FujiFilm X-H2 Owner's manual

Manual (Network and USB Settings)
New Features Guide
Version 2.00
Features added or changed as a result of rmware updates may no
longer match the descriptions in the original documentation for this
product. Visit our website for information on the updates available
for dierent products:
https://fujifilm-x.com/support/download/firmware/cameras/
BL00005295-200 EN

Contents
X-H2 rmware version 2.00 adds or updates the features
listed below. For the latest manuals, visit the following
website.
https://fujifilm-dsc.com/en/manual/
No. Description X-H2
P
See
PVer.
1
1
Photos and movies can now be uploaded to Frame.io.
A Frame.io Camera to Cloud item has been added to the
network/USB settings menu for this purpose.
viii
3
4
29
76
79
88
1
2
3
5
16
19
20
2.00
2
2
A Bluetooth DEVICE LIST item has been added to
Bluetooth/SMARTPHONE SETTING in the network/USB
setting menu.
73 21 1.20

1
Changes and Additions
Changes and additions are as follows.
X-H2 Manual (Network and USB Settings): Pviii
The FT-XH File Transmitter (Available Separately) Ver. 2.00
• When an optional FT-XH le transmitter is attached, you can:
- take photographs remotely via wired or wireless LAN (teth-
ered photography),*
- upload les to Frame.io via wired or wireless LAN or using
the USB tethering feature on a smartphone or tablet,
- upload pictures to an FTP server via wired or wireless LAN us-
ing the USB tethering feature on a smartphone or tablet, and
- lm movies remotely while using a web browser to control
the camera (or multiple cameras, each with its own wireless
transmitter attached) from a computer, smartphone, or tab-
let.
* The FT-XH le transmitter supports 2×2 MIMO wireless LAN for
transmission speeds faster than are available with the camera
alone.
• Menu items marked with an ficon are available when a le
transmitter is attached.
• A list of the cameras that support le transmitters is available
from the website below. Consult the camera manual for infor-
mation on such topics as attaching le transmitters.
https://fujifilm-dsc.com/en/manual/

2
X-H2 Manual (Network and USB Settings): P3
Supported Features Ver. 2.00
Features Available When an Optional FT-XH File Transmitter Is Attached
Feature
Feature
Description
Description
Tethered photography
Tethered photography
Take pictures from a computer to which the camera is
connected (“tethered”) via high-speed wireless LAN or
USB.
Upload to Frame.io
Upload to Frame.io Upload files to Frame.io.
FTP upload
FTP upload Upload files to an FTP server.
Remote movie
Remote movie
recording
recording
Control the camera and take pictures remotely using a
web browser on a computer or tablet.
With the exception of upload to Frame.io, these features can
be accessed by selecting a connection setting prole to which
the desired settings and connection type have been saved us-
ing CREATE/EDIT CONNECTION SETTING. Settings for upload to
Frame.io can be accessed via the network/USB settings menu.
O• Access to the network/USB features in only available when a battery
is inserted in the camera and at least one battery is inserted in the
transmitter.
• If the le transmitter battery runs low while the transmitter is in use,
upload and remote (“tethered”) photography will continue—albeit
at reduced speeds—powered by the camera battery. Charge the le
transmitter battery or insert a fully-charged battery.

3
X-H2 Manual (Network and USB Settings): P4
The File Transmitter Indicator Lamp Ver. 2.00
The le transmitter indicator lamp shows
the status of its connection to comput-
ers, Frame.io, FTP servers, and the like.
NOnly the left lamp lights or ashes.
Indicator lamp
Indicator lamp
Connection status
Connection status
Blinks red No network connection.
Glows red No network connection; pictures awaiting upload.
Blinks orange Connected to network but not to computer teth-
ered photography software, Frame.io, or FTP server.
Blinks orange and red
Connected to network but not to computer teth-
ered photography software, Frame.io, or FTP server;
pictures awaiting upload.
Blinks green
Ready for tethered photography, upload to Frame.io,
or FTP upload.
Blinks green and red Ready for tethered photography, upload to
Frame.io, or FTP upload; pictures awaiting upload.

