F21C & F21S Quick Assembly Guide
For installation questions or if you need replacement components please call
888.883.8346, email [email protected] or visit support.fuegoliving.com.
1) With a box knife, cut along the
dotted line marked all around carton
and remove carton top.
2) Separate cartons by removing wheel
base, pulling away end carton and
unpacking remaining cartons.
3) Set base on wheels and fasten rear
panel to the grill base with x4 M5 (A)
screws.
4) Fasten tank hook to marked label
with x2 M6 (B) screws.
8) Install control knob onto gas valve
stem as shown.
5) Place fire bowl assembly flat; fasten
wheel base assembly w/ rear panel onto
control assembly with x4 M5 (A) screws.
6) Insert support spine into control
assembly slot and fasten with x2 M6 (B)
screws.
7) Fasten support spine to wheel base
with x2 M6 (B) screws.
(A) M5 x8 (B) M6 x6 x1
x1 x1
*The carton pieces are designed to interlock in order to prevent freight damage. Cutting and removing the cover carton
allows easy access to the nested box components.

www.fuegoliving.com
9) Flip grill on wheels, install door panel
by first inserting bottom hinge into
place.
10) Depress top hinge with finger, and
release once aligned into locking
position.
11) Slide residue tray into place.
12) Place diffuser panel into fire-bowl
and then place grate on top of fire-
bowl.
13) Insert temperature gauge into grill
lid. Align locking tab with notch on lid
and fasten tightly.
16) Place propane tank in storage
compartment and secure in place on
hook.
17) Install regulator by fastening
clockwise. Be sure to perform the leak
test outlined in the Use & Care Manual.
15) Place grill lid onto cooking grate.
14) Insert AA battery into pack with (+)
end facing the battery cap.
This quick assembly guide is a quick overview of the Fuego Element grill installation process. Please refer to
the Use & Care manual contained in the packing carton for details on use, safety, detailed setup, parts and
warranty information. Please call 888.883.8346, email [email protected] or visit support.fuegoliving.com
with any questions.
