FRTek PrimAer 39GHz User manual

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
1
PrimAer 39GHz Operating Manual
PrimAer 39GHz
Operating Manual
Document Reference
Company: Fiber Radio Technologies
Version: Ver 0
Document Status: Release 0
Issue Date: 2021. 09.
Department: R&D Group 2
Author Manager: Soo Hyeon, Jeong

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
2
PrimAer 39GHz Operating Manual
▪Copyright
The contents of this Manual are owned and copyrighted by FRTek Co., Ltd.
This manual may not be reproduced, distributed, modified in any form without the written consent of
FRTek Co., Ltd
Unauthorized disclosure, distribution, copying or use of the information contained in this document in
whole or in part without written permission is strictly prohibited.
▪Trademark
The trademarks mentioned in this manual are registered trademarks of FRTek
Please read this Manual prior to installation and operation. Use the system only in accordance with the contents and
directions of this Manual.
The specification and information regarding the products in this manual are subject to change due to updates to system
functionality or system revision changes without notice. For the latest revision of this manual or for technical inquiries, please
contact below :
Company Address : 39120 Argonaut Way, Suite 451, Fremont, California 94538
Homepage : www.frtek.com
Contact for technical inquires or troubleshooting.
Telephone : [phone] or 510-390-1939
E-mail : [e-mail]

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
3
PrimAer 39GHz Operating Manual
Revision History
Version Issue Date Details of Revision Author
Authorizing
Manager
V 0 Sep. 6, 2021. Initial Release Soo Hyeon, Jeong Jun Hyun, Lee
This manual is produced by R&D Group 2 Printed in FRTek.

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
4
PrimAer 39GHz Operating Manual
Contents
Chapter 1 Safety & Certification Notice ............................................................. 8
1.1 FCC Warning Statements ............................................................................. 9
1.1.1 FCC Part 15.105 statement.................................................................. 9
1.1.2 FCC Part 15.21 statement.................................................................... 9
1.1.3 Health and Safety Warnings................................................................ 9
1.2 Certification Notice .................................................................................... 11
Chapter 2 System Overview ............................................................................. 12
2.1 System Overview ....................................................................................... 13
2.1.1 Overview ........................................................................................... 13
2.1.2 PrimAer 39 Design Consideration...................................................... 13
2.2 System Network Configuration .................................................................. 14
Chapter 3 System Configuration ...................................................................... 15
3.1 DU Function and Configuration .................................................................. 17
3.2 SU Function and Configuration .................................................................. 19
3.3 Rectifier Function and Configuration ......................................................... 22
Chapter 4 System Specification ....................................................................... 24
4.1 System Specification .................................................................................. 25
4.1.1 Downlink Specification...................................................................... 25
4.1.2 Uplink Specification........................................................................... 25
4.2 Instrumental Specification......................................................................... 26
4.2.1 Structure and Type ............................................................................ 26
4.2.2 Material and Components.................................................................. 26
4.3 Electrical Specification ............................................................................... 26
4.4 Environmental Specification ...................................................................... 27
Chapter 5 System Installation.......................................................................... 28
5.1 Kits & Tools ................................................................................................ 29
5.2 DU Installation ........................................................................................... 35
5.2.1 Product Installation........................................................................... 35
5.2.2 Ground Cable Connection .................................................................. 38
5.2.3 Antenna Tilt....................................................................................... 38
5.3 SU Installation ........................................................................................... 39
5.3.1 Product Installation........................................................................... 39

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
5
PrimAer 39GHz Operating Manual
5.3.2 Ground Cable Connection .................................................................. 43
5.3.3 Antenna Tilt....................................................................................... 43
5.4 Rectifier Installation .................................................................................. 44
5.4.1 Product Installation........................................................................... 44
5.4.2 Ground Cable Connection .................................................................. 48
5.5 DU/ SU/ Rectifier Connection ...................................................................... 48
5.5.1 DU/ SU/ Rectifier Connection ............................................................. 48
5.5.2 Other Installation Scenarios.............................................................. 58
Chapter 6 Local GUI(Graphical User Interface) ............................................... 59
6.1 GUI Configuration ...................................................................................... 60
6.1.1 Initial Main Screen ............................................................................ 60
6.1.2 DU Main Screen Configuration........................................................... 64
6.1.3 SU Main Screen Configuration ........................................................... 68

