying chamber, air
should circulate freely. Open interior doors and turn on Air Movers to increase
the circulation.

Position the dehumidifier
Place the dehumidifiers in the center of a room and keep it away from anything
that could prevent airflow into and out of the unit.
Managing the rising temperature
The dehumidifier warms the air as it removes its moisture. Room temperatures
of about 20oC to 29oC are usually a good condition for drying.
CAUTION! Never operate the Suntec ST Series dehumidifier at temperature
above 38oC. It could damage the machine and building contents.
Operating Your Dehumidifier
Place the dehumidifiers in upright position
If the dehumidifier has been in a horizontal position for any time over a few
minutes, you must set it upright (vertical) for 30 minutes before starting.
Connect drainage system
You can find the hose wrapped around the back of the machine. Unwrap the
entire hose and run it into a sink, toilet, drain, or bucket.
Plug in the electrical cord
Locate the electrical cord and unwrap around the air outlet located on the back
of the unit. Plug it into a standard outlet with the correct voltage and amperage
for the unit. If the unit experiences a loss of power, which can result from a
power interruption and overheated.
Before Transporting Your Dehumidifier
Before moving the unit, make sure the pump is empty of water. To d o this, l e t
the unit stop dehumidification for 10mins. Push PURGE key to clear waters.
See “How to Use the Touch Pad Control Panel” for more details.
l Inspect filter. Look for accumulated dust and dirt that would restrict airflow
through the filter into the unit. If any is visible, vacuum out the debris. Do
not wash the filter.
Important: Replace the filter whenever
l It has been vacuumed clean 3 times.
l It has been used on a mold remediation job.
Periodically Inspection (as needed)
Make sure the unit is unplugged. Remove housing, in order to locate the coil,
pump and drain hose.
l Check coil and clean visible dirty
n Vacuum both sides of the coils until clean.
l Check pump
n Inspect and clean the pump system regularly to maintain effective
operation. Remove one screw to open up the top cover, and then
open up the second cover. Clean the float shaft to make sure the
floating switch can operate smoothly.
l Check drain hose
n Look for obstructions. Disconnect and clear any debris present.
Warranty
SunTec warrants to the original purchaser that if, within a period of 12 months
from the date of purchase, this equipment is found to be defective either in
original materials or workmanship (excluding normal usage wear and/or
mishandling or abuse) the faulty part will be replaced free of charge upon
presentation of the appropriate evidence, provided the unit is returned to the
original supplier. Shipping expenses are not covered under the warranty.

Error Messages
Message
Icon
Description
Er01
“PUMP ON”
flashing
Problem with pump or pump tube is kinked.
Er02
N/A
Check coil temperature sensor at the side of coil and
its sensor cable.
Er03
N/A
Check ambient temperature sensor in the front of the
coil and its senor cable.
Note:
l When Er01 or Er02 error message comes up, the dehumidification will stop
automatically. The machine will be back to STANDBY MODE and it won’t be
automatically turn off unless you do so. Contact your local distributor for service.
l When Er03 error message comes up, the dehumidification is still on. Contact
your local distributor for service.
Indication Light:
Status
Colors
Description
Off
N/A
Machine has been turned off.
On
Red
Machine has been turned on.
On
Green
Machine start dehumidification.
Maintenance
WARNING! Always unplug any dehumidifier before performing maintenance
procedures.
Before Each Use
l Inspect the electrical cord for damage.
l Inspect pump tube. Make sure the pump tube is completely unwrapped
and not kinked. Failure to do so can cause water to back up in the pump
and leak out. The control panel may signal this problem by displaying
“ER01
How to Use the Touch Pad Control Panel
There are one LCD Display, one
Indication Light (Red/Green) and
five keys in the Suntec
Dehumidifier touch pad control
panel.
LCD Display:
DEHUMIDIFIER ON.
PURGE ON. The pump is on and it is pumping water out
of the container.
DEFROST ON. Frost forming on the coils, defrost cycle
start.
DELAY BAR AND COUND DOWN.
“TIMER” CLOCK. While displaying the “TIMER” CLOCK
time, “TIMER” CLOCK icon is on. The four digits show how
many HOURS and MINUTES the “TIMER” is.
“TOTAL” CLOCK. While displaying the “TOTAL” CLOCK
time, “TOTAL” CLOCK icon is on. The digits show how
many DAYS the machine has been used.
“JOB” CLOCK. While displaying the “JOB” CLOCK time,
“JOB” CLOCK icon is on. The four digits show how many
HOURS and MINUTES either the CURRENT JOB is
running or the LAST JOB has been run.

