FujiFilm FF210003 User manual

This manual covers the network and USB settings available when the cam-
era is used alone or with an optional FT-XH le transmitter attached. Be
sure that you have read this manual and understood its contents before
using the camera. Keep the manual handy for future reference once you
have nished.
The latest versions of the product manuals are available at the website be-
low.
https://fujifilm-dsc.com/en/manual/
EN
BL00005214-200
FF210003
Manual (Network and USB Settings)

ii
MEMO

iii
Menu List iv
P Chapter Index
1 Getting to Know and Using Network/USB Settings 1
2 Network/USB Setting Menus 65
3 Appendix 81

iv
Menu List
Menu List
Camera menu options are listed below.
The Network/USB Settings Menu
This menu contains network and USB settings available when
the camera is used alone or with an optional FT-XH le transmit-
ter attached.
INETWORK/USB SETTING P
1⁄
1⁄
CREATE/EDIT CONNECTION SETTING 66
SELECT CONNECTION SETTING 71
AIRPLANE MODE 72
Bluetooth/SMARTPHONE SETTING 73
instax PRINTER CONNECTION SETTING 76
FTP OPTIONAL SETTING 76
USB POWER SUPPLY/COMM SETTING 78
INFORMATION 79
2⁄
2⁄ RESET NETWORK/USB SETTING 79

v
P Table of Contents
Chapter Index......................................................................................................iii
Menu List...............................................................................................................iv
The Network/USB Settings Menu.........................................................................iv
About This Manual........................................................................................... vii
Symbols and Conventions.......................................................................................vii
Terminology ......................................................................................................................vii
Network Settings...........................................................................................................viii
The FT-XH File Transmitter (Available Separately).....................................viii
1
Getting to Know and Using Network/USB Settings 1
Getting to Know and Using Network/USB Settings 1
Overview................................................................................................................2
Supported Features........................................................................................................2
Connection Setting Proles.......................................................................................5
Connecting to Smartphones (Bluetooth)...................................................6
Installing Smartphone Apps.....................................................................................6
Connecting to a Smartphone..................................................................................6
Using the Smartphone App......................................................................................8
Connecting to Smartphones (USB) ...........................................................11
Copying Pictures to a Smartphone ................................................................... 11
Connecting the Camera and Computer ........................................................ 14
Using the Camera as a Webcam ................................................................. 16
instax SHARE Printers .....................................................................................17
Establishing a Connection.......................................................................................17
Printing Pictures............................................................................................................. 18
Tethered Photography................................................................................... 19
Tethered Photography via USB.............................................................................19
Tethered Photography via Wireless LAN ........................................................ 21
Tethered Photography via Wired LAN (Ethernet)...................................... 26

vi
Uploading Pictures via FTP........................................................................... 29
Connecting to FTP Servers...................................................................................... 29
Adjusting Settings for Connection to FTP Servers................................... 39
Uploading Pictures to FTP Servers ..................................................................... 42
RAW Processing ................................................................................................45
Saving and Loading Settings....................................................................... 46
Remote Movie Recording Using a Web Browser ..................................47
Connecting to the Camera from a Web Browser......................................47
Connecting to the Camera from a Computer or Tablet ....................... 57
The Remote Recording Display............................................................................58
Recording Movies Remotely..................................................................................62
Viewing Movies .............................................................................................................. 62
Saving and Loading Camera Settings..............................................................63
2
Network/USB Setting Menus 65
Network/USB Setting Menus 65
Network/USB Setting Menus.......................................................................66
CREATE/EDIT CONNECTION SETTING............................................................... 66
SELECT CONNECTION SETTING ........................................................................... 71
AIRPLANE MODE ........................................................................................................... 72
Bluetooth/SMARTPHONE SETTING.................................................................... 73
instax PRINTER CONNECTION SETTING...........................................................76
FTP OPTIONAL SETTING............................................................................................ 76
USB POWER SUPPLY/COMM SETTING ............................................................. 78
INFORMATION................................................................................................................. 79
RESET NETWORK/USB SETTING ........................................................................... 79
3
Appendix 81
Appendix 81
Troubleshooting............................................................................................... 82
Errors.....................................................................................................................85

vii
About This Manual
This manual contains instructions for your FUJIFILM X-H2
digital camera’s network and USB features. Be sure you have
read and understood its contents before proceeding.
Symbols and Conventions
The following symbols are used in this manual:
O
Information that should be read to prevent damage to the
product.
N
Additional information that may be helpful when using the
product.
PPages on which related information may be found.
Menus and other text in the displays are shown in bold. Illustrations
are for explanatory purposes only; drawings may be simplied,
while photographs are not necessarily taken with the model of
camera described in this manual.
Terminology
The optional SD, SDHC, SDXC, and Type B CFexpress memory
cards the camera uses to store pictures are referred to as “mem-
ory cards”. The electronic viewnder may be referred to as the
“EVF”and the LCD monitor as the“LCD”. Smartphones and tablets
are referred to as“smartphones”.