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
6
PrimAer 39GHz Operating Manual
Figures
Figure 1. Network Configuration...................................................................... 15
Figure 2. DU Figure .......................................................................................... 17
Figure 3. DU Port Configuration ....................................................................... 18
Figure 4. SU Figure........................................................................................... 19
Figure 5. SU Port Configuration ....................................................................... 20
Figure 6. SU_C & SU_E Distinction (Cascade & End)........................................ 21
Figure 7. Rectifier Figure.................................................................................. 22
Figure 8. Rectifier Port Configuration .............................................................. 23
Figure 9. Required Space for DU Installation................................................... 35
Figure 10. DU Anchor Bolt Assembly for Wall Installation ............................... 35
Figure 11. DU Wall Installation Assembly ........................................................ 36
Figure 12. DU Pole Installation Assembly ........................................................ 37
Figure 13. DU Ground Cable Connection .......................................................... 38
Figure 14. DU Tilt ............................................................................................. 39
Figure 16. Required Space for SU Installation ................................................. 40
Figure 17. SU Anchor Bolt Assembly ................................................................ 40
Figure 18. SU Wall Installation Assembly ........................................................ 41
Figure 19. SU Pole Installation Assembly......................................................... 42
Figure 20. SU Ground Cable Connection .......................................................... 43
Figure 21. SU Tilt.............................................................................................. 44
Figure 22. Required Space for Rectifier Installation ........................................ 45
Figure 23. Rectifier Anchor Bolt Assembly ....................................................... 45
Figure 24. Rectifier Wall Installation Assembly ............................................... 46
Figure 25. Rectifier Pole Installation Assembly ............................................... 47
Figure 26. Rectifier Ground Cable Connection ................................................. 48
Figure 27. Optic Cable Connection ................................................................... 49
Figure 28. DU Optical Cable Connection........................................................... 50
Figure 29. SU_C Optical Cable Connection ....................................................... 51
Figure 30. SU_E Optical Cable Connection ....................................................... 52
Figure 31. DU/ SU Cable Connections from Rectifier ........................................ 53
Figure 32. DU & SU Input Port Pinout.............................................................. 54
Figure 33. Rectifier DC & AC Cable Connections .............................................. 55
Figure 34. Rectifier DC Output Port Pinout ...................................................... 56
Figure 35. Rectifier Battery Port Pinout ........................................................... 56
Figure 36. Rectifier AC Port Pinout .................................................................. 57
Figure 37. Standing Pole or Mounting Tripod Pole........................................... 58
Figure 38. Initial GUI Main Screen................................................................... 60
Figure 39. Initial GUI Main Screen................................................................... 64
Figure 40. SU Main Screen. .............................................................................. 68

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
7
PrimAer 39GHz Operating Manual
Used Abbreviations
DU Donor Unit
SU_C Service Unit_Cascade
SU_E Service Unit_End
GUI Graphical User Interface
SISO Single Input Single Output
MIMO Multiple Input Multiple Output
ALC Auto Level Control
AGC Auto Gain Control
EVM Error Vector Magnitude
3GPP 3rd Generation Partnership Project
DIFM Donor InterFace Module
DAOM Donor Analog Optic Module
EMS Element Management System
SIFM Service InterFace Module
SAOM Service Analog Optic Module
NC Not Connect

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
8
PrimAer 39GHz Operating Manual
Chapter 1
Safety & Certification Notice
1.1 FCC Warning Statements
1.2 Certification Notice

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
9
PrimAer 39GHz Operating Manual
Safety & Certification Notice
1.1 FCC Warning Statements
1.1.1 FCC Part 15.105 statement
-This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
1.1.2 FCC Part 15.21 statement
-Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment
1.1.3 Health and Safety Warnings
PrimAer 39 should only be operated by approved or certified integrator(or 'Integrator'). The integrator
who is tasked with handling, installation, operation, and servicing of PrimAer 39 System must follow
the instructions in the Manual prior to handling.
-To a vo i d any injury, the integrator must turn off the main power switch before installing the system or
performing any maintenance related work.
-PrimAer 39 is not a field service unit. The only access compartment is to insert a USIM for modem or
resetting the Ethernet port.
-Due to power dissipation, the remote unit may reach very high temperatures. Do not operate this
equipment on or close to any flammable or combustible materials. Always use caution when servicing
the unit.
-This product should only be used for the purpose specified by F RTe k . Do not alter or make any
modifications or fit any spare parts which are not sold or recommended by FRTe k. This could cause