Touch Pad Keys:
ON/OFF. Press the ON/OFF key to turn the machine on or off.
l When turning the machine on, the machine is under STANDBY
MODE. The red indication light and LCD light up. LCD displays
“TIMER” CLOCK icon. Four Time digits flash, which indicates the
operator either to set the “TIMER” by pressing the “TIMER” KEY or
to start the machine directly by pressing the “START/STOP” KEY.
l Press the ON/OFF key again to turn the machine off. The red
indication light and LCD light off. Note: In STANDBY MODE, the
machine can also be automatically turned off if there are no other
keys pressed within 15mins.
TIMER. By using the “TIMER” key, the dehumidification time can be set as
you require.
l The “TIMER” time setting range is from 00:00 to 23:50. It increases
by 10mins for every key press
l Press the “TIMER” key without releasing; the time can be adjusted
continually.
START/STOP. Press the START/STOP key to start or stop the
dehumidification.
l When dehumidification starts, the machine performs a compressor
delay. The display reads a numeral count down from a maximum of
90 seconds to 0. (30 seconds count down for the first startup). The
DELAY BAR flashes during this count down period.
l While the dehumidification is on, the display reads “DEHUMIDIFIER
ON” icon.
l The dehumidification runs continuously if there is no “TIMER” has
been set before it starts.
l Otherwise, the dehumidification stops as the “TIMER” set.
l Press the START/STOP key again to stop the dehumidification. The
“DEHUMIDIFICATION ON” icon comes off while the dehumidification
stops.
Touch Pad Keys (Cont.):
PURGE. Press the PURGE key to empty water from the pump
reservoir. During the normal operation, the pump purges automatically
whenever the reservoir is full. The display will read PURGE ON icon.
TO PURGE THE PUMP MANUALLY BEFORE TRANSPORTATION:
l Stop the dehumidification using the START/STOP key, and let
the unit sit for about 10mins. This allows water to drip from the
coils.
l Press PURGE to remove residual water.
DISPLAY. Press the DISPLAY key to display “TIMER” CLOCK,
“TOTAL” CLOCK and “JOB” CLOCK while the machine has been turned
on. Press the DISPLAY key once can only display ONE kind of clock
time.
l In STANDBY MODE, the default display is “TIMER” CLOCK time.
By press the DISPLAY key once to display the “TOTAL” CLOCK
time. Press it again to display “JOB” CLOCK time, which shows
the LAST JOB run time.
l While the dehumidification stops as the “TIMER” set, the default
CLOCK display is “TIMER” CLOCK time, which shows remaining
running time of the CURRENT JOB. Press the DISPLAY key once
to display the “TOTAL” CLOCK time. Press it again to display
“JOB” CLOCK time, which counts the CURRENT JOB run time.
l While the dehumidification runs continuously without “TIMER”
setting, the default CLOCK display is “JOB” CLOCK, which shows
the CURRENT JOB running time. Press the DISPLAY key once
to display “TIMER” CLOCK time, which reads “00:00”. Press it
again to display the “TOTAL” CLOCK time.
l If the DISPLAY key has not been pressed within 15 seconds, the
CLOCK time will back to its default display.
l When error messages are on, “TIMER”, “TOTAL” and “JOB”
CLOCK displays disappear. Press DISPLAY key once to get the
clock displays back.