4
The EVF/LCD Displays
The status of the connection to computers,
Frame.io, FTP servers, and the like is also shown
by an icon in the electronic viewnder or LCD
monitor.
Icon
Icon
Connection status
Connection status
No network connection.
Connected to network but not to computer teth-
ered photography software, Frame.io, or FTP server.
Ready for tethered photography, FTP upload, or
upload to Frame.io.

5
X-H2 Manual (Network and USB Settings): P29
Uploading Files to Frame.io Ver. 2.00
Upload les to Frame.io.
• Connecting via Wireless LAN (P5)
• Connecting via Wired LAN (Ethernet) (P7)
• Connecting via USB Tethering (P9)
NConrm that the camera clock is set to the correct time and date be-
fore proceeding.
Connecting via Wireless LAN
Connect to Frame.io via wireless LAN.
1
Select Frame.io Camera to Cloud>
CONNECT.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
UPLOAD STATUS
UPLOAD SETTING
SELECT FILE TYPE
DISCONNECT
CONNECT
Frame.io Camera to Cloud
2 Select WIRELESS LAN.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
GET PAIRING CODE
USB SMARTPHONE TETHERING
WIRED LAN
WIRELESS LAN
CONNECT
3 Select ACCESS POINT SETTING.
Select IP ADDRESS SETTING to
choose the IP address manually as
described in “Connecting Using an IP
Address” (P11).
FINISH
IP ADDRESS SETTING
ACCESS POINT SETTING
WIRELESS LAN

6
4 Select SIMPLE SETUP.
NTo select a wireless LAN router or en-
ter the router SSID manually, choose
MANUAL SETUP.
SET UP CONNECTION TO
DESTINATION PC
(SIMPLE BUTTON OPERATION)
SIMPLE SETUP
MANUAL SETUP
ACCESS POINT SETTING
5 Follow the on-screen instructions to
ready the wireless LAN router.
NYou also have the option of connect-
ing using a PIN. Display the camera
PIN by pressing the focus stick (focus
lever) up and enter it on the wireless
LAN router.
SIMPLE SETUP
PUSH WPS BUTTON ON
Wi-Fi ROUTER UNTIL LAMP ON
Wi-Fi ROUTER STARTS FLASHING
CANCEL
CONNECT BY PIN CODE
6 Press MENU/OK when setup is com-
plete.
SIMPLE SETUP
REGISTRATION COMPLETED
END
7 Once connected, select GET PAIRING
CODE.
A pairing code will be displayed.
AAAAAA003
WIRELESS LAN
SUCCESS
GO TO Frame.io AND
ENTER PAIRING CODE TO CONNECT
GET PAIRING CODE
CHANGE NETWORK
FINISH
8 Sign in to Frame.io from a computer or other device and en-
ter the pairing code displayed on the camera.
9 Upload les to Frame.io (
P13 ).

7
Connecting via Wired LAN (Ethernet)
Connect to Frame.io via wired LAN (Ethernet).
1 Connect to the wired LAN by plugging an Ethernet cable into
the le transmitter’s LAN connector.
2
Select Frame.io Camera to Cloud>
CONNECT.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
UPLOAD STATUS
UPLOAD SETTING
SELECT FILE TYPE
DISCONNECT
CONNECT
Frame.io Camera to Cloud
3 Select WIRED LAN.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
GET PAIRING CODE
USB SMARTPHONE TETHERING
WIRED LAN
WIRELESS LAN
CONNECT
4 Adjust IP ADDRESS SETTING.
•
Select AUTO to use an IP address as-
signed by the network.
•
Select MANUAL to choose the IP
address manually as described in
“Connecting Using an IP Address”
(P11).
IP ADDRESS SETTING
IP ADDRESS SETTING
FINISH
5 Once connected, select GET PAIRING
CODE.
A pairing code will be displayed.
AAAAAA003
WIRED LAN
SUCCESS
GO TO Frame.io AND
ENTER PAIRING CODE TO CONNECT
GET PAIRING CODE
CHANGE NETWORK
FINISH

8
6 Sign in to Frame.io from a computer or other device and en-
ter the pairing code displayed on the camera.
7 Upload les to Frame.io (
P13 ).