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
10
PrimAer 39GHz Operating Manual
fires, electric shock, or other injuries.
-Read and follow all the warning labels attached to the unit. Make sure that all warning labels are
visible and are kept in a legible condition.
-The network provider needs to ensure that PrimAer 39 is operated within the FCC OET Bulletin 65
standards regarding RF Emissions to avoid health hazards associated with radiation from the antennas
in the unit. Suggested remedies are “RF hazard” type signs.
-Do not use any solvents, chemicals, or cleaning solutions containing alcohol, ammonia, abrasives, or
any corrosive type products on the unit.
-This device is part of an Industrial Signal Booster/Distributed Antenna System that supports FR2 5G
NR modes for the n260 band.. Professional installation required.
Warning
The antenna (or antennas) must be installed so as to maintain at all times a distance minimum of at
least 48 cm between the radiation source (antenna) and any individual. This device may not be
installed or used in conjunction with any other antenna or transmitter.
Warning
Follow all general and regional installation and safety regulations relating to performing work on high
voltage installations. Also, follow regulations and guidelines covering correct use of tools and
personal protective equipment.
Warning
Use of unauthorized antennas, cables, and/orcoupling devices not conforming with ERP/EIRP
and /or indoor‐only restrictions is strictly prohibited.
Home/ personal use are prohibited
Warning
Please be informed that the external temperatures of the unit can be extremely high.
Warning
Product contains “Laser Radiation”. Do not look directly into the laser or with any optical instruments.
Warning
Condensation : Silica gel is applied inside the initial packaging. Please apply silica gel when
packaging is required to avoid condensation. (During operation, internal condensation is prevented

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
11
PrimAer 39GHz Operating Manual
by turning the power ON)
•[FCC] BOOSTER WARNING LABEL
WARNING. This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES
and QUALIFIED INSTALLERS Only. You MUST have an FCC LICENSE or express consent of an
FCC Licensee to operate this device. Unauthorized use may result in significant forfeiture penalties,
including penalties in excess of $100,000 for each violation.
1.2 Certification Notice
For Pluggable Equipment, the socket‐outlet shall be installed near the equipment and shall
be easily accessible.
-FCC : This equipment complies with the applicable sections of Title 47 CFR Parts 15,30
-UL : This equipment complies with UL Standard for safety for information technology equipment,
including electrical business equipment.
-FDA/CDRH : This equipment uses a LASER according to FDA/CDRH Rules. This product conforms to
all applicable standards of 21 CFR Chapter 1, Subchapter J, Part 1040.
Designed to comply with IP66 standard, test data available upon request.
Note
ACCESS RESTRICTED LOCATION: Equipment location should comply with the following:
-access should only be granted to AUTHORIZED PERSONNEL or CERTIFIED USERS who have
been trained on the installation and operation of PrimAer 39
-FRTek recommends that the equipment be mounted at least 20ft above the ground

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
12
PrimAer 39GHz Operating Manual
Chapter 2
System Overview
2.1 System Overview
2.2 System Network Configuration

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
13
PrimAer 39GHz Operating Manual
System Overview
2.1 System Overview
2.1.1 Overview
PrimAer 39 is a 5G repeater system that can provide and/or enhance high quality telecommunications
service both in-building & outdoors. PrimAer 39 System can provide mmWave 39GHz frequency band
coverage to all venues.
PrimAer 39 system provides coverage for in-building and outdoor environments. A “proper RF design”
will provide a more accurate representation of the expected coverage.
This system can service mmWave 39GHz frequency band service and can be used for public and
private facilities.
39GHz Wireless Optic DAS system installation location:
-Shopping mall
-Hotel
-Campus
-Airport
-Subway
-Stadium and convention center
System frequency band :
- mmWave 39GHz SISO/MIMO (37.6GHz ~ 40.0GHz)
PrimAer 39 system is configured with a Donor Unit (DU), a Service Unit (SU_C: Cascading unit or SU_E:
End unit), and a Rectifier. 1 DU can operate up to 4 Service Units connected in a cascade configuration.
2.1.2 PrimAer 39 Design Consideration
PrimAer 39 model name and configure is as below.
Item
Model No.
FCC ID
Type
Donor Unit FR-R5G39AO38ADU 2AFEG-R5G39AO38ADU Outdoor Enclosure type
Service Unit FR-R5G39AO33ASUC 2AFEG-R5G39AO33ASUC

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
14
PrimAer 39GHz Operating Manual
(Cascade)
Service Unit (End) FR-R5G39AO33ASUE 2AFEG-R5G39AO33ASUE
Rectifier FR-ERECD48A
-
PrimAer DU receives the 39GHz 5G signal from the gNB over the air. The DU then amplifies the signal and
provides 5G service to the SU. The SU then extracts the TDD sync signal received from the gNB and
sends to each unit.
For outdoor usage, the DU, SU, and Rectifier are designed within IP66 specification so that dust,
pollutants, and insects cannot penetrate.
Item DU SU(Cascade) SU(End) Rectifier
Input Power
DC -53.3V 2.44A
(-48 ~ -53.3V)
(from Rectifier)
DC -53.3V 2.44A
(-48 ~ -53.3V)
(from Rectifier)
DC -53.3V 2.44A
(-48 ~ -53.3V)
(from Rectifier)
AC 100V ~ 6.8A,
240V ~ 2.85A
Interface(Input) RF Optic Optic -
Interface(Output) Optic RF RF Power
Service mmWave 39GHz 5G NR -
Typ e
In-building /
Outdoor
In-building /
Outdoor
In-building /
Outdoor
In-building /
Outdoor
2.2 System Network Configuration
PrimAer 39 network configuration shown below.