viii
Network Settings
• Please note that FUJIFILM is unable assist in troubleshooting
network connections. For information on network settings,
consult the network administrator.
• The customer is responsible for securing wireless connections.
FUJIFILM accepts no liability for damages resulting from faulty
settings or unauthorized third-party access to wireless net-
works.
The FT-XH File Transmitter (Available Separately)
• When an optional FT-XH le transmitter is attached, you can:
- take photographs remotely via wired or wireless LAN (teth-
ered photography),*
- upload pictures to an FTP server via wired or wireless LAN us-
ing the USB tethering feature on a smartphone or tablet, and
- lm movies remotely while using a web browser to control
the camera (or multiple cameras, each with its own wireless
transmitter attached) from a computer, smartphone, or tab-
let.
* The FT-XH le transmitter supports 2×2 MIMO wireless LAN for
transmission speeds faster than are available with the camera
alone.
• Menu items marked with an ficon are available when a le
transmitter is attached.
• A list of the cameras that support le transmitters is available
from the website below. Consult the camera manual for infor-
mation on such topics as attaching le transmitters.
https://fujifilm-dsc.com/en/manual/

1
Getting to Know and Using
Network/USB Settings

2
1
Getting to Know and Using Network/USB Settings
Overview
This chapter outlines features that can among other things
be used to upload pictures to, or control the camera and
take pictures remotely from, a smartphone or computer.
Supported Features
Some camera features can be accessed when the camera is used
alone, while others require you to attach an optional FT-XH le
transmitter.
Features Available When the Camera Is Used Alone
Feature
Feature
Description
Description
P
P
Connecting to the
Connecting to the
smartphone app
smartphone app
Connect to smartphones via Bluetooth® and upload
pictures or control the camera remotely while the
smartphone displays the view through the lens.
6
USB card readers
USB card readers Connect a card reader to a computer or smartphone
via USB and copy pictures from memory cards. 11
Web camera
Web camera Connect the camera to a computer via USB for use
as a webcam. 16
instax printers
instax printers Print pictures on connected instax printers. 17
Tethered photography
Tethered photography Take pictures from a computer to which the camera
is connected (“tethered”) via wireless LAN or USB. 19
RAW processing
RAW processing
Harness the power of the camera’s image
processing engine when processing RAW pictures
on a computer.
45
Saving and Loading
Saving and Loading
Settings
Settings
Save camera settings to, or load existing from, a
computer. 46
These features can be accessed via SELECT CONNECTION
SETTING.

3
1
Getting to Know and Using Network/USB Settings
Overview
Features Available When an Optional FT-XH File Transmitter Is Attached
Feature
Feature
Description
Description
P
P
Tethered photography
Tethered photography
Take pictures from a computer to which the camera
is connected (“tethered”) via high-speed wireless
LAN or USB.
19
FTP upload
FTP upload Upload pictures to an FTP server. 29
Remote movie
Remote movie
recording
recording
Control the camera and take pictures remotely using
a web browser on a computer or tablet. 47
These features can be accessed by selecting a connection setting
prole to which the desired settings and connection type have
been saved using CREATE/EDIT CONNECTION SETTING.
O• Access to the network/USB features in only available when a battery
is inserted in the camera and at least one battery is inserted in the
transmitter.
• If the le transmitter battery runs low while the transmitter is in use,
upload and remote (“tethered”) photography will continue—albeit
at reduced speeds—powered by the camera battery. Charge the le
transmitter battery or insert a fully-charged battery.

4
1
Getting to Know and Using Network/USB Settings
The File Transmitter Indicator Lamp
The le transmitter indicator lamp shows
the status of its connection to comput-
ers, FTP servers, and the like.
NOnly the left lamp lights or ashes.
Indicator lamp
Indicator lamp
Connection status
Connection status
Blinks red No network connection.
Glows red No network connection; pictures awaiting upload.
Blinks orange Connected to network but not to computer teth-
ered photography software or FTP server.
Blinks orange and red
Connected to network but not to computer teth-
ered photography software or FTP server; pictures
awaiting upload.
Blinks green Ready for tethered photography or FTP upload.
Blinks green and red Ready for tethered photography or FTP upload;
pictures awaiting upload.
The EVF/LCD Displays
The status of the connection to computers, FTP
servers, and the like is also shown by an icon in
the electronic viewnder or LCD monitor.
Icon
Icon
Connection status
Connection status
No network connection.
Connected to network but not to computer teth-
ered photography software or FTP server.
Ready for tethered photography or FTP upload.

