FROST NOVA2 CARE GRAB RAIL 2 Install guide

1
GRAB RAIL 2, STRAIGHT
GRAB RAIL 2
Fitting instruction
Montageanleitung
Monteringsvejledning
Monteringsvägledning
Montage hanleiding
Manuel de montage
NOVA2 CARE
Exclusion of liability
FROST accepts no liability whatsoever
for damage to persons or property that
occurs or has occurred as a result of
improper installation or maintenance,
particularly if the safety instructions
and other points to note listed are not
or have not been observed in full.
Warning and hazard notices
Improper mounting or use can lead to
accidents and serious injuries.
N1965
300 mm
380 mm
90
90
332 mm
96 mm
80 mm
8
32 mm
Cleaning and maintenance
Stainless steel surfaces should be cleaned
with a microbre cloth, glass cleaner or other
non abrasive and gentle agents.
Attention:
Never use solvents or aggressive household
cleaners like bleach, acids (e.g. descalers) or
ammonia-based bathroom cleaner to clean
the product. Steel wool and hard brushes can
permanently damage the surfaceof the steel.
Before installing, the installer must ensure that the
material and strength of the wall are sucient.
FROST CARE products must be mounted on a solid
or reinforced wall.

2
Method of testing
To ensure that the Grab Rail is capable of withstanding heavy load and conditions every
day, the product has been tested in accordance to the requirements of the European
standard for technical aids for disabled, BS/EN 12182:2012.
The Grab Rail was then subjected to static load; Veftical load of 3.43 kN (350 kg) followed by
a horizontal load of 5.89 kN (600 kg), After the last test, the handrail was loaded until failure
at a Horisonatal load of 1314 kg.
We recommend all FROST CARE products are installed on a solid wall. Reinforcement should
always be used if the wall is not stable. All tests are carried out on products mounted on a
solid wall, thus we cannot guarantee the same performance and durability if this is not
observed.
For safety reasons, we recommend to check all bolt connections to ensure that no parts are
loose and that all attachment to the wall are intact.
350 kg
600 kg
Operating
Bedienung
Betjening
Buk
Bediening
Emploi
12
3
4

GRAB RAIL 2, STRAIGHT
3
Bavne Allé 32
DK-8370 Hadsten
[phone]
[e-mail]
www.frost.dk
Material: Stainless steel, AISI 304
Design: Bønnelycke mdd.
Manufacturer: FROST A/S
N1964 O1964
N1964-C N1964-GO
N1964-WN1964-B
8x 8x
D10,8 - DB6 - L50D8 - H40
AB