9
Connecting via USB Tethering
Connect to Frame.io via a network connection on your smart-
phone.
1 Using a USB cable, connect the smartphone to the le trans-
mitter’s USB connector.
O• The camera’s USB connector cannot be used for this purpose.
• Choose a cable with a USB Type C connector at one end and at
the other a connector chosen to match your smartphone (typi-
cally USB Type C, USB Micro B, or Lightning).
• Apple Lightning to USB Camera Adapters and USB on-the-go
(OTG) cables cannot be used.
• Before connecting the camera, check that the smartphone bat-
tery is fully charged, as otherwise the smartphone will attempt
to charge itself from the battery in the camera or le transmitter.
2
Select Frame.io Camera to Cloud>
CONNECT.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
UPLOAD STATUS
UPLOAD SETTING
SELECT FILE TYPE
DISCONNECT
CONNECT
Frame.io Camera to Cloud

10
3
Select USB SMARTPHONE TETHER-
ING.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
GET PAIRING CODE
USB SMARTPHONE TETHERING
WIRED LAN
WIRELESS LAN
CONNECT
4 Once connected, select GET PAIRING
CODE.
A pairing code will be displayed.
AAAAAA003
USB SMARTPHONE TETHERING
SUCCESS
GO TO Frame.io AND
ENTER PAIRING CODE TO CONNECT
GET PAIRING CODE
CHANGE NETWORK
FINISH
5 Sign in to Frame.io from a computer or other device and en-
ter the pairing code displayed on the camera.
6 Upload les to Frame.io (
P13 ).

11
Connecting Using an IP Address
Connect to Frame.io using a manually-created network/USB set-
ting prole giving the IP address and other network settings.
1 Select MANUAL.
NSelect AUTO to assign the camera an
IP address automatically.
000.000.000.000
NEXT
IP ADDRESS SETTING
ACCESS POINT SETTING
WIRELESS LAN
N
EXT
IP ADDRE
S
ACC
E
SS
P
WIRELESS LAN
SS
PO
LA
AUTO
MANUAL
2 Enter an IP address.
DNS SERVER ADDRESS
GATEWAY ADDRESS
SUBNET MASK
IP ADDRESS
IP ADDRESS SETTING
• Select IP ADDRESS and enter an IP
address.
IP ADDRESS
SET
ENTER CANCEL
• Select SUBNET MASK and enter a
subnet mask.
ENTER CANCEL
SET
SUBNET MASK

12
• Select GATEWAY ADDRESS and en-
ter a gateway address. SET
GATEWAY ADDRESS
ENTER CANCEL
• Select DNS SERVER ADDRESS and
enter a DNS server address.
DNS SERVER ADDRESS
SET
ENTER CANCEL
Connection Status
The status of the connection to Frame.io is
shown by an icon in the electronic viewnder
or LCD monitor.
Icon
Icon
Connection status
Connection status
(white) Connected to Frame.io.
(amber)
Camera has temporarily suspended upload to
Frame.io. To resume, select Frame.io Camera
to Cloud> UPLOAD SETTING> TRANSFER/
SUSPEND> TRANSFER.
(gray) Not connected to Frame.io.
(red)
Frame.io server has set camera status to “paused”.
To restore connection, clear “paused”status using
computer or other device.

13
Uploading Items to Frame.io
Uploading Selected Items Using “Frame.io Camera to Cloud”
1 Select Frame.io Camera to Cloud in network/USB settings
menu.
2 Select UPLOAD SETTING> SELECT
IMAGE & TRANSFER.
NETWORK
Frame.io
PROJECT
USER
AAAAAAAA
AAAAAAAA
WIRELESS LAN
CONNECTED
ROOT CERTIFICATE
IMAGE TRANSFER WHILE POWER OFF
TRANSFER/SUSPEND
AUTO IMAGE TRANSFER ORDER
SELECT IMAGE & TRANSFER
UPLOAD SETTING
N• The NETWORK eld shows how the camera is connected to the net-
work and the Frame.io eld, the status of the connection to Frame.io.
• The PROJECT and USER elds show information supplied to Frame.
io using a computer or other device. Note that some characters may
not display correctly, in which case they will be replaced by question
marks (“?”).
3 Mark items for upload.
Highlight photos and movies and
press MENU/OK to mark them for up-
load.
• To switch to the memory card in the
other slot or display only items that
meet selected criteria, press DISP/
BACK before marking begins.
SELECT IMAGE
FRAME
FINISH/SETTINGSELECT
SELECT RANGESELECT ALL
•
To select all items, press the Qbutton.
• Selecting any two items with the AEL button also selects all
items between them.

