Fronus 24V Series User manual

Wall Mounted Lithium Battery Series
User Manual

Content
1 Safety Information............................................................................ 1
1.1 General Safety....................................................................................... 1
1.2 Personal Safety..................................................................................... 2
1.3 Electrical Safety..................................................................................... 2
1.4 Environment Safety............................................................................... 4
1.5 Transportation Safety............................................................................ 4
2 Product Information ........................................................................ 5
2.1 Battery Overview.................................................................................... 5
2.2 Appearance........................................................................................... 6
2.3 Dimensions............................................................................................ 6
2.4 Capacity Options................................................................................... 7
2.5 Display .................................................................................................. 8
2.6 Operation .............................................................................................. 8
2.7 Multiple Batteries Parallel Connection................................................... 10
3 Specifications..................................................................................................... 11
3.1 24V Series Battery Specifications .......................................................... 11
3.2 48V Series Battery Specifications .......................................................... 12

1
1 Safety Information
1.1 General Safety
Please carefully read the manual safety precautions, and observe all the safety
instructions on the equipment and in this document.
The "DANGER”，"WARNING", and "NOTICE” statements in this document do not
cover all the safety instructions. They are only supplements to the safety
instructions.
For user safety and utilization efficiency of this manual, a list of symbols are
designed to alert people from danger. You must understand and comply with the
emphasized information to avoid personal injury and property damage. Relative
safety symbols have been listed below.
DANGER indicates a hazardous situation which, if
not avoided will result in serious injury and fire.
WARNING indicates a hazardous situation which, if
not avoided will result in property loss or void
warranty.
NOTICE indicates normal situation which, if not
avoided will result in that battery doesn't work.
Follow local laws and regulations when installing, operating, or maintaining the
equipment. The safety instructions in this document are only supplements to local
laws and regulations.
Danger
Warning
Notice

2
1.2 Personal Safety
Personal Requirements
People who plan to install or maintain battery equipment must be trained,
understood all necessary safety precautions, and are able to perform all operations
correctly.
Only qualified professionals or trained people are allowed to install, operate, and
maintain the equipment.
Personal Safety
Do not place battery at a children or pet touchable area.
Do not touch the energized battery, as the enclosure is hot.
Do not touch the energized battery terminals.
Do not stand on, lean on, or sit on the battery.
1.3 Electrical Safety
Symbols on battery
There are some electrical symbols on battery relate to electrical safety. Please
make sure you have fully understand them before installation.
Electrical danger
Voltage exits when the battery is
powered on. Only qualified engineers are
allowed to operate.
Earth connector
Earth connection.
DC positive and
negative connectors
Identify positive and negative connectors
of DC power source.
CE mark
The product meets CE certification.
WEEEtag
Can't leave battery as garbage disposal.
Recycle
Battery can be recycled.

3
Electrical Safety
Before installation, ensure that the equipment is intact. Otherwise, electric
shocks or fire may occur.
Do not connect or disconnect power cables when battery is power-on.
Which may cause electric arcs and sparks more overfire or personal injury.
Before connecting a power cable, check the positive or negative connectors are
correct.
Do not parallel connection with different batteries.
Do not connect battery with AC directly.
Do not connect battery with PV wiring directly.
Do not connect batteries in series.
Do not connect battery to faulty or unqualified inverter or charger.
Do not create short circuits with the external connection.
Make sure the grid is cut off and the battery is powered off before
maintenance.
Make sure the earth cable is connected correctly before operation.
Recharge battery in every six months.
Recharge battery within 10 days after battery is fully discharged.
Please engage greater than or equal to two batteries when maximum
charge current is more than 80A.
Make sure battery cable placement is installed correctly.
When the battery is being installed or repaired, make sure the battery is
powered off and using a multimeter to make sure there is no voltage in the positive
and negative terminals.
Please use dedicated insulated tools for install and maintenance.
Please make sure all batteries are power-off when multiple parallel connection.
Please check lights on sequence when battery power-on.
Please make sure communication connection connect correctly with battery
and inverter.
Please make sure ADDS dip switch settings are correctly for single or multiple
batteries.
Please check inverter alarm or SOC reading when there is BMS
communicated with inverter.

4
1.4 Environment Safety
Ensure that the equipment is installed in a dry and well-ventilated
environment.
The installation position must be away from direct sunlight and rain.
The installation position must be far away from fire sources.
The installation position must be far away from water sources such as taps,
sewer pipes, and sprinklers to prevent water seepage.
The bracket must be installed solidly and horizontally.
Do not expose the equipment to flammable or explosive gas or smoke.
Do not perform any operation on the equipment in such environments.
The operation and service life of the battery depends on the operating
temperature. Operate the battery at a temperature equal to or better than the
ambient temperature. The recommended operating temperature range is from 0°C
to 30°C.
1.5 Transportation Safety
The products passed certification UN38.3.
The products have MSDS.
The products belong to class 9 dangerous goods.
Please protect the packing case from the below situations.
Being dampened by rains, snows, or falling into water.
Falling or mechanical impact.