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
15
PrimAer 39GHz Operating Manual
Figure 1. Network Configuration
PrimAer 39 receives a 39GHz mmWave signal over the air from a 5G gNB to the DU. The DU then
converts the mmWave signal to IF over fiber and amplifies the signal. The SU then converts the IF to 5G
mmWave signal for service.
PrimAer 39 is comprised of 3 units, the DU, SU, and Rectifier. The Rectifier supplies DC power to the
DU and SU through a power cable. Also, the DU and SU's are connected with a single fiber-optic cable,
and multiple SU’s can also be connected in series with a single fiber-optic cable.
The DU can support antenna beam steering ±50˚ (Up/down/left/right) through the GUI.
The DU and SU have internal Cross Polarized Antennas that support MIMO.
Chapter 3
System Configuration
3.1 DU Function and Configuration
3.2 SU Function and Configuration
3.3 Rectifier Function and Configuration

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
16
PrimAer 39GHz Operating Manual

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
17
PrimAer 39GHz Operating Manual
System Configuration
3.1 DU Function and Configuration
The DU is in a single enclosure with a mounting bracket on the back enabling wall or pole attachment.
The DU receives a MIMO 5G gNB signal over the air, converts it to an optical signal, and sends it to the
SU via Fiber-Optic cable. (Downlink). It also converts the optical signal received from the SU via fiber-
optic cable and converts this back to 39GHz 5G RF which is sent to the gNB through the internal antenna.
(Uplink).
The DU is comprised of an antenna, DIFM, DAOM, and EMS board. The rectifier powers the DU
through the power port with -53.3V DC p o w e r.
Figure 2. DU Figure
Item Content Remark
Size 200 x 320 x 190.8mm (7.87 x 12.59 x 7.51") Including bracket

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
18
PrimAer 39GHz Operating Manual
Weight Approx. 5.66kg (12.4lb) Including bracket
Input Interface Internal Antenna 19.37 dBi (Max.)
Output Interface Optic 1 Port
Figure 3. DU Port Configuration
No Content
①Port that transmit/receives optic signal
②Port to monitor T-SYNC
③Port to monitor Downlink SISO Path RF signal
④Antenna port to transmit external signal from the Modem
⑤Port to monitor Downlink MIMO Path RF signal
⑥Port to monitor internal 122.88MHz Reference signal
⑦Port to connect WEB GUI
⑧Port to supply -53.3V(-48V ~ -53.3V) power from the Rectifier
⑨Port to connect Local GUI (Not used after installation)
⑩Internal Antenna (centered on +), transmit/receive RF wireless signal & status lights

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
19
PrimAer 39GHz Operating Manual
3.2 SU Function and Configuration
The SU is in a single enclosure with a mounting bracket on the back enabling wall or pole attachment.
The SU receives an optical signal from the DU via Fiber-Optic cable, converts it to a 39GHz RF signal, and
sends the 5G signal through the antenna. (Downlink). It also converts the 39GHz RF signal received from
the UE into an optical signal and sends it to the DU through Fiber-Optic cable. (Uplink)
When cascading there is the SU_C that connects between the DU and SU_E, the figure and
configuration is the same. Cascade can be up to 4 SUs, but the SU_E can only be at the end of the chain.
The SU is comprised of an antenna, SIFM, and SAOM module. The rectifier powers the SU through the
power port with -53.3V DC power
Figure 4. SU Figure

PRIVATE AND CONFIDENTIAL : FRTEK CO., LTD.
20
PrimAer 39GHz Operating Manual
Item Content Remark
Size 200 x 320 x 190.8mm (7.87 x 12.59 x 7.51") Bracket included
Weight Approx. 5.68kg (12.5lb) Bracket included
Input Interface Internal Antenna 19.37 dBi
Output Interface Optic 1-2 Ports
Figure 5. SU Port Configuration
Item Content
①Port to transmit/receive optic signal
②Port to monitor T-SYNC
③Port to monitor Downlink SISO Path RF signal
④Port to monitor Downlink MIMO Path RF signal
⑤Port to monitor internal 122.88MHz Reference signal
⑥Port to supply -53.3V(-48V ~ -53.3V) power from the Rectifier
⑦Port to connect Local GUI (Not used after installation)
⑧Internal Antenna (centered on +), transmit/receive RF wireless signal & status lights