14
4 Press DISP/BACK and select START
TRANSFER.
The selected items will be uploaded
to Frame.io.
SWITCH MEMORY CARD SLOT
FILTERING
START TRANSFER
FINISH IMAGE SELECT AND
START TRANSFER
SELECT IMAGE & TRANSFER
BACK
Filtering Items/Choosing a Slot
To switch to the memory card in the other slot or display only items that
meet selected criteria, press DISP/BACK in the selection dialog.
• To display only items that meet selected crite-
ria, choose FILTERING.
• To switch to the memory card in the other slot,
choose SWITCH MEMORY CARD SLOT. SWITCH MEMORY CARD SLOT
FILTERING
START TRANSFER
SELECT IMAGE & TRANSFER
FILTERING THE IMAGE
WITH CONDITIONS
BACK
OSwitching slots or changing the lter criteria removes any existing up-
load marking.
N• Image transfer orders can contain a maximum of 9999 items.
• If ON is selected for Frame.io Camera to Cloud> IMAGE TRANSFER
WHILE POWER OFF, upload will continue even while the camera is
o.

15
Uploading Photos and Movies as They Are Taken
Photos and movies shot with ON selected for Frame.io Camera
to Cloud> UPLOAD SETTING> AUTO IMAGE TRANSFER ORDER
in the network/USB setting menu are automatically marked for
upload.
Selecting Photos and Movies for Upload During Playback
If HFrame.io TRANSFER ORDER is selected for DBUTTON/
DIAL SETTING> aISO BUTTON SETTING, you can mark les for
upload or change or remove their upload marking using the ISO
button during playback.

16
X-H2 Manual (Network and USB Settings): P76
Frame.io Camera to Cloud Ver. 2.00
Adjust settings for use with Frame.io.
CONNECT
Connect to Frame.io.
Option
Option
Description
Description
WIRELESS LAN Connect via wireless LAN.
WIRED LAN Connect via wired LAN.
USB SMARTPHONE
TETHERING Connect to Frame.io via USB tethering.
GET PAIRING CODE View the pairing code for connection to the Frame.io proj-
ect.
NThe pairing code can only be viewed when the camera is connected
to Frame.io.
DISCONNECT
End the connection to the Frame.io project and terminate the
network connection.
SELECT FILE TYPE
Choose the types of les uploaded to Frame.io. You can select or
deselect each le type individually.
Options
Options
MOV - PROXY MOV - ProRes OTHER MOV/MP4 JPEG
RAW HEIF TIFF

17
UPLOAD SETTING
Adjust settings Frame.io upload settings.
SELECT IMAGE & TRANSFER
SELECT IMAGE & TRANSFER
Mark picture for upload.
AUTO IMAGE TRANSFER ORDER
AUTO IMAGE TRANSFER ORDER
Select ON to automatically mark photos and movies for upload
as they are taken.
Options
Options
ON OFF
TRANSFER/SUSPEND
TRANSFER/SUSPEND
Pause or resume upload to Frame.io.
Options
Options
TRANSFER SUSPEND
IMAGE TRANSFER WHILE POWER OFF
IMAGE TRANSFER WHILE POWER OFF
If ON is selected, upload of les to Frame.io will continue while
the camera is o.
Options
Options
ON OFF
ROOT CERTIFICATE
ROOT CERTIFICATE
Copy a root certicate to the camera for use with Frame.io.
Option
Option
Description
Description
LOAD FROM MEMORY
CARD Copy the root certificate from the camera memory card.
DELETE Delete the current root certificate from the file transmitter.
NFrame.io and FTP OPTIONAL SETTING> ROOT CERTIFICATE use the
same root certicate. Changing one changes the other.

18
UPLOAD STATUS
View Frame.io upload status.
TRANSFER QUEUE
View a list of the les awaiting upload.
RESET TRANSFER ORDER
Remove upload marking from all les selected for upload to
Frame.io.