5
Being upside-down or tilted.
24 batteries per pallet (4x6 pcs )
2 Product Information
2.1 Battery Overview
The battery is a wall mounted lithium battery pack which consists of long span
LiFePO4 battery cells and functional BMS. It can store and release electric energy
based on the requirements of the inverter controller. It is mainly for home energy
storage system.
Features
LiFePO4 prismatic cell
6000 cycles @0.5C conditions
Maximum 1C charge and discharge capability
Wall mounted IP 54 grade
Be extended to 16 packs maximum
Protective and active BMS allows greater reliability and control
IP 54 grade
Building in terminal design
Fully recyclable at the end of life
Compact

6
①Working status display light ②LED display
③Positive terminal ④Negative terminal
⑤Battery parallel communication Port ⑥Inverter communication port
⑦Dial the code switch ⑧Operating area
⑨The power switch ⑩The handle
⑪Wall-mounted bracket
2.3 Dimensions
2.2 Appearance
⑧

7
2.4 Capacity Options
The battery can be parallelly connected for extending power(kW) and energy(kWh).
The maximum power(kW) is limited by main cables from master battery to
inverter.
The maximum 8 battery packs can be parallelly communicated.
For example, ONE PACK is 4.8kWh,
4.8kWh
9.6kWh
19.2kWh
AND MORE ……

8
2.5 Working status display light
Standby :Green light flashing Discharge : Green light normally on
Trouble/alarm：Red light normally on Charging: Blue light normally on
Alarm
When the red light is on, some parameters of the battery have reached the warning
value, or the battery has begun to be protected, BMS will send a warning when the
battery is being charged or discharged.But after the battery protection, some
functions of the battery can not be used.
2.6 Operation
Power Switch ON/OFF
To power on the whole battery system, no power output.
Power Connector
There are two sets of power connectors in the operation area, as shown in the
figure, the one on the left is the positive pole, and the one on the right is the
negative pole. The polarity of the power connectors in the same group is the same,
and the battery can be connected in parallel or the inverter can be connected.
Please remove operation plate to find operation area.
Please wire in cables from bottom inlets firstly.

9
Please use standard M6 lug to install cable and connectors.
Communication Port
There are three RJ45 ports for BMS to inverter and parallel batteries communication.
INVCOM is for updating battery information to compatible inverter or top tier when
necessary. It is RS232 communication. BATCOM is RS485 for link to next battery
pack to allow parallel batteries to work as one group.
INVCOM
The BMS has the RS232 communication function for battery pack data upload, and
the baud rate is 2400bps. RS232 upload communication interface. It can
communicate with the host computer through the RS232 communication interface.
INVCOM pin interface definition
BATCOM
The BMS has RS485 communication for battery pack collection, and the baud rate
is 9600bps. RS485 communication interface adopts 8P8C network cable interface.
BATCOM pin interface definition
Pins
Definitions
1、2
NC (empty )
3、6
GND
4
TX
5
RX
7、8
NC (empty )
Pins
Definitions
1、8
RS485 -B
2、7
RS485 -A
3、6
Ground
4、5
NC (empty )
INVCOM BATCOM

10
Please find communication ports in operation area.
RS232 communication baud rate is 2400.
RS485 communication baud rate is 9600.
Please wire in cables from bottom inlets firstly.
Address switch settings
2.7 Multiple Batteries Parallel Connection
Please set dip address switches as above.
Please see communication ports link connection below
Please see power parallel connection below.
Please ensure that the equipment is connected permanently to the protective
ground individually or parallelly.

11
3 Specifications
3.1 24V Series Battery Specifications
Item
Specifications
remark
25F100T
25F200T
Battery Type
LiFePO4
Typical Capacity (Ah)
100Ah
200Ah
Typical Voltage (V)
25.6V
Connection
2P8S
4P8S
Voltage Working Range (V)
21.6V-29.2V
Single cell:
2.7V-3.65V
Working Temperature(°C)
Charge: 0°C~+55°C,
Discharge: -20°C~+60°C
Storage Temperature(°C)
-20°C~+35°C
Nominal Capacity (kWh)
2.56kWh
5.12kWh
Max. Charge Current(A)
70A
100A
Max. Discharge Current(A)
75A
100A
Cycle Life
>5000
25°C ,0.5C ,
90%DOD
SOC Accuracy
<8%
Weight(kg)
33kg
53kg
Dimensions(mm)
185x450x580mm
D x W x H
IP Grade
IP54
Transportation SOC
30%
Cooling
Nature

12
3.2 48V Series Battery Specifications
Item
Specifications
remark
4885T
48100T
Battery Type
LiFePO4
Typical Capacity (Ah)
85Ah
100Ah
Typical Voltage (V)
48V
Connection
2P15S
Voltage Working Range (V)
41V-55V
Single cell:
2.7V-3.65V
Working Temperature(°C)
Charge: 0°C~+55°C,
Discharge: -20°C~+60°C
Storage Temperature(°C)
-20°C~+35°C
Nominal Capacity (kWh)
4.08kWh
4.8kWh
Max. Charge Current(A)
70A
100A
Max. Discharge Current(A)
75A
100A
Cycle Life
>5000
25°C ,0.5C,
90%DOD
SOC Accuracy
<8%
Weight(kg)
49kg
51kg
Dimensions(mm)
185x450x580mm
D x W x H
IP Grade
IP54
Transportation SOC
30%
Cooling
Nature