5
1
Getting to Know and Using Network/USB Settings
Overview
Connection Setting Proles
Connection setting proles contain information on both network
settings and the type of connection used. You can connect to
computers and smartphones by selecting the associated prole.
Selecting a Connection Setting Profile
To select a connection setting pro-
le, press MENU/OK and choose SELECT
CONNECTION SETTING in the I(net-
work/USB setting) tab.
NO
T
C
REATE
D
NO
T
C
REATE
D
USB WEBCAM
USB RAW CONV./BACKUP RESTORE
USB TETHER SHOOTING FIXED
USB TETHER SHOOTING AUTO
USB CARD READER
UNIVERSAL SETTING
SELECT CONNECTION SETTING
NFor tethered photography via wireless LAN, you will rst need to create
and save a new connection setting prole by following the instruc-
tions of a wizard displayed by selecting CREATE/EDIT CONNECTION
SETTING.
Saving Connection Setting Profiles
To create a connection setting prole containing information on
network/USB settings and the type of connection used, select
CREATE/EDIT CONNECTION SETTING in the network/USB set-
ting menu.
Choose CREATE/EDIT CONNECTION
SETTING> CREATE USING WIZARD, se-
lect the desired network/USB settings,
and save the resulting prole (P66). TETHER SHOOTING
PRINTER PRINT
WEBCAM
USB CARD READER
SMARTPHONE APP
CONNECT TO SMARTPHONE APP
CREATE USING WIZARD

6
1
Getting to Know and Using Network/USB Settings
Connecting to Smartphones (Bluetooth)
Connect the camera with a smartphone via Bluetooth® to
copy pictures to the smartphone or control the camera re-
motely while previewing the view through the lens in the
smartphone display.
NThe camera automatically switches to a wireless LAN connection when
copying pictures to the smartphone.
Installing Smartphone Apps
Before establishing a connection between the smartphone and
camera, you will need to install at least one dedicated smart-
phone app. Visit the following website and install the desired
apps on your phone.
https://app.fujifilm-dsc.com/
NThe apps available vary with the smartphone operating system.
Connecting to a Smartphone
Pair the camera with the smartphone and connect via Bluetooth®.
1 Press the x(Bluetooth) button when
the camera is in shooting mode.
NYou can also proceed directly to Step 3 by holding the xbutton
during playback.

7
1
Getting to Know and Using Network/USB Settings
Connecting to Smartphones (Bluetooth)
2
Highlight Bluetooth and press MENU/OK.
X-H2123456
Bluetooth & FUNCTION (Fn) SETTING
Bluetooth
3 Highlight PAIRING and press MENU/OK.
Bluetooth ON/OFF
PAIRING
Bluetooth
4 Launch the app on the smartphone and pair the smartphone
with the camera.
More information is available at the following website:
https://app.fujifilm-dsc.com/
When pairing is complete, the cam-
era and smartphone will automati-
cally connect via Bluetooth. A white
Bluetooth icon will appear in the
camera display when a connection is
established.
N• Once the devices have been paired, the smartphone will automati-
cally connect to the camera when the app is launched.
• Disabling Bluetooth when the camera is not connected to a smart-
phone reduces the drain on the battery.

8
1
Getting to Know and Using Network/USB Settings
Using the Smartphone App
Before launching the smartphone app, choose 1: UNIVERSAL
SETTING for SELECT CONNECTION SETTING.
NBefore proceeding, select ON for Bluetooth/SMARTPHONE
SETTING> Bluetooth ON/OFF.
Selecting and Downloading Pictures Using the Smartphone App
You can download selected pictures to a smartphone using the
smartphone app.
NMore information is available from the following website:
https://app.fujifilm-dsc.com/
Uploading Pictures as They Are Taken
Pictures taken with ON selected for Bluetooth/SMARTPHONE
SETTING> AUTO IMAGE TRANSFER ORDER in the network/USB
setting menu will automatically be uploaded to the paired de-
vice.
N• If ON is selected for both IMAGE TRANSFER WHILE POWER OFF
and Bluetooth/SMARTPHONE SETTING> Bluetooth ON/OFF in
the network/USB settings menu, upload to the paired device will
continue even while the camera is o.
• Selecting ON for Bluetooth/SMARTPHONE SETTING> RESIZE
IMAGE FOR SMARTPHONE in the network/USB setting menu en-
ables compression, reducing le size for upload (P75).
• Pictures are uploaded in the format chosen for Bluetooth/
SMARTPHONE SETTING> SELECT FILE TYPE in the network/USB
setting menu.

9
1
Getting to Know and Using Network/USB Settings
Connecting to Smartphones (Bluetooth)
Selecting Pictures for Upload in the Playback Menu
Use TRANSFER IMAGE TO SMARTPHONE> SELECT IMAGE &
TRANSFER to select pictures for upload to a paired smartphone
or tablet via Bluetooth®.
1 Select TRANSFER IMAGE TO SMARTPHONE> SELECT IMAGE
& TRANSFER.
NSelect RESET to remove “upload to smartphone”marking from all
pictures before proceeding.
2 Mark pictures for upload.
Highlight pictures and press MENU/OK
to mark them for upload.
• To switch to the memory card in the
other slot or display only pictures
that meet selected criteria, press
DISP/BACK before marking begins.
•
To select all pictures, press the Qbut-
ton.
• Selecting any two pictures with the
AEL button also selects all pictures
between them.
SELECT IMAGE
FRAME
FINISH/SETTINGSELECT
SELECT RANGESELECT ALL
3 Press DISP/BACK and select START
TRANSFER.
The selected pictures will be upload-
ed.
SWITCH MEMORY CARD SLOT
FILTERING
START TRANSFER
FINISH IMAGE SELECT AND
START TRANSFER
SELECT IMAGE & TRANSFER
BACK

10
1
Getting to Know and Using Network/USB Settings
Connecting to Smartphones (Bluetooth)
Filtering Pictures/Choosing a Slot
To switch to the memory card in the other slot or display only pictures that
meet selected criteria, press DISP/BACK in the picture-selection dialog.
• To display only pictures that meet selected cri-
teria, choose FILTERING.
• To switch to the memory card in the other slot,
choose SWITCH MEMORY CARD SLOT.
BACK
FILTERING THE IMAGE
WITH CONDITIONS
SWITCH MEMORY CARD SLOT
FILTERING
START TRANSFER
SELECT IMAGE & TRANSFER
OSwitching slots or changing the lter criteria removes any existing up-
load marking.
N• Image transfer orders can contain a maximum of 999 pictures.
• The following cannot be selected for upload:
- Protected pictures
- Movies
- RAW images
- “Gift” pictures (pictures taken with other cameras)
• If ON is selected for both IMAGE TRANSFER WHILE POWER OFF
and Bluetooth/SMARTPHONE SETTING> Bluetooth ON/OFF in
the network/USB settings menu, upload to the paired device will
continue even while the camera is o.
• When aSMARTPHONE TRANSFER ORDER is selected for
DBUTTON/DIAL SETTING> aISO BUTTON SETTING, the pic-
ture-selection dialog can be displayed by pressing the ISO button.

11
1
Getting to Know and Using Network/USB Settings
Connecting to Smartphones (USB)
Connect to smartphones and computers via USB to upload
pictures from the camera.
Copying Pictures to a Smartphone
Before connecting to the smartphone to upload pictures via USB,
select either AUTO or POWER SUPPLY OFF/COMM ON for USB
POWER SUPPLY/COMM SETTING in the network/USB setting
menu.
For Customers Using Android Devices
How you will connect the camera depends on the type of USB
connector with which your smartphone is equipped.
Type-C
Type-C
Use the supplied USB cable.
Supplied USB cable
Type-C connector (male) Type-C connector (male)

12
1
Getting to Know and Using Network/USB Settings
Micro-B
Micro-B
Use a USB on-the-go (OTG) cable.
Third-party USB cable USB OTG cable
Type-C connector (male) Micro-B connector (male)
Type-A connector
(male)
Type-A connector
(female)
O• The smartphone must support USB OTG.
• The desired results cannot be achieved with a USB Type-C–to–
Mirco-B cable. Use an OTG cable.
1 Select either AUTO or POWER SUPPLY OFF/COMM ON for
USB POWER SUPPLY/COMM SETTING in the network/USB
setting menu.
2 Choose 2: USB CARD READER for SELECT CONNECTION
SETTING.
3 Connect the camera and smartphone using a USB cable.
NIf the smartphone asks for permission for an app other than the
“Camera Importer” to access the camera, tap “Cancel” and move
on to the next step.
4 On your smartphone, tap the notication “Connected to USB
PTP”.
